Speech-Based Interaction

Using Speech as a “Natural” Data Type Speech as Input  Chief decision: Recognition versus Raw Data  Recognition  Translate into other information (words)  Must deal with errors  Useful for either human or machine consumption of results  Raw Data  For use “as data” (not commands) for human consumption  Often linked with other context (time) in capture applications  Speech as Output  Main issues: length of presentation time, lack of persistence, etc.  2

Issues in Speech as Input Perfect recognition of speech (or semantic understanding of any kind of audio) is  difficult to achieve Challenge: How would you begin?  Segmentation  Syntax  3

Interesting features in speech Pauses between phrases as well…  4

Issues  Use of open air microphones & speakers can result in undesired audio  ambient noise  audio feedback  Challenge: allow developers to easily add/use functions in their applications  Noise reduction  Enhance audio quality  Echo cancellation 5

Noise Reduction f(t) f’(t) Noise Filter Random noise is hard to predict  6

Echo Cancellation Echo f(t) f’(t) Canceller Software and hardware exist, but are hard for developers to easily add to  application Random noise is hard to predict, but echoes are not so random...  7

More Issues It is still difficult to:  grab  chunk (segment)  store  search/index/grep  playback (think about the pain of automated phone menus...)  Challenge: provide support for handling audio in manner similar to text  8

Most Straightforward Speech Interface Voice menu systems  System speaks list of possibilities then waits for you to select one  Minor improvement: you can jump in whenever you hear the item you want  Why are these so painful?  9

Most Straightforward Speech Interface Voice menu systems  System speaks list of possibilities then waits for you to select one  Minor improvement: you can jump in whenever you hear the item you want  Why are these so painful?  Hierarchy -- very wide and deep makes for a big search space  Often no easy way to jump around in the tree  “Where you are” matters, but there’s no way to know “where you are” other  than just hearing the menu again Presentation time -- reading of long lists of options  There are good points:  You know what you can do at any given time  Triumph of ease of implementation over imagination  10

Audio Features Think of as “degrees of freedom” of speech as an input device  Pauses  Analogy to mouse up/down/drag?  Who is speaking?  Turn-taking  How is someone speaking?  Prosody, afffect  What is being said?  Recognition of words  11

Case Study: Speech Acts Big idea: move away from voice as a replacement for menus (easy to implement but  painful to use), toward more conversational interfaces “Designing SpeechActs: Issues in Speech User Interfaces,” Yankelovich, Levow, Marx, CHI’95  Mail:   SpeechActs: You have 14 new messages and 47 old  messages. The first new message is from Eric Baatz regarding "report completed."   User: Let me hear it.  SpeechActs: "The first draft is ready for your comments.  Eric."  User: Reply and include the current message.  SpeechActs: Preparing message to Eric Baatz. Begin  recording after the tone. When finished,  pause for several seconds. User: Eric, I'll get those to you this afternoon.   SpeechActs: Say cancel, send, or review.  User: Send.  SpeechActs: Message sent. What now?  User: Next message.  SpeechActs: New message two from Stuart Adams,  subject "Can we meet at 3:00 today?"  User: Switch to calendar... Other commands:   What do I have tomorrow?  What about Bob?  What did he have last Wednesday?  And next Thursday? What was Paul doing three days after Labor Day?  What's the weather in Seattle?  How about Texas?  I'd like the extended forecast for Boston.  12

Speech Acts How is this an improvement over voice menu systems?  No formal hierarchy -- so no need for commands to navigate it  “Where you are” doesn’t matter so much, so no need to fret over how to  present it Presentation time -- minimizes output from the system, focusing on content  rather than commands or context Conversational -- takes advantage of implicit contextual cues in the workflow,  mimicking the way human conversation works Bad points?  You may not know what you have to say in order to control the system (not as  explicit as in menus) 13

Speech Acts Design Challenges Simulating Conversation  Avoid prompting wherever possible  Build context around subdialogs  Output prosodics: system asks “huh?”  Pacing: people often have to speak more slowly when talking to machines; need a  way to “barge in” to machine output Transforming GUIs into SUIs  Vocabulary: need wide, domain-dependent vocabulary  Information organization: how to present content like email messages, flags, message  numbers, etc., with consistency and w/o overwhelming the user Information flow: speech “dialog boxes” (force users into a small set of choices)  don’t fit well into conversational style (Users ignore or may produce unexpected answers: “Do you have the time?” not always answered by yes/no) 14

Speech Acts Design Challenges (cont’d) Recognition errors  Rejection errors (utterance not recognized) are frustrating. Can yield “brick wall” of “I  don’t understand” messages. Solution: provide progressive assistance Substitution errors are damaging. Don’t want to verify every utterance. Approach:  commands that present data are verified implicitly; commands that destroy data or are undoable are verified explicitly Insertion errors (background audio picked up as commands or data). Solution: key to  turn off recognizer The Nature of Speech  Lack of visual feedback. Users feel less in control; users can be faced with silence if they  don’t do anything; long pauses in conversations are uncomfortable so users may feel a need to respond quickly; less information transmitted to hte user at one time Speed and persistence: although speech is easy for humans to produce it is hard to  consume. Also not persistent: easy to forget, no on-screen reminder. 15

Speech Acts Summary SpeechActs shows the challenges in doing speech “right” (as opposed to  just voice menus) Speech as input  Speech as output  Real recognition  Other systems that address the same set of challenges:  Voice Notes (MIT): speech as data, plus input and output  There are other uses of speech that don’t involve so much hard  (recognition and design) work though Case studies:  Suede (Berkeley): faking “working” speech for UI design  Personal audio loop (GT): uninterpreted audio UI for human consumption  Family Intercom (GT): uninterpreted audio UI for human consumption  16

Case Study: Suede  Toolkit for prototyping speech interface  http://guir.berkeley.edu/projects/suede/ 17

18

19

20

Case Study: Personal Audio Loop  Application which continuously buffers user’s last 15 minutes of audio  ”What were we talking about…?”  ”What was that phone number I heard?”  Features above are used to speed up audio playback when skimming for point of access  compressed or discarded in some cases 21

Case Study: The Family Intercom Use location sensing in context-aware environment to connect people in  different places in a conversation 22

The Family Intercom (Ubicomp 2001) How do I do this math homework? son He is alone in his room. Jamie, have you finished your I want to talk homework? to Jamie. Mom 23

The Family Intercom (Ubicomp 2001) What is this little son two above the number? … Power of 2. When you finish, come set the dinner table. Bye. 24

Resources Java Speech API:  Recognition and synthesis  http://java.sun.com/products/java-media/speech/  FreeTTS:  A Java port of a very high quality speech synthesis package:  http://freetts.sourceforge.net/docs/index.php  25
