Statistics 3-1 Definitions Statistics is a branch of Mathematics - - PDF document

Statistics

ءاـصحلئا 3-1 Definitions فيراعت

• Statistics is a branch of Mathematics that deals collecting,

analyzing, summarizing, and presenting data to help in the decision-making process.

• Statistics is applied in all fields of life such as:

2 SET 3 - Chapter 3 GFP - Sohar University

• Industry
• Business
• Education
• Physics
• Chemistry
• Economics
• Biology
• Agriculture
• Psychology
• Astronomy, etc.

• Population is all the members of a group about which we want

to draw a conclusion.

3 GFP - Sohar University

• All Omani citizens who are currently above 40 years
• All patients treated at a particular hospital in Sohar last year
• The entire daily output of a food factory’s production line
• All students who studied Maths in GFP in 2016 / 2017
• Sample is the part of the population selected for analysis.

Examples on sample are:

• 500 people above 40 years selected from Oman people.
• The patients selected to fill out a patient satisfaction

questionnaire

• 100 boxes of food selected from a factory’s production line
• 50 students selected from all students who studied Maths in

GFP in 2016 / 2017 Examples on population are:

SET 3 - Chapter 3 4 GFP - Sohar University

• Variable is a property of an item or an individual that will be

analyzed using statistics. Examples on variable are:

• Gender (boy or girl)
• Age of students study in Sohar University
• Income in OMR of a hypermarket in Sohar per month
• Number of traffic accidents in Muscat per year

SET 3 - Chapter 3

3 - 2 Presentation of Ungrouped Data ةـبﱠوـَبـُملا ريغ تانايبلا ضرع

• Ungrouped data can be presented as diagrams in several ways

including bar graph and pie chart.

5 GFP - Sohar University

• Bar graph or chart consists of two or more categories along one axis and a

series of bars, one for each category, along the other axis. The length of the bar represents the magnitude of the measure (amount, frequency, money, percentage, etc.) for each category. The bar graph may be either horizontal

• r vertical.

SET 3 - Chapter 3 6 SET 3 - Chapter 3 GFP - Sohar University

• Pie chart is a circular diagram of data where the area of the whole

pie represents 100% of the data and slices of the pie represent the percentage breakdown of the categories. Pie charts show the relative magnitudes of the parts to the whole.

7 GFP - Sohar University

• The figure below shows a vertical bar graph presentation of the

expenditures of a college undergraduate for the past year.

• Comparing the size of the bars, we can quickly see that room and

board expenses are nearly double tuition fees, and tuition fees are more than double books and lab or transportation expenses.

SET 3 - Chapter 3 8 GFP - Sohar University

• A bar graph may also be placed on its side with the bars going

horizontally, as shown in the figure below:

SET 3 - Chapter 3

9 GFP - Sohar University

• The bar graph have a limitation that it’s difficult to see what portion
• f the total each item comprises. If knowing about a “part of the

whole” is important, then a pie chart is a better choice for showing the same data.

• A pie chart may also display each category’s percentage of the total.
• Using the same data from the previous example, we get the pie

chart shown below.

SET 3 - Chapter 3

3 - 3 Frequency Distribution يراركتلا عيزوتلا

• A frequency distribution is an organized tabulation showing exactly

how many values are located in each class.

• A frequency distribution presents an organized picture of the entire set
• f scores, and it shows where each values is located relative to others in

the distribution.

• An example on frequency distribution is the marks of 16 students

scored in a SET 1 quiz: {65, 73, 64, 85, 66, 77, 82, 93, 86, 63, 58, 63, 62, 79, 61, 74}

10 GFP - Sohar University

Class Class Boundaries Tally Frequency

50 – 59 49.5 – 59. 5 I 1 60 – 69 59.5 – 69.5 IIII II 7 70 – 79 69.5 – 79.5 IIII 4 80 – 89 79.5 – 89.5 III 3 90 – 99 89.5 – 99.5 I 1 Total 16

SET 3 - Chapter 3

• Below is the steps of constructing a frequency distribution:
• Step 1: Figure out how many classes you need. There are no strict

rules about how many classes to choose, but there are a two general guidelines:

• Choose between 5 and 20 classes.
• Make sure you have a few values in each category. For example,

if you have 20 values, choose 5 classes (4 values per category), not 20 classes (which would give you only 1 value per category).

• Step 2: Find the range by subtracting the lowest value from the highest

value in your data set.

• Step 3: Divide your answer in Step 2 by the number of classes you

chose in Step 1.

• Step 4: Round the number from Step 3 up to a whole number to get the

class width.

11 GFP - Sohar University SET 3 - Chapter 3

• Step 5: Write down your lowest value for your first lower limit. Add

the class width from Step 4 to Step 5 to get the next class lower limit.

• Step 6: Keep on adding your class width to your lower limit values

until you have created the number of classes you chose in Step 1.

• Step 7: Write down the class upper limits. These are the highest values

that can be in the category, so in most cases you can subtract 1 from class width and add that to the lower limit.

• Step 8: Find the class boundaries by subtracting 0.5 from each lower

class limit and adding 0.5 to each upper class limit.

• Step 9: Tally the scores by counting the number of items in each class,

and put the total in the third column called frequency.

12 GFP - Sohar University SET 3 - Chapter 3

3 - 4 Presentation of Grouped Data ةـبﱠوـَبـُملا تانايبلا ضرع

• Grouped data is presented by histogram and frequency polygon.
• The table at right is a frequency distribution
• f heights (recorded to the nearest inch) of

100 male students at Sohar University.

• The histogram and frequency polygon for

this distribution are as shown below:

13 SET 3 - Chapter 3 GFP - Sohar University

Histogram Frequency Polygon Example 1: For the set of IQ scores: 118, 123, 124, 125, 127, 128, 129, 130, 130, 133, 136, 138, 141, 142, 149, 150, and 154, construct: (a) 5 classes frequency distribution (b) histogram (c) frequency polygon.

14

Solution:

GFP - Sohar University

(a) Frequency Distribution: Step 1: We will construct a frequency distribution with 5 classes. Step 2: Range = Highest Value – Lowest Value = 154 – 118 = 36 Step 3: Class width = (Range / No. of classes) = 36 / 5 = 7.2 Step 4: Class width = 8

SET 3 - Chapter 3

15 GFP - Sohar University

Step 5, 6, 7, 8 and 9: are as in the following table: Thus, the frequency distribution is shown in the table below:

SET 3 - Chapter 3 16 GFP - Sohar University

(b) Histogram

SET 3 - Chapter 3

17 GFP - Sohar University

(c) Frequency Polygon

SET 3 - Chapter 3

3 - 5 Measures of Central Tendancy for Ungrouped Data

ريغ تانايبلل زكرمتلا سـيـياقمةـبﱠوـَبـُملا

• There are many different measures of central tendency. The three

most widely used measures of central tendency are the mean, median, and mode.

• The mean ( ) for a sample consisting of n observations is:

18 GFP - Sohar University

• The median is the middle number in a group of numbers arranged in

sequential order. In a set of numbers, half will be greater than the median and half will be less than the median.

• The mode is the value in a data set that occurs the most often. If no

such value exists, we say that the data set has no mode. If two such values exist, we say the data set is bimodal. If three such values exist, we say the data set is trimodal.

SET 3 - Chapter 3

Example 2: Find the mean of the following set of numbers: 6, 8, 19, 14, 4, 11, 15.

19

Solution:

GFP - Sohar University

Example 3: Ahmed has four grades of equal weight in Maths. They are 82, 90, 88, and 85. What is Ahmed’s mean in Maths?

Solution:

SET 3 - Chapter 3

Example 4: Find the median of the following set of numbers: 5, 7, 19, 12, 4, 11, 15.

20

Solution:

GFP - Sohar University

Example 5: Find the median of the following set of numbers: 5, 7, 19, 12, 4, 11, 15, 13.

Solution:

Putting the numbers in sequential order gives: 4, 5, 7, 11, 12, 15, 19 The middle number is the median, so 11 is the median. Arranging the values gives: 4, 5, 7, 11, 12, 13, 15, 19 There are two middle numbers: 11 and 12, So, the median

SET 3 - Chapter 3

Example 6: Find the mode of the following set of numbers: 5, 7, 9, 12, 9, 11, 15.

21

Solution:

GFP - Sohar University

Example 7: Find the mode of the following set of numbers: 5, 7, 19, 12, 4, 11, 15.

Solution:

The number 9 occurs twice in the list, so 9 is the mode. None of the numbers occurs more than once, so there is no mode. Example 8: Find the mode of the following set of numbers: 5, 7, 9, 12, 9, 11, 5.

Solution:

The numbers 5 and 9 both occur twice in the list, so both 5 and 9 are modes and the set is bimodal.

SET 3 - Chapter 3

3 - 6 Measures of Central Tendancy for Grouped Data

تانايبلل زكرمتلا سـيـياقمةـبﱠوـَبـُملا

• r

22 GFP - Sohar University

• The mean for grouped data is found as follows:

Example 9: The frequency distribution of the prices of items sold at a supermarket in $ is as shown. Determine the mean value

• f the prices.

1 – 5 8 6 – 10 6 11 – 15 4 16 – 20 2 21 – 25 4 26 – 30 6 31 – 35 2

SET 3 - Chapter 3

23

Solution:

GFP - Sohar University

The table below shows the calculations for finding the mean: Substituting into the formula gives:

SET 3 - Chapter 3 24 GFP - Sohar University

Example 10: The frequency distribution for the length of a spare part in centimeters of a sample of 48 parts is as shown below. Determine the mean value of length.

20.5 – 20.9 3 21.0 – 21.4 10 21.5 – 21.9 11 22.0 – 22.4 13 22.5 – 22.9 9 23.0 – 23.4 2

SET 3 - Chapter 3

25

Solution:

GFP - Sohar University

Calculations for finding the mean are shows the table below: Substituting into the formula gives:

= 21.92 cm

SET 3 - Chapter 3

3 - 7 Standard Deviation for Ungrouped Data

ريغ تانايبلل يرايعملا فارحنلئاةـبﱠوـَبـُملا

26 GFP - Sohar University

• The standard deviation of a set of data gives an indication of the

amount of dispersion, or the scatter, of values of the set from the measure of central tendency.

• The population standard deviation is indicated by σ (the Greek letter

small ‘sigma’), and is calculated for ungrouped data as follows:

• The sample standard deviation is indicated by s, and is calculated

for ungrouped data as follows :

Where µ is the population mean, and N is the number of values in the population. Where is the sample mean, and n is the number of values in the sample.

SET 3 - Chapter 3

27 SET 3 - Chapter 3 GFP - Sohar University

Example 11: Find the sample standard deviation from the mean for the data set: {5, 6, 8, 4, 10, 3} First, find the mean:

Solution:

= 2.61

3 - 8 Standard Deviation for Grouped Data

تانايبلل يرايعملا فارحنلئاةـبﱠوـَبـُملا

28 SET 3 - Chapter 3 GFP - Sohar University

• The population standard deviation σ for grouped data is calculated

as follows:

• The sample standard deviation s for grouped data is calculated as

follows:

Where µ is the population mean, N is the number of values in the population, f is the frequency, and x is the class midpoint Where is the sample mean, n is the number of values in the sample, f is the frequency, and x is the class midpoint

29 GFP - Sohar University

Example 12: Find the standard deviation from the mean of the heights of a random sample of 100 male students at Sohar University whose heights is as shown in the table below. Height (in) Number of Students 60 – 62 5 63 – 65 18 66 – 68 42 69 – 71 27 72 – 74 8

SET 3 - Chapter 3 30

Solution:

SET 3 - Chapter 3 GFP - Sohar University

The calculations for finding the standard deviation for this sample are shown in table below: The mean = = 67.45 in The standard deviation = = 2.93 in

3 - 9 Median for Grouped Data ةـبﱠوـَبـُملا تانايبلل طـيسولا

31 GFP - Sohar University

• The median for grouped data is calculated as follows:

Where: L = the lower boundary of the median class cfp = a cumulative total of the frequencies up to but not including the frequency of the median class fmed = the frequency of the median class W = the class width N = total number of frequencies

SET 3 - Chapter 3 32 GFP - Sohar University

Example 13: The following frequency distribution shows the time needed to travel to work in minutes for 50 employees. Find the median for this distribution. Time to travel to work (min) Number of employees 1 – 10 5 11 – 20 8 21 – 30 11 31 – 40 14 41 – 50 7 51 – 60 3 61 – 70 2

SET 3 - Chapter 3

33

Solution:

GFP - Sohar University

Step 1: Construct the cumulative frequency distribution: Time to travel to work (min) Number of employees Cumulative Frequency 1 – 10 5 5 11 – 20 8 13 21 – 30 11 24 31 – 40 14 38 41 – 50 7 45 51 – 60 3 48 61 – 70 2 50 Step 2: Find the class that contains the median: The Median Class is the class with the value of cumulative frequency that is equal to at least n/2.

=

= Median class is the 4th class So, L = 30.5, cfp = 24, fmed = 14, and W = 10

SET 3 - Chapter 3 34 GFP - Sohar University

• The median is calculated as follows:

Median Median = 31.2 minutes

SET 3 - Chapter 3
