Solar AC Pump Controllers for Irrigation Prospe sper farmer, Prospe per India ABOUT US Green Life Solutions Pvt Ltd. is a concern dedicated to the promotion of renewable Energy propagation and Implementation in India. It is R&D effort


slide-1
SLIDE 1

Solar AC Pump Controllers for Irrigation

Prospe sper farmer, Prospe per India

slide-2
SLIDE 2

Solar AC Pump Controllers for Irrigation

Prospe sper farmer, Prospe per India

ABOUT US

Green Life Solutions Pvt Ltd. is a concern dedicated to the promotion of renewable Energy propagation and Implementation in India. It is R&D effort translate into better, more user friendly solutions a fact that has been appreciated by thousand of customers across India and the World. Green Life is having its own manufacturing setup for pump GREEN LIFE (GL) is one of the leading manufacture of high efficient Pump Controllers in central India. ‘Greenlife’ is continuously involved in R & D and experimentation to develop and

  • ffer green solutions to the society at large and serve the nation. As a result after

many years of rigorous experimentation GL has design “Grid-Connected Solar Pump Controllers“ from 1 HP to 20 HP. We are one of the Rate Contract (RC) Holder for solar products in Maharashtra in the name of Shrinath Engineering with Maharashtra Energy Development Authority (MEDA) and channel partner in MNRE off-Grid solar program. We are also registered with National Small Industries Corporation (NSIC) for procurement of solar products in Government.

slide-3
SLIDE 3

Solar AC Pump Controllers for Irrigation

Prospe sper farmer, Prospe per India

HOW SYSTEM WORKS

slide-4
SLIDE 4

Solar AC Pump Controllers for Irrigation

Prospe sper farmer, Prospe per India

CONTROLLER SPECIFICATIONS

1 HP PUMP CONTROLL ROLLER ER

SPECIFICATION MIN TYP MAX UNIT Input Voltage from PV 100 120 200 VDC Input Power 400 750 1000 W Motor Type Asynchronous / Induction / Synchronous motor Output Voltage – R / Y / B 100

  • 330

VAC Output Current Per Phase 1.5 A Output Frequency 18 to 50 Hz

slide-5
SLIDE 5

Prosper sper farmer mer, Prosper sper India ia

CONTROLLER SPECIFICATIONS

1 HP PUMP CONTROLL ROLLER ER – Other Features

PROTECTIONS OPERATIONAL MODE CONTROLS & SWITCHES LED / Visual Alarms in Front Panel DISPLAY REMOTE MONITORING (Optional) CONNECTORS COOLING METHOD ENVIRONMENTAL CONDITIONS ALTITUDE MECHANICAL

Input Low & High , Overload , Output Short , Any Output Phase Open Auto and Manual

Pump ON , Pump OFF, Water Force Adjustment Pump ON , Overload, Output Short, Phase Open 2 x 16 Character LCD Display SMS on preprogrammed mobile in local languages 2-Pin Plug-in connector for PV input, 3-Pin Plug-in/connector for AC 3-Phase Motor Force Air Cooling

  • Op. Temp: -20 to 60 ºC, Humidity: up to 95% RH

Maximum 11500 feet Cabinet Type : Outdoor, Wall Mounting Dimension : D=200, L=350, H=450 MM Weight : < 18 Kg

slide-6
SLIDE 6

Solar AC Pump Controllers for Irrigation

Prospe sper farmer, Prospe per India

CONTROLLER SPECIFICATIONS

2 HP to 25HP PUMP P CONTROLL ROLLER ER

SPECIFICATION MIN TYP MAX UNIT Input Voltage from PV 150 120 440 VDC Input Power 400 x HP 750 x HP 1000 x HP W Motor Type Asynchronous / Induction / Synchronous motor Output Voltage – R / Y / B 100

  • 330

VAC Output Current Per Phase 1.5 x HP A Output Frequency 18 to 50 Hz

slide-7
SLIDE 7

Prosper sper farmer mer, Prosper sper India ia

CONTROLLER SPECIFICATIONS

2 HP to 25HP PUMP P CONTROLL ROLLER ER – Other Features

PROTECTIONS OPERATIONAL MODE CONTROLS & SWITCHES LED / Visual Alarms in Front Panel DISPLAY REMOTE MONITORING (Optional) CONNECTORS COOLING METHOD ENVIRONMENTAL CONDITIONS ALTITUDE MECHANICAL

Input Low & High , Overload , Output Short , Any Output Phase Open Auto and Manual

Pump ON , Pump OFF, Water Force Adjustment Pump ON , Overload, Output Short, Phase Open 2 x 16 Character LCD Display SMS on preprogrammed mobile in local languages 2-Pin Plug-in connector for PV input, 3-Pin Plug-in/connector for AC 3-Phase Motor Force Air Cooling

  • Op. Temp: -20 to 60 ºC, Humidity: up to 95% RH

Maximum 11500 feet Cabinet Type : Outdoor, Wall Mounting Dimension : D=200, L=350, H=450 MM Weight : < 18 Kg

slide-8
SLIDE 8

Solar AC Pump Controllers for Irrigation

Prospe sper farmer, Prospe per India

THANKS

Lets lights up those life who really need for it.

Green Life Solutions Pvt. Ltd.

F-2, Prince Complex, Chattrapati Sq, Wardha Rd., Nagpur- 440015, Email :- info@greenlifesolution.in Tel: +91 712 2289548, +91 9225664282
