SFR: Scalable Forwarding with RINA for Distributed Clouds

Fatma Hrizi, Anis Laouiti and Hakima Chaouchi Telecom SudParis, France

6th International Conference NOF 2015, MONTREAL, CANADA, SEPTEMBER 30, 2015

07/10/2015 1 NOF 2015

Outline

• Intro & Motivation
• VIFIB Distributed Clouds
• RINA: Recursive InterNetwork Architecture
• SFR: Scalable Forwarding with RINA
• Simulation Results
• Conclusion

07/10/2015 2 NOF 2015

Generated from https://tagul.com

Intro & Motivation

• Cloud Computing

– Fast Emergence

• Research, industries and standardizations

– Enables ubiquitous and on-demand access to shared resources – Large scale applications become feasible

• Big data, HPC..

– Single central point Scalability & Availability issues

• Distributed Clouds

– Decentralized management – Resources distributed in several geo area – “Volunteer” clouds

• An example: VIFIB

07/10/2015 3 NOF 2015

VIFIB Distributed Clouds

• VIFIB: Resilient Computing

– No data center architecture:

• Micro servers located in homes, offices..
• Distributed resources More Availability: 99.99%!

– Master/Slave architecture – Resiliency

• Data is encrypted and replicated

in different locations

• Overlay Network of

Open VPN tunnels (re6st)

07/10/2015 NOF 2015 4

Source: http://www.vifib.com/ Source: http://www.vifib.com/

Re6st: Resilient Overlay Networking System

• Re6st

– Mesh network of Open VPN

• Flat and random graph

– Babel Protocol used to calculate best routes – Fast recovery!

• Issues with Re6st

– Security issues

• Bad routes flooding

– Scalability issues

• Flat topology does not scale
• Tunnels might consume

extensive resources

07/10/2015 NOF 2015 5

Source: http://www.vifib.com/

RINA: Recursive InterNetwork Architecture

07/10/2015 NOF 2015 6

• Inter-Process Communication (IPC) model
• Unlike TCP/IP, one single layer
• that could be

repeated recursively

• Clean separation

between mechanism and policy

• Divide and Conquer
• Scalability

GroupS

Group1

GroupD

GroupN-1 Group2

InterGroup1_N InterGroup1_1 InterGroup1_2 InterGroup1_N-1

InterGroup2_N

• The distributed clouds is divided into groups
• Group leaders are created to interconnect nodes from

different groups and to form the inter groups

• To support scalability, multiple levels could be created

SFR: Scalable Forwarding with RINA

07/10/2015 7 NOF 2015

SFR: DIF Architecture

IGroup2_N DIF GroupD DIF GroupS DIF IGroup 1_1 DIF

VIFIB nodeA VIFIB nodeF VIFIB nodeC VIFIB nodeE VIFIB nodeB VIFIB nodeD

Tenant Cloud DIF

IGroup 1_N DIF

DAP 1 DAP N

Tenant App DIF

07/10/2015 8 NOF 2015

Performance Evaluation Scenario

Parameter Value

Number of VIFIB nodes 120 Number of regions 4 Number of VIFIB nodes per region 30 Application Ping Packet Size 1500 Bytes Ping Starts at 140s Ping rate 5 Simulation Time 300s for each run

07/10/2015 9 NOF 2015

• RINASim Simulator: Omnet++

based

• Medium scale distributed clouds

scenario

• Performance indicator:

– Forwarding table size

Simulation Results (1/2)

Smaller PDU Forwarding Table!

Variation of PDU forwarding table size / simulation time Comparison between SFR and simple distance vector routing protocol

07/10/2015 10 NOF 2015

Variation of the PDU forwarding table size with regards the simulation time. Dynamic Tenant Cloud DIF management

Simulation Results (2/2)

07/10/2015 11 NOF 2015

Conclusion

• SFR: new and generic routing architecture for distributed

clouds

– Hierarchical DIF architecture

• SFR achieves better results compared to current distributed

clouds networking solutions

– The forwarding table size is drastically decreased

• In future works, we plan

– Further evaluate the assets of applying RINA to distributed clouds

• Consider more evaluation metrics: latency, throughput..

– Deploy SFR within VIFIB infrastructure to compare it to re6st

07/10/2015 12 NOF 2015

Thank you for your attention! Questions?
