Sensor Networks Where Theory Meets Practice Roger Wattenhofer ETH Zurich Distributed Computing www.disco.ethz.ch Theory Meets Practice SenSys OSDI HotNets Multimedia Ubicomp PODC STOC Mobicom FOCS SIGCOMM ICALP SPAA SODA EC

slide-1
SLIDE 1

ETH Zurich – Distributed Computing – www.disco.ethz.ch

Roger Wattenhofer

Sensor Networks

Where Theory Meets Practice

slide-2
SLIDE 2

Theory Meets Practice

PODC SODA STOC FOCS ICALP SPAA EC SenSys OSDI Mobicom Multimedia Ubicomp SIGCOMM HotNets

slide-3
SLIDE 3

Wireless Communication?

slide-4
SLIDE 4

Capacity!

slide-5
SLIDE 5

Interference Range

Protocol Model

Reception Range

slide-6
SLIDE 6

6

slide-7
SLIDE 7

Physical (SINR) Model

slide-8
SLIDE 8
slide-9
SLIDE 9

Signal-To-Interference-Plus-Noise Ratio (SINR) Formula

Minimum signal- to-interference ratio Power level

  • f sender u

Path-loss exponent Noise Distance between two nodes Received signal power from sender Received signal power from all other nodes (=interference)

slide-10
SLIDE 10

Example: Protocol vs. Physical Model

1m

Assume a single frequency (and no fancy decoding techniques!)

Let =3, =3, and N=10nW Transmission powers: PB= -15 dBm and PA= 1 dBm SINR of A at D: SINR of B at C: 4m 2m

A B C D

Is spatial reuse possible? NO Protocol Model YES With power control

slide-11
SLIDE 11

This works in practice

… even with very simple hardware Time for transmitting 20‘000 packets: Speed-up is almost a factor 3 u1 u2 u3 u4 u5 u6

[Moscibroda, W, Weber, Hotnets 2006]

slide-12
SLIDE 12

Possible Application – Hotspots in WLAN

X Y Z

slide-13
SLIDE 13

Possible Application – Hotspots in WLAN

X Y Z

slide-14
SLIDE 14

The Capacity of a Network

(How many concurrent wireless transmissions can you have)

slide-15
SLIDE 15

Convergecast Capacity in Wireless Sensor Networks

15

Protocol Model Physical Model (power control)

  • Max. rate in arbitrary,

worst-case deployment (1/𝑜) (1/log3 𝑜)

  • Max. rate in random,

uniform deployment (1/log 𝑜) (1/log 𝑜)

Worst-Case Capacity

Topology Model/Power

Classic Capacity

[Giridhar, Kumar, 2005] [Moscibroda, W, 2006]

slide-16
SLIDE 16

Capacity of a Network

Classic Capacity Worst-Case Capacity

How much information can be transmitted in nice networks? How much information can be transmitted in nasty networks? How much information can be transmitted in any network?

Real Capacity

slide-17
SLIDE 17

Core Capacity Problems

Given a set of arbitrary communication links One-Shot Problem Find the maximum size feasible subset of links O(1) approximations for uniform power [Goussevskaia, Halldorsson, W, 2009 & 2014] as well as arbitrary power [Kesselheim, 2011] Scheduling Problem Partition the links into fewest possible slots, to minimize time Open problem: Only 𝑃(log 𝑜) approximation using the one-shot subroutine

slide-18
SLIDE 18

The Capture Effect

slide-19
SLIDE 19

Receiving Different Senders

slide-20
SLIDE 20

Layer 4 Layer 3 Layer 2 Layer 1

  • 64 dBm
  • 70 dBm
  • 75 dBm
  • 81 dBm

“Layer” Abstraction

[König, W, 2016]

slide-21
SLIDE 21

Constructive Interference

slide-22
SLIDE 22

Energy Efficiency?

slide-23
SLIDE 23

Clock Synchronization!

slide-24
SLIDE 24

Clock Synchronization Example: Dozer

  • Multi-hop sensor network with duty cycling
  • 10 years of network life-time, mean energy consumption: 0.066mW
  • High availability, reliability (99.999%)
  • Many different applications use Dozer: TinyNode, PermaSense, etc.

[Burri, von Rickenbach, W, 2007]

slide-25
SLIDE 25

Problem: Physical Reality

t clock rate

1 1 + 𝜁

message delay

1 − 𝜁

slide-26
SLIDE 26

Given a communication network

1. Each node equipped with hardware clock with drift 2. Message delays with jitter Goal: Synchronize Clocks (“Logical Clocks”)

  • Both global and local synchronization!

Clock Synchronization in Theory?

worst-case (but constant)

slide-27
SLIDE 27
  • Time (logical clocks) should not be allowed to stand still or jump

Time Must Behave!

slide-28
SLIDE 28

Local Skew

Tree-based Algorithms Neighborhood Algorithms e.g. FTSP e.g. GTSP

Bad local skew

slide-29
SLIDE 29

Synchronization Algorithms: An Example (“Amax”)

  • Question: How to update the logical clock based on the messages from

the neighbors?

  • Idea: Minimizing the skew to the fastest neighbor

– Set clock to maximum clock value you know, forward new values immediately

  • First all messages are slow (1), then suddenly all messages are fast (0)!

Time is T Time is T

…

Clock value: T Clock value: T-1 Clock value: T-D+1 Clock value: T-D Time is T

skew D

Fastest Hardware Clock

T T

slide-30
SLIDE 30

Dynamic Networks! [Kuhn et al., PODC 2010]

Local Skew: Overview of Results

1 logD √D D …

Everybody‘s expectation, 10 years ago („solved“) Lower bound of logD / loglogD [Fan & Lynch, PODC 2004] All natural algorithms [Locher et al., DISC 2006] Blocking algorithm Kappa algorithm [Lenzen et al., FOCS 2008] Tight lower bound [Lenzen et al., PODC 2009] Dynamic Networks! [Kuhn et al., SPAA 2009] together [JACM 2010]

slide-31
SLIDE 31

Experimental Results for Global Skew

FTSP PulseSync

[Lenzen, Sommer, W, 2014]

slide-32
SLIDE 32

Experimental Results for Global Skew

FTSP PulseSync

[Lenzen, Sommer, W, 2014]

slide-33
SLIDE 33

Network Dynamics?

slide-34
SLIDE 34

Distributed Control!

slide-35
SLIDE 35
slide-36
SLIDE 36

Complexity Theory Can a Computer Solve Problem P in Time t?

slide-37
SLIDE 37

Complexity Theory Can a Computer Solve Problem P in Time t? Network Distributed

slide-38
SLIDE 38

Complexity Theory Can a Computer Solve Problem P in Time t? Network Network Distributed

slide-39
SLIDE 39

Distributed (Message-Passing) Algorithms

  • Nodes are agents with unique ID’s that can communicate with neighbors

by sending messages. In each synchronous round, every node can send a (different) message to each neighbor.

69 17 11 10 7

slide-40
SLIDE 40

Distributed (Message-Passing) Algorithms

  • Nodes are agents with unique ID’s that can communicate with neighbors

by sending messages. In each synchronous round, every node can send a (different) message to each neighbor.

  • Distributed (Time) Complexity: How many rounds does problem take?

69 17 11 10 7

slide-41
SLIDE 41

An Example

slide-42
SLIDE 42

How Many Nodes in Network?

slide-43
SLIDE 43

How Many Nodes in Network?

slide-44
SLIDE 44

How Many Nodes in Network?

slide-45
SLIDE 45

How Many Nodes in Network?

slide-46
SLIDE 46

How Many Nodes in Network?

slide-47
SLIDE 47

How Many Nodes in Network?

1 1 1 1 1 1

slide-48
SLIDE 48

How Many Nodes in Network?

2 1 1 2 1 4 1 1 1

slide-49
SLIDE 49

How Many Nodes in Network?

With a simple flooding/echo process, a network can find the number

  • f nodes in time 𝑃(𝐸), where 𝐸 is the diameter (size) of the network.

2 1 1 2 1 4 1 1 1 10

slide-50
SLIDE 50

Diameter of Network?

  • Distance between two nodes = Number of hops of shortest path
slide-51
SLIDE 51

Diameter of Network?

  • Distance between two nodes = Number of hops of shortest path
slide-52
SLIDE 52

Diameter of Network?

  • Distance between two nodes = Number of hops of shortest path
  • Diameter of network = Maximum distance, between any two nodes
slide-53
SLIDE 53

Diameter of Network?

slide-54
SLIDE 54

Diameter of Network?

slide-55
SLIDE 55

Diameter of Network?

slide-56
SLIDE 56

Diameter of Network?

slide-57
SLIDE 57

Diameter of Network?

slide-58
SLIDE 58

Diameter of Network?

slide-59
SLIDE 59

(even if diameter is just a small constant) Pair of rows connected neither left nor right? Communication complexity: Transmit Θ(𝑜2) information over O(𝑜) edges  Ω(𝑜) time! [Frischknecht, Holzer, W, 2012]

Networks Cannot Compute Their Diameter in Sublinear Time!

slide-60
SLIDE 60

e.g., dominating set approximation in planar graphs

Distributed Complexity Classification

1 log∗ 𝑜 polylog 𝑜 𝐸 poly 𝑜

various problems in growth-bounded graphs MIS, approx. of dominating set, vertex cover, ... count, sum, spanning tree, ... diameter, MST, verification of e.g. spanning tree, …

e.g., [Kuhn, Moscibroda, W, 2016]

slide-61
SLIDE 61

Sublinear Algorithms Self- Stabilization Self- Assembly Applications e.g. Multi-Core Dynamic (e.g. Ad Hoc) Networks Distributed Complexity

slide-62
SLIDE 62

Sublinear Algorithms Self- Stabilization Self- Assembly Applications e.g. Multi-Core Dynamic (e.g. Ad Hoc) Networks Distributed Complexity

slide-63
SLIDE 63
slide-64
SLIDE 64

Summary

slide-65
SLIDE 65

The Capture Effect

slide-66
SLIDE 66

How many lines of pseudo code Can you implement on a sensor node? The best algorithm is often complex And will not do what one expects. Theory models made lots of progress Reality, however, they still don’t address. My advice: invest your research £££s in ... impossibility results and lower bounds!

Theory for sensor networks, what is it good for?!

slide-67
SLIDE 67

Thank You!

Questions & Comments?

Thanks to my co-authors, mostly Silvio Frischknecht Magnus Halldorsson Stephan Holzer Michael König Christoph Lenzen Thomas Moscibroda Philipp Sommer www.disco.ethz.ch
