1 SmartGrid Implications of Cloud Computing New Technology in the Utility Environment PG&E Territory Characteristics 70,000 square miles of diverse topography Approximately 20,000 employees Energy Services to approximately 15


slide-1
SLIDE 1

1

SmartGrid

Implications of Cloud Computing

New Technology in the Utility Environment

slide-2
SLIDE 2

2

PG&E

  • 70,000 square miles of diverse topography
  • Approximately 20,000 employees
  • Energy Services to approximately 15 million

people

  • Over 9 million SmartMeters (Electric & Gas)
  • 1,008,186 Transformers
  • 6,833 MW of Generation
  • 18,616 miles of electric transmission circuits
  • 120,000 miles of electric distribution circuits
  • Regulated by the California Public Utilities

Commission (CPUC)

Territory Characteristics

slide-3
SLIDE 3

3

Vendor Hosted Electric Head End System

Utility Application Landscape Hosted off site today

  • SmartMeter Systems
  • Demand Response

CAISO

Hosted PG&E Data Center

Gas Head End Meter Data Management

Customer

The Cloud – Data at Rest

slide-4
SLIDE 4

4

Security – Risk Management

PG&E utilizes the following five information classifications:

  • PG&E Public

Anything produced for public review and available to anyone inside or outside the

  • company. This includes materials such as press releases, advertisements, or bill inserts.
  • PG&E Internal

Information intended primarily for use within PG&E, such as organization charts,

personnel numbers, and company email messages. Distribution should be limited based

  • n business need to know, and access controls are required.
  • PG&E Confidential

Information such as trade secrets, customer or employee information, and passwords that should be shared solely on a business need to know basis. PG&E Confidential data must be encrypted for storage and transmission if electronic and, if printed, protected through controlled physical access, such as a locked filing cabinet.

  • PG&E Restricted or PG&E Privileged (Law only)

Information such as Social Security Numbers, undisclosed financial information, and protected health information should be shared solely on a business need to know basis. Data must be for storage and transmission encrypted if electronic and, if printed, protected through controlled physical access. Note that PG&E Privileged is only used by Law.

slide-5
SLIDE 5

5

Networks - Critical Infrastructure

ODN (air-gapped secure network) - SCADA UDN – Traditional IT MPLS – Physical Isolation and Connectivity

Operational Data Network Utility Data Network

Multiprotocol Label Switching – Packet Level Network Path

slide-6
SLIDE 6

6

Volt / VAR on the test network

Test Network

UDN

ODN

UPS #1 Set Voltage 2 Set Voltage 3 Set Voltage 1

LabView Interface

LabView Driver

Access Point UIQ System CVR Software Load Tap Changer Line Regulator Line Capacitor

Read Voltage Adjust Voltage

Node Simulator 4.1

LabView Driver TCP/IP

Meter Farm

Remote Access Firewall

Negotiating Network Access in the test environment is not trivial

slide-7
SLIDE 7

7

Security is Physical

Control of assets is critical to our business:

  • San Jose Mercury News

June 4th, 2013

In the early-morning hours of April 16, someone opened fire at the utility's substation on Metcalf Road near Highway 101. The gunshots damaged five transformers and caused cooling oil to leak from a transformer bank, and the damage prompted state regulators to urge electricity conservation in the ensuing days. AT&T phone service in the area was also affected.

slide-8
SLIDE 8

8

The Cloud

SmartMeter™ Performance Statistics

Interval data supplied from SmartMeter™ systems for billing within 48 hours of expected delivery as a percentage

  • f expected interval data.

Safety and Reliability

slide-9
SLIDE 9

9

Thank you

Art Anderson arthur.anderson@pge.com

slide-10
SLIDE 10

10

North American Electric Reliability Corporation

Critical Infrastructure Protection (CIP) standards

Version 5 now requires the following:

  • Encryption
  • Role-based instead of risk-based classifications
  • Multiple levels of compliance – Low, Medium and High Impact (in theory, a company could

have 10 facilities of which six are low impact facilities, three are medium impact facilities, and

  • ne is a high impact facility)
  • New terminology (such as BES Cyber Asset)
  • All serial connections are to be considered
  • Multi-factor authentication requirements
  • Triggers are required to be defined for recovery plans
  • All software (COTS and custom) must be known
  • All security patches from the beginning of time on each device must be known
