Stamtec Lift Control Panels T h e A r t o f E l e v a t i n g Stamtec Lift Control Panels T h e A r t o f E l e v a t i n g Company Presentation Stamtec, based in Thessaloniki, Greece, designs, develops and manufactures control panels

slide-1
SLIDE 1

Stamtec

Lift Control Panels

T h e A r t o f E l e v a t i n g

slide-2
SLIDE 2

Stamtec

Lift Control Panels

T h e A r t o f E l e v a t i n g

slide-3
SLIDE 3

Company Presentation

Stamtec, based in Thessaloniki, Greece, designs, develops and manufactures control panels for lifts

slide-4
SLIDE 4

Company Presentation

Sta Stamtec products are manufactured in accordance with current European and Greek regulations. Specifically, Sta Stamtec control panels comply fully with the requirements of the Community Directives 95/16/EC, 2006/95/EC, 2004/108/EC and are in conformity with standards EN12015, EN12016, EN 60439-1, EN 81-1+A3 and EN 81-2+A3.

slide-5
SLIDE 5

Company Presentation

Certificates

slide-6
SLIDE 6

Company Presentation

Based on the long experience of its executives, Sta Stamtec presents two decades of constantly rising. Sta Stamtec is one of the leading manufacturers of lift control panels in Greece, with sales also in the Balkan Peninsula, in the Mediterranean Islands and the Arab countries.

slide-7
SLIDE 7

Company Presentation

Stamtec Greek Market

  • Sales all over Greek territory
  • Special projects
slide-8
SLIDE 8

Company Presentation

Stamtec Exports

Cyprus, United Kingdom (UK), FYROM, Albania, Serbia, Montenegro, Malta, Libya, Morocco, Tunisia, Iraq, Syria, Kuwait, United Arab Emirates, Algeria, Saudi Arabia

slide-9
SLIDE 9

Principles

  • Safety
  • Reliability
  • Immediate and Ongoing Support

Stamtec manufacture high igh tech technology lift lift con control l panels els, having as principles the safety fety, the quality lity, and the on

  • ngo

goin ing support of

  • f all

ll its its prod roducts. Chosen materials from well known suppliers are used in the manufacture of the control panels so that their correct, smooth and long lasting operation may be ensured.

slide-10
SLIDE 10

Zero Max Main Board

Main board Ze Zero ro Max is designed and manufactured entirely by Sta tamtec. Programming and configuration are made directly on board. Immediate and easy determination of any faulty operation may be ascertained via the pioneering fault and event recording. Discernible legible messages appear on the liquid crystal display concerning the type of fault, the car location and direction at the time the fault appears, as well as the degree of its repetition.

slide-11
SLIDE 11

Zero Max Main Board

Layout

slide-12
SLIDE 12

Zero Max Main Board

Drawing

slide-13
SLIDE 13

Zero Max Main Board

Call and Display Board for Zero Max (LFT06SDEC-00)

slide-14
SLIDE 14

Zero Max Main Board

Zero Max User Interface – Upper Part

RESET INC DEC PREV NEXT ENTER ESC

Zero Max Main Board (Upper Part)

LCD BRIGHT

S T A M T E C

Jumper CAN LIN2 RS232 LIN1
slide-15
SLIDE 15

Zero Max Main Board

Boards Buttons Function

Buttons Function Description INC + DEC 1) Enter in programming mode. Initially Board and Memory Version are shown and Enter Code is requested. 2) Exit from programming mode – the panel is ready to work again in Normal Mode ENTER 1) Enter in a submenu. 2) Select a menu item to modify. An arrow “>” is displayed on the left of the current data value, that means we can change the value. 3) Complete the operation of changing a data value, saving the new value. The arrow “>” disappears. ESC 1) Exit from a current submenu and go back to the previous menu. 2) Exit from the current data value without saving any changes. The arrow “>” disappears. PREV 1) Scroll up in the current submenu. 2) Increase - change the value of a setting, when the arrow “>” is displayed on the left of the current setting. NEXT 1) Scroll down in the current submenu. 2) Decrease - change the value of a setting, when the arrow “>” is displayed on the left of the current setting. RESET 1) Reset of the board and check serial communication between main board and serial car card and serial landing modules.

slide-16
SLIDE 16

Zero Max Main Board

Lcd Display Indications during Normal Mode

U C R T L B N e x t S t

  • p

X X E R

DOWN PRE-FINAL LIMIT (U) COUNT / CHANGE SPEED (CK) STOP AT FLOOR (R) UP PRE-FINAL LIMIT (T) LOCKS CLOSED UP / DOWN DIRECTION CURRENT CAR POSITION CURRENT CALL EXECUTED (XX) : XX = Floor 0, 1, 2, ..., 17 ERROR REGISTERED CAR DOOR CLOSED M=MASTER S=SLAVE (DUPLEX)
slide-17
SLIDE 17

Stamtec Products

  • Elevator Control Panels
  • Hydraulic Lift Control Panels with Emergency Lowering System: Direct On

Line Start, Star-Delta Start, Hydraulic VVVF, Electronic Valve Control, Hydraulic MRL, Any Valve Block

  • Traction Lift Control Panels: One Speed, Two Speed, VVVF Control, Traction

VVVF MRL for Gearless Machines

  • Emergency Traction Panels: Emergency Battery Powered Evacuation

Systems for All Type Traction Elevators

  • Car Serial Interface Board Incorporated in Pre-wired Lift Inspection Control

Box

  • Landing Serial Interface Boards
  • Reactive Power Compensation Panels (Cosf Correction)

Elevator Control Panels

slide-18
SLIDE 18

Stamtec Products

  • Hydraulic Lift Control Panels with Emergency Lowering System: Direct On

Line Start, Star-Delta Start, Hydraulic VVVF, Electronic Valve Control, Hydraulic MRL, Any Valve Block

Elevator Control Panels

slide-19
SLIDE 19

Stamtec Products

  • Traction Lift Control Panels: One Speed, Two Speed, VVVF Control

Elevator Control Panels

slide-20
SLIDE 20

Stamtec Products

  • Traction Lift Control Panels: Traction VVVF MRL for Gearless Machines

Elevator Control Panels

Single Floor Panel Single Shaft Panel Floor & Shaft Panel

slide-21
SLIDE 21

Stamtec Products

  • Emergency Traction Panels: Emergency Battery Powered Evacuation

Systems for All Type Traction Elevators

Elevator Control Panels

slide-22
SLIDE 22

Stamtec Products

  • Full Prewiring System

Machine Room, Shaft & Car Prewiring

Elevator Control Panels

slide-23
SLIDE 23

Stamtec Products

  • Car Serial Interface Board Incorporated in Pre-wired Lift Inspection Control

Box

Elevator Control Panels

slide-24
SLIDE 24

Stamtec Products

  • Landing Serial Interface Boards

Elevator Control Panels

slide-25
SLIDE 25

Stamtec Products

  • Reactive Power Compensation Panels (Cosf Correction)

Elevator Control Panels

slide-26
SLIDE 26

Stamtec Products

Escalator Control Panels

slide-27
SLIDE 27

Lift 232

Monitor and Control Program for main board Zero Max

The main board can communicate with the computer (Netbook, Laptop, Desktop) through the Lift232 Monitor and Control Program. The Monitor and Control Program gives the user many possibilities including:

  • Check in real-time the traffic and current state of the lift (change of inputs state, check safety circuit, ...)
  • Customization of the program to meet the requirements of the elevator installation (eg , Hydraulic,

Traction, ... )

  • Enable / disable specific functions (eg , Car and Floor Serial Operation ... )
  • Timers Modification
  • Overview of Active Faults
  • Overview / Delete Stored Faults (Installation, Internal and Serial Communication Faults)

The program gives also extra possibilities:

  • Check the board status (check inputs and outputs)
  • Enable the Request Service Counter (Limited number of movements over which is required the

intervention of the maintainer for restarting the elevator )

  • Introduction and modification of Login Passwords for the Main Board and the Program Lift232
slide-28
SLIDE 28

Lift 232

Monitor and Control Program for main board Zero Max

Main board connection with the program

RS232 Port Power Supply 12Vdc

slide-29
SLIDE 29

Lift 232

Monitor and Control Program for main board Zero Max

Main board connection with the program

Usb to serial 9 pin sub-D male cable Serial null modem cable 9pin sub-D fem - fem PC USB Port Board RS232 Port

slide-30
SLIDE 30

Lift 232

Monitor and Control Program for main board Zero Max

Program Home Screen

slide-31
SLIDE 31

Lift 232

Monitor and Control Program for main board Zero Max

Lift232 Submenus Expanded

File Edit View Port Tools Options Help

slide-32
SLIDE 32

Lift 232

Monitor and Control Program for main board Zero Max

Lift232 Submenus Expanded

File Edit View Port Tools Options Help

slide-33
SLIDE 33

Lift 232

Monitor and Control Program for main board Zero Max Normal Control Mode Serial Control Mode Tools > Setup Board

slide-34
SLIDE 34

Lift 232

Monitor and Control Program for main board Zero Max Normal Control Mode

Check for Board and Program Version

*** STAMTEC – ZERO MAX *** LF2061 V1.60I -B for LF2050-5B *** Monitor and Control Program ***

slide-35
SLIDE 35

Lift 232

Monitor and Control Program for main board Zero Max Normal Control Mode

Check for Serial Communication (Car, Floors, Duplex)

Checking Cabine Duplex Error Cabine Found Searching LIN2.. Floor 0 OK Floor 1 OK Floor 2 OK Floor 3 OK Floor 4 OK

slide-36
SLIDE 36

Lift 232

Monitor and Control Program for main board Zero Max Normal Control Mode

Additional Checks and Results

PHASE SEQUENCER CAR PCB DISCON. MOTOR THERMISTOR SAFE INPUT OPEN OVERLOAD INVERTER REPORT STOP SWITCH OPEN 2 PREFINALS OPEN DOOR OPEN OIL THERMISTOR LIMIT SWITCH OVERLOAD CLEARED OIL THERMISTOR CLEARED MOTOR THERMISTOR CLEARED INVERTER REPORT CLEARED Top PFinal Closed PHOTO CELL CLOSED 1 PREFINAL CLOSED 0 floor Lock Input Closed Bus door Closed STOP SWITCH CLOSED DOOR CLOSED SAFE INPUT CLOSED PHASE SEQUENCER CLEARED LIMIT SWITCH CLEARED PHOTO CELL CLOSED CAR PCB CONNECTED

slide-37
SLIDE 37

Lift 232

Monitor and Control Program for main board Zero Max Normal Control Mode

Check Real-Time Lift Motion

Next Stop : 1 floor Direction Up Starting Fast... Bottom PFinal Closed Counter Closed Counter Opened Counter Closed 1 floor Counter Opened Land Stop Closed Direction None

slide-38
SLIDE 38

Lift 232

Monitor and Control Program for main board Zero Max Normal Control Mode

Normal Control Commands

slide-39
SLIDE 39

Lift 232

Monitor and Control Program for main board Zero Max Normal Control Mode

Show Inputs Command (SHOWINPUTS)

slide-40
SLIDE 40

Lift 232

Monitor and Control Program for main board Zero Max Normal Control Mode

Show Active Errors Command (SHOWACTER)

*** ACTIVE ERRORS *** PHASE SEQUENCER LIMIT SWITCH STOP SWITCH OPEN DOOR OPEN 2 PREFINALS OPEN OIL THERMISTOR OVERLOAD SAFE INPUT OPEN MOTOR THERMISTOR CAR PCB DISCON.

slide-41
SLIDE 41

Lift 232

Monitor and Control Program for main board Zero Max Normal Control Mode

Show Installation Errors Command (SHOWERINST)

*** INSTALLATION ERRORS *** 0 Installation Errors

Car Call Execution Command (CARCALL)

CARCALL Χ

slide-42
SLIDE 42

Lift 232

Monitor and Control Program for main board Zero Max Serial Control Mode

Serial Control Commands

slide-43
SLIDE 43

Lift 232

Monitor and Control Program for main board Zero Max Tools > Setup Board

slide-44
SLIDE 44

Lift 232

Monitor and Control Program for main board Zero Max Tools > Setup Board

LIN BUS – Serial Setup

slide-45
SLIDE 45

Lift 232

Monitor and Control Program for main board Zero Max Tools > Setup Board

Basic Setup

slide-46
SLIDE 46

Lift 232

Monitor and Control Program for main board Zero Max Tools > Setup Board

Standard Timers

slide-47
SLIDE 47

Lift 232

Monitor and Control Program for main board Zero Max Tools > Setup Board

Hydraulic Setup

slide-48
SLIDE 48

Lift 232

Monitor and Control Program for main board Zero Max Tools > Setup Board

Advanced Setup

slide-49
SLIDE 49

Lift 232

Monitor and Control Program for main board Zero Max Log File

Log File Open / Creation Log File View

slide-50
SLIDE 50

Lift 232

Monitor and Control Program for main board Zero Max Time Stamps

Time Stamp Activation and Period Setting

slide-51
SLIDE 51

Stamtec

Lift Control Panels
