SI P Communicator Emil Ivov FOSDEM, February 25 th 2007 Table of Contents What is SIP Communicator? SIP Communicator Overview Currently supported and planned features. Deployment, customization and maintenance Extensibility,
FOSDEM, February 25th 2007
FOSDEM, February 25th 2007
What is SIP Communicator? SIP Communicator Overview – Currently supported
and planned features.
Deployment, customization and maintenance –
Extensibility, ease of maintenance and deployment.
Creating plug-ins for SIP Communicator
FOSDEM, February 25th 2007
SIP Communicator is an open source (LGPL) Audio/Video software phone and instant messenger. Among others, we currently support:
Audio and Video calls with SIP Instant messaging with Jabber, ICQ/AIM, Yahoo! Msngr and MSN IPv6 support for SIP and Jabber Support for multiple accounts and meta contacts Basic NAT & Firewall Traversal with STUN. Modularity, extensibility, and flexibility with OSGi Platform specific installers for Windows, Debian, Fedora, Mac OS X
visit http://sip-communicator.org for more details
FOSDEM, February 25th 2007
FOSDEM, February 25th 2007
FOSDEM, February 25th 2007
FOSDEM, February 25th 2007
FOSDEM, February 25th 2007
STUN, ICE and P2P in order to achieve powerful, secure, and scalable firewall support.
“support for IPv6”. We would like to guarantee its transparent and seamless
configuration and should not cause any problems.
reliable security of all media transmitted by the SIP Communicator in order to prevent relaying nodes from eavesdropping.
Provide a user interface and an online repository for SIP Communicator plug-ins.
IRC, shared whiteboards, multiparty video and chat
conferencing.
FOSDEM, February 25th 2007
OSGi Framework
Jabber SI P MSN Media User I nterface Message History Meta Contact List Firewall Traversal I CQ
FOSDEM, February 25th 2007
OSGi Framework
Jabber SI P MSN Media User I nterface Message History Meta Contact List Firewall Traversal I CQ
SIP Communicator is built upon the Apache Felix implementation of the OSGi framework. This helps us provide qualities such as:
Modularity
& Flexibility – All components
SIP Communicator are implemented as separate, replaceable
sets of features and functionalities depending on the intended user or target platform.
Extensibility – It is very easy to implement additional
features in the form of plug-ins. Developers that are new to SIP Communicator could easily start developing for it since they only need to get acquainted with existing APIs and not the entire source code.
Ease of maintenance and deployment – The concept of an
OSGi Bundle Repository allows SIP Communicator users to download, install and configure new plug-ins with a few clicks.
FOSDEM, February 25th 2007
SIP Communicator is built upon the Apache Felix implementation of the OSGi framework. This helps us provide qualities such as:
Modularity
& Flexibility – All components
SIP Communicator are implemented as separate, replaceable
sets of features and functionalities depending on the intended user or target platform.
Extensibility – It is very easy to implement additional
features in the form of plug-ins. Developers that are new to SIP Communicator could easily start developing for it since they only need to get acquainted with existing APIs and not the entire source code.
Ease of maintenance and deployment – The concept of an
OSGi Bundle Repository allows SIP Communicator users to download, install and configure new plug-ins with a few clicks.
OSGi Framework
MSN Message History I CQ User I nterface Compact User I face Jabber SI P Media Meta Contact List Firewall Traversal
FOSDEM, February 25th 2007
SIP Communicator is built upon the Apache Felix implementation of the OSGi framework. This helps us provide qualities such as:
Modularity
& Flexibility – All components
SIP Communicator are implemented as separate, replaceable
sets of features and functionalities depending on the intended user or target platform.
Extensibility – It is very easy to implement additional
features in the form of plug-ins. Developers that are new to SIP Communicator could easily start developing for it since they only need to get acquainted with existing APIs and not the entire source code.
Ease of maintenance and deployment – The concept of an
OSGi Bundle Repository allows SIP Communicator users to download, install and configure new plug-ins with a few clicks.
OSGi Framework
User I nterface Compact User I face Jabber SI P Media Meta Contact List Firewall Traversal
FOSDEM, February 25th 2007
Jabber SIP SIP Communicator is built upon the Apache Felix implementation of the OSGi framework. This helps us provide qualities such as:
Modularity
& Flexibility – All components
SIP Communicator are implemented as separate, replaceable
sets of features and functionalities depending on the intended user or target platform.
Extensibility – It is very easy to implement additional
features in the form of plug-ins. Developers that are new to SIP Communicator could easily start developing for it since they only need to get acquainted with existing APIs and not the entire source code.
Ease of maintenance and deployment – The concept of an
OSGi Bundle Repository allows SIP Communicator users to download, install and configure new plug-ins with a few clicks.
OSGi Framework
Jabber SI P Media Meta Contact List Firewall Traversal
GPS Navigation Voice Recognition
Compact User I face
FOSDEM, February 25th 2007
Web Repository
SIP Communicator is built upon the Apache Felix implementation of the OSGi framework. This helps us provide qualities such as:
Ease of maintenance and deployment – The concept of an
OSGi Bundle Repository allows SIP Communicator users to download, install and configure new plug-ins with a few clicks.
OSGi Framework
Jabber SI P Firewall Traversal
Voice Recognition
Media User I nterface Meta Contact List
GPS Navigation IRC Zero Conf Spell Checker
FOSDEM, February 25th 2007
Web Repository
SIP Communicator is built upon the Apache Felix implementation of the OSGi framework. This helps us provide qualities such as:
Ease of maintenance and deployment – The concept of an
OSGi Bundle Repository allows SIP Communicator users to download, install and configure new plug-ins with a few clicks.
OSGi Framework
Jabber SI P
Voice Recognition
Media User I nterface Meta Contact List
GPS Navigation
http
IRC Zero Conf Spell Checker
FOSDEM, February 25th 2007
Web Repository
SIP Communicator is built upon the Apache Felix implementation of the OSGi framework. This helps us provide qualities such as:
Ease of maintenance and deployment – The concept of an
OSGi Bundle Repository allows SIP Communicator users to download, install and configure new plug-ins with a few clicks.
OSGi Framework
Jabber SI P
Voice Recognition
Media User I nterface Meta Contact List
GPS Navigation
http
IRC Zero Conf Spell Checker
FOSDEM, February 25th 2007
Abstract API s
Jabber I mpl Protocol Service OSGi History I mpl Msg History
Some Plug-in Stats Plug-in Bundle Specifics
SI P (jain-sip-ri) Protocol Service JMF Media Service Java Swing UI Service
FOSDEM, February 25th 2007
Abstract API s
Jabber I mpl Protocol Service OSGi History I mpl Msg History
Some Plug-in Bundle Specifics
SI P (jain-sip-ri) Protocol Service JMF Media Service Java Swing UI Service
Stats Plug-in
FOSDEM, February 25th 2007
Swing UI ServiceI mpl Bundle
UserI nterfaceService
Send
network network
Dude (Online) _ o x
OSGi Framework
FOSDEM, February 25th 2007
Swing UI ServiceI mpl Bundle
UserI nterfaceService
Hi dude, what r u up to?
Send
network network
1 actionPerformed(evt)
Dude (Online) _ o x
OSGi Framework
FOSDEM, February 25th 2007
Swing UI ServiceI mpl Bundle
UserI nterfaceService
Hi dude, what r u up to?
Send
Jabber Protocol I mpl Bundle
ProtocolProviderService
2 getService( providerRef )
network network
1 actionPerformed(evt)
Dude (Online) _ o x
OSGi Framework
FOSDEM, February 25th 2007
Swing UI ServiceI mpl Bundle
UserI nterfaceService
Hi dude, what r u up to?
Send
Jabber Protocol I mpl Bundle
ProtocolProviderService
2 getService( providerRef )
network network
3 sendMsgTo( Contact) 4 send message 1 actionPerformed(evt)
Dude (Online) _ o x
OSGi Framework
FOSDEM, February 25th 2007
SIP Communicator 1.0 Architecture
Transfer CallTransfer Plug-In
SI P Communicator _ o x
network network
OSGi Framework
FOSDEM, February 25th 2007
SIP Communicator 1.0 Architecture
Swing UI ServiceI mpl Bundle
UserI nterfaceService
Transfer
2 registerComponent(this)
CallTransfer Plug-In
SI P Communicator _ o x
1 getService( uiServiceRef ) 3 container.addComponent(button) container.addComponent(field)
network network
OSGi Framework
FOSDEM, February 25th 2007
CallTransfer Plug-In SIP Implementation Bundle
ProtocolProviderService
SIP Communicator 1.0 Architecture
1 getService( providerRef ) 2 registerCallListener( this )
network network
OSGi Framework
Transfer
SI P Communicator _ o x Swing UI ServiceI mpl Bundle
UserI nterfaceService
FOSDEM, February 25th 2007
CallTransfer Plug-In SIP Implementation Bundle
ProtocolProviderService
Swing UI ServiceI mpl Bundle
UserI nterfaceService
SIP Communicator 1.0 Architecture
Alerting … The Duke is calling you!
2 incomingCallReceived( evt ) 3 container.addComponent(cmp)
network network
OSGi Framework
1 I NVI TE req received
SI P Communicator _ o x
Transfer
FOSDEM, February 25th 2007
CallTransfer Plug-In SIP Implementation Bundle
ProtocolProviderService
Swing UI ServiceI mpl Bundle
UserI nterfaceService
SIP Communicator 1.0 Architecture
Alerting … The Duke is calling you!
4 actionPerformed(evt) 5 transferCall(call, dst)
+3592166166
network network
OSGi Framework
6 send REFER req
SI P Communicator _ o x
Transfer
FOSDEM, February 25th 2007
How to create OSGi Services for SI P Communicator:
http://www.sip-communicator.org/index.php/Documentation/CreatingServices
How to write GUI plugins:
http://www.sip-communicator.org/index.php/Documentation/HowToWriteGuiPlugins
How to implement support for your favorite protocol in SI P Communicator:
http://www.sip-communicator.org/index.php/Documentation/HowToImplementProtocols
How to create and maintain a SI P Communicator installer:
http://www.sip-communicator.org/index.php/Documentation/HowToBuildAnInstaller
