Software Engineering Seminar Stephan Semmler A Dynamically Tuned Sorting Library Xiaoming Li, Mara Jess Garzarn, and David Padua 2004 The Sorting Library Installation Runtime Hardware Input data Empirical Machine Sorting

SLIDE 1

A Dynamically Tuned Sorting Library

Xiaoming Li, María Jesús Garzarán, and David Padua 2004 Stephan Semmler

Software Engineering Seminar

SLIDE 2

Installation Runtime Empirical Search Machine Learning

Hardware Input data

Optimized Algorithms Sorting Algorithms

Fastest Algorithm

The Sorting Library

SLIDE 3

Overview

Sorting Algorithms
Optimizing the Algorithms
Factors of Performance
The Library
Results
Final Words

SLIDE 4

Merge Sort

Divide and Conquer
Runtime O(n·log(n))
Needs additional memory to merge

4 1 3 2 4 1 2 3 2 1 3 4

SLIDE 5

Multiway Merge Sort

Partition data into p subsets
Sort each subset
Merge p subsets using a heap

1 2 p …

Heap

Sorted Subset Sorted Subset Sorted Subset Sorted Subset

p subsets

SLIDE 6

7 5 6 4 2 3 1 9 8 7 5 6 4 2 3 1 9 8 7 5 9 4 2 3 1 6 8 7 5 9 4 2 3 1 6 8 7 5 9 4 2 3 1 6 8 7 5 9 4 2 3 1 6 8 7 5 9 4 2 3 1 6 8 7 5 9 4 2 3 1 6 8 7 5 9 4 2 3 1 6 8 7 5 9 6 2 3 1 4 8

Average runtime O(n·log(n))
Inplace
Worst Case runtime O(n²)

Quicksort

SLIDE 7

13 322 44 142 34 431 1 23

Radix Sort

1 2 3 4

SLIDE 8

34 44 23 13 142 322 1 431 13 322 44 142 34 431 1 23 13 322 44 142 34 431 1 23

Radix Sort

1 2 3 4

SLIDE 9

Radix Sort

13 322 44 142 34 431 1 23

1 2 3 4

SLIDE 10

Radix Sort

13 322 44 142 34 431 1 23 13 322 44 142 34 431 1 23 431 322 142 23 44 1 13 34

1 2 3 4

SLIDE 11

Radix Sort

431 322 142 23 44 1 13 34

1 2 3 4

SLIDE 12

Radix Sort

142 431 322 23 44 1 13 34 44 23 322 34 431 1 13 142 431 322 142 23 44 1 13 34

1 2 3 4

SLIDE 13

Radix Sort

Non-comparative sorting algorithm
Needs Integer Keys
Linear Time Complexity O(n)
Highly dependent on key distribution

SLIDE 14

Insertion Sort

Average case O(n²)
Best case O(n) for sorted data
Good for small partitions

1 4 6 5 2 1 4 6 2 5 1 4 6 5 2 1 4 6 5 2 1 4 6 2 5 1 4 6 2 5 1 4 6 2 5 1 5 6 2 4 1 5 6 2 4 1 5 6 2 4 1 5 6 2 4 1 5 6 2 4 6 5 1 2 4 6 1 5 2 4 6 4 5 2 1 6 4 5 1 2 6 4 5 1 2

SLIDE 15

Sorting Networks

Like hardwired
Only appropriate for very small amount of data

1 2 3 4 5 6 7 1 2 3 4 5 6 7

Sorted Unsorted

SLIDE 16

Optimizing Algorithms

For a given Architecture

– Cache Size – Registers – Cache Line Size

Which Parameters to tune?

Empirical Search

Hardware

Optimized Algorithms Sorting Algorithms Parameters

SLIDE 17

Tuning Quicksort

Small partitions

– Insertion Sort – Sorting Networks

Threshold for small partitions
Apply immediately
r at the end

Small Partition

SLIDE 18

Tuning Radix sort (CC-radix sort)

Create sub-buckets if data is too large for cache
Apply radix sort for sub-buckets
Insertion sort / Sorting networks for small partitions

SLIDE 19

Tuning Multiway Merge sort

Number of subset p
Operation on heap: find smallest child

– Adapt fanout such that children fit into Cache Line Cache Line

Subset Subset Subset Subset

p subsets

SLIDE 20

Empirical Search

Hardware

Optimized Algorithms Sorting Algorithms Parameters

SLIDE 21

Comparison of Sorting Algorithms

1 2 3 4 5 6 7 8 9 5 10 15 20

Execution Time (G=2^30 Cycles) Number of Keys (M=2^20)

Intel PIII Xeon

Quicksort Radix sort Merge sort

SLIDE 22

Varied Standard Deviations

6.0E+08 6.5E+08 7.0E+08 7.5E+08 8.0E+08 8.5E+08 9.0E+08 9.5E+08 1.0E+09 1.1E+09 1.E+02 1.E+03 1.E+04 1.E+05 1.E+06 1.E+07 1.E+08 Execution Time (Cycles) Standard Deviation

Intel PIII Xeon (2M)

Quicksort Radix sort Merge sort

6.0E+08 6.5E+08 7.0E+08 7.5E+08 8.0E+08 8.5E+08 9.0E+08 9.5E+08 1.0E+09 1.1E+09 1.1E+09 1.E+02 1.E+03 1.E+04 1.E+05 1.E+06 1.E+07 1.E+08 Execution Time (Cycles) Standard Deviation

Intel PIII Xeon (12M)

Quicksort Radix sort Merge sort

SLIDE 23

Impact of Input Data

Number of keys does not affect the relative

performance

Standard deviation matters!

– Distribution among buckets in radix sort – Fewer operations on the heap in multiway merge sort

Problems with Standard deviation

– Only related to distribution of digit in keys – Expensive to compute – Use Entropy instead

SLIDE 24

Entropy

Expected value of the information

2 1 4 3 1 5 3 1 6

−𝑄𝑗 ∗ log2 𝑄𝑗

𝑗

0.9 1.58

Entropy vector

SLIDE 25

Empirical Search Machine Learning

Building the Library

Sorting Algorithms Parameters

Input data sets Quicksort Radix sort Merge sort Input sizes Entropy Prediction function Optimized Algorithms

SLIDE 26

Sorted data Best Sorting Algorithm

Select Algorithm

Prediction function Input size Entropy Input data

Runtime Procedure

SLIDE 27

Results

Library chooses best algorithm
Overhead of 5%
On average 44% better than worst algorithm

300 350 400 450 500 550 600 1.E+02 1.E+03 1.E+04 1.E+05 1.E+06 1.E+07 Execution Time (Cycles per key) Stadard Deviation

AMD Athlon

Quicksort Radix sort Merge sort Result

SLIDE 28

Final words

Optimizies Sorting Algorithms
Works well for unknown input
Overhead for known data
Unclear degree of Optimization
Hard-coded decisions
Further work: See next presentation
