solids solutions group solids solutions group

• More than the sum of its single companies

Competence of the group

• Founded 1969, decade-long experience in the development and

manufacturing of components for bulk solids handling as well as in the engineering and realisation of complete, automatic bulk handling systems

• Own Engineering capacity: Approximately 45 engineers for process

technology, design and production of machinery and components, technology, design and production of machinery and components, process automation, plant enginieering and construction as well as project management

• Own Manufacturing capacity: 5000m² workshop, 10t max. piece

weight, 200m³ silo in one piece max. dimension

• Direct manufacturer service with engineering services and after-sales

service

Group members

system-technik GmbH, Landsberg solids system-technik s.l., Zarauz/Spain engineering and realisation of automatic bulk handling systems S.S.T. Schüttguttechnik GmbH, Landsberg S.S.T. Schüttguttechnik GmbH, Landsberg group manufacturing company for machinery and components with direct manufacturer service solids components MIGSA s.l., Aizarnazabal/Spain Producer of the group´s standard equipment and components programme

Core competences

solids Pneumatic conveying systems solids Weighing- and metering- technology solids Complete silo installations solids Process automation solids Intralogistics for bulk solids

solids Pneumatic conveying systems

• Fly Pneu Classic dilute phase

conveying for suction- or pressure- conveying

• for every product and every task the

beneficial system conveying

• Fluid Pneu Dense phase pressure

conveying

• Step Pneu Push conveying systems

for powders and granulates

• Split Pneu Dense phase conveying

systems for demanding bulk solids

• Puls Pneu Low velocity conveying

systems for sensitive and abrasive products

• Vibro Puls Pneu Plug conveying

systems for cohesive, damp, sticky products and blends

• Vacu Fill Vaccum batch conveyor
• Vacu Fill Vaccum batch conveyor

systems for dusts, granulates and fibres

• Vacu Dense Vacuum plug conveying

systems for slow and gentle suction conveying

• Truck Discharge like Puls Pneu

with silo truck as pressure vessel

solids Weighing- / metering- technology

• Bin Scale and Flex Scale

Metering of batches

• Giro Scale Metering of small

components with PreciDos

• the complete programme for every accuracy

precision dosing equipments

• Diff Dos Continuous metering

with loss-in-weight scales

• Vacu Scale Vacuum scales

for the generation of large and small components batches

• Pressure Scale Conveyor for feeding blenders, reactors,

dissolving tanks etc. with weighed batches

solids Complete silo installations

• Core flow The well-priced silo beyond of

special conditions

• Mass flow Dimensioned and equipped

for „first in / first out“, residuelessly,

• individually projected and completely equipped

in steel, stainless steel, aluminium, GRP for

for „first in / first out“, residuelessly, discharge without segregation

• Piston flow Gentle filling and unloading

for susceptible to abrasion and pressure- sensitive products

• Blending silos Equipped with

fluidisation / fluidised bed bottom for the homogenisation and blending of bulk solids which can be aerated

solids Process automation

• PCP-Transport-processor for the

controling of pneumatic conveying systems

• user-friendly also for non-IT-specialists
• WDP-Metering-processor for the

controling of weighing / metering systems

• Vario-Batch-processor for the managing of recipes and

batch processes

• WinCC Visulisation for the demonstration of process

cycles

• PLC-systems for the controling of process cycles

solids Intralogistics for bulk solids

• non-interfaced integrated storage-, conveying

metering- and automation-systems The complete solution for your bulk solids, in the right your bulk solids, in the right batch, in the right time at the right place, in the process.

solids components

Machinery and components for

• Discharge
• Filling and Emptying
• Pneumatic Conveying
• Dosing and Weighing
• Crushing and Filtering

solids components

Discharge

• Vibration bin dischargers
• Aeration bottoms
• Aeration bottoms
• Aeration panels
• Agitators

Filling and Emptying

• Big-Bag-Filling devices
• Container-Filling devices

solids components

• Container-Filling devices
• Big-Bag-Dischargers
• Sack-Dischargers
• Big-Bag-/Sack-Dischargers

Pneumatic Conveying

Conveyors for pressure and vacuum

solids components

Rotary valves Blow through rotary valves Vacuum batch conveyors Vacu Fill Pneumatic conveyors

Dosing and Weighing

solids components

Hopper scale with dosing screw Rotating bowl scale Type GiroScale GSC Precision dosing equipment up to ± 1g accuracy

Multi-heads feeder up to 15 dosing heads, from1g per batch

solids components

solids Fine dosing

Micro feeder with highest accuracy up to 0,05g Linear powdering machine up to 2m width

Crushing and Filtering

• Coarse crushers
• Fine crushers

solids components

• Fine crushers
• Coarse- / Fine crusher-

combinations

• Fine crusher with sieve

• Assembling of installations
• After-Sales-Service

solids Direct manufacturer service

Our concept for your operating safety

• Inspection and maintenance
• Original spare parts service
• Repairs and modifications
• Around-the-clock service

system-technik GmbH Lechwiesenstraße 21 86899 Landsberg / Lech

• Tel. 08191 / 33 59 0

Since 40 years individual solutions for your bulk solids

• Tel. 08191 / 33 59 0

Fax 08191 / 33 59 22 Email: info@solids-systems.de

www.solids.de
