Eui-Nam Huh, PhD

• Dept. of Computer Engineering

Kyung Hee University Korea

Sensor Data Sharing System for Global IP-USN

2

Background(1/2)

• 21 Century IT : Revolution of “Object to Object Intelligent Network”

– The Internet of Things(object-to-object, M2M) : M2M communications is a new information communication concept, it refers to the networked interconnection of every objects – Government-funded network of intelligent things In Korea – The Korea Communications Commission : Establishing M2M construction Basic Plan for ‘2020 Super IT Korea’

Resources: ETRI Planning Report, network of intelligent things based Broadcasting & Telecommunications Convergence Strategy Configuration (2009.4)

자료 : ETRI 기획보고서, 만물지능통신망 기반의 방송통신융합전략 구성(2009.4)

Intelligent Network Paradigm Network Paradigm Information Processing Paradigm Distributed Networked Intelligential

IT : Information Processing Machine IT : Communication and Collaboration IT : Intelligent object fusion Main Frame [Centralized Computing] Client/Server PC [Distribute Computing] Commercialized Internet Broadband IT Web2.0 Ubiquitous Network Ubiquitous Computing

M2M

Web X 1970 1980 1990 2000 2005 2010 2015

4

Background(2/2)

• Global u-Society movement by the change of IT paradigm
• Increase necessity of data share through heterogeneous sensor network

(ex – Weather cast, Environment detect information like ash in Iceland)

• Increase of error rate and traffic while providing service in large scale

IP-USN environment. Need International Working Group through international collaboration Need the metadata define and classification

• f sensor data

5

Research Purpose

IP-USN Integration Environment Sensor Data 6LoWPAN Sensor Data Define USN Security, Authentication Specifications Network Access Method Sensor Metadata Define Metadata Sharing System Structure

USN Service Field Classification

y Data Access Policy Data Search Method Format Define

Korea Working Group Kyung Hee University Research Team International Research Team Working Group

6

Outline

IP-USN common interface and data standard Survey and analysis international standard(TTA, IEEE, ISO, etc.) Classification and definition of application services Classification and definition of kinds of Sensor Data Required metadata specification: the sensor data specifications required for data sharing To identify the strengths and weaknesses of various format defined Metadata format System Architecture Specification for metadata sharing Data Access Policy Definition: data access between Heterogeneous sensor networks ZigBee defines the network access method for such 6LoWPAN WSN authentication access control research, 6LoWPAN Authentication access method Define the method of data search through server such as Web or SOA

8

9

Requirements for sensor data sharing

• Resource Management

– Sensor Node Resource Management – Sensor Network Resource Management

• Data Management

– Exchange data among different domains – Exchange data among nations – Metadata establishment

• Sensor Node Deployment

– Sensor Node capacity, Standard RF – Topology – MAC – Power

Sensor Data Sharing Issues(1/2)

• Who search/access your data?

– User: Anyone, Authorized Users, Differentiated Access

• What types of Data?

–

Batch Data(Daily, Weekly, Monthly, Yearly) – Interactive Data(Currently holding data)

• Scale of Data Sharing

– Nations to Nations – Applications to Applications – Gateways to Gateways

10

Sensor Data Sharing Issues(2/2)

• Scope of Sharing Information

– Metadata (What Kinds of data we have) – Original Sensor Data – Metadata First and Data access secondly

• Which object to share

– Sensor Node – Gateway(Data node) – DB(Application) Sever – Metadata Manager

• How to exchange?(Communication Protocol)

– Disk, USB – Web x.0, Web Services(SOAP), FTP, Email, Socket Applications

11

SDSS – System Configuration

• Store all the metadata of nation on the each nation metadata server database
• The actual sensor data access through stored metadata available
• When metadata update, need the all metadata server update for metadata synchronization

12

USN Data Level Classification

Data Scope for global data sharing

Nation Wide Level : Select country for Global data sharing Application Level : Traffic, Weather, Structure Monitoring… Local Area Level : Seoul, Hanoi, Tokyo, Beijing… Network Level : WSN in specific area(Gateway, Data node) Node Level : Sensor Nodes

13

Nation Wide Metadata Server Country 1

Hierarchical Search Architecture

Weather Weather

WSN Application

Incheon Local area

Traffic Traffic

WSN Application

. . .

Seoul Local area Suwon Local area SN 1

Network

SN 2

Network

SN 3

Network

. . . . . . . . .

A B C n

Nation Wide Metadata Server Country 2

metadata 14

SDSS – System Design

precipitation meter Anemometer Anemoscope Pressure Gauge

Sink

Water Thermometer Thermometer

Basic Architecture Basic Architecture

Gateway (Data node) Gateway (Data node)

15

SDSS – System Design (Virtual Overlay Network)

Local Area Local Area

Seoul Seoul

Gateway

Application Database Metadata Server

SN 16

SDSS - System Design

Nation Wide Nation Wide

Metadata server W/ Web

KOREN

17

SDSS - System Design

Global Global

Metadata Server WSN Gateway Server DB

18

SDSS – Details Architecture

19

SDSS – Details Information

• Metadata Creation and Storage

– Generated sensor data in each USN stored in database and transmission on the sensor data server through Sink node – Harvest sensor data into metadata using XML – Store converted metadata on the metadata server – Exchange metadata via TEIN to on the metadata database of each nation

• User metadata access

– Access to the metadata server using web – Request the sensor data through the metadata – Output requested data on the web

• Metadata Sharing

– In each country has a Meta data server with database – Communicate using P2P Library to find servers – Exchange metadata and store all metadata on one server – When metadata updates, metadata sever need to exchange 20

SDSS - Features

• The sensor data using metadata can be their own security
• Available easily search through the metadata
• Real-time data

– Update sensor data in real time, real-time data acquisition will create the metadata available

• Synchronization between the server

– Metadata updates can be synchronized between servers (Because of less traffic, available a quick updates)

21

SDSS Implementation – Testbed

Sink Node & Sensor Nodes Metadata Service Server (Metadata DB) Local Server (Original Sensor DB)

Sink Node Sensor Node

• User environment :

Web x.0, mobile phone

• DB(Database) : Mysql
• Tool : editplus, xftp, ultraedit-32
• Language : php, xml, sql

23

SDSS Implementation

• National XML Metadata Create

Ex) Korea

– Si = City – Di = District – Ar = Area – Application = Application – Data Type = Type – Selected Sensor Data Address = URL – Input = Request Input Items

• Metadata Search System

– Create XML Classifieds search form

• Original Data File Transport Provide (P2P)

– User can check the sensor data and download as file in web

• Data Synchronization Between each Metadata Service Servers

– Apply the techniques for data synchronization between the service server

Metadata Structure(Korea)

24 City Di Ar Application Type Date URL Input

SDSS Implementation – User Screen

Map through Select Area Search Direct Input latitude and longitude Tree through Select Area

http://sensor.icnslab.net/

25

• User select the desired area in Google map or tree

SDSS Implementation – User Screen

Period set Value range set Selected location information

26

• Display the kinds of sensor data in the area, Set the property value range and the period range

SDSS Implementation – User Screen

Select file download method XML Meta Data

27

• Output the sensor data and XML metadata in selected area

SDSS Implementation – User Screen

Select file download method Chart download XML download

28

• User download the table and the chart, the xml

SDSS Implementation – User Screen

E-mail download XML & Chart Send E-mail

29

• User Send the files to e-mail

Expected Effect

• IP-USN Core Technology Joint Development and

Research Evaluation Exchange

– Core technology joint development – Exchange technology through periodical seminar – Exchange research evaluation – Exchange labor

• Application Service Joint Research

– Institute for Infocomm Research Singapore (IIR) – Camera Sensor Video Data Handling joint research – Use TEIN 3 research network – Publish International Conference paper by joint research evaluation

• Core Technology – SNMP Technology Joint Use Experience

– Joint usage of Fraunhofer FOKUS, Germany lab. technology

Pressure sensors Wearable vital sign sensors Accelerometers Video camera Ultrasound sensors concealed in the ceiling

31

Expected Effect

• Apply various application service in large scale USN environment(u-City, Green IT)
• Establish next generation u-sensor convergence network infrastructure

by leading ALL-IP policy through international strategy.

• Prepare international standard joint research through domestic

working group and APAN activity.

• Lead international standards and next generation u-IT infrastructure

trade market.
