SLIDE 1
Sketch, design, implement and document via a portfolio an animated touch-based and a sensor-based interface for a mobile phone that is an alternative to “slide to unlock”.
Smart Phone Interaction Sketch, design, implement and document via - - PowerPoint PPT Presentation
Smart Phone Interaction Sketch, design, implement and document via - - PowerPoint PPT Presentation
Project One Smart Phone Interaction Sketch, design, implement and document via a portfolio an animated touch-based and a sensor-based interface for a mobile phone that is an alternative to slide to unlock. Goal Create 2 prototypes to
SLIDE 2
SLIDE 3
Goal
Create 2 prototypes to demonstrate a method for unlocking a phone:
One using touch screen interface One using other device sensors
Constraints:
Apple’ s “slide to unlock” patent Avoid copying Windows/Android designs too
SLIDE 4
Methodology
SLIDE 5
However…
Don’ t neglect the first phases of the design process! Empathize:
Think about it in the context of your needs Ask friends/family if you find it helpful
Define:
What does it mean to “unlock” a phone?
SLIDE 6
Materials
Nokia Lumia 520 or your own device Standard sensors:
ambient light accelerometer proximity camera (back) microphone
SLIDE 7
Constraints
Requirement:
Do not infringe US Patent 8046721 B2 (Apple’ s “slide to unlock”)
Recommend to avoid:
Google’ s various schemes for Android OS Nokia’ s “double tap” to wake
SLIDE 8
US.
Patent
Device 400 Device 400
- Oct. 25, 2011
Sheet 5 0f 15 Touch Screen 408 502 Touch Screen 408
4
O4 \
L4
02
Movement 502 504 Menu
Button 410
US
8,046,721 B2
Figure 5A Figure 5B
US.
Patent
Device 400 Device 400
- Oct. 25, 2011
Sheet 5 0f 15 Touch Screen 408 502 Touch Screen 408
4
O4 \
L4
02
Movement 502 504 Menu
Button 410
US
8,046,721 B2
Figure 5A Figure 5B
(12) United
States Patent
Chaudhri
et a].
US008046721B2
US
8,046,721 B2
*Oct. 25, 2011
(10) Patent
N0.:
(45) Date
- f
Patent:
(54) (75) (73) (21) (22) (65) (63) (51) (52) (58)
UNLOCKING A
DEVICE
BY PERFORMING GESTURES
ON AN UNLOCK
Inventors: Imran
Chaudhri, San
Francisco, CA
(US); Bas
Ording, San
Francisco, CA (US); Freddy
Allen Anzures, San
Francisco, CA (US); Marcel
Van
Os,
San
Francisco, CA (US); Stephen
O.
Lemay,
San
Francisco, CA (US); Scott Forstall, Mountain
View, CA (US);
Greg
Christie, San Jose, CA
(US) Assignee: Apple
Inc., Cupertino, CA
(US)
Notice: Subject
to any
disclaimer, the
term
- f
this
patent is extended or adjusted under 35
U.S.C. 154(b) by
days.
This patent is subject to a terminal dis
claimer.
Appl. No.: 12/477,075
Filed:
Jun.
2, 2009
Prior Publication
Data
US
2009/0241072
A1
- Sep. 24, 2009
Related
US.
Application
Data
Continuation of
application No. 11/322,549, ?led on
- Dec. 23, 2005, noW
- Pat. No. 7,657,849.
- Int. Cl.
G06F
3/033 (2006.01) US.
- Cl. .......................
.. 715/863; 345/173; 345/179
Field of Classi?cation Search ................
.. 715/154,
715/863; 345/156
See
application ?le for complete search
history. (56)
References Cited
U.S. PATENT
DOCUMENTS
5,465,084 A 11/1995 Cottrell ..................
.. 340/825.31
5,559,961 A 9/1996 Blonder .................
.. 395/18801
5,677,710 A 10/1997 Thompson-Rohrlich 345/173
5,821,933 A 10/1998 Keller
et al.
.........
..
345/348
5,907,327 A 5/1999 Ogura
et a1.
345/339
6,151,208 A 11/2000 Bartlett .....
..
361/683
6,160,555 A 12/2000 Kang
et a1. ..
345/358
6,192,478 B1 2/2001 Elledge .....
..
713/202 6,249,606 B1 6/2001 Kiraly
et a1. ................ .. 382/195
(Continued) FOREIGN PATENT
DOCUMENTS
EP
1 284
450 A2
2/2003
(Continued)
OTHER
PUBLICATIONS
IBM,
“Access/ Control Icons (Icon Keys),”
IBM
Technical Disclosure
Bulletin, V0. 38, No.
4, Apr. 1995.
(Continued)
Primary Examiner
*
Boris Pesin Assistant
Examiner
*
Andres
E
Gutierrez
(74) Attorney, Agent, or
Firm * Morgan, LeWis & Bockius
LLP
(57)
ABSTRACT
A
device With a
touch-sensitive display may
be unlocked
via gestures
performed
- n
the touch-sensitive
display.
The
device
is unlocked
if
contact
With
the display corresponds to a pre
de?ned
gesture for
unlocking
the
- device. The
device displays
- ne or more
unlock images With respect to Which
the pre
de?ned gesture is to be performed in order to unlock the
- device. The performance of the prede?ned gesture With
respect
to the unlock
may
include
moving
the unlock
image to a prede?ned location and/or moving the unlock
along
a prede?ned
- path. The
device may
also display
visual cues of the prede?ned gesture on the touch screen
to
remind
a user
- f
the
gesture.
15 Claims, 15 Drawing Sheets
Device
400 404 Touch Screen 408
Movement
504
Button 410
Menu
SLIDE 9
Interpretation
What actually constitutes infringement? Let’ s look at some examples…
SLIDE 10
SLIDE 11
SLIDE 12
SLIDE 13
SLIDE 14
Bottom Line
Infringement is not black or white:
In the real world, companies pay huge $$$ for lawyers to duke it out I am not a patent lawyer, so I will not be a stickler about details
In this project, original ideas will score better in the evaluation
SLIDE 15
