SIPs: An Engineers Perspective Tom Moore, PE Principal at Pinnacle Engineering, Inc SIPA Board of Directors, Chair of Education Committee, on Technical Committee Wood & SIP Committee of ASTM SIP B SIP BASICS: WHA ASICS: WHAT ARE SIPS?

slide-1
SLIDE 1

SIPs: An Engineer’s Perspective

Tom Moore, PE Principal at Pinnacle Engineering, Inc SIPA Board of Directors, Chair of Education Committee, on Technical Committee Wood & SIP Committee of ASTM

slide-2
SLIDE 2

SIP B SIP BASICS: WHA ASICS: WHAT ARE SIPS? T ARE SIPS?

  • SIP = Structural

Insulated Panel

  • Composite structural panel
  • Rigid foam core - EPS, XPS,
  • r polyurethane
  • Structural facings - usually

7/16” OSB

  • Structural adhesive
slide-3
SLIDE 3

Rigid Foam Insulation Structural Facings Structural Adhesive Optional Electrical Chase

WHA WHAT AR T ARE E SIP SIPS? S?

slide-4
SLIDE 4

Insulated metal wall panels

TYPE TYPES S OF SIPS? OF SIPS?

slide-5
SLIDE 5

Also available with cementitious skins – cement board, MgO board Resistant to fire, mold, mildew

TYPE TYPES S OF SIPS? OF SIPS?

slide-6
SLIDE 6

SIP B SIP BASICS: DET ASICS: DETAILS AILS

Panel joints are designed to reduce thermal bridging where structurally possible and sealed to reduce air infiltration

slide-7
SLIDE 7

SIP B SIP BASICS: DET ASICS: DETAILS AILS

⚫

SIP screws go through the panels, into structure

⚫

Wood screw point for wood

⚫

Light drill point for metal/light gauge

⚫

Heavy drill point for steel/iron up to ¼” thick

slide-8
SLIDE 8

SIP B SIP BASICS: DET ASICS: DETAILS AILS

slide-9
SLIDE 9

SIP B SIP BASICS: DET ASICS: DETAILS AILS

slide-10
SLIDE 10
  • A structural engineer with knowledge of SIP applications should

be a part of the design process for any SIP structures

  • Prevent the overdesign of the structural system, reduce costs,

and meet code minimums

  • Consult manufacturer

code report and load charts for engineering information (www.sips.org)

ENG NGIN INEERI RING NG MET METHO HODS DS

slide-11
SLIDE 11

SIP ENGINEER vs. EOR ENG NGIN INEERI RING NG MET METHO HODS DS

Structure Magazine Feb 2013

slide-12
SLIDE 12

ENG NGIN INEERI RING NG MET METHO HODS DS

  • Sample manufacturer

load chart from code report

  • Loads are calculated per

Chapter 16 of the IBC

  • 2x4 studs @ 16”oc =

1600plf at 8’-0” tall

  • 2x6 studs @ 16”oc =

2600plf up to 12’ tall

  • 4.5” SIP = 3600plf at 8’-0”

tall

slide-13
SLIDE 13
  • Load charts vary by spline

type and load type

  • This is a block spline and

surface spline chart

  • Other spline types include

I-joist, LVL, and 2x lumber

  • 2x10 rafters @ 24”oc max

span = 14’-8” for 35psf (#2SYP)

  • 10.25” SIP max span for

35psf = 15’-0” (superimposed)

ENG NGIN INEERI RING NG MET METHO HODS DS

slide-14
SLIDE 14

ENG NGIN INEERI RING NG MET METHO HODS DS

Shear wall components

  • OSB skins nailed to lumber

at edges and splines at interior joints – similar to typical wood stud shear wall

  • Standard SIP shear wall = 380plf
  • Wood stud shear wall = 260plf
  • 380plf with 4”oc edge nailing
slide-15
SLIDE 15
  • Shear wall strap diagrams
  • Hold down anchors at the ends of shear walls
  • Shear plate anchor bolts must resist shear load

ENG NGIN INEERI RING NG MET METHO HODS DS

slide-16
SLIDE 16

ENG NGIN INEERI RING NG MET METHO HODS DS

  • Shear wall values are

available to cover all seismic design categories

  • Diaphragm values for wind

design for SIP roof panels should be available from the manufacturer

  • Like all shear walls and

diaphragms, chord forces are

  • critical. Straps can help

transfer these forces across joints in the edge lumber

slide-17
SLIDE 17

ENG NGIN INEERI RING NG MET METHO HODS DS

  • Openings with heavy loads may

require structural header

  • Some openings possible with

SIP acting as header; consult engineer or manufacturer

slide-18
SLIDE 18
  • SIP Screws connect panels to each other and to supporting

structure – resisting loads through tension and shear

ENG NGIN INEERI RING NG MET METHO HODS DS

slide-19
SLIDE 19

SIP ST IP STAN ANDAR ARDS DS

slide-20
SLIDE 20

SIP ST IP STAN ANDAR ARDS DS

slide-21
SLIDE 21

SIP ST IP STAN ANDAR ARDS DS

slide-22
SLIDE 22

SIP ST IP STAN ANDAR ARDS DS

slide-23
SLIDE 23

SHOP DR HOP DRAWINGS WINGS

slide-24
SLIDE 24

SHOP DR HOP DRAWINGS WINGS

slide-25
SLIDE 25

SHOP DR HOP DRAWINGS WINGS

slide-26
SLIDE 26

SHOP DR HOP DRAWINGS WINGS

slide-27
SLIDE 27

SHOP DR HOP DRAWINGS WINGS

slide-28
SLIDE 28

SHOP DR HOP DRAWINGS WINGS

slide-29
SLIDE 29

SHOP DR HOP DRAWINGS WINGS

slide-30
SLIDE 30

Beyond combining SIPs with wood framing, other structural systems can be combined with SIPs to increase heights and spans in a building: ▪ Metal framing ▪ Structural steel ▪ Pre-engineered buildings ▪ Timber framing ▪ Glu-Lams

STRUC UCTUR URAL AL SIP IP HY HYBR BRIDS IDS

slide-31
SLIDE 31

Hybrid systems: SIPs with metal framing

Buffalo University Day Care Buffalo, New York Kideney Architects

STRUC UCTUR URAL AL SIP IP HY HYBR BRIDS IDS

slide-32
SLIDE 32

Hybrid systems: bar joists and structural steel with SIPs

STRUC UCTUR URAL AL SIP IP HY HYBR BRIDS IDS

Silvis Middle School, East Moline, IL

slide-33
SLIDE 33

Hybrid systems: bar joists and structural steel with SIPs

STRUC UCTUR URAL AL SIP IP HY HYBR BRIDS IDS

Silvis Middle School, East Moline, IL

slide-34
SLIDE 34

Pre-engineered building with SIPs

STRUC UCTUR URAL AL SIP IP HY HYBR BRIDS IDS

SIPs manufacturing plant, Cottonwood, MN

slide-35
SLIDE 35

SIPs and timber framing

STRUC UCTUR URAL AL SIP IP HY HYBR BRIDS IDS

Darien Nature Center, Darien, CT

slide-36
SLIDE 36

SIPs and timber framing

STRUC UCTUR URAL AL SIP IP HY HYBR BRIDS IDS

Washington Fruit & Produce Corporate Office, Yakima, WA

10” SIPs roof panels covering 14,900 square feet of conditioned space, achieving R-values that qualified for tax incentives as an Energy Qualified Cool Roof

slide-37
SLIDE 37

SIPs with Glu-Lams

STRUC UCTUR URAL AL SIP IP HY HYBR BRIDS IDS

Silverwood Park Visitor Center, Minneapolis, MN

slide-38
SLIDE 38

Specification for SIPs available at www.sips.org

CO CONST NSTRUC UCTIO ION N MET METHO HODS DS AN AND D SPECI CIFICA FICATION IONS

slide-39
SLIDE 39

Specifications for SIPs (available at www.sips.org)

CO CONST NSTRUC UCTIO ION N MET METHO HODS DS AN AND D SPECI CIFICA FICATION IONS

slide-40
SLIDE 40

Coventry Senior Living, Mahtomedi, MN

COMMER COMMERCIAL APPLICA CIAL APPLICATIONS TIONS

slide-41
SLIDE 41

Finn Hill Junior High School, Kirkland, WA

COMMER COMMERCIAL APPLICA CIAL APPLICATIONS TIONS

slide-42
SLIDE 42

Finn Hill Junior High School, Kirkland, WA

COMMER COMMERCIAL APPLICA CIAL APPLICATIONS TIONS

slide-43
SLIDE 43

COMMER COMMERCIAL APPLICA CIAL APPLICATIONS TIONS

Aeon Alliance Expansion, Minneapolis, MN

slide-44
SLIDE 44

COMMER COMMERCIAL APPLICA CIAL APPLICATIONS TIONS

Aeon Alliance Expansion, Minneapolis, MN

slide-45
SLIDE 45

COMMER COMMERCIAL APPLICA CIAL APPLICATIONS TIONS

Bend Parks and Recreation, Bend, OR

slide-46
SLIDE 46

COMMER COMMERCIAL APPLICA CIAL APPLICATIONS TIONS

Bend Parks and Recreation, Bend, OR
