Slips and falls Better information, fewer accidents Food and Drink - - PowerPoint PPT Presentation
Slips and falls Better information, fewer accidents Food and Drink - - PowerPoint PPT Presentation
Slips and falls Better information, fewer accidents Food and Drink Federation May 2012 Steve Thorpe Health and Safety Laboratory steve.thorpe@hsl.gov.uk 1 Slips and falls Use risk assessment Do them first ! 2 Slip Potential Model
SLIDE 2
SLIDE 3
3
Floor Environment Slip / Trip Potential Contamination Obstacles People Footwear
Cleaning
Slip Potential Model
SLIDE 4
4
CoF Test Methods
Pendulum CoF test Imitate heel impact Produce correct fluid dynamics Realistic CoF measurement wet and dry HSE/HSL preferred method BS 7976:2002 & UKSRG Guidelines
SLIDE 5
5
The Ramp Test
DIN 51130
Shod test on motor oil Reported as R9, R10, R11, R12, R13
HSL / UKSRG Ramp Method
Slider 96 potable water Bespoke combinations Reported as CoF
SLIDE 6
6
Surface Microroughness
Range of instruments Quick easy on site measurement Indicator, monitor Used by SAT, risk assessment process Good on profiles, stairs and steps
SLIDE 7
7
Profiles?
Don’t necessarily improve slip resistance Characterise with pendulum and microroughness Wear / change quickly Lots of slips! Food sector, vehicles
SLIDE 8
8
Profiled surfaces
SLIDE 9
9
Cleaning
Correct detergent Concentration very important Contact time most important Solution must be removed Rinse with clean water Mops only effective on smooth floors
SLIDE 10
10
Cleaning
Residual coverage following floor cleaning (Field conditions vs. Two-steps at 24° C)
20 40 60 80 100
K 3 ( . 7 , 7 2 ) K 1 6 ( . 5 , 3 6 ) L I F T ( . 3 3 , 5 2 ) F L A S H ( . 1 7 , 3 3 ) F L A S H ( . 2 , 1 5 ) F L A S H ( . 5 1 , 5 8 ) D A S H ( 1 . 2 2 , 2 2 ) H S D C ( . 1 1 , 1 ) U L T R A ( . 1 , 1 9 ) O X Y G E L ( . 1 1 , 5 4 )
RC (%)
Field (FQT, DM at C and T) Optimal (FQT, 2SM at Rec. And 24° C)
Residual Contamination (RC)
As Found Improved Regime
www.irsst.qc.ca
SLIDE 11
11
Roving cleaner
SLIDE 12
12
Effective control of spills?
SLIDE 13
13
Footwear - Over 50 types tested Some examples
SLIDE 14
14
Footwear
Effective footwear available What does safety footwear mean? Thresholds in EN? HSL Ramp method is a valid test Trial a range of footwear in workplace Use peer group information Involve staff, comfort, fit e mail HSE/HSL for specific advice Footwear costs less than accidents
SLIDE 15
15
Sample Claim HSL ramp wet CoF Safety Boot (toe midsole) No 0.37 Safety Boot (toe midsole) No 0.37 Safety Boot (toe midsole) No 0.36 Wellington (toe midsole) Yes 0.25 Boot (toe) Yes 0.18 Clogs Yes 0.15
Slip resistant footwear?
SLIDE 16
16
Steps and Stairs
Dimensions – consistency, rise and going Shape of nosing Position of nosing strip Visibility of nosing strip Slip resistance of nosing strip Handrails – position, shape Lighting BS5395
SLIDE 17
17
Wear Need maintenance
Steps and Stairs
SLIDE 18
18
Steps on vehicles
Step Dimensions: 1st Step 340 – 530mm 4 of 48 Cabs consistent
330mm 340mm 330mm
SLIDE 19
19
Shattered Lives Campaign
www.hse.gov.uk/slips/shatteredlives.htm Phase 1 from Sept 2008 Phase 2 from Feb 2009 Phase 3 from Feb 2010 resources/posters on website industry sectors
Food and drink manufacturing Food retail Construction Building and plant maintenance Catering and hospitality Health Education
SLIDE 20
20
STEP tool
www.hse.gov.uk/slips/step/index.htm
SLIDE 21
21
Some food sector examples Case studies Some successes !
SLIDE 22
22
Abattoir
Year
- No. of slips
- No. of claims
Cost £ 1 102 24 207,800 2 84 21 157,137 3 51 15 136,000
SLIDE 23
23
How was this achieved?
HSE Guidance, UKSRG Guidelines Clear floor specification, new areas and repairs, Matched footwear to floor, contamination Monitor wear Reviewed cleaning regimes Rolling programme to remove chequer plate Yield monitoring, link to staff bonus
SLIDE 24
24
Meat processing
New factory built 2001 Epoxy floor, rough texture PTV 48 wet (manufacturers) low slip potential. HSL (on site) confirm low slip potential maintained. Deep cleaning issues identified during HSL visit.
SLIDE 25
25
HSL Pendulum data
Area Wet, as found Wet, cleaned Low traffic 39 50 Boning line 35 46 Cutting line 21 40 Cleaning very important!
SLIDE 26
26
Sausage factory
Slips costing £2500+ per month Company considering new floor Inspector not convinced Gross contamination Poor cleaning Poor footwear
SLIDE 27
27
Sausage factory
Changes to cleaning regime Improved footwear Changed system of work Floor now OK Slips cost less than £300 pm
SLIDE 28
28
Some generic examples Case studies Successes !
SLIDE 29
29
Flooring: Office entrance
Floor slippery on wet days Procured slip-resistant floor following HSE guidelines Larger entrance matting Looks good Easy to maintain NO SLIPS
SLIDE 30
30
Footwear: food processing factory
Many slips despite safety boots 6 month trial – new footwear No slip accidents £12,000 saved Now adopted for all workers NO SLIPS IN 5 YEARS
SLIDE 31
31
Footwear: local authority kitchen
450 kitchens – 1500 workers 317 slipping accidents in 4 years Trial new footwear no slips Slip resistant overshoes provided for all Or can buy trainers at subsidised price BIG REDUCTION IN ACCIDENTS
SLIDE 32
32
Cleaning: NHS Trust
Lots of slips after cleaning Consulted cleaners and nurses Changed to microfibre mops (same cost) Quicker BIG REDUCTION IN ACCIDENTS
SLIDE 33
33
Flooring + cleaning + footwear Fast food chain
Flooring New ceramic safety tile Cleaning Double mopping to clear grease Footwear Trial slip resistant footwear Now adopted
75% REDUCTION IN ACCIDENTS
SLIDE 34
34
Support, help and share your ideas
www.hse.gov.uk/slips/ Information, Guidance, Research reports, FAQs, Case studies
Result fewer accidents, lower costs all facilitated by better information
