Supporting the Defense industry to improve troop readiness & Survivability Small Business Supplier 350,000 Sq. ft. Of Manufacturing Over 400 skilled employees Over 100 Stamping Presses 75 CNC Machines 30 Laser Cutting Systems 3 and 5 Axis

slide-1
SLIDE 1

Supporting the Defense industry to improve troop readiness & Survivability Welded Assemblies * Stampings * Castings * Injection Molding * Precision Machining

Small Business Supplier

350,000 Sq. ft. Of Manufacturing Over 400 skilled employees Over 100 Stamping Presses 75 CNC Machines 30 Laser Cutting Systems 3 and 5 Axis 20 robotic Weld arms, 42 Manual weld stations MIG, TIG, and Laser Welding 15 Injection Mold Presses

Up-Armoring Kit Manufacturing Rapid Response & Emergency Manufacturing

slide-2
SLIDE 2

Rapid response supplier of prototype & low volume production Driven to provide solutions to your manufacturing problems Available 24-7 to help protect our service men & women

Determined to be a leader in providing our Service Men & Women with the necessary equipment, tools, and protection in helping keep America safe.

Mission:

slide-3
SLIDE 3

 Founded in 1992  privately owned small business  4 locations : Headquartered in Rochester Hills, MI

Total operation is over 350,000 Square feet

 Employ over 400 skilled employees  Known for our ability to react to all situations

About 3-Dimensional

slide-4
SLIDE 4

Our Expertise

  • Prototype and short run production for metal

stampings, welded assemblies, plastic injection molding, castings, and high precision cnc machining

  • Urgent Requests And Quick Turn Around Projects
  • Around The Clock Service 24/7
  • Equipment & Technical Expertise
  • Experience and ability to get the job done right and on time
slide-5
SLIDE 5

Maxx-Pro

1: Design and manufacture of Mine-Roller interface assembly

47 Part Numbers, all components and assembly done in-house Processes used: Laser Cutting, machining, CNC Lathe turning, Robotic & Manual MIG Welding, CARC Painted

2: Supplied Kinematic door components

65 Part Numbers, all components done in-house Processes used: Laser Cutting, Water Jet Cutting, Precision Machining, CNC Lathe turning, Robotic & Manual MIG Welding, Rust Protective Plating

slide-6
SLIDE 6

Robotic Weld In Process Completed Assembly

35 detail components manufactured & assembled : First production assemblies shipped in 30 days : Total order qty of 230 Assemblies completed to date

Front Interface- RG31, Cougar & Stryker

slide-7
SLIDE 7

Cougar

1: Design and manufacture of Mine-Roller interface assembly

42 Part Numbers, all components and assembly done in-house Processes used: Laser Cutting, machining, CNC Lathe turning, Robotic & Manual Welding

slide-8
SLIDE 8

Urgent requirement 200 individual components manufactured & assembled : First production assemblies shipped in 30 days.

Hyex assembly

slide-9
SLIDE 9

In Process Weld Completed Assembly

Atec assembly

Urgent requirement 200 individual components manufactured & assembled : First production assemblies shipped in 30 days.

slide-10
SLIDE 10

Hyex and Atec Cabs

slide-11
SLIDE 11

Cheetah

1: manufacture and assembly of door frames and skins

80 Part Numbers, all components manufactured in-house Processes used: Laser Cutting, press brake, machining, CNC Lathe turning, manual welding

slide-12
SLIDE 12

Emergency retrofit for vehicles : 100 individual components manufactured & assembled : First production assemblies shipped in 30 days.

M939 Weapons Station

slide-13
SLIDE 13

Aluminum Night Vision Housing High Precision CNC Machining

slide-14
SLIDE 14

Full truck frame

Stamping, Laser Cutting, Robotic Welding: 200 part numbers

slide-15
SLIDE 15

Banjo Axle Assembly

Stampings, Castings, Robotic Welding, Machining

slide-16
SLIDE 16

Banjo Axle Assembly

Stampings, Castings, Robotic Welding, Machining

slide-17
SLIDE 17

Chassis Assemblies

40-50 Components : 4-6 week delivery

slide-18
SLIDE 18

Seating Assemblies

Structures and Mechanisms

slide-19
SLIDE 19

(21) 5-Axis Lasers ( 9 ) 3-Axis Lasers

Laser Cutting

slide-20
SLIDE 20

CNC Machining

75 CNC machines : up to 1

1’ x 17’ Travel

slide-21
SLIDE 21

Machined Castings

All high precision machining done in-house

slide-22
SLIDE 22

High Definition Stampings

Up to 7000 ton presses

slide-23
SLIDE 23

CNC Tube Bending

slide-24
SLIDE 24

High Pressure Hydroforming

slide-25
SLIDE 25

Robotic welding

20 robotic weld arms

slide-26
SLIDE 26

Frame / module assembly 2 Gantry weld systems

slide-27
SLIDE 27

Quality Control and fixtures

slide-28
SLIDE 28

Intake and exhaust louver weld assy

Aluminum welded assembly for aircraft program

slide-29
SLIDE 29

In-House Capability

  • Tooling Design and Manufacturing
  • CNC Machining
  • 3-Axis Laser Cutting
  • 5-Axis Laser Cutting
  • Metal Stamping
  • CNC Tube Bending
  • Hydroforming
  • Production Intent Robotic MIG Welding
  • Spot Welding
  • Injection Molding
  • Patterns and Castings
  • Wire EDM
