Stability, phase transitions, phase diagrams following Callen 1985 book 8Stability of thermodynamic systems 2 Intrinsic stability Basic extremum principle: dS = 0 and d 2 S < 0 or extremum and maximum Stable


slide-1
SLIDE 1

Stability,
 phase transitions,
 phase diagrams

following Callen 1985 book

slide-2
SLIDE 2

8—Stability of thermodynamic systems

2

slide-3
SLIDE 3

Intrinsic stability

3

  • Basic extremum principle: dS = 0 and d2S < 0 or extremum and maximum
  • Stable vs. unstable equilibrium (analogy in mechanics)
  • Considerations of stability … most interesting and significant predictions of thermodynamics
  • Consider two identical subsystems, fundamental relation S(1) = S(2) = S(U,V,N)
  • Suppose we remove ΔU from (1) and transfer it to (2)
  • Change in total entropy is:

2S(U, V, N) ⟶ S(U + ΔU, V, N) + S(U + ΔU, V, N) > 2S(U, V, N) !

  • That is, if adiabatic restraint were removed, energy would flow spontaneously


across the wall, U(1) would increase and U(1) would decrease

  • Even within one subsystem, internal inhomogeneities would tend to develop
  • Loss of homogeneity … hallmark of a phase transition
  • Condition of stability: concavity of the entropy

S(U + ΔU, V, N) + S(U + ΔU, V, N) ≤ 2S(U, V, N) ∀ΔU For ΔU → 0 : ∂2S ∂U2

V,N

≤ 0 global condition local condition

slide-4
SLIDE 4

Intrinsic stability

4

  • If we were to “transfer” volume, condition of stability:

S(U, V + ΔV, N) + S(U, V − ΔV, N) ≤ 2S(U, V, N) ∀ΔV For ΔV → 0 : ∂2S ∂V2

U,N

≤ 0

  • A fundamental relation may be obtained somehow (e.g., extrapolation of experimental data or

statistical mechanical calculation) that looks, for example:

  • The “underlying” F

.R. above does not satisfy the concavity condition.

  • The proper thermodynamic F

.R. is constructed as the envelope of the superior tangent lines.

  • A point on the straight line BHF (e.g., H) corresponds to a phase separation. Part of the system is

in state B and the rest in state F .

  • In the 3-dimensional S–U–V subspace, the global condition of stability:


Entropy surface must lie below its tangent planes. global condition local condition S(U + ΔU, V + ΔV, N) + S(U − ΔU, V − ΔV, N) ≤ 2S(U, V, N) ∀ΔU, ∀ΔV

slide-5
SLIDE 5

Intrinsic stability

5

  • In the 3-dimensional S–U–V subspace, the global condition of stability:

S(U + ΔU, V + ΔV, N) + S(U − ΔU, V − ΔV, N) ≤ 2S(U, V, N) ∀ΔU, ∀ΔV Entropy surface must lie below its tangent planes. For ΔU → 0 and ΔU → 0 : ∂2S ∂U2

V,N

≤ 0 & ∂2S ∂V2

U,N

≤ 0 & ∂2S ∂U2 ∂2S ∂V2 − ( ∂2S ∂U∂V)

2

≥ 0

  • Mathematically: d2S(U,V) < 0 … negatively definite form … Hessian matrix …

Conditions of stability for thermodynamic potentials

∂2U ∂S2

V,N

≥ 0 & ∂2U ∂V2

S,N

≥ 0 & ∂2U ∂S2 ∂2U ∂V2 − ( ∂2U ∂S∂V)

2

≥ 0 ∂2F ∂T2

V,N

≤ 0 & ∂2F ∂V2

T,N

≥ 0 & ∂2F ∂T2 ∂2F ∂V2 − ( ∂2F ∂T∂V )

2

≥ 0 ∂2H ∂S2

P,N

≥ 0 & ∂2H ∂P2

S,N

≤ 0 & ∂2H ∂S2 ∂2H ∂P2 − ( ∂2H ∂S∂P)

2

≥ 0 ∂2G ∂T2

P,N

≤ 0 & ∂2G ∂P2

T,N

≤ 0 & ∂2G ∂T2 ∂2G ∂P2 − ( ∂2G ∂T∂P)

2

≥ 0

slide-6
SLIDE 6

Physical consequences of stability

6

∂2S ∂U2

V,N

= ∂ ∂U ( 1 T)V,N = − 1 T2 ∂T ∂U

V,N

= − 1 T2NCV ≤ 0 ⇔ CV ≥ 0 ∂2F ∂V2

T,N

= − ∂P ∂V

T,N

= 1 VκT = KT V ≥ 0 ⇔ κT ≥ 0 (KT ≥ 0) CP − CV = Tvα2 κT ⇒ CP ≥ CV ≥ 0

Recall:

κS κT = CV CP ⇒ κT ≥ κS ≥ 0

Recall:

slide-7
SLIDE 7

9—First order phase transitions

7

slide-8
SLIDE 8

Phase diagram

8

A chart showing conditions (P ,T,V,…) at which thermodynamic phases occur and coexist

slide-9
SLIDE 9

First order phase transition

9

G

low density phase (vap.) high density phase (liq.)

V

slide-10
SLIDE 10

First order phase transition

10

A,B,C … first-order transition
 The two phases inhabit different regions in the "thermodynamic space"
 D … second-order transition

slide-11
SLIDE 11

Discontinuity in entropy: latent heat

11

g … (molar Gibbs potential) equal in the two phases u, f, h, v, s … discontinuous across the transition solid solid + liquid liquid time T steady supply of heat … latent heat of fusion … latent heat of first-order transition

lLS ≡ lf = T(sL − sS) l = TΔs = Δh h = Ts + g

slide-12
SLIDE 12

Slope of coexistence curves: Clapeyron equation

12

Phase equilibrium: At any point along coexistence curve g is the same in both phases (and in single-component system, g = μ) Clapeyron slope … along coexistence curve Solid–solid phase transitions of minerals in the Earth's: some dP/dT>0, some <0 While the low-P phase → high-P phase transition always has Δv<0, Δs can go both ways.

[figure source]

μA = μA′ μB = μB′ dμ = dμ′ −sdT + vdP = − s′dT + v′dP dP dT = s′− s v′− v = Δs Δv = Δh TΔv = l TΔv

slide-13
SLIDE 13

13

24 THERh4ODYNAhIICS

Table 5. Enthalpy, Entropy and Volume Changes for High Pressure Phase Transitions AH’ (kJ/mol) AS” (J/m01 K) AV“ (cm3/mol)

Mg2Si04(a= P>

30.0 f 2.8a f2]

Mg2SiO4(a=Y)

39.1 f 2.d21 Fe2Si04(a=P) 9.6 + 1 .3L21 I%2Si04(a=y) 3.8 f 2.4L2J MgSi03 (px = il) 59.1 f 4.3131 MgSi03 (px = gt) 35.7 f 3.d91 MgSi03 (il = pv) 51.1 + 6.d171 Ws 2siWYk MgSiWpv)+MgO 96.8 + 5.8/l 71 SiO 2 (q = co) 2.1+ 0.5[11 SiO 2 (co = st) 49.0 f 1 .l[lJ

  • 77*19a[21

. .

  • 15.0

t 2.4L21

  • 10.9

AZ 0.8[21

  • 14.0

f 1.912J

  • 15.5

f 2.0[3J

  • 2.0 + 0.5

L91 +5 + 4[171 +4 f 41171

  • 5.0

* 0.4[1J

  • 4.2

f l.l[IJ

  • 3.16a

12]

  • 4.14[21
  • 3.20[21
  • 4.24

L2J

  • 4.94

131

  • 2.83

[9J

  • 1.89[171
  • 3.19[17J
  • 2.05

[I]

  • 6.63

[II

a AH and AS are values at I atm near 1000 K, AV is AV”298, for all listings in table, a = olivine, /I = spinelloid

  • r wadsleyite,

y = spinel, px = pyrox-ene, il = ilmenite, gt = garnet, pv = perovskite, q = quartz, co = coesite, st = stishovite

Table

  • 6. Thermodynamic

Parameters for Other Phase Transitions Transition AH” AS” AV” (Wmol) (J/K*mol) (cm 3/mol> SiO 2 ( o-quartz = p-quartz) Si02 ( fi-quartz = cristobalite)

GeO2 (Wile = quartz)

CaSiO3 (wollastonite = pseudowollastonite) Al2SiO5 (andalusite = sillimanite) Al2SiO5 (sillimanite = kyanite) MgSi03 (ortho = clino) MgSi03 (ortho = proto) FeSi03 (ortho = clino) MnSi03 (rhodonite = pyroxmangite) 0.25 Lz5J MnSi03 (pyroxmangite = pyroxene) NaAlSi308 (low albite = high albite) 13.51311 KAlSi 309 (microcline = sanidine)

0.47a.b 0.35 2.94151 1.93 561231 5:0[311 4.0 3.6 3.8815j 4.50

  • 8.13L51
  • 13.5
  • 0.37[51

0.16 1.59[51 1.21

  • 0.11~2~~
  • 0.03
  • 1.03
  • 0.39

0.88[251

  • 2.66

14.0

0.40

11.1[51

15.0

0.101

0.318

11.51 0.12

  • 0.164
  • 0.511
  • 0.002

0.109

  • 0.06
  • 0.39
  • 0.3

0.40 0.027

a Treated as though allfirst

  • rder, though a strong higher order component

bAH and AY are values near 1000 K, AV is AV ‘298 for all listings in table.

Navrotsky, A., Thermodynamic properties of minerals, in Mineral Physics & Crystallography: A Hand- book of Physical Constants, AGU Reference Shelf, vol. 2, edited by T. J. Ahrens, pp. 18–28, American Geophysical Union, Washington DC, doi:10.1029/RF002p0018, 1995.

slide-14
SLIDE 14

Unstable (van der Waals) isotherms

14

P = RT v − b − a v2 high T low T

slide-15
SLIDE 15

15

dµ = −sdT + vdP

Gibbs-Duhem: Integrate at T = const:

µ = Z vdP + φ(T)

Assign μ(A) ≡ μA:

µB − µA = Z B

A

v(P)dP

slide-16
SLIDE 16

16

for a given (low) T μ–T–P

slide-17
SLIDE 17

17

µD = µO ⇔ Z O

D

v(P)dP = 0

Unstable isotherm ~ underlying fundamental relation Physical isotherm ~ thermodynamic fundamental rel.

slide-18
SLIDE 18

First-order phase transitions in multi-component systems

18

Single-component U = U(S, V, N) u = u(s, v) Multi-component U = U(S, V, N1, …, Nc) u = U(s, v, x1, …, xc−1) r components xj = Nj N N = N1 + … + Nc where

  • At equilibrium, U, H, F

, G are convex functions of mole fractions x1,…,xr

  • If stability criteria not satisfied, a phase transition occurs.


Mole fractions (xj), molar entropies (s), molar volumes (v) differ in each phase.

  • Example 1: a two-component system (1,2) at a given T, P with two coexisting phases (I,II)

μ(I)

1 (T, P, x(I) 1 ) = μ(II) 1 (T, P, x(II) 1 )

μ(I)

2 (T, P, x(I) 1 ) = μ(II) 2 (T, P, x(II) 1 )

… condition of equilibrium coexistence w.r.t. transfer of component 1 … condition of equilibrium coexistence w.r.t. transfer of component 2

Two equations to solve for x1(I) and x1(II).

  • Example 2: a two-component system (1,2) at a given T, P with three coexisting phases (I,II,III)

μ(I)

1 (T, P, x(I) 1 ) = μ(II) 1 (T, P, x(II) 1 ) = μ(III) 1

(T, P, x(III)

1

) μ(I)

2 (T, P, x(I) 1 ) = μ(II) 2 (T, P, x(II) 1 ) = μ(III) 2

(T, P, x(III)

1

) Four equations to solve for only three variables x1(I), x1(II), x1(III). ?? ⟶ Cannot independently specify T and P. Set one, the other is given by equilibrium coexistence.

  • Example 3: a two-component system (1,2) at a given T, P with four coexisting phases (I,II,III) …
slide-19
SLIDE 19

Gibbs phase rule

19

f = c − p + 2

# degrees of freedom = # components - # phases + 2

  • Example 1: pure H2O, coexistence of two phases … f = 1 - 2 + 2 = 1 … coexistence curves in

the P–T diagram (s–l, l–g, s–g)

  • Example 2: pure H2O, coexistence of ice, water, steam … f = 1 - 3 + 2 = 0 … triple point
slide-20
SLIDE 20

?Phase diagram of mineral mixture?

20

slide-21
SLIDE 21

Phase diagram of a binary system

21

slide-22
SLIDE 22

Phase diagram of a binary system

22

slide-23
SLIDE 23

Phase diagram of a binary system

23

slide-24
SLIDE 24

Phase diagram of a binary system

24

slide-25
SLIDE 25

25

slide-26
SLIDE 26

26

slide-27
SLIDE 27

27

slide-28
SLIDE 28

28

slide-29
SLIDE 29

29 https://www.sciencedirect.com/referencework/9780444538031/treatise-on-geophysics

slide-30
SLIDE 30

Mineral phases in Earth’s mantle

30

Bellini et al. 2013

P T P T

Clapeyron slope (phase equilibrium)

at 410 km depth exothermic transition at 660 km depth endothermic transition

slide-31
SLIDE 31

2000 4000 6000 Depth (km) Temperature (K) 1000 2000 3000 4000 5000 solidus t e m p e r a t u r e inner core

  • uter

core lower mantle

670 400 L A D" 2891 6371 5150

Depth (km)

L = lithosphere (0–80 km) A = asthenosphere (80–220 km) D" = lower-mantle D" layer 400, 670 = phase transitions

1000 2000 3000 4000 5000 Temperature (°C)

  • Fig. 4.14 Variations of estimated temperature and melting point with

410 km depth 660 km depth z

  • m

i n

31

Anchor points for geotherm

slide-32
SLIDE 32

Dynamic consequences of phase transitions

32

Exothermic phase transition at 410 km facilitates sinking of subducting plate Endothermic phase transition at 660 km hinders sinking of subducting plate

Subducting slabs are colder than ambient mantle Phase transition takes place and different depth Resulting density anomaly may facilitate or hinder flow

Phase equilibrium Phase equilibrium Tmantle Tplate Tmantle Tplate

slide-33
SLIDE 33

33

slide-34
SLIDE 34

Ideal solutions

  • Consider a system with >1 components
  • Measure of concentration of components: mole fraction (alternative: molality, molarity,

weight fraction as %, ppm, ppb, …)

  • Ideal gaseous solution … ideal gas of vanishingly small non-interacting particles of several

types, PV = nRT (no particle feels any other)

  • Ideal liquid solution … all two particle interactions identical (A–A, B–B, A–B interactions

indistinguishable)

  • Ideal solid solutions … rigid structure, molecules/ions/atoms confined to structural sites

(crystal lattice, glass), component-dependent two-particle interactions (Si–Si, Si–O, Si–Mg O–O, Mg–O), substitutions of some species possible and indistinguishable (Mg⟷Fe)

  • Two kinds of ideality (for liquids and solids):
  • all of A–A, A–B, B–B interactions … Raoult’s law
  • A–A and A–B but no B–B interactions … limit of infinitely dilute B … Henry’s law
  • Goes back to 19th century investigations of gas/vapor pressure associated with solutions
  • Dalton 1811: Ptot V = n1RT + n2RT

34

slide-35
SLIDE 35

Henry’s law

35

slide-36
SLIDE 36

Raoult’s law

36

slide-37
SLIDE 37

Ideal Gibbs free energy of mixing

37
