SLIDE 1
Service Mesh sh Interface
Brendan Burns – QCon New York – 2019
This Photoby Unknown Author is licensed under CC BY-SA
The e Service ice Me Mesh Landsc scape
This Photoby Unknown Author is licensed under CC BY-NC-ND
Service Mesh sh Interface Brendan Burns QCon New York 2019 This - - PowerPoint PPT Presentation
Service Mesh sh Interface Brendan Burns QCon New York 2019 This - - PowerPoint PPT Presentation
Service Mesh sh Interface Brendan Burns QCon New York 2019 This Photoby Unknown Author is licensed under CC BY-SA The e Service ice Me Mesh Landsc scape This Photoby Unknown Author is licensed under CC BY-NC-ND The problem for users
SLIDE 2
SLIDE 3
The problem for users
SLIDE 4
The problem for users – Adoption timeline
Excitement Adoption Production
SLIDE 5
Problem for users - Complexity
This Photoby Unknown Author is licensed under CC BY-SA
SLIDE 6
The problem for the ecosystem
Tools Ecosystem Mesh A Mesh B Mesh C
SLIDE 7
The solution? Moar Abstraction!
Tools Ecosystem Mesh A Mesh B Mesh C Adapter Interface
SLIDE 8
Service Mesh Interface: Community
https://smi-spec.io
SLIDE 9
Service Mesh Interface: Goals
Isolate concepts from implementation Provide the “core concepts” of service mesh Release and iterate Build a community around Service Mesh as a concept
SLIDE 10
This isn't a new pattern...
- Open Container Image
- Container Network Interface
- Container Storage Interface
- Storage Volumes
- Ingress
- NetworkPolicy
- ...
SLIDE 11
Good reasons for this approach
USERS NEED CONCEPTS NOT IMPLEMENTATION TOOL VENDORS NEED ABSTRACTION, NOT SPECIALIZATION IMPLEMENTORS NEED ISOLATION FROM USERS
SLIDE 12
Service Mesh Interface – API Overview
TrafficSpec TrafficTarget TrafficSplit TrafficMetrics
SLIDE 13
Service Mesh Interface: Routes
apiVersion: v1beta1 kind: HTTPRouteGroup metadata: name: api-route matches:
- name: api
pathRegex: /api methods:
- GET
SLIDE 14
Service Mesh Interface: Routes
apiVersion: v1beta1 kind: TCPRoute metadata: name: my-db-route
SLIDE 15
Service Mesh Interface: TrafficTarget
kind: TrafficTarget apiVersion: access.smi-spec.io/v1alpha1 metadata: name: example-target destination: # destination spec here specs: # route spec here sources: # source spec(s) here
SLIDE 16
Service Mesh Interface: Destinations
… destination: # This selects a set of Pods kind: ServiceAccount name: my-api-impl # This defines the traffic port: 8080 …
SLIDE 17
Service Mesh Interface: TrafficTarget
kind: TrafficTarget apiVersion: access.smi-spec.io/v1alpha1 metadata: name: example-target destination: # destination spec here specs: # route spec here sources: # source spec(s) here
SLIDE 18
Service Mesh Interface: Routes
… # This selects a set of paths specs:
- kind: HTTPRouteGroup
name: api-route matches:
- api
…
SLIDE 19
Service Mesh Interface: TrafficTarget
kind: TrafficTarget apiVersion: access.smi-spec.io/v1alpha1 metadata: name: example-target destination: # destination spec here specs: # route spec here sources: # source spec(s) here
SLIDE 20
Service Mesh Interface: Sources
… # This identifies the allowed sources sources: # This selects a set of Pods
- kind: ServiceAccount
name: my-api-callers …
SLIDE 21
Putting it all together…
SMI TrafficTarget ServiceAccount: my-api-impl Destination ServiceAccount: my-api-callers Sources SMI HTTPRouteGroup https://service:8080/api
SLIDE 22
Service Mesh Interface: TrafficSplit
kind: TrafficSplit apiVersion: split.smi-spec.io/v1alpha1 metadata: name: one-percent-experiment spec: backends:
- service: experiment
weight: 1
- service: canary
weight: 10
- service: production
weight: 100
SLIDE 23
Service Mesh Interface – Traffic Split
SMI TrafficSplit my-experiment experiment Service canary Service production Service Kubernetes Services my-experiment Service
SLIDE 24
Service Mesh Interface - TrafficMetrics
kind: TrafficMetrics … resource: name: my-pod-asdae kind: Pod edge: … timestamp: 2019-06-26T12:00:00 window: 30s metrics: …
SLIDE 25
Service Mesh Interface - TrafficMetrics
# all in-bound traffic edge: direction: to resource: {} # all out-bound traffic to Pod foobar edge: direction: from resource: name: foobar kind: Pod
SLIDE 26
Service Mesh Interface - TrafficMetrics
# all in-bound traffic from a Service edge: direction: to resource: name: my-service kind: Service
SLIDE 27
Service Mesh Interface - TrafficMetrics
… metrics:
- name: p99_response_latency
unit: seconds value: 987m
- name: p90_response_latency
unit: seconds value: 250m …
SLIDE 28
Service Mesh Interface – TrafficMetrics Overview
Kubernetes API Server traffic.metrics.k8s.io Traffic Metrics Server Prometheus, etc. metrics scrape/push
SLIDE 29
Concerns: Lowest Common Denominators
SLIDE 30
Service Mesh Interface: Approach to iteration
SLIDE 31
Service Mesh Interface: Iteration plan.
Start with the basics Lots of custom extensions Adopt the common extensions to v+1
SLIDE 32
Service Mesh Interface: State of the art.
- Consul
- LinkerD
- Istio
Implementations:
- Flagger (WeaveWorks)
- Rio (Rancher)
- ...
Tooling:
SLIDE 33
Service Mesh Interface: Futures
- Come and join us!
- https://smi-spec.io
- https://github.com/deislabs/smi-spec
- https://github.com/deislabs/smi-sdk-go
- https://github.com/weaveworks/flagger/blob/
master/docs/gitbook/tutorials/flagger-smi- istio.md
- https://github.com/hashicorp/microsoft-smi-
webinar
