Status of SiC high voltage device technology Mikael stling, KTH Royal Institute of Technology, Sweden Outline 1. Introduction 2. Device Review (JFET, MOSFET, BJT) 3. 6 kV-Class BJTs 4. 15 kV-Class BJTs 5. HT & harsh environments 6.

slide-1
SLIDE 1

Status of SiC high voltage device technology

Mikael Östling, KTH Royal Institute of Technology, Sweden

slide-2
SLIDE 2

NEREID WORKSHOP BERTINORO OCT 2016

Outline

2

  • 1. Introduction
  • 2. Device Review (JFET, MOSFET, BJT)
  • 3. 6 kV-Class BJTs
  • 6. Summary
  • 4. 15 kV-Class BJTs
  • 5. HT & harsh environments
slide-3
SLIDE 3

NEREID WORKSHOP BERTINORO OCT 2016

Outline

3

  • 1. Introduction
  • 2. Device Review (JFET, MOSFET, BJT)
  • 3. 6 kV-Class BJTs
  • 6. Summary
  • 4. 15 kV-Class BJTs
  • 5. HT & harsh environments
slide-4
SLIDE 4

NEREID WORKSHOP BERTINORO OCT 2016

At least 50 % of the electricity used in the world is controlled by Power Devices.

4

Global Warming Energy Conservation Improving the Efficiency Renewable Energy Power Devices Electrical Conversion

B.J. Baliga, Advanced High Voltage Power Device Concepts, Springer

slide-5
SLIDE 5

NEREID WORKSHOP BERTINORO OCT 2016

Application for Power Devices

5

101 102 103 104 10-2 10-1 100 101 102 103 104

TELECOM. DISPLAY DRIVES

Voltage rating (V)

Current rating (A)

LAMP BALLAST ROBOTICS MOTOR DRIVES ELECTRIC TRAINS HVDC TRANSMISSION POWER SUPLIES AUTOMOTIVE ELECTRONICS

slide-6
SLIDE 6

NEREID WORKSHOP BERTINORO OCT 2016

SiC Device Roadmap

6

Source: Dr. Muhammad Nawaz, ABB, ESCDERC 2016 but modified

slide-7
SLIDE 7

NEREID WORKSHOP BERTINORO OCT 2016

Price Scenario SiC

7

Source: Dr Anant Agarwal, US Department of Energy, ESCDERC 2016

slide-8
SLIDE 8

NEREID WORKSHOP BERTINORO OCT 2016

Price Scenario SiC

8

The price for a 1.2 kV, is significantly below the PowerAmerica’s target of 10 cents/A. If the industry can approach these numbers in 3-5 years then the device demand will grow exponentially across multiple applications. 200mm SiC substrates, expected by 2020, will further reduce the cost of SiC MOSFETs. 4.6 cents/A 6.1 cents/A

slide-9
SLIDE 9

NEREID WORKSHOP BERTINORO OCT 2016

Outline

9

  • 1. Introduction
  • 2. Device Review (JFET, MOSFET, BJT)
  • 3. 6 kV-Class BJTs
  • 6. Summary
  • 4. 15 kV-Class BJTs
  • 5. HT & harsh environments
slide-10
SLIDE 10

NEREID WORKSHOP BERTINORO OCT 2016

MOSFETs

Application: Solar inverters, switch mode power supplies, high voltage DC/DC converters, battery chargers, motor drive, pulsed power applications, renewable energy, lighting, telecom power supplies, induction heating, auxiliary power supplies, HVAC, LED lighting power supplies

10

slide-11
SLIDE 11

NEREID WORKSHOP BERTINORO OCT 2016

1700 MOSFETs

11

slide-12
SLIDE 12

NEREID WORKSHOP BERTINORO OCT 2016

JFETs

Applications: Solar inverters, high voltage DC/DC or AC/DC conversion, bidirectional inverter.

12

slide-13
SLIDE 13

NEREID WORKSHOP BERTINORO OCT 2016

CoolSiC™ 1700 V JFETs

13

Recently, Infineon presented their 1200V CoolSiC™ with record low Ron of 45 mΩ·cm2

slide-14
SLIDE 14

NEREID WORKSHOP BERTINORO OCT 2016

BJTs

Application: Down hole oil drilling, geothermal instrumentation, hybrid electric vehicles (HEV), solar inverters, switched, mode power supply (SMPS), power factor correction (PFC), induction heating, uninterruptible power supply (UPS), motor drives.

14

slide-15
SLIDE 15

NEREID WORKSHOP BERTINORO OCT 2016

SiC power bipolar junction transistors by TranSiC

15

  • Vertical epitaxial NPN structure
  • Dry etching to form base-emitter and base-collector junctions
  • Al implantation for low-resistive base contact and junction termination (JTE)
  • Surface passivation by SiO2, reduced surface recombination
  • Large area BJT has many narrow emitter fingers
  • Deposited isolation oxide, via holes and Al metal pads
  • Active areas between 4.3mm2 and 15 mm2

Base Emitter

ND+ Emitter contact N+ substrate Collector contact P Base implant Base contact SiO2 surface passivation JTE implant N

slide-16
SLIDE 16

NEREID WORKSHOP BERTINORO OCT 2016

Recent Performance of SiC BJTs

16

  • Current gain at T=25 C : hFE=117 at IC=22 A
  • VCESAT=0.95 V at IC=15 A (JC=350 A/cm2), ρON=2.7 mΩcm2
  • Low leakage current at VCEO=1200 V, Open-base breakdown ~ 1800 V

5 10 15 20 25 30 35 40 1 2 3 4 5

Collector current (A) Collector emitter voltage VCE (v)

IB=100 mA

T=25 C

IB=200 mA IB=300 mA IB=400 mA hFE=117

4.3 mm2 BJT

slide-17
SLIDE 17
slide-18
SLIDE 18

NEREID WORKSHOP BERTINORO OCT 2016

1200 V 4H-SiC Unipolar and Bipolar Devices

18

slide-19
SLIDE 19

NEREID WORKSHOP BERTINORO OCT 2016

1700 V 4H-SiC Unipolar and Bipolar Devices

19

slide-20
SLIDE 20

NEREID WORKSHOP BERTINORO OCT 2016

Ultra High Voltage Devices

The on-resistance for a 4H-SiC unipolar device above 15 kV, increases to the point where it is impractical from a yield standpoint and cost. Bipolar devices are likely to be the first choice.

20

Source: Dr. John W. Palmour, CREE, IEDM 2014

slide-21
SLIDE 21

NEREID WORKSHOP BERTINORO OCT 2016

21 kV BJT (T. Kimoto Kyoto University)

21

MIYAKE et al. IEEE ELECTRON DEVICE LETTERS, VOL. 33, NO. 11, NOVEMBER, 2012, p.1598

slide-22
SLIDE 22

NEREID WORKSHOP BERTINORO OCT 2016

22

Active area small – 0.0035 mm2

MIYAKE et al. IEEE ELECTRON DEVICE LETTERS, VOL. 33, NO. 11, NOVEMBER, 2012, p.1598

slide-23
SLIDE 23

NEREID WORKSHOP BERTINORO OCT 2016

Outline

23

  • 1. Introduction
  • 2. Device Review (JFET, MOSFET, BJT)
  • 3. 6 kV-Class BJTs
  • 6. Summary
  • 4. 15 kV-Class BJTs
  • 5. HT & harsh environments
slide-24
SLIDE 24

NEREID WORKSHOP BERTINORO OCT 2016

6 kV-Class 4H-SiC BJTs

24

in Proc. 27th ISPSD, May 2015, pp. 249-252

slide-25
SLIDE 25

NEREID WORKSHOP BERTINORO OCT 2016

Trench JTE Design

25

IEEE ELECTRON DEVICE LETTERS, VOL. 36, NO. 2, Feb. 2015

slide-26
SLIDE 26

NEREID WORKSHOP BERTINORO OCT 2016

I-V Characteristics

26

Termination efficiency 92 % Termination efficiency 93 %

IEEE ELECTRON DEVICE LETTERS, VOL. 36, NO. 2, Feb. 2015 in Proc. 27th ISPSD, May 2015, pp. 249-252

slide-27
SLIDE 27

NEREID WORKSHOP BERTINORO OCT 2016

Outline

27

  • 1. Introduction
  • 2. Device Review (JFET, MOSFET, BJT)
  • 3. 6 kV-Class BJTs
  • 6. Summary
  • 4. 15 kV-Class BJTs
  • 5. HT & harsh environments
slide-28
SLIDE 28

NEREID WORKSHOP BERTINORO OCT 2016

15 kV-Class BJTs and PiN Diodes

28

15 kV-class PiN diodes will be presenteded in Tu1.04

slide-29
SLIDE 29

NEREID WORKSHOP BERTINORO OCT 2016

I-V Characteristics of the BJTs

A current gain record of 139 for 15 kV-class BJTs

29

slide-30
SLIDE 30

NEREID WORKSHOP BERTINORO OCT 2016

Current Gain Wafer map

30

β ≥ 100 (91 % of the dies)

slide-31
SLIDE 31

NEREID WORKSHOP BERTINORO OCT 2016

Outline

31

  • 1. Introduction
  • 2. Device Review (JFET, MOSFET, BJT)
  • 3. 6 kV-Class BJTs
  • 6. Summary
  • 4. 15 kV-Class BJTs
  • 5. HT & harsh environments
slide-32
SLIDE 32

NEREID WORKSHOP BERTINORO OCT 2016

Applications for HT & harsh environments

32

Application Type Temperature Radiation Oil and gas drilling P, S 600 °C No Industrial motor drives P 300 °C No Automotive P, S 300-600 °C No Aviation P, S 300-600 °C (Yes) Space exploration S 600 °C Yes Nuclear energy (P) S 300-600 °C Yes

P = Power switching applications S = Sensor signal processing

slide-33
SLIDE 33

NEREID WORKSHOP BERTINORO OCT 2016

A new high temperature SiC electronics project

33

WOV – Working on Venus

$ 3,3M Project funding 2014 – 2018

slide-34
SLIDE 34

NEREID WORKSHOP BERTINORO OCT 2016

34

Radiation stability of SiC BJT vs. MOSFET

Commercially available 24 A (CMF10120D) SiC power MOSFETs fabricated by CREE, shows a large negative threshold voltage shift and becomes inoperative after a dose of only 300

  • krad. A. Akturk, et.al, IEEE Trans. Nucl. Sci., 59 (2012).

Forward current gain degradation up to 38 Mrad was found negligible, but for the dose of 332 Mrad, a degradation of 52% is seen.

To be published in IEEE TED

slide-35
SLIDE 35

NEREID WORKSHOP BERTINORO OCT 2016

35

Comparison of various bipolar technology

  • 4H-SiC technology show more tolerance to gamma radiation in comparison to other

technologies.

  • 4H-SiC devices irradiated with 3 MeV protons show about one order of magnitude

higher tolerance in comparison to the Si technology Gamma irradiation Protons irradiation 4H-SiC

KTH-Low Power BJT[7] Si- BJT[8]

slide-36
SLIDE 36

NEREID WORKSHOP BERTINORO OCT 2016

Outline

36

  • 1. Introduction
  • 2. Device Review (JFET, MOSFET, BJT)
  • 3. 6 kV-Class BJTs
  • 6. Summary
  • 4. 15 kV-Class BJTs
  • 5. HT & harsh environments
slide-37
SLIDE 37

NEREID WORKSHOP BERTINORO OCT 2016

Summary

  • Replacing Si with SiC switch devices gives great savings with

respect to energy density, efficiency, and physical systems volume

  • At 1200-1700V SiC MOSFETs, JFETs and BJT performs about

equally good

  • In a few years the cost issues with SiC looks very competitive

< 5 cents/Amp

  • Above 15 kV, BJTs/IGBTs are likely to be the first choice
  • For high temperature and radhard environments BJTs have a clear

advantage

37

slide-38
SLIDE 38

NEREID WORKSHOP BERTINORO OCT 2016

Acknowledgments

38

The KTH research team The Swedish Energy Agency The Swedish Research Council VINNOVA – research and innovation for sustainable growth Swedish Foundation for Strategic Research KAW Foundation STandUP for Energy

slide-39
SLIDE 39

NEREID WORKSHOP BERTINORO OCT 2016

Commercial SiC-MOSFET (Si-IGBT) Power Module

10/21/16 39

slide-40
SLIDE 40

NEREID WORKSHOP BERTINORO OCT 2016

Emitter Size Effect

40

slide-41
SLIDE 41

NEREID WORKSHOP BERTINORO OCT 2016

Base Size Effect

10/21/16 MIKAEL ÖSTLING 41

slide-42
SLIDE 42

NEREID WORKSHOP BERTINORO OCT 2016

Current Gain vs Geometry

10/21/16 MIKAEL ÖSTLING 42

WE = 40 µm WB = 30 µm

slide-43
SLIDE 43

NEREID WORKSHOP BERTINORO OCT 2016

Compactness: Si Vs SiC

10/21/16 MIKAEL ÖSTLING 43

Source: Dr. Muhammad Nawaz, ABB

slide-44
SLIDE 44

NEREID WORKSHOP BERTINORO OCT 2016

Current Gain vs Applied Voltage

10/21/16 MIKAEL ÖSTLING 44

Decreasing effective base Base width modulation (Early effect)

slide-45
SLIDE 45

NEREID WORKSHOP BERTINORO OCT 2016

Current gain improvement

10/21/16 MIKAEL ÖSTLING 45

To be published in IEEE TED

slide-46
SLIDE 46

NEREID WORKSHOP BERTINORO OCT 2016

On-resistance and current density improvement

10/21/16 MIKAEL ÖSTLING 46

To be published in IEEE TED

slide-47
SLIDE 47

NEREID WORKSHOP BERTINORO OCT 2016

1) A. Akturk, et.al, IEEE Trans. Nucl. Sci., 59 (2012) 3258-3264. 2) S S. Suvanam, et al., submitted to IEEE Trans. Nucl. Sci., (2016) 3) M. Nawaz, et al., 2009 Device Research Conference, University Park, PA, (2009) 279-280. 4) L. Ratti et al., IEEE Trans. Nucl. Sci., 52 (2005) 1040-1047. 5) J. Metcalfe et al., Nucl. Instr. Meth. Phys. Res. A, 579 (2007) 833–838. 6) S. L. Kosier et al., IEEE Trans. Nucl. Sci., 40 (1993) 1276- 1285. 7) S. S. Suvanam, et al., IEEE Trans. Nucl. Sci., 61 (2014)1772-1776. 8) X. J. Li et al., Chin. Phys. B, 19 (2010) 066103.

10/21/16 MIKAEL ÖSTLING 47

slide-48
SLIDE 48

NEREID WORKSHOP BERTINORO OCT 2016

Switching waveforms at 150 C

10/21/16 MIKAEL ÖSTLING 48

  • Turn-on to IC=6 A (140 A/cm2), VCE fall-time of 15 ns
  • Turn-off to 800 V with VCE rise-time of 12 ns, and negligible tail current
  • Fast switching using 22 nF external base cap for dynamically increased IB
slide-49
SLIDE 49

NEREID WORKSHOP BERTINORO OCT 2016

10/21/16 MIKAEL ÖSTLING 49

slide-50
SLIDE 50

NEREID WORKSHOP BERTINORO OCT 2016

Darlington pairs with square-cell intertwined layout design

50

To be published in IEEE TED

E

2

B1 E1 , B2 700 µm

Driver Output

Collector Emitter Base C2 E2 B2 E1 C1 B1

slide-51
SLIDE 51

NEREID WORKSHOP BERTINORO OCT 2016

I-V Characteristics

51

To be published in IEEE TED

slide-52
SLIDE 52

NEREID WORKSHOP BERTINORO OCT 2016

Intertwined Design

52

The oxide openings (black) and top metal contacts (magenta). The hexagon and square emitter contacts (orange) and base contacts (blue) which are inverted in the center of BJTs to form the intertwined design.

To be published in IEEE TED

slide-53
SLIDE 53

NEREID WORKSHOP BERTINORO OCT 2016

53

300 µm 300 µm 20 µm

To be published in IEEE TED

About 15% higher current density and lower On-resistance

slide-54
SLIDE 54

NEREID WORKSHOP BERTINORO OCT 2016

Emitter Cell Geometry

54

At the first time, new cell geometries (square and hexagon) were investigated for BJTs, which opens a new design space for improved performance.

slide-55
SLIDE 55

NEREID WORKSHOP BERTINORO OCT 2016

Optimal Emitter Cell Geometry 42 % higher JC and 21% lower RON for the new cell geometries due to a better utilization of the base area.

55

IEEE ELECTRON DEVICE LETTERS, VOL. 36, NO. 10, Oct. 2015

slide-56
SLIDE 56

NEREID WORKSHOP BERTINORO OCT 2016

High Switching Speeds Enable Greater Power Density

56

Comparisons 80kHz 200kHz Delta PCB Area 23.9 in2 154.1 cm2 14.8 in2 95.5 cm2

  • 38%

Volume 47.8 in3 782.8 cm3 29.6 in3 485.1 cm3

  • 38%

Weight 18.4 oz. 521.6 gm 10.4 oz 294.8 gm

  • 44%

Density 10.5 W/ in3 0.64 W/ cm3 16.9 W/ in3 1.03 W/cm3 +61%

Low Frequency Silicon vs. High Frequency Silicon Carbide
