SCAR RADIOGRAPHY

SCAR and ‘Baby’ SCAR GAMMA RADIOGRAPHY

SLIDE 2

Who we are

Conventional and Advanced NDT and Inspection Services Oil and Gas, Refinery, Petrochemical, Heavy Industry, Mining Over 400 personnel including more than 300 inspectors Thailand headquarters with International expertise since 1979

SLIDE 3

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

SCAR

Small Controlled Area Radiography

Two different SCAR systems

1. ‘Baby’ SCAR 989 Se 75, (Max 20 Curie) 2. SCAR 959M. 80 Ci of Se 75 or 15 Ci of Ir 192

SLIDE 4

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Se-75 working range of 5-30mm steel thickness
Ir 192 working range of 10-50mm steel thickness
Se-75 has a softer gamma ray spectrum (66-401 keV)

than Iridium-192 (295-612 keV)

Se 75 = Half Life of 119.8 days, (120 days)
Ir 192 = Half Life of 73.83 days. (74 days)

Approx 46 days difference

SCAR

SLIDE 5

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Baby SCAR Projector

SLIDE 6

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

SCAR Radiography

Se75 is mid-thickness gamma radiography
‘Baby’ SCAR has a tungsten shield
Weighs 7.5 kg
‘Encapsulated source’ NEVER leaves container

SLIDE 7

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Baby SCAR Projector

Baby SCAR container showing lock device and beam port.

SLIDE 8

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Octagonal Cross Section Pellet shape improves Geometric Unsharpness therefore better quality radiograph

SLIDE 9

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Octagonal Cross Section

Diagonal of the octagonal pellet is 1.145 times pellet

diameter. Diagonal of cylinder
f the same diameter,

is 1.414 times its diameter. The pellet geometry allows source to be up to 23.5%

closer. This increases exposure

rate per Curie at the object.

SLIDE 10

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Projector Placement

SLIDE 11

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Shielding Projector

SLIDE 12

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Survey Safe Distance

SLIDE 13

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Record Measurement of Safe Zone

SLIDE 14

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Reduced Area of Safe Zone From Football Pitch Size to Centre Circle Or Less

SLIDE 15

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

Baby SCAR Radiography Advantages of SCAR System

 Safety Improvements - daylight working  No Downtime  Allows Continuous Construction Work  Schedules Maintained or Improved  On-line Radiography - Allows Instant Welder Performance Monitoring  ‘Nucleonics’ Type instruments Not Affected

SLIDE 16

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

SCAR Summary

SCAR + Baby SCAR is safe to use 24 hours a day - no need for specific

radiography windows.

Cost efficient.
The barriered area is always very small, plus collimation less than 10 m

diameter (SCAR).

Safe area is easier to see & control.
SCAR will rarely affect other work.
Equipment fits most pipe geometries.
SCAR can replace most conventional radiography when planned in

advance.

SLIDE 17

DACON INSPECTION SERVICES P E R F O R M A N C E YO U C A N T R U S T

How Can We Help?

Contact Tim Shaw Chief Marketing Officer Email : info@dacon-inspection.com Mobile Phone : +66 (0) 89 245 9966 www.dacon-inspection.com
