Programming tiny devices

You would like to have:

structured programs with multiple concurrent threads good responsiveness to events (some applications pose RT requirements) readable, reusable code

Programming tiny devices

So what is the problem? Practically, the only problem is multithreading, i.e., keeping track of multiple concurrent activities This is because normally such activities require a considerable amount of RAM for their stacks

Thread =

code data stack

x N

constant, in flash, shared, not a problem global, shared, determined by the application, not by the program structure per thread, implied by program structure, needed to provide save area for context switch, wasted from the viewpoint of the application

Allocating stack to threads …

… results in nasty memory fragmentation:

threads can be preempted every which way you never know when a thread will be preempted, so you have to allocate to it the maximum amount of stack it may ever need

Note that interrupts fare better

… because they use the stack in order

this one will not receive control until this one is gone

… so they can reasonably share the same stack

TinyOS

This is one popular operating system for devices with very little RAM; here’s its approach to multithreading: Well, there isn’t any: what they call “tasks” are chunks of code executed back to back (not co-existing) All the truly fine parts of the program are implemented as interrupt service routines

In our OS, dubbed PicOS, …

… there are threads, but their preemption mechanism is restrictive: A thread can only lose the CPU at a moment when it has given up the stack

In TinyOS:

A lot of finesse (“multithreading”), causes stack containment problems Too little finesse may make the program respond poorly to events This is because the interrupt stack is the critical place for implementing all concurrency in the system The moral: the stack provides a poor way of saving thread context for preemption

Reactive thread model in PicOS:

Wait for events Wake up Declare events Do things

thread = FSM

state ...

... ... ... ... ...

state state state

PicOS thread (strand) example:

strand (sniffer, sess_t) char c; entry (RC_TRY) data->packet = tcv_rnp (RC_TRY, efd); data->length = tcv_left (packet); entry (RC_PASS) if (data->user != US_READY) { wait (&data->user, RC_PASS); delay (1000, RC_LOCKED); release; } c = 1; ... ... entry (RC_ENP) tcv_endp (data->packet); signal (&data->packet); proceed (RC_TRY); endstrand

Two types of threads:

thread has no private (differentiating) data; usually, a thread exists in a single copy at a time

thread (name)

strand has a private data pointer (representing its specific data structure)

strand (name, data_pointer_type)

Co-existing threads:

State B0 State B1 State B2 State B3 State A0 State A1 State A2 State A3 State A4

Hitting the end of a state amounts to a temporary “return” from the thread’s code

IPC

thread (coordinator) entry (MN_START) mon = runthread (monitor); for (int i = 0; i < NP; i++) { runstrand (consumer, bufptr [i]); runstrand (producer, bufptr [i]); } entry (MN_WAIT) if (!running (consumer) || !running (producer)) { killall (producer); killall (consumer); ptrigger (mon, 0); finish; } joinall (consumer, MN_WAIT); joinall (producer, MN_WAIT); endthread

Flowcharts

thread (hrate) address packet; entry (HR_INIT) delay (3 * 1024, HR_SEND); release; entry (HR_SEND) if ((HeartRate = hrc_get ()) > 255) HeartRate = 255; if (XWS == 0) { // Don't do this if a sample is being sent packet = tcv_wnp (HR_SEND, BSFD, 2); put1 (packet, PT_HRATE); put1 (packet, HeartRate); tcv_endp (packet); } proceed (HR_INIT); endthread INIT

3 sec

SEND calculate HR XWS? yes get xmt buffer send HR no

Layer-less I/O programming

VNETI A P I P H Y P L U G I N S Application Device NULL plug-in TARP plug-in … Device . . .

• pen-ended

Plugin structure

typedef struct { int (*tcv_ope) (int, int, ...); int (*tcv_clo) (int, int); int (*tcv_rcv) (int, address, int, int*, tcvadp_t*); int (*tcv_frm) (address, int, tcvadp_t*); int (*tcv_out) (address); int (*tcv_xmt) (address); int (*tcv_tmt) (address); int tcv_info; } tcvplug_t;

how to open a session how to close a session preprocessing upon reception application packet boundary preprocessing for output after packet transmission

• n timeout

Praxis view

Open a session, specifying the PHY and the Plug-in:

SFD = tcv_open (RS_RETRY, 1, 2);

Use the session ID for receiving and sending packets:

packet = tcv_rnp (RS_RDP, SFD); ... tcv_endp (packet); packet = tcv_wnp (RS_WRP, SFD, length); ... tcv_endp (packet);

VNETI

Implements a tagged pool of packet buffers Packets can be queued at sessions (for reception by the praxis) Packets can be queued at PHYs for dispatching to the device Plug-in functions can manipulate those packets by returning disposition codes They can also modify their contents and determine header boundaries

Plug-ins tell VNETI what to do with their packets

int tcv_out_oep (address pbuff) { ... return TCV_DSP_XMT; ... return TCV_DSP_DROP; ... } int tcv_rcv_oep (int phy, address rawp, int len, int *ses, tcvadp_t *bounds) { if (not_ours (rawp)) return TCV_DSP_PASS; ... *ses = ...; bounds->head = ...; bounds->tail = ...; return TCV_DSP_RCV; }

System layout

VUEE (or VUE2): virtual execution

This part can be re-compiled and executed in a virtual environment called VUEE (Virtual Underlay Execution Engine)

This means that …

… you can emulate a whole network of nodes

possibly running a multiplicity of praxes

in a way practically indistinguishable from a realistic execution In particular, any programs (OSS) developed to communicate with the nodes, can easily be fooled to talk to the model instead

How it works

SMURPH VUEE library PicOS code … PicOS code PicOS code wrapper

+

data set Internet IF agent … UART node 10 OSSI program

Real time aspects of PicOS

Criticism: limited preemptibility of threads gets in the way of RT response First note that interrupts are handled

• utside of threads

wait for event handle event thread retrieve data (into a buffer) trigger event (wake the thread) interrupt scheduler

Reducing the granularity of states

... entry (RCV_READ) do { Pkt = tcv_rnp (RCV_READ, Ses); update (Pkt [SensorValue]); tcv_endp (Pkt); } while (Pkt [MsgType != MSG_LAST); ... ... entry (RCV_READ) Pkt = tcv_rnp (RCV_READ, Ses); update (Pkt [SensorValue]); tcv_endp (Pkt); if (Pkt [MsgType != MSG_LAST) proceed (RCV_READ); ...

Event polling

... entry (RCV_READ) while (MoreToDo) { lots_of_work (...); } ... ... entry (RCV_READ) while (MoreToDo) { if (ImportantEventPending) proceed (RCV_READ); lots_of_work (...); } ... allows the scheduler to run more important threads
