Science Program at Test Facilities

Mark J. Hogan SAREC Meeting at SLAC, July 2013

FACET ● ESTB ● NLCTA ● ASTA

2

ESTB NLCTA FACET ASTA 20-23 GeV 2-15 GeV & single e- 5 MeV 60-220 MeV

Gorgeous view to physicist…

SLAC Electron Beam Test Facilities 5 MeV to 23 GeV

Very Productive User Run at FACET Every Program Expecting Publishable Results

3

Switching Mechanisms in Ultrafast Electromagnetic Pulses Demonstration of Gigavolt- per-meter Accelerating Gradients in Dielectric Wakefield Accelerating Structures An Automated Method for Dispersion Free Steering THz Reconstruction of Two- Bunch Profile Mono-energetic Acceleration in a Beam-driven Plasma Wakefield Accelerator

NLCTA Continues to be an Incredibly Productive Facility

4

First Acceleration Observed in Laser Driven "Accelerator on a Chip"

E-163 XTA

Higher Brightness Beams from X-Band Photoinjector Large Aperture RF Undulator with Flexible Polarization, Wavelength Control

Laser Room

λ ~ 0.8µm

NLCTA

1590 ¡nm ¡only, ¡V=0 1590 ¡nm ¡only, ¡V=85 ¡kV 1590 ¡nm ¡only, ¡V=170 ¡kV 1590 ¡nm ¡only, ¡V=255 ¡kV 795 ¡nm ¡+1590 ¡nm, ¡V=255 ¡kV 4th 5th 6th 7th

• D. Xiang, et al, PRL 108, 024802 (2012)

Coherent optical vortices from electron beams Echo-7 Harmonics EEHG in the energy space Cascaded Optical IFEL

The EEHG beamline and laser systems at NLCTA enable broad range of diverse experiments

Tunable THz generation through EEHG

• M. Dunning, et al. PRL 109, 074801 (2012)
• M. Dunning et al., PRL 110, 244801 (2013)
• E. Hemsing, et al, Nature Physics (2013)
• E. Hemsing, et al, Submitted to PRL (2013)

Echo (program) Has Enabled Broad Science at NLCTA

ASTA Program Benefits Near and Medium Term Applications

6

Gun & Cathode Development

• Study effects of material, geometry under high-power
• Cathode & gun development with focus on LCLS
• Commission gun for LCLS-II

Copper-silver structures operating reliably above 175 MV/m

ESTB is a Unique Test Beam Resource

7

• World’s only high-energy primary electron

beam for large scale Linear Collider MDI and beam instrumentation studies

• Exceptionally clean and well-defined

primary and secondary electron beams for detector development

Test of a RICH-Prototype Based on CsI- GEMs for an Electron-Ion Collider (T-507) HERA-B e-Cal modules beam test for GEp(5) at J- Lab

Evolution of FACET to Enable New Science

• Constructed with long term goal of PWFA demonstration
• Operates as a National User Facility
• FACET facility developments offer shared benefit to broader

community

• All SLAC accelerator test facilities will operate as user facilities

in the future offering mutually beneficial operations of test facilities: experimental expertise and user experience => efficiency

• Upgrades benefit all all programs (TCAV, laser, SS window,

motors)

8

9

10TW FACET Ionization Laser: Conceived, planned, installed, commissioned in < 7 months!

Laser System in new S20 Laser Room Laser Transport in Klystron Gallery Plasma Integration Optics on Beamline Molten Li Vapor Source

E200 Uses Laser to Turn Lithium Vapor into a Plasma – Energy, Axicon Geometry Determine the Plasma Length

10

40 ¡cm ¡long ¡argon ¡plasma from ¡2 ¡degree ¡axicon ¡at ¡UCLA ¡

This run (~250mJ): Coming in November (>500mJ):

E-210 Trojan Horse needs Better Synchronization

• Implement laser-electron beam timing diagnostic via EOS
• Release electrons in plasma wave with focused, ~mJ, synchronized laser

pulse to generate highest quality witness beam (∊n <10-8 m-rad)

11

Laser pulse 20 TW / 30 fs

Toroidal mirror

He gas jet Magnet

x

• r

a y C C D

Grating Betatron x-rays LWFA 10‘s MeV electrons

FACET electron beam 20 GeV, 3 nC

Filter to block laser Beam dump / e- spectrometer

Sample X-ray spectrometer

Use LWFA generated betatron radiation to probe extreme conditions generated by focussed, compressed FACET e- beam

12

FACET electron pump / x-ray probe experiments

Now operating the tools to make and measure beams for the two bunch PWFA experiments

X-band TCAV installed in Sector 20

13 V(t) e σz σx 2.44 m βc βp 〈Δx〉$ Δψ ≈ 60° 1.00 90°

Time

Measured Temporal Profile

3 2 1 1 2 3 2 1 1 2 x (mm) y (mm) Profile Monitor OTRS:LI20:3075 24Mar2013 02:20:07

Time

Measured Temporal Profile

Collimator IN Collimator OUT

Exploring Addition of a Photoinjector in 2015 Independent Injection/control of Witness Bunch

• 50-100MeV, injected for staging dielectric & plasma accelerators
• Use 100 fold difference in energy with bend/chicane to merge
• Upgrade dumpline to dump spent beam and preserve emittance of

accelerated beam

• Need feedback on beam parameters from users

14

20GeV Beam 200MeV Witness

Single Shot Emittance Measurement with Interference of Edge Radiation

E-210, witness injector experiments will require new beamline for better emittance measurements

Commissioning Positron Systems in FY14 Run

16

5.7GeV in 39cm

Focusing and acceleration of positrons has been characterized at low densities

• High-gradient positron acceleration is possible
• Can use wake of an electron or positron beam
• Need to iterate plasma source to minimize

emittance growth but preserve high-gradients (hollow channels)

• FACET will make first tests of high-gradient

positron acceleration in the next couple years

• Phys. Rev. Lett. 90, 205002 (2003)

17

New proposals for 2013 SAREC review (FACET)

• High-quality witness bunch generation and acceleration in a beam-driven

wakefield accelerator by density down-ramp injection, Jens Osterhoff, DESY

• Temporal Limits of Electron-Phonon Interaction in Metal-Insulator

Transitions, Electro-magnetostriction and Plastic Deformation, Ioan Tudosa, University of Pennsylvania

• Single-Shot Imaging of THz-Induced Switching in Information Technology

Materials, Hermann Dürr, Stanford

• Proposed Experiment for Single Shot Femtosecond Beam Pulse Length

Measurements at FACET using the Angular Distribution of Coherent Diffraction Radiation, Ralph Fiorito, University of Maryland

• Monochromatic 10 MeV Gammas by a Miniature Undulator, for

Experiments at the Intersection of Photonuclear and Materials Science. Michael Di Rosa, LANL

• Gyromonotron as an instrument for electron beam cooling in accelerators,

Volodymyr Khoruzhi, Kharkov Institute of Physics and Technology New proposals are direct result of the high quality of FY13 run.

18

New Proposals for 2013 SAREC Review (NLCTA, ESTB, ASTA)

• Biological effectiveness of very high-energy electron radiation therapy

– implications for a novel radiation treatment system for cancer, Billy

• W. Loo Jr, MD, Department of Radiation Oncology, Stanford
• Suppression of Spontaneous Undulator Radiation at NLCTA, Daniel

Ratner, SLAC

• Development of Electron Radiography for Material Science, Frank E.

Merrill, LANL

• Advanced IFEL bunching experiments at NLCTA, P. Musumeci, UCLA
• Channeling and Volume-Reflection Studies of High-Energy Electrons

in Crystals, H.-Ulrich (Uli) Wienands, SLAC

• High gainX-band active SLED-II pulse compression experiment, Jay L.

Hirshfield , Omega-P, Inc. SLAC is transitioning to operate all of its test facilities in the “user facility” mode with external program advisory committees reviews.

Science/User Perspective

19

• FACET development to address needs of all programs (TCAV, laser, SS

window, motors = addressing needs of the users)

• It was great run at FACET, next run is coming, short time to publish,

necessary for community/DOE to support run time.

• New directions (gamma beams, radiography, …diagnostics)
• Wide range of facilities available at SLAC offer one stop shopping for users
• FACET operates as a National User Facility and is living up to its’ potential

with machine performance routinely exceeding expectations

• Upgrades in the works will benefit PWFA program but also serve the entire

community and help broaden the program

• Offer one stop shopping for users => efficient user experience
• NLCTA transition to user operation mode will focus on reliability and

predictable, well characterized beam quality.
