Presented by:

Justin Willette

Simulating System Reliability using Monte Carlo Simulation

15 October 2013

1

Table of Contents

• System Reliability
• Reliability Block Diagrams
• Structure Function
• Calculating System Reliability
• Simulating System Reliability
• Simulation Demonstration

2

• Systems are comprised of multiple components specifically arranged for a

design.

• If component reliabilities are known, or reasonably estimated, the

reliability of the system can be estimated with certain confidence.

• This estimate is based on the component configuration, laws of

probability, and key assumptions.

System Reliability

3

• The first step in estimating the system reliability is to create a Reliability

Block Diagram (RBD)

• A RBD is a graphical representation of the components of a system and

how they are related to each other in the system

Reliability Block Diagrams

4

• Each complete RBD is unique to its design
• RBD’s can be in several different arrangements
• Series
• Parallel
• Complex

B A D C

Reliability Block Diagrams

5

• Reduce the RBD into:

– a parallel arrangement of series subsystems OR – a series arrangement of parallel subsystems

RBD

1 3 4 2 2 5 4 1 2 1 3 5 4 2 4 5

Simplifying RBD’s

6

• Assumptions:

– A component can only exist in 2 states – Functioning or Failed – Component failures are statistically independent

• Definition:

– The state of component i, denoted by xi, is: 0 if component i has failed 1 if component i is functioning for i = 1, 2, … n

• The structure function, φ(x), relates the state of the system to the states of its

individual components 0 if the system has failed when the state vector is x 1 if the system is functioning when the state vector is x



i

x

  ) (

i

x

Structure Function

7

Minimal Path Set: Where s is the number of minimal path sets

) 1 ( 1 ) (

1

 

 

   

s j P i i i

j

x x

RBD

Minimal Cut Set: Where k is the number of minimal cut sets

 

 

           

k j C i i i

j

x x

1

) 1 ( 1 ) ( ) 1 )( 1 )( 1 ( 1 ) (

5 2 4 3 2 4 1

x x x x x x x xi       ) 1 )( 1 )( 1 )( 1 ( ) (

4 2 5 3 1 5 4 2 1

x x x x x x x x x xi      

Calculating the structure function

8

• Using the structure function:

Cut Method ≤ Actual Reliability ≤ Path Method ≤ R(S) ≤

• Calculating the actual reliability

– Decomposition also known as the Keystone Method = +

 

 

         

k j C i i

j

p

1

) 1 ( 1

) 1 ( 1

1

 

 

 

s j P i i

j

p

1 2 3 4 1 2 3 4 1 2 3 4

Calculating the System Reliability

9

• Software

– Standard Microsoft Excel – VBA programming within Excel – Reliasoft – Raptor

Simulating System Reliability

10

• Benefits of using VBA code

– Reuse – More precise calculations – Less likelihood of errors – Simple interface with user – Ability to run a set number of iterations – Ability to lock cells from the user – Faster simulations – Can run on any computer with Microsoft Office

Simulating System Reliability

11

• Information needed for simulation using VBA programming

– Reliability Block Diagram – Failure rate of each component (λ) – Operating time of the system (t) – Number of iterations to run

Reliability =

t

e 



Simulating System Reliability

12

Simulation demonstration in Excel

Simulating System Reliability

13

• VBA Programming reference

Helpful Reference

14

• Simulating reliability of a system is preferred to demonstrating reliability

by testing

• Reliability Block Diagrams are specific to each system and must be

considered in order to produce accurate reliability simulations

• Reliability estimates are based on the component configuration, laws of

probability, and key assumptions

• Monte Carlo simulation in Excel is one way to predict a reasonable

estimate of the system reliability

• Using VBA Code is an effective way to run simulations in Excel

Conclusion

15

Back-up Slides

16

Simulating System Reliability

17

Start button

Simulating System Reliability

18

Simulating System Reliability

19

Simulating System Reliability

20

Simulating System Reliability

21

Simulating System Reliability

22

VBA Code

23
