STRUCTURAL ACCOUNTS OF MEMORY Lecturer: Dr. Benjamin Amponsah, Dept. - - PowerPoint PPT Presentation

College of Education School of Continuing and Distance Education

2014/2015 – 2016/2017

STRUCTURAL ACCOUNTS OF MEMORY

Lecturer: Dr. Benjamin Amponsah, Dept. of Psychology, UG, Legon Contact Information: bamponsah@ug.edu.gh

SESSION OVERVIEW

• This section aims at helping you to appreciate human

memory in terms of its structures of sensory memory, short term memory and long term memory. This viewpoint maintains that memory can be considered as a system of components that have both structural and process aspects. Structurally, memory seems to differ notably in their nature and organization. By process aspects we are referring to the cognitive operations that transferred and altered the memories stored in different locations

Slide 2

Session Objectives

At the end of the session, the student will be able to

• Understand the structures of memory including sensory

memory, short-term memory and long-term memory.

• Describe the relationship that exist between the

structures and their interdependence.

• Understand that cognitive operations are brought to bear
• n the information before it can be transferred or

evacuated from one location to another.

Slide 3

Session Outline

The key topics to be covered in the session are as follows:

• Topic One: Structural Accounts of Memory
• Topic Two: Sensory Memory (Register)
• Topic Three: Short-term Memory
• Topic Four: Separation of STM and LTM Memories
• Topic Five: Long-term Memory

Slide 4

Reading List

• Ashcraft, M. H. (2006). Cognition (4th edn.), London: Pearson

Education Int.

• Galotti, K. M. (2004). Cognitive Psychology: In and out of the

laboratory (3rd Edn.). Belmont, CA: Wadsworth.

• Hunt, R. R. & Ellis, H. C. (1999). Fundamentals of Cognitive

Psychology (6th edn.), New York: McGraw-Hill.

• Willingham, D, B. (2001). Cognition: The thinking animal. NJ:

Prentice-Hall.

Slide 5

STRUCTURAL ACCOUNTS OF MEMORY

Topic One

Slide 6

Structural Accounts of Memory

• The information processing viewpoint maintains that

memory can be thought of as a system of interrelated components that have both structural and process aspects.

• By structural aspects we mean memories seem to differ

markedly in their nature, duration and organization of information.

• For example, if we consider the duration of memory task,

we realize that if you are distracted while trying to memorize something unfamiliar, the memory will certainly vanish, indicating that memory is fragile.

Slide 7

Structural Accounts of Memory

• Information kept in memory therefore seems to differ in terms of the

nature of the code, duration, capacity and so on.

• Other memories seem to be much more permanent, suggesting

that memories are stored in different locations.

• We may hang on to memory stored permanently but memory has

to go to a temporary location first.

• By process we are referring to cognitive operations that transferred

and altered the memories stored in different locations.

Slide 8

Information Processing Position

• The information processing paradigm is the most

popular theory in the study of cognition.

• In the 1950s, Communication science and

Computer science began to develop and became popular.

• Several researchers then began speculating that

human thought process could be analyzed from similar perspective (Reed, 1997).

Slide 9

Information Processing Position

• The influence of computerization is exerted at two levels;
• One is to provide a metaphorical language (figurative or

symbolism that may not literally represent real things) and

• Second is a more specific use of the computer program as a

theory of the mind. Similarity in storage function and Search process – The storage function of the computer is also analogous to the process we normally think of as memory. The stored information can later be retrieved, used to solve a problem, and then expressed as output from the computer.

Slide 10

Information Processing Position

• It is also striking to see the similarity in the search process and the

problem-solving activities of the computer and human beings. Note:

• Using the computer as an analogy, however, is far from suggesting

that the human brain works like a computer.

• The brain processes of perception, thinking, memory and language

are much more complex than those of any existing computer.

• However, the computer model provides a general way of thinking

about human cognitive functioning.

Slide 11

Summary

• In summary the two important components of the

information processing approach assume that: (a) mental process can best be understood by comparing it with the operations of a working computer. (b) mental process can be interpreted as information progressing through the system in a series of stages, one step at a time.

Slide 12

What is Information?

• In cognitive psychology, information refers to any attended input,

idea, image, fact, knowledge etc.

• Information represents things we see, hear, feel and so on.
• To process means to move toward some goal by going through a

series of stages or sequence of acts or actions until the desired

• utcome is reached.
• These actions may produce a change or development.

Slide 13

Basic Parts of Information Processing

1. The theory considers memory as a system of interrelated components. 2. Each component referred to as storage is capable of processing particular types of cognitive codes (representation of physical energy by the nervous system that is potentially capable of entering our awareness). 3. The information we receive from the environment (e.g., light waves) are precategorical (no meaning), which means that the physical energy has not been categorized. 4. Psychological processes must interact with the physical energy in

• rder to add meaning to sensory experiences.

Slide 14

Basic Parts of Information Processing

• The question is why is it difficult to identify an object when

cues are based solely on visual description of that object? (a) The difficulty is due in part to the fact that visual properties do not exhaust the meaning of an object. (b) When we extract meaning from visual experience, we actually add more information to that experience. That is, the visual properties of an apple activate other knowledge of apples such as taste, smell, color and information such as fruit.

Slide 15

Basic Parts of Information Processing

• 5. Finally, the information processing theory holds that cognitive

codes can be transferred from one storage to another storage using controlled processes (effortful cognitive processes that require the allocation of attention to sustain them).

• A model of this representation showing the interrelated

components called storages and the links are demonstrated in Figure 1.2.

Slide 16

Basic Parts of Information Processing

Slide 17

Figure 1-2 Atkinson and Shiffrin’s (1964) Stages

• f Memory (also referred to as Modal Model

Theory of Memory

The Components

• The first of the storages is known as the sensory register. This

is where the feature detection and pattern recognition processes rapidly produce a cognitive code that can be stored for a brief period.

Slide 18

The Components

• The modal model theory shows three different storages that

differ in their capacities, durations, operating characteristics (type of codes and mechanism of loss).

• This multi-store model became very popular within the

emerging field of cognitive psychology. Because Atkinson and Shiffrin’s model became standard approach, it is often called the “modal model”.

• The theory proposed that memory can be understood as a

sequence of discrete steps, in which information is transferred from one storage area to another and this was consistent with the information processing position.

Slide 19

The Components

• Sensory memory is assumed to possess a large-capacity

storage system that records information from each of the senses with reasonable accuracy.

• The stored information is next transferred to other stores like

the Short-term memory, where certain cognitive processes are brought to bear on the information.

Slide 20

Summary

• Structures of the memory system
• The information processing position in terms of the

assumptions made.

• Atkinson and Shiffrin’s model, also referred to as the

modal model or the stage model

• You have also become familiar with the terms

(storages) sensory memory, short-term memory and long-term memory, which are of course interrelated in one model.

Slide 21

SENSORY MEMORY (REGISTER)

Topic Two

Slide 22

The Sensory Storage

– The sensory store or sensory register is a memory system designed to store a record of the information received by the receptor cells. – Receptor cells are the specialized sense organs of the ear, eye, nose, tongue and skin, which respond to physical energy from the environment. – Firing the receptor cells begins the psychological processes of seeing, hearing, smelling, tasting and feeling. – Once these receptor cells are activated, the record of this activation is preserved or stored in the sensory registers. – The stored record is known as the sensory trace.

Slide 23

Using the Information

• If we want to use the information in the sensory memory (the sensory

trace), we must quickly encode it into a more durable form.

• Processing that information begins with attention, which selectively

determines what will 'get through' for further examination and what will not.

• Attention allows us to focus on parts of the stimulus and thereby to

recognize some of its features.

• Sensory memory allows us to take a 'snapshot' of our environment, and

to store this information for a brief period.

• Only information that is transferred to another level of memory will be

preserved for more than 1 or two seconds

Slide 24

Using the Information

• Information processing thus begins with the

activation of sensory receptors and this pattern of activity is stored in a memory system, the sensory register.

• Why do we need to store or maintain the sensory

trace?

Slide 25

Functions of the Sensory Register

(a) The sensory register serves as a buffer or a holding bin for sensory information until the interpretative processes are free. The information is held until other cognitive processes are capable of interpreting or adding meaning (Hunt& Ellis, 1999). (b) This initial memory helps us to avoid losing present information while we are processing the one which just

• ccurred. In other words, it helps us to avoid

immediate decay of information (Hunt& Ellis, 1999).

Slide 26

Characteristics of the Sensory Register

• There are certain important characteristics of the

sensory register that enables it to serve its storage function optimally. (1) The information is stored in a veridical form. This means that the information stored should accurately reflect what happened at the sensory receptor.

Slide 27

Characteristics of the Sensory Register

(2) The sensory register needs to be relatively large. Large enough to store all the information impinging on the sensory receptor. Both characteristics are necessary because the sensory trace is precategorical. (3) The information remains on the sensory register for

• nly a brief period of time. It has rapid decay time (brief

trace life). The sensory register is also thought to be modality specific (that is, part of the storage is devoted to visual stimuli and part to auditory stimuli).

Slide 28

Characteristics of the Sensory Register

• The contents of the sensory register must be cleared quickly

to avoid superimposing information from two exposures.

• Therefore a conceivable means to avoid superimposition is a

rapid decay time for the sensory register.

Slide 29

Characteristics of the Sensory Register

• Experimental evidence supports each of the characteristics.

Let us examine some of the evidence and their implications.

• Size and Duration of the Sensory Register
• A very important study by George Sperling (1960) illustrates well

some of the important properties of visual (iconic) memory.

• We have sensory modalities of vision, hearing, touch, taste and

smell – they are presumed to have their own subsystem within sensory memory.

Slide 30

Size and Duration of the Sensory Register

Visual sensory memory - George Spelling Experiment

• Array of letters (letter matrix such as the matrix below) were

presented very briefly (duration of 50 ms) [.05 of a second]), it was so brief that subjects could not rehearse verbally the letters in the display, and were followed by a blank white viewing field.

Slide 31

A Twelve Letter Matrix and a Tachistoscope

Slide 32

A Twelve Letter Matrix Tachistoscope

Size and Duration of the Sensory Register

• Sperling’s Research tells us 4 important things about Visual

Sensory Memory: (1) More can be seen in a single glance than can be remembered. The capacity of the sensory memory appears to be very large and that a complete (or nearly complete) and brief memory record of a complex stimulus can be provided in a brief glance. (2) The memory record appears to be in the form of a literal (visual) copy (veridical) of the eliciting stimulus, since its duration depends on viewing conditions and there is not time for the letters to be named individually and then rehearsed.

Slide 33

Size and Duration of the Sensory Register

(3) The duration of iconic memory is very short, effective approximately 300 milliseconds. (4) The fading away of the icon seems to reflect a decay process. – Forgetting from sensory memory seems to be caused by

• decay. There is little reason to believe decay is caused by

interference of some sort.

• According to the theory, such traces gain access to more durable

representations when they are acted upon by control processes such as attention and rehearsal.

Slide 34

SHORT-TERM MEMORY

Topic Three

Slide 35

Short-term Memory

• Information processing theorists believe that cognitive codes

are next transferred from the sensory register to a component called the Short-term memory.

• Cognitive codes stored in short-term memory can be transferred to

a long-term storage whose capacity like the sensory register, is extremely large.

• The control process that permits the transfer of coded material

between short-term memory and long-term storage is referred to as Rehearsal.

Slide 36

Short-term Memory

• The term rehearsal has so many meanings in cognitive psychology,

but for our purpose we will restrict its usage to two procedures: (1) Rehearsal refers to procedures that maintain the vitality of the code or information in short-term memory. As long as the short-term code is occasionally refreshed by rehearsal, it can reside there for long periods (rote or maintenance rehearsal).

Slide 37

Short-term Memory

(2) Rehearsal also refers to operations that build up a corresponding code of the short-term material in long-term storage (elaborative rehearsal). That is, rehearsal

• perates by duplicating a representation of the short-term

material in long-term storage

• Maintenance rehearsal aims at keeping the code active and
• Elaborative rehearsal aims at transferring the code from the short-

term to the long-term memory.

• Another important control process in the short-term memory is

coding, which involves attaching appropriate information from long-term memory to the short-term information.

Slide 38

Short-term Memory

• We can now define STM as :

A conceptual system which not only stores information, but also serves as a work space for rehearsing, coding, retrieving and decision making.

Slide 39

Short-term Memory

• Klatzky (1980) uses the workbench analogy to

explain the short-term memory phenomenon.

• That is, items from other stores may be transferred to

the bench to be “worked on” and changed to different shapes or even transformed entirely. Benches have limited space, which means it can contain only a few items at the same time.

Slide 40

Sensory and STM

DIFFERENCES - SENSORY MEMORY AND STM: Short-term storage differs from the sensory memory in several ways. Some of these are:

. The capacity of the short-term memory is assumed to be

quite limited.

• The sensory register has large capacity and it is unlimited.
• The information in the short-term memory is organized in a

cognitive code that is Acoustic /AVL.

• Information in the sensory register is veridical and

precategorical.

Slide 41

Sensory and STM

Similarity: The short-term memory and the sensory memory are similar in one aspect.

• In both cases, material that is not attended to,

elaborated and transferred certainly decays.

Slide 42

Characteristics of the Short-term Memory

• Three basic characteristics have been proposed to distinguish

short-term memory and the long-term memory.  Trace life (duration)  Storage Capacity  Nature of the code

• 1. Trace life (Duration of the Short-term Memory)
• As information moves from sensory memory to short-term

memory, the trace life increases somewhat, although it is still brief when compared to the duration of the long-term memory.

Slide 43

Characteristics of the Short-term Memory

• There have been classic experiments to demonstrate the

short-term trace of the short-term memory.

• Two experiments reported simultaneously by Brown (1958) in

England and Peterson (1959) in the US are used to demonstrate the trace life of the short-term memory.

• The experimental procedure has come to be known as the

Brown-Peterson’s paradigm (Hunt & Ellis, 1999).

Slide 44

Characteristics of the Short-term Memory

• 2. Capacity of Short-term Memory
• George Miller (1956) a prominent psychologist conducted a

series of studies concerning immediate memory performance.

• Miller noticed that most people remembered between five

and nine items (7±2 items), which suggested that short-term storage has quite limited capacity.

• The limitation of short-term storage capacity is additional

evidence calling for separate memory systems (short-term and long-term memory stores).

Slide 45

Characteristics of the Short-term Memory

• 3. Nature of the Code in Short-term Store
• Another distinction between short-term memory and the other

stores is the memory code of each system.

• Information stored in long-term memory is assumed to be

based on semantic code whereas short-term is acoustically

• r phonetically coded.
• In other words, information stored in long-term memory is in

terms of its meaning whereas sound patterns are remembered in the short-term memory.

Slide 46

SEPERATION OF SHORT-TERM AND LONG-TERM MEMORY

Topic Four

Slide 47

Separation of Short-term and Long-term Memories

• Separation of Short-term and Long-term Memories

– Short-term memory has a brief trace, small capacity and is acoustically coded, whereas long-term memory is assumed to be permanent, have large capacity and semantically coded (based on meaning). – Serial Position effect When a subject’s memory is tested in a free-recall situation, initial and final items are more likely to be recalled than items presented in the middle of the list.

Slide 48

Separation of Short-term and Long-term Memories

• That is, early items are recalled well and so are

the last items, but the middle items are remembered poorly, which results in a U-shaped function.

Slide 49

Separation of Short-term and Long-term Memories

Slide 50

Demonstration of Serial Position Effect

Separation of STM and LTM Neuropsychological Evidence

• Neuropsychological evidence
• Studies of amnesic patients provide another source of

indirect evidence for the distinction between STM and

• LTMs. Alzheimer’s disease produce a memory

impairment known as anterograde amnesia (after – inability to remember events that occur after injury - accident or disease).

• What has emerged is that we have two distinct memory

systems which obey different principles and produce different retention.

Slide 51

LONG-TERM MEMORY

Topic Five

Slide 52

Long-term Memory

• The long-term memory or storage is the ultimate repository
• f our knowledge or experience from day one.
• The LTM is a concept which represents the vast store of

knowledge we have about the world, ranging from everyday events such as how to use a knife and fork to more esoteric information such as axioms of geometry.

• Two lines of evidence have traditionally being used to support

the idea of a long-term storage.

Slide 53

Long-term Memory

• The first concerns the nature of the memory code which

changes as a function of its time in the memory system.

• The second evidence comes from neuropsychological

literature (a sub-discipline in physiology and psychology that focuses on the relationship between neurological processes and behaviour) which points to a distinction between STM and LTMs.

Slide 54

Structure of the Long-term Memory

Slide 55

Schematic representation of contents of long-term memory The long-term memory is a well organized store of events and as such it is well structured and organized. This is the structure.

PROCEDURAL MEMORY

• This is the part of the long term memory made up of

conditioned responses. Usually, it is expressed as skill (requiring training and experience) or disposition (inclination or certain types of automatic reactions).

• It’s about knowledge of how to perform various tasks

e.g., lacing a shoe, riding, driving, typing, using fork and knife etc.

Slide 56

Declarative Memory

• This constitutes the part of long-term memory containing

factual information. It is about knowledge about which a person can make a declaration.

• These include knowledge, facts, information, ideas, or

anything that can be recalled and described in words, pictures or symbols.

• Endel Tulving (1983) has proposed a distinction

between two types of permanent LTMs (Semantic and Episodic Memories).

Slide 57

Declarative Memory

• Episodic memories are autobiographical, personal

and sensitive to the effects of context. These are memories organized by time and place of occurrence (autobiographical reference).

Slide 58

Semantic Memory

Semantic Memory

• This section of the LTM refers to encyclopaedic

knowledge of the world and language. In other words, it’s general knowledge that is not specifically time- tagged.

• These are memory of words, concepts, rules and
• language. It’s simply a mental encyclopaedia or

thesaurus.

Slide 59

CHARACTERISTIC EPISODIC MEMORY SEMANTIC MEMORY

• 1. Source of information

Sensory experiences – things we see, hear etc Comprehension – things understood

• 2. Units of information

Episodes and events that are context based Concepts, ideas, and facts

• 3. Organization

Time-tagged or related Conceptual

• 4. Emotional content of the

memory More important Less important

• 5. Likelihood of forgetting

Great, imagine things you have to recall based on time e.g., 1.00pm, 2.00pm etc. Small

• 6. Time required to remember

info. Relatively long time Relatively short time 7. How it’s tested in the laboratory Recall of particular episodes General knowledge

• 8. Interference

Highly susceptible Less susceptible

• 9. General usefulness

Less useful More useful, based on meaning, comprehension

DISTINCTION BETWEEN EPISODIC AND SEMANTIC MEMORY

Sample Questions

• Why do you think that the nature of the cognitive

code in the short-term memory is acoustic?

• Discuss the various meaning of rehearsal?
• Discuss evidence from neuropsychological research

and the serial position effect as further evidenc.e of the separation between STM and LTM.

• Outline the structure of the LTM

Slide 61

References

• Atkinson, R. C. & Shiffrin, R. M. (1964). Human memory: A

proposed system and its control processes. In K. W. Spence & J. T. Spence (Eds.), Advances in the psychology

• f learning and motivation: Research and theory (vol.

2). New York: Academic Press.

• Best, J. B. (1995). Cognitive Psychology (4th Edn.). MN. West

Publishing Company.

• Hunt, R. R. & Ellis, H. C. (1999). Fundamentals of Cognitive

Psychology (6th edn.), New York: McGraw-Hill.

Slide 62

References

• Klatzky, R. L. (1980). Human Memory: Structures and

processes (2nd ed.). San Francisco: Freeman.

• Reed, E. (1997). The cognitive revolution from an

ecological point of view. In D. M. Johnson & C. E. Erneling (Eds.), The future of the cognitive revolution (pp. 261-273). New York: Oxford Univ. Press.

• Sperling, G. (1960). The information available in brief visual
• presentations. Psychological Monographs, 74, 1-29.

Slide 63
