Speakers Arnaud Cresp Jaume Mir Kuban Altan IT Manager Project Manager VP of Research & Development Notl MEBD Professional Video Systems Zero Density AW-UE150 The first PTZ with tracking data Overview AW-UE150 is the first PTZ

SLIDE 1

SLIDE 2

Speakers

Jaume Miró

Project Manager MEBD Professional Video Systems

Arnaud Cresp

IT Manager Notélé

Kuban Altan

VP of Research & Development Zero Density

SLIDE 3

AW-UE150 The first PTZ with tracking data

SLIDE 4

AW-UE150 is the first PTZ that provides Position Data Notification (PTZF), becoming compatible with Virtual Studios and Augmented Reality applications. Thanks to the adoption of FreeD protocol both via IP and Serial, the AW-UE150 is compatible with the major AR/VR systems, such as Zero Density. Free upgrade.

Overview

SLIDE 5

AW-UE150

4K acquisition (2160/50p)
20x Zoom
Wider angle of view (75.1°)
Integrated Lens Calibration file
Simultaneous UHD & HD outputs
HDR and V-Log
Genlocked tracking data

Overview

SLIDE 6

Presets

How to Control the PTZ

a) Web Browser b) ZD’s Reality Control c) AW-RP150 Panel

Large touchscreen for easy usability
Presets from touchscreen/buttons
New joystick for one-handed operation
Built-in camera control
Switcher Link & ROP Link functions

Reality Control

SLIDE 7

A bit of history…

SLIDE 8

How to speed-up the setup: Calibration file

User guide available!!!

SLIDE 9

Case Study

https://youtu.be/qUdRdofuO7g Creating a virtual reality set at notélé Belgium

SLIDE 10

UE150 on Tuning motorized dollies and totems

https://youtu.be/ymmuyXyIYc4 https://youtu.be/GLZd-638M5M

Wide Floor Dolly AR by Zero Density

SLIDE 11

AW-UE150

How to connect the camera over public internet for Virtual production?

Los Angeles Connecticut

FreeD (PTZFI Tracking Data) Video Control

Use a VPN connection to extend IP network to receive tracking data stream.
Use SRT for audio and video transmission on the same network.
Camera control would be on the same network.

SLIDE 12

AW-UE150

Reality Engine supports V-Log gamma

curve from Panasonic

It improves the acquisition and keying
f UHD HDR pictures

V-Log Output V-709 Output

SLIDE 13

Why 4K if I am broadcasting in HD

Future-proof investment
4K HDR acquisition brings a high resolution

picture to the Keyer

Keyer works in 4K without downscaling
Final output has better quality, also in HD
