samuel.marchal@uni.lu 23/05/12 Semantic Exploration of DNS Samuel Marchal, J´ erˆ ome Fran¸ cois, Cynthia Wagner and Thomas Engel
Motivation Semantic exploration Experiments and Results Conclusion Outline 1 Motivation 2 Semantic exploration 3 Experiments and Results 4 Conclusion 2 / 18
Motivation Semantic exploration Experiments and Results Conclusion Outline 1 Motivation 2 Semantic exploration 3 Experiments and Results 4 Conclusion 3 / 18
Motivation Semantic exploration Experiments and Results Conclusion Why DNS brute forcing ? DNS scanning: ◮ Test DNS names by sending requests to a DNS recursive server ◮ Network mapping: discover all machines of a domain ◮ penetration testing ◮ network security assessment (prevention) ◮ recon stage to craft attack (find accessible services) ◮ use by worms to spread themselves 4 / 18
Motivation Semantic exploration Experiments and Results Conclusion Alternative to IP scanning ◮ Provided services (ftp, www, etc.) � = network interfaces ◮ Machines are not probed directly (DNS requests) ◮ Can be enhanced by using multiple open recursive servers ◮ Reduce the search space (particularly in IPv6) uni.lu DNS authoraitative WWW server R DNS recursive A server FTP R MAIL google.com WWW A FTP DNS DNS scanning IP scanning authoraitative MAIL server 5 / 18
Motivation Semantic exploration Experiments and Results Conclusion Current Approaches ◮ How names are defined? ◮ by human and easy to remember → pc1, pc2, atlanta, boston, etc. ◮ to reflect the provided service → www, ftp, ssh, etc. ◮ → same names often used → scan the most popular names ◮ dictionary based tools ◮ DNSenum: 266 930 names by default ◮ fierce: 1 895 names by default ◮ tool relying on natural language ◮ SDBF: domain name generator (domain names features, Markov chain model) 6 / 18
Motivation Semantic exploration Experiments and Results Conclusion Outline 1 Motivation 2 Semantic exploration 3 Experiments and Results 4 Conclusion 7 / 18
Motivation Semantic exploration Experiments and Results Conclusion Names definition Domain names are given by human: ◮ Reflect a provided service (ftp, www, etc.) ◮ Follow numerical patterns (ftp1, ftp2) ◮ Share a common semantic field 8 / 18
Motivation Semantic exploration Experiments and Results Conclusion Names discovery Given a subdomain ⇒ generate new subdomains: 9 / 18
Motivation Semantic exploration Experiments and Results Conclusion Tool overview ◮ Generation of semantically close names ◮ name split in words ◮ generate similar words using Disco ◮ Enumeration of numbers marsserver1 uni.lu split mars server 1 www related numerical ftp SDBF ns1 names increment ns2 Fierce venus pc 2 marsserver1 neptun computer 3 DNSenum paris jupiter mail 4 london pc2room103 merge venuspc3.uni.lu jupitermail5.uni.lu 10 / 18
Motivation Semantic exploration Experiments and Results Conclusion Semantic exploration: Disco Horizontal exploration surf 0 valid not valid disco rugby whitewater help reggae runner skate soccer surfing … ... 1 disco disco d i s c o Vertical exploration disco cricket football assistance football voleyball … ... aid … ... basketball … ... 2 hedgehog athlete broadcaster relay tunes …… . disco disco disco disco concolor announcer songs extensions … ... 3 badger …… . piglet …… . tune …… . disco disco 4 roadgoing mockingbird …… .. freestyle sprint …… .. 11 / 18
Motivation Semantic exploration Experiments and Results Conclusion Outline 1 Motivation 2 Semantic exploration 3 Experiments and Results 4 Conclusion 12 / 18
Motivation Semantic exploration Experiments and Results Conclusion Method and Results ◮ 24 popular domains ◮ 3 tools: DNSenum, Fierce, SDBF ⇒ initial list of subdomains % Imp i = | New i | | Init i | , i ∈ { SDBF , DNSenum , Fierce , overall } 13 / 18
Motivation Semantic exploration Experiments and Results Conclusion Detailed Results SDBF Fierce DNSenum Overall Domains | Init | | New | % Imp | Init | | New | % Imp | Init | | New | % Imp | Init | | New | % Imp livejasmin.com 24 39 162 20 14 70 18 14 77 37 33 89 ebay.com 123 284 230 115 257 223 185 225 121 284 158 55 google.com 69 125 181 84 87 103 83 108 130 149 77 51 vdl.lu 15 15 100 11 13 118 16 12 75 23 11 47 amazon.com 78 82 105 55 72 130 75 75 100 132 52 39 msn.com 207 281 135 196 246 125 236 223 94 372 140 37 baidu.com 369 243 65 178 280 157 238 253 106 478 157 32 microsoft.com 115 121 105 91 90 98 97 98 101 189 56 29 apple.com 141 128 90 65 116 178 130 106 81 241 70 29 ask.com 88 82 93 78 65 83 79 71 89 135 40 29 all domains 2057 1739 84 1520 1558 102 1788 1565 87 3170 954 30 ◮ From 84% to 102% of newly discovered names ◮ Up to 230% of improvement ◮ Complementarity ⇒ 30 % overall improvement 14 / 18
Motivation Semantic exploration Experiments and Results Conclusion Overhead ◮ Average of 40,000 probes per domain // SDBF & DNSenum: 260,000 (6 times less) 15 / 18
Motivation Semantic exploration Experiments and Results Conclusion Outline 1 Motivation 2 Semantic exploration 3 Experiments and Results 4 Conclusion 16 / 18
Motivation Semantic exploration Experiments and Results Conclusion Conclusion ◮ New methods to brute-force DNS: ◮ semantic relatedness ◮ incremental techniques ◮ Results: ◮ able to generate valid names... ◮ ... mainly not present in well used dictionaries → complementarity ◮ low overhead ◮ Future works: ◮ use other databases ◮ improve semantic relatedness metric 17 / 18
samuel.marchal@uni.lu 23/05/12 Semantic Exploration of DNS Samuel Marchal, J´ erˆ ome Fran¸ cois, Cynthia Wagner and Thomas Engel
