Simplicial complexes associated with cloud points Seminar algorithms Jorge Cordero Eindhoven University of Technology 8 May 2018 Outline Motivation 1 Recap 2 Nerves 3 Cech complex 4 Vietoris-Rips complex 5 Delaunay complex 6
SLIDE 2
SLIDE 3
Topological data analysis
Data can be complex in terms of size or features. Sometimes, data has shape.
SLIDE 4
Topological data analysis
Topological data analysis (TDA) help us to understand the structure (shape) of data. Application: Find coverage in networks of sensors Understand protein interactions Credit card fraud detection
SLIDE 5
Simplex
σ is an n-simplex spanned by n + 1 affinely independent points in P ∈ Rn. A 0-simplex is a point A 1-simplex is a line A 2-simplex is a triangle A 3-simplex is a tetrahedron
SLIDE 6
Simplicial complex
A simplicial complex K in Rn is a collection of simplices in Rn such that: Every face of a simplex of K is in K Every pair of distinct simplices of K has a disjoint interior The intersection of two distinct simplices of K is a face of each of them
SLIDE 7
ASC and Homotopy
An abstract simplicial complex is a collection of finite non-empty subsets
- f S.
If A ⊆ S, each non-empty subset B ⊆ A is also in S.
SLIDE 8
ASC and Homotopy
An abstract simplicial complex is a collection of finite non-empty subsets
- f S.
If A ⊆ S, each non-empty subset B ⊆ A is also in S. For our purposes, we can think of homotopy equivalent spaces (X ≃ Y) as spaces that can be deformed continuously one into another.
SLIDE 9
Simplicial representation
Our goal is to compute a simplicial representation of a set of points to apply topological tools for data analysis.
SLIDE 10
Nerves
We can use the nerve of a finite collection of sets S to create an abstract simplicial complex.
SLIDE 11
Nerves
We can use the nerve of a finite collection of sets S to create an abstract simplicial complex. The nerve of S consists of all non-empty subcollections whose sets have a non-empty common intersection, NrvS = {X ⊆ S|
- X = ∅}.
SLIDE 12
Nerves
From X = ∅ and Y ⊆ X = ⇒ Y = ∅, it follows that NrvS is always an abstract simplicial complex. We represent the nerve as an abstract simplicial complex, NrvS = {R, B, P, G, {R, B}, {B, P}, {P, G}, {G, R}}.
SLIDE 13
Nerves
The topological space of S = {R, G, B, Y } is a disk with three holes. NrvS has the homotopy type of a sphere. Hence, the homotopy types for NrvS and |S| are different.
SLIDE 14
Nerves
We want to compute a nerve that resembles the structure inherent to the set of points.
SLIDE 15
Nerves
We want to compute a nerve that resembles the structure inherent to the set of points.
Nerve theorem
Let S be a finite collection of closed, convex sets in Euclidean space. Then, the nerve of S and the union of the sets in S have the same homotopy type.
SLIDE 16
Closed ball
A closed ball with center x and radius r is defined by, Bx(r) = x + rBd = {y ∈ Rd| ||y − x|| ≤ r}
SLIDE 17
ˇ Cech complex
Let’s construct a simplicial complex from a set of points.
SLIDE 18
ˇ Cech complex
Let’s construct a simplicial complex from a set of points.
SLIDE 19
ˇ Cech complex
Let’s construct a simplicial complex from a set of points.
SLIDE 20
ˇ Cech complex
Let’s construct a simplicial complex from a set of points.
SLIDE 21
ˇ Cech complex
Let S be a finite set of points in Rd. The ˇ Cech complex of S and r is given by, ˇ Cech(r) = {σ ⊆ S|∩Bx(r) = ∅} The ˇ Cech complex is equivalent to the nerve of the collection of balls.
SLIDE 22
ˇ Cech complex
ˇ Cech complexes for different values of r
SLIDE 23
ˇ Cech complex
ˇ Cech complexes for different values of r
SLIDE 24
ˇ Cech complex
Some properties of the ˇ Cech complex: When ri ≤ rj, ˇ Cech(ri) ⊆ ˇ Cech(rj).
SLIDE 25
ˇ Cech complex
Some properties of the ˇ Cech complex: When ri ≤ rj, ˇ Cech(ri) ⊆ ˇ Cech(rj). ˇ Cech(r) of a set S of points in Rd can always be represented as an abstract simplicial complex.
SLIDE 26
ˇ Cech complex
Some properties of the ˇ Cech complex: When ri ≤ rj, ˇ Cech(ri) ⊆ ˇ Cech(rj). ˇ Cech(r) of a set S of points in Rd can always be represented as an abstract simplicial complex. Computing the complex takes an exponential time in the size of S.
SLIDE 27
Vietoris-Rips complex
The Vietoris-Rips VR complex of S and r consists of all subsets of diameter at most 2r, VR(r) = {σ ⊆ S|diamσ ≤ 2r}. The diameter of σ is the supremum of all pairwise distances between points in σ.
SLIDE 28
Comparing ˇ Cech and Vietoris-Rips complex
ˇ Cech complex Vietoris-Rips complex
SLIDE 29
Vietoris-Rips
Notice that ˇ Cech(r) ⊆ VR(r) but ˇ Cech(r) ≃ VR(r). For appropriate values of ra and rb, we have VR(ra) ⊆ ˇ Cech(rb).
Vietoris-Rips Lemma
Let S be a finite set of points in some Euclidean space and r ≥ 0. It follows that VR(r) ⊆ ˇ Cech( √ 2r).
SLIDE 30
Vietoris-Rips
Properties of VR complexes: VR complexes avoid the intersection test used in ˇ Cech.
SLIDE 31
Vietoris-Rips
Properties of VR complexes: VR complexes avoid the intersection test used in ˇ Cech. VR complexes also take exponential time to compute.
SLIDE 32
Vietoris-Rips
Properties of VR complexes: VR complexes avoid the intersection test used in ˇ Cech. VR complexes also take exponential time to compute. VR complexes might not have a geometric representation in the underlying space of S.
SLIDE 33
Voronoi diagram
What if we want the simplicial complex to have a geometric representation?. Delaunay complexes can be used for this task. To explore Delaunay complexes, we first introduce the Voronoi diagram.
SLIDE 34
Voronoi diagram
Consider a finite set of points S = {v1, v2, ..., vn} in Rd: The Voronoi cell of vi ∈ S is the set of points in Rd closest to vi, Vvi = {x ∈ Rd| ||x − vi|| ≤ ||x − vj||, ∀vj ∈ S}. Together, the Voronoi cells of all points vi cover the entire space.
SLIDE 35
Voronoi diagram
For a set of points in a plane: Encode proximity information useful for answering point queries.
SLIDE 36
Voronoi diagram
For a set of points in a plane: Encode proximity information useful for answering point queries. Can be computed in time O(nlogn) using Fortune’s algorithm.
SLIDE 37
Voronoi diagram
For a set of points in a plane: Encode proximity information useful for answering point queries. Can be computed in time O(nlogn) using Fortune’s algorithm. It uses O(n) space.
SLIDE 38
Delaunay complex
The Delaunay complex of a finite set of points S ⊆ Rd is equivalent to the nerve of the Voronoi diagram, Delaunay(S) = {σ ⊆ S|
- ui∈σ
Vui = ∅}.
SLIDE 39
Delaunay complex
The Delaunay complex seems to always create triangles in R2.
SLIDE 40
Delaunay complex
The Delaunay complex seems to always create triangles in R2. Is this always the case?
SLIDE 41
Delaunay complex
The Delaunay complex seems to always create triangles in R2. Is this always the case? No, unless the set of points is in general position.
SLIDE 42
Delaunay complex
A set of points S is in general position if not d + 2 points lie on a common (d − 1)-sphere. For a finite set of points S ∈ Rd, assuming general position, the geometric realization of a Delaunay complex fits in Rd.
SLIDE 43
Delaunay complex
For a set of points in the plane: It can be computed from the Voronoi diagram. It takes expected O(nlogn) time. It uses O(n) space.
SLIDE 44
Alpha complexes
Let S be a finite set of points in Rd and r ≥ 0. Let Ru(r) = Bu(r) ∩ Vu, with Vu being the Voronoi cell of u. The alpha complex is defined as Alpha(r) = {σ ⊆ S|
- u∈σ
Ru(r) = ∅}.
SLIDE 45
Delaunay filtration
Different values of r to create different alpha complexes.
SLIDE 46
Delaunay filtration
Eventually, we obtain the Delaunay complex.
SLIDE 47
Delaunay filtration
The filtration of Km = Delaunay is represented as, ∅ = K0 ⊆ ... ⊆ Ki ⊆ ... ⊆ Km. Ki corresponds to the i-th alpha complex from the sequence of different alpha complexes obtained by varying r.
SLIDE 48
Summary
The nerve of a set of points S allows us to compute simplicial complexes.
SLIDE 49
Summary
The nerve of a set of points S allows us to compute simplicial complexes. ˇ Cech complexes and Vietoris-Rips complexes allows us to construct abstract simplicial complexes from S.
SLIDE 50
Summary
The nerve of a set of points S allows us to compute simplicial complexes. ˇ Cech complexes and Vietoris-Rips complexes allows us to construct abstract simplicial complexes from S. The Delaunay triangulation allows to create simplicial complexes with geometric realizations.
SLIDE 51
Summary
The nerve of a set of points S allows us to compute simplicial complexes. ˇ Cech complexes and Vietoris-Rips complexes allows us to construct abstract simplicial complexes from S. The Delaunay triangulation allows to create simplicial complexes with geometric realizations. The alpha complex can be seen as a filtered version of the Delaunay complex.
SLIDE 52
Sources
- H. Edelsbrunner, J. L. Harer, Computational topology. An
- introduction. American Mathematical Society, Providence, RI, 2010.
Mark de Berg, Otfried Cheong, Marc van Kreveld, and Mark
- Overmars. 2008. Computational Geometry: Algorithms and
Applications (3rd ed.). Lecture notes and videos on Computational Topology. Lectures 11, 12, and 13. Topological data analysis of genes ˇ Cech and Vietoris-Rips complex Persistent homology
