Semantic Modularity for DSLs

Bruno C. d. S. Oliveira The University of Hong Kong

Can you give a 35m talk on Domain- specific type systems using Object Algebras?

Sure!

That should be easy I know Object Algebras well!

Humm… Wait a minute! How about domain-specific type systems?

A little twist on Sebastian’s invitation

• How to use type systems to develop:
• modular
• reusable
• separately compilable
• and type-safe (of course!)

DSL components

My work

• Lots of mentions to composition/modularity this

week.

• Highly overload term
• My work is primarily on semantic modularity
• Not syntax/parser modularity
• Not syntactic modularity

DSL Components

Syntactic (AST) Components

Binding \x . x, \x . (\y . y) x Arithmetic 1,3+4,5*6 Logic true, false, if true then false else true Graphics point(3,4), scale(2,point(4,5))

Semantic Components

Type-checking tcheck (n) -> Int Evaluation [x+y] -> [x] + [y] Pretty Printing pp (x+y) -> pp x + “ + “ + pp y

Syntactic Compositions

Arithmetic + Logic + Binding \x . if x then x+1 else x Arithmetic + Binding + Graphics \x y. point(10+x, point 10 + y)

Semantic Compositions

Evaluation + Pretty Printing [x+y] -> [x] + [y] pp (x+y) -> pp x + “ + “ + pp y Evaluation + Type- Checking [x+y] -> [x] + [y] tcheck (n) -> Int

The Matrix

The Matrix

Arithmetic Logic Binding Graphics Evaluation [n] -> n [true] -> true [x] = x [point(e1,e2)] = … Type- Checking tc(n) -> Int tc(true)

• > Bool

tc(x,e) -> lookup(x,e) tc(point(e1,e2))

• > Point

Pretty- Printing pp(n) -> n.toString pp(true) -> true.toString pp(x) = x pp(point(e1,e2 )) = …

How to Program such Components?

Meta-Programming

Reflection Casts

Dynamic Languages Superimposition

How to Program such Components/Compositions?

• How about:
• Type-safety? absence of pattern matching and/or

messageNotUnderstood errors; safe composition

• IDE support (code completion, refactoring,…)?
• Separate Compilation?
• Maintainability?
• We would like to program such components modularly

while still having all of the above!

The Matrix

Arithmetic Logic Binding Graphics Evaluation [n] -> n [true] -> true [x] = x [point(e1,e2)] = … Type- Checking tc(n) -> Int tc(true)

• > Bool

tc(x,e) -> lookup(x,e) tc(point(e1,e2))

• > Point

Pretty- Printing pp(n) -> n.toString pp(true) -> true.toString pp(x) = x pp(point(e1,e2 )) = …

Each cell can be viewed as a separate module! Each Module should allow for:

• Static type-checking
• Separate compilation

Each composition should ensure that interpretations handle all cases

The Matrix

Arithmetic Logic Binding Graphics Evaluation [n] -> n [true] -> true [x] = x [point(e1,e2)] = … Type- Checking tc(n) -> Int tc(true)

• > Bool

tc(x,e) -> lookup(x,e) tc(point(e1,e2))

• > Point

Pretty- Printing pp(n) -> n.toString pp(true) -> true.toString pp(x) = x pp(point(e1,e2 )) = …

The Expression Problem!

Object Algebras

Object Algebras

• Lightweight technique (a design pattern) to solve

the Expression Problem and various other (semantic) modularity issues.

• In their basic form, they work on common OO

languages (Java, C#, Scala, …)

• Inspired by type-theoretic encodings of datatypes

Theory

• Object Algebra interfaces are simply algebraic

signatures

• From an OO point to view they can be viewed both as:
• (Internal) Visitor interfaces
• Generic Abstract Factory Interfaces
• f some primitive built-in sorts

signature E lit: Int → E add: E × E → E A general algebraic sign

Extensibility

interface IntAlg<A> { A lit(int x); A add(A e1, A e2); }

interface IntBoolAlg<A> extends IntAlg<A> { A bool(Boolean b); A iff(A e1, A e2, A e3); }

Extensibility!

Demo

Uses of Object Algebras

• Batch Script Language
• Oliveira and Cook, Extensibility for the Masses: Practical Extensibility with

Object Algebras, ECOOP (2012)

interface BatchFactory<E> { E Var(String name); // variable reference E Data(Object value); // simple constant (number, string, or date) E Fun(String var, E body); E Prim(Op op, List<E> args); // unary and binary operators E Prop(E base, String field); // field access E Assign(Op op, E target, E source); // assignment E Let(String var, E expression, E body); // control flow E If(E condition, E thenExp, E elseExp); E Loop(Op op, String var, E collection, E body); E Call(E target, String method, List<E> args); // method invocation E In(String location); // reading and writing forest E Out(String location, E expression); }

• Fig. 13. Batch script language abstract syntax

Uses of Object Algebras

• Batch Script Language
• Oliveira and Cook, Extensibility for the Masses: Practical Extensibility with

Object Algebras, ECOOP (2012)

interface PartitionFactory<E> extends BatchFactory<E> { E Other(Object external, E... subs); E DynamicCall(E target, String method, List<E> args); E Mobile(String type, Object obj, E exp); }

Uses of Object Algebras

• One-pass Modular (subset of) C compiler

long some_function(); /* int */ other_function(); /* int */ calling_function() { long test1; register /* int */ test2; test1 = some_function(); if (test1 > 0) test2 = 0; else test2 = other_function(); return test2; }

• Rendel et al., From Object Algebras to Attribute Grammars, OOPSLA (2014)

Uses of Object Algebras

• QL Language with Object Algebras
• Gouseti et al., Extensible Language Implementation with Object Algebras,

GPCE (2014)

form HouseOwning { soldHouse: "Did you sell a house?" boolean boughtHouse: "Did you buy a house?" boolean if (soldHouse) { sellingPrice: "Selling price:" integer privateDebt: "Private debts:" integer valueResidue: "Value residue:" integer = (sellingPrice - privateDebt) } }

Uses of Object Algebras

• Streams a la Carte

int sum = widgets.stream() .filter(b -> b.getColor() == RED) .mapToInt(b -> b.getWeight()) .sum();

• Biboudis et al., Streams à la carte. Extensible Pipelines with Object Algebras.

submitted

Some Work on Object Algebras

• First paper
• Oliveira and Cook, Extensibility for the Masses: Practical Extensibility with

Object Algebras, ECOOP (2012)

• Increasing the expressive power of object

algebras:

• Oliveira et al., Feature-Oriented Programming with Object Algebras,

ECOOP (2013)

• Rendel et al., From Object Algebras to Attribute Grammars, OOPSLA

(2014)

• Domain-Specific Languages
• Gouseti et al., Extensible Language Implementation with Object Algebras,

GPCE (2014)

• Biboudis et al., Streams à la carte. Extensible Pipelines with Object
• Algebras. submitted

Pre-History of Object Algebras

• Church Encodings of Datatypes as (Haskell) Type

Classes

• Hinze, Generics for the Masses, ICFP (2004) and JFP (2006)
• Oliveira and Gibbons, TypeCase: A Design Pattern for Type-Indexed Functions, HW

(2005)

• Extensibility: Solving the Expression Problem (Haskell)
• Oliveira et al., Extensible and Modular Generics for the Masses, TFP (2006)
• Applications to Embedded DSLs (Haskell & Scala)
• Carrete et al., Finally tagless, partially evaluated: Tagless staged interpreters for

simpler typed languages, APLAS (2007) & JFP (2009)

• Hofer et al., Polymorphic Embedding of DSLs, GPCE (2008)
• Rompf and Odersky, Lightweight Modular Staging, GPCE (2010)
• Modular Visitors & Church Encodings (Scala)
• Oliveira et al., The Visitor Pattern as a Reusable Type-Safe Component, OOPSLA

(2008)

• Oliveira, Modular Visitor Components, ECOOP (2009)

Structure-Shy Components

Semantic Components

FreeVars fv(e1+e2) -> fv(e1) + + fv(e2) Substitution [x -> e] (e1+e2) -> [x -> e] e1+ [x -> e] e2

The Matrix

Arithmetic Logic Binding Graphics FreeVars Boring! Boring! Interesting! Boring! Substitution Boring! Boring! Interesting! Boring!
