About Eco1st Technology Group

Established in 2008, Eco1st Technology group is the sole manufacturer of the Separation, Filtration and Irrigation Enhancers. This is a worldwide patented technology with over 20 years of research and development and the original patent holder and CEO Steve Lopes is still very active in the company. To date, we hold 137 U.S. and international patents. All Enhancers are made with high grade materials and are hand build at our facility in Huntington Beach, California U.S.A. Our systems are in use in an array of application and industries treating various fluids and improve efficiencies around the world. The Separation Enhancer is a Industrial quality, time tested, solid state, inline fluid ionization system. Our Enhancer's make use of known electro chemical ionization principles. The Separation Enhancer induce frequencies into the flowing fluid, which breaks molecular bonds, while simultaneously stripping free electrons. The free electrons will then be routed and or drawn to a dedicated earth ground. This process can be seen and measured instantly, by utilizing a volt/amp meter, as the electrons are drawn from the fluid by the Separation Enhancer to the earth ground . Once the electrons are stripped away, the fluid will become positively ionized. Like charges repel, resulting in stratification of each fluid based

• n their individual specific gravity.

The Separation Enhancer will directly improve the purity and value of each of the separated fluids, while reducing operational costs, processing time, waste and environmental impact. Additionally, the Separation Enhancer is designed to be powered by the energy of the flowing fluids. Therefore, no other outside power source or routine maintenance is required.

Common Applications We Serve

Oil & Gas Producers * Oil Refineries * Produced Water Disposals

About the Separation Enhancer

2

• Will treat any and all oil weights/qualities
• Reduces retention time needed to treat and recover oil
• Increases oil recovery and quality (Lower BS&W)
• Reduces the waste stream and expenses associated
• Kills sulfide reducing bacteria
• Reduces the need of chemicals, biocides and some equipment
• Eliminates and prevents scale and paraffins build up
• Reduces the fluid drag coefficient (Improves flow rate)
• Improves process controllability and site efficiencies

3

• No emission or water permits are necessary
• Compact size
• Designed to meet all common line sizes and flow rates
• Simple inline installation (Requires little down time)
• Requires no operator adjustment or routine maintenance
• Makes use of the energy of the moving fluid (No outside power source)
• No noise, odors or emissions - 100% Green & Sustainable
• Designed and made in the U.S.A
• High grade stainless steel construction
• We manufacture our systems to meet any code requirements
• Affordable and provides high return on investment

Additional features the Separation Enhancer offers

4

Overview of Applications and Tests

The following pages offer examples of the Separation Enhancers non discriminating ability to treat and separate various fluids

Real World Test Results:

• A. Separation of solid waste from produced water
• B. Improving hydrocarbon separation from produced water
• C. Separation and removal of chemicals from produced water
• D. Demulsification of water soluble phosphorus solution

Site specific piloting programs available.

5

Test Conducted on Rust Laden Water

• A. Test

Fluid: Rust laden water Location: GATX – Long Beach, CA Treated With: Separation Enhancer Process: 250 gl single pass, batch test

Goal:

Separate the water from suspended rust partials.

Results:

The treated water and rust separated instantly in the settling tank.

Conducted at GATX, Located in Long Beach, CA.

Untreated / Treated

6

Test conducted on crude oil production

• Separating hydrocarbons from produced water-
• B. Untreated

Total Dissolved Solids Sodium Chloride Boron Bicarbonate Silica Sulfate Potassium Iron Total Hydrocarbons Barium Lead Zinc Treated Total Dissolved Solids Sodium Chloride Boron Bicarbonate Silica Sulfate Potassium Iron Total Hydrocarbons Barium Lead Zinc mg/l 6000 5300 64 1500 240 72 59 0.87 1700 mg/kg 0.58 0.097 0.62 mg/l 510 450 3.5 200 40 41 4.4 <0.1 13 mg/kg 0.58 0.097 0.62

Conducted at Tannehill Oil Co.

Untreated / Treated

7

Test conducted on crude oil production

• Separating hydrocarbon-based cleaning chemicals from produced water-

Conducted at Bechtel Petroleum

• C. Untreated

Ethyl Benzene Toluene Methylene Chloride Total Trihalomethanes Chromium Copper Lead Zinc

Treated

Ethyl Benzene Toluene Methylene Chloride Total Trihalomethanes Chromium Copper Lead Zinc mg/l 250 950 1.4 2000 mg/kg 0.76 3.1 5.1 19 mg/l Non-Detect ND ND ND mg/kg ND ND ND ND

Untreated / Treated

8

Test conducted on water soluble phosphorus solution

• Separating used concentrated water soluble phosphorus solution-

Conducted at Edwards Air Force Base

• D. Prior to Treatment

Personnel at Edwards Air Force Base in California routinely mix up a solution of water and concentrated water soluble phosphorus to spray on aircraft as a tool that enables them to visually inspect for damage. The phosphorus glows under black light, which will easily reveal stress fractures or cracks on the planes hull

• r outer surface.

Reuse of the phosphorus solution was not possible after it acquired dirt and

• bacteria. The sample shown on the

left is what the recovered phosphorus solution looks like after being used on the planes.

After Treatment

The sample shown on the right is the recovered phosphorus solution after being treated by the Separation Enhancer.

• Phosphorus solution separated

efficiently and according to its specific gravity.

• Bacteria was non-detectable.
• The lab analysis showed

the water soluble phosphorous concentration level in the treated samples matched that

• f their undiluted phosphorous.

Untreated / Treated

9

10

WHAT TO EXPECT FROM YOUR

Research has proven the Separation Enhancer technology will effectively improve efficiencies, quality, and the levels of separation most oil & gas related businesses are looking to achieve. We also realize and understand that while this is true, customers new to the Separation Enhancer may not be familiar with the systems performance capabilities. The following slides will describe examples of common stages and processes, that can be expected from the use of this one of a kind technology.

PLACEMENT & INSTALLATION

11

• All Eco1st Separation Enhancers are made application specific to

effectively treat a variation of emulsions while maintaining optimum performance and dependability. We always take into account the working pressures, temperatures, flow rates, fittings, line sizes, fluid description, applicable code requirements and our customer’s objective.

• With little down time or site modification the Separation Enhancer

(similar to a pipe spool section) will easily adapt to most any site; making for a straight forward installation. Addition, the system is designed to be powered by the energy of the flowing fluids. Therefore, no outside power source is required.

• Sites vary, but operators generally notice some or all of the following

benefits rather quickly, a reduction in pump pressure, better separation, increased recovery, improved oil quality and a diminished waste stream. These results are all achieved in far less time, with fewer processes and equipment compared to conventional treatment commonly utilized today.

IONIZATION BEGINS

12

• Once installed and production resumes, the Separation Enhancer will

immediately begin ionizing the fluid and any solids in continuity with the

• Enhancer. The system will separate simple emulsions throughout the

pipeline and tanks, but complex emulsions will separate best after traveling through the Enhancer.

• Operators will observe additional carryover of oil and solids in the

recovery tanks in most cases. Depending on each sites cleanliness this process could take weeks or months before the tanks and pipelines become thoroughly clean. Once this phase is complete issues related to scale and paraffin build up will no longer exist.

ECO1ST ADVANCED SEPARATION

13

• All sites that have been in use for an extended period of time will likely

have scale and paraffin build up throughout the pipeline and tanks. As we mentioned earlier the Separation Enhancer will ionize all fluids and solids in continuity with the Enhancer. This will also cause an expected one-time cleaning phase to occur as the scale and paraffin's begin breaking down and sloughing off in both the tanks and pipelines.

COMPLETE OPTIMIZATION & ROI

14

• The Separation Enhancer technology does not discriminate. It achieves

consistent separation regardless of fluid ratios. You can expect to improve your sites efficiencies, while increasing the quality and volume of your produced oil and water.

• These benefits are all achieved without the need for unnecessary -

equipment, processes, chemical applications, routine maintenance or

• perator adjustment. If you are interested in improving your companies’

ability to become more productive and profitable, contact us today for a free consultation.

Contact Us For More Information

With years of experience in numerous oil and waste water treatment applications, you can expect continued excellence in service. Our Product Specialist will be happy to assist you by answering any questions and provide clear solutions. visit us online at www.separationenhancer.com www.eco1st.com Eco1st corporate office and manufacturing facility is located at: 7575 Reynolds Circle Huntington Beach, CA. 92606 U.S.A

Phone: (714) 662-7514 Toll Free: (855) 842-5800 Fax: (714) 842-5899 Contact: Info@eco1st.net
