Steffen Bartsch Technical Integrator Agenda HDS Corporate Profile Hitachi Freedom Storage Solutions Product Family Enterprise <-> Midrange SAN: 1Gbit / 2Gbit ? SAN NAS or both? Virtualisation

SLIDE 1

Steffen Bartsch Technical Integrator

SLIDE 2

Midrange April 2002

Rev. 1.5 SBA

Page 2

Agenda

HDS Corporate Profile
Hitachi Freedom Storage Solutions

– Product Family – Enterprise <-> Midrange – SAN: 1Gbit / 2Gbit ? – SAN – NAS – or both? – Virtualisation – Freedom Storage Thunder 9200

Thunder 9200 Features
Thunder 9200 Software Offering

Duration: ~ 30 minutes

SLIDE 3

Midrange April 2002

Rev. 1.5 SBA

Page 3

HDS: Company Data at a Glance

Founded 1989
Wholly-owned subsidiary
f Hitachi,Ltd. (NYSE:HIT)
Total Employees - 2,900
Operations in 48 countries
Hitachi Freedom Storage

software, hardware, and services

Hitachi, Ltd.’s focal point for

storage technology

SLIDE 4

Midrange April 2002

Rev. 1.5 SBA

Page 4

Netherlands Balkans Poland Sweden Finland France Turkey Denmark UK Germany Spain

Italy

Romania Bulgaria Greece Belgium Portugal Norway

Russian Federation

Hungary Austria Switzerland Czech Republic Slovakia Albania

Hitachi Data Systems Europe Countries Not Covered yet! Hitachi Data Systems Distributor Countries

Saudi Arabia Israel Kuwait

South Africa

Baltic States Ire. Slovenia

Hitachi Data Systems Reseller Countries

Hitachi Data Systems EMEA

SLIDE 5

Midrange April 2002

Rev. 1.5 SBA

Page 5

Wit SoundView

How do you rate the following vendors disk storage?

(on a scale of 1 to 5, with 1 being best)

Source: Wit SoundView survey of Gartner conference attendees (July/01)

2.4 2.4 3.0 3.0 2.9 2.7

2.0 2.0

Hitachi Data Systems Hitachi Data Systems

Compaq EMC IBM Dell HP Storage Technologies

SLIDE 6

Midrange April 2002

Rev. 1.5 SBA

Page 6

Product Family

4 – 100 Disk‘s
Open-Systems
4 - 512 Disk‘s
Mainframe
Open-System

SLIDE 7

Midrange April 2002

Rev. 1.5 SBA

Page 7

HiStar Architecture – 9900 Enterprise Class

Connect up to 32 servers directly or hundreds through switches

Up to 512

SLIDE 8

Midrange April 2002

Rev. 1.5 SBA

Page 8

FC Architecture 9200 Midrange Class

High Speed FC-AL

backend

Quad 100MB/s Full

duplex FC loops

2 Tachyon chips per

controllers

Loop switching

architecture

– Primary / Alternate – Alternate used if Primary is busy or unavailable

SLIDE 9

Midrange April 2002

Rev. 1.5 SBA

Page 9

The Hitachi Data Systems Vision

Any Data, Any Computer, Anytime, Anywhere Any Data, Any Computer, Anytime, Anywhere

SLIDE 10

Midrange April 2002

Rev. 1.5 SBA

Page 10

1Gbit – 2Gbit ?

Backup ! Backup ! Multiplexing Multiplexing ! !

SLIDE 11

Midrange April 2002

Rev. 1.5 SBA

Page 11

Networked Storage for the Networked World

Concept of storage

as “Utility”

Connectivity

technology is irrelevant: availability and simplicity are everything!

Where is all the data coming from?

SLIDE 12

Midrange April 2002

Rev. 1.5 SBA

Page 12

SAN or NAS?

SLIDE 13

Midrange April 2002

Rev. 1.5 SBA

Page 13

IT Departments

– Consolidation of hosts with small storage requirements – NT storage consolidation

Enterprise data centers

– Storage pooling with NAS and SAN – Offload file services from general purpose processors

Internet Data Centers

– Web hosting front-ends – Streaming media applications

Where Does NAS Fit ?

SLIDE 14

Midrange April 2002

Rev. 1.5 SBA

Page 14

NAS SAN

LAN

SAN + NAS : Freedom !

Thunder 9200

SLIDE 15

Midrange April 2002

Rev. 1.5 SBA

Page 15

Virtualisation Strategy

We already have virtualisation integrated in
ur storage solutions!! (but failed to call it that way…)
Partnering with ISV’s for truly open

virtualisation solutions

– Investment in Datacore (SAN Symphony) – Potential partnership with other vendors – Involved with the development of Veritas’ virtualisation solution with Brocade

SLIDE 16

Midrange April 2002

Rev. 1.5 SBA

Page 16

Server

Volume Manager

RAID Group e.g. RAID5 (4D+1P)

Storage

RAID Group RAID1 (2D+2P)

Storage

... ...

„Storage Consumer“ „Storage Admin“

Virtualisation: So what?

SLIDE 17

Midrange April 2002

Rev. 1.5 SBA

Page 17

Freedom Storage Thunder 9200

Full Fibre Architecture
Modular, building-block design for flexible

configurations

Rackmount and Deskside
From 18GB to 18TB RAW capacity
High speed18GB*, 36GB*, 72GB and 180GB

disk drives (*15.000RPM)

Up to 5 global dynamic hot spares
RAID 0, 1, 0+1, 3*, 5 intermixed
Up to 4GB cache
Fibre or SCSI host connectivity
Redundant, hot-swappable components
Online microcode upgrade, LUN expansion,

LUN mapping

Extensive software offering
NT/2000, Netware, AIX, Solaris, HP-UX

SLIDE 18

Midrange April 2002

Rev. 1.5 SBA

Page 18

Performance vs. Capacity

1 RK 1 RK + 1 RKA 2 RK + 2 RKA 2 RK + 4 RKA 2 RK + 6 RKA 2 RK + 7 RKA 3 RK + 4 RKA 3 RK + 6 RKA 1 RK + 9 RKA

SLIDE 19

Midrange April 2002

Rev. 1.5 SBA

Page 19

Multi platform support

SLIDE 20

Midrange April 2002

Rev. 1.5 SBA

Page 20

Heterogeneous Connectivity

SLIDE 21

Midrange April 2002

Rev. 1.5 SBA

Page 21

Thunder 9200 Management

Easy to use Java based GUI:

– Resource Manager 9200

Supports multiple 9200 units
Supports Windows, Solaris, Irix, HP/UX
Web enabled monitoring of critical components
Internet based Hi-Track call home
Remote Management via LAN / RS-232 port
SNMP Compliant

– Integration in CA Unicenter, HP Openview, Tivoli, etc.

SLIDE 22

Midrange April 2002

Rev. 1.5 SBA

Page 22

Enterprise Copy Functions

Local Volume copy

Complete physical mirror
Backup applications
Application dev.

Hardw are based copy through Fibre Channel
