Survey Marks Enquiry Service (SMES) Join us at Webinar 2 slido.com #SMES Please post any questions in Slido www.slido.com Event Code: #SMES or https://app.sli.do/event/azxongbi 2 What is SMES History Part 1 SMES in action

slide-1
SLIDE 1

Survey Marks Enquiry Service (SMES)

Webinar 2

Join us at slido.com #SMES

slide-2
SLIDE 2

2

www.slido.com Event Code: #SMES

  • r

https://app.sli.do/event/azxongbi

Please post any questions in Slido

slide-3
SLIDE 3

3

  • What is SMES
  • History
  • SMES in action
  • SMES under the hood

Part 1

  • Registered user functionality
  • Survey Control Network and uncertainty
  • API, development and roadmap
  • Deep dive into your questions

Part 2 (This week)

slide-4
SLIDE 4

4

Introduction How to register as a new user

slide-5
SLIDE 5

5

Introduction How to reset your password

slide-6
SLIDE 6

6

Overview of Session 1

How to Lodge a New Survey Mark

  • Reserve Survey Mark Names
  • Lodge a New Survey Mark

How to Update an Existing Survey Mark

  • Mark Status
  • Additional Files

– Mark Photos – New Sketch Plan – Raw Survey Data & Booking Sheet SMES Website Resources

  • Sketch Plan Templates
  • Protection & Maintenance of Survey Marks
  • GNSS Data Submission & Booking Sheet
slide-7
SLIDE 7

7

www.slido.com Event Code: #SMES

  • r

https://app.sli.do/event/azxongbi

Please post any questions in Slido

slide-8
SLIDE 8

8

Session 2 Class & Order

  • Based on equipment & technique
  • Empirically derived
  • Assigned (with help of Least

Squares)

  • Useful when classifying new

survey network to existing network Uncertainty

  • Based on uncertainty of each

measurement, control coordinates

  • Statistically derived (Least

Squares)

  • Useful when adjusting all

measurements simultaneously In 2014, ICSM SP1 (Standard for the Australian Survey Control Network) transitioned to uncertainty as the basis for evaluating and expressing the quality of measurements and positions.

slide-9
SLIDE 9

9

Session 2 SMES, SCN and Uncertainty – Horizontal Coordinates

  • SCN(GDA) – Coordinates derived from National

Adjustment in GDA2020

  • Horizontal (Positional) Uncertainty derived from

National Adjustment

National Adjustment Statistics ~500,000 Stations ~1.9 million Measurements Victorian Component of National Adjustment ~44,000 Stations ~280,000 Measurements

slide-10
SLIDE 10

10

Session 2 SMES, SCN and Uncertainty – Vertical Coordinates

  • SCN(AHD) – Height derived from Victorian Levelling

Network (part of Australian National Levelling Network)

  • Vertical (Positional) Uncertainty mostly derived from

Victorian Levelling Network Adjustment

Victorian Levelling Network Adjustment ~300 Constraining Stations ~25,000 Stations ~31,000 Measurements

slide-11
SLIDE 11

11

Session 2

An Example of Improving Coordinates Bright

slide-12
SLIDE 12
slide-13
SLIDE 13

13

Session 2 Collection and Processing of GNSS Data

Contribute your Raw GNSS Observations

  • RINEX format or Manufacturer Raw Format (e.g. T02, m00)
  • 1 Second Interval
  • 5 min Metro, 10 min Regional/Remote (the longer the better!)
  • 2x sessions >1hr apart
  • Completed Booking Sheet

Submit through SMES or smes.support@delwp.vic.gov.au

Collect Raw GNSS Observations Connect Observations to CORS, Process Baselines Test Measurements in Minimally Constrained Adjustment Add Baselines to National Adjustment

slide-14
SLIDE 14

14

www.slido.com Event Code: #SMES

  • r

https://app.sli.do/event/azxongbi

Please post any questions in Slido

slide-15
SLIDE 15

15

SMES Development and API

Supports REST and SOAP Protocols Function examples: getMarkInformation getSurveyMarkSketches getSurveyMarkReports updateMarkDetailsSubmission

slide-16
SLIDE 16

16

Third Party SMES Apps

https://mrpeel.github.io/smes-on-the-go/ https://benchmrk.com.au

slide-17
SLIDE 17

17

GIS Data

http://services.land.vic.gov.au/SpatialDatamart/ Search for ‘SMES’

slide-18
SLIDE 18

18

Development Roadmap Q3 2020

  • New Mark

Categories

  • Monthly

Adjustment Uploads

Q4 2020

  • Complete

Australian Geospatial Reference System Support

Q1 2021

  • Enhanced

search capability

  • Dual Zone

Coordinates + Boundary layer

Q2 2021 and Beyond

  • Interface &

responsive web- design

  • Improved

analytics

* Along with backend and administrator improvements

slide-19
SLIDE 19

19

New Symbology

+

slide-20
SLIDE 20

20

Summary

Session 1

  • Lodge a New Survey Mark
  • Update an Existing Survey Mark

Session 2

  • Survey Control Network & Uncertainty
  • GNSS Data Submission & Impact on Adjustment

Session 3

  • API and Applications
  • Development Roadmap
slide-21
SLIDE 21

21

Future Webinars

  • New functionality updates
  • The Future of SMES
  • User focused engagement
  • Other Geodesy related topics

Future Webinars Date: TBC

slide-22
SLIDE 22

22

www.slido.com Event Code: #SMES

  • r

https://app.sli.do/event/azxongbi

Please post any questions in Slido

slide-23
SLIDE 23

23

Thank you for your time. Stay tuned for future webinar events!
