KEYNOTE 2 GUIDE DELINE LINES S FOR THE PROVIS VISION ION OF TWO WHEELERS LERS FACILITIES ILITIES IN MALAYSI SIA Ir. RAZHIAH BINTI WAHAB Director of Geometric & Traffic Engineering Roads & Bridge Engineering Specialists Road

slide-1
SLIDE 1

MIROS & PIARC INTERNATIONAL SEMINAR

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

BERJAYA TIMES SQUARE HOTEL, 23-25 APRIL 2019

  • Ir. RAZHIAH BINTI WAHAB

Director of Geometric & Traffic Engineering Roads & Bridge Engineering Specialists Road Branch, Public Works Department Malaysia

GUIDE DELINE LINES S FOR THE PROVIS VISION ION OF TWO WHEELERS LERS FACILITIES ILITIES IN MALAYSI SIA

KEYNOTE 2

slide-2
SLIDE 2

GUIDELINES FOR THE PROVISION OF TWO WHEELERS FACILITIES IN MALAYSIA

Ir Razhiah binti Wahab Director of Geometric & Traffic Engineering Roads & Bridge Engineering Specialists Roads Branch, Public Works Department of Malaysia Mohd Syukri bin Md Hanafiah Senior Civil Engineer Road Design Unit, Roads & Bridge Engineering Specialists Roads Branch, Public Works Department of Malaysia

2

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

slide-3
SLIDE 3

CONTENTS OF PRESENTATION

➢ Overview of Motorcycle Scenario in Malaysia ➢ History of Guidelines on Two Wheelers Facilities ➢ JKR Guidelines on Two Wheelers Facilities

  • NTJ 33/2015 Guidelines For Motorcycle Facilities
  • ATJ 35/2018 Geometric Guideline For Exclusive Motorcycle
  • ATJ 10/86 (Pindaan 2018) A Guide On The Design of Cycle Track

3

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

slide-4
SLIDE 4

Overview of Motorcycle Scenario in Malaysia

  • Vehicle registration

4

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Source: 2017 Road Traffic Volume Malaysia

45.8%

slide-5
SLIDE 5

Overview of Motorcycle Scenario in Malaysia

  • Vehicle composition (JKR Annual National Traffic Census)

5

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Source: 2017 Road Traffic Volume Malaysia

slide-6
SLIDE 6

Overview of Motorcycle Scenario in Malaysia

  • Accident Data

6

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Source: Statistical Report Road Accidents Malaysia, RTD 2018 ROAD ACCIDENTS FATALITIES IN MALAYSIA (2008-2017)

2017: Motorcyclists 64.5%

slide-7
SLIDE 7

Overview of Motorcycle Scenario in Malaysia

7

  • Motorcycle lane length - JKR Federal Road
slide-8
SLIDE 8

Overview of Motorcycle Scenario in Malaysia

8

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Source: JKR Statistik Jalan Edisi 2018

slide-9
SLIDE 9

Overview of Motorcycle Scenario in Malaysia

  • Motorcycle lane length - Tolled Highway (exclusive motorcycle lane)

9

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Source: JKR Statistik Jalan Edisi 2018

slide-10
SLIDE 10

History of Guidelines on Two Wheelers Facilities

ATJ 10/86 A Guide on The Design of Cycle Track

10

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

slide-11
SLIDE 11

ATJ 10/86 A Guide on The Design of Cycle Track

Purpose of Guidelines:

  • Help designer decide the minimum value of design criteria to be

used when designing cycle tracks (bicycle and motorcycle).

  • A very simple guideline

11

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

slide-12
SLIDE 12

JKR Guidelines on Two Wheelers Facilities

  • 1. NTJ 33/2015 Guidelines for Motorcycle Facilities
  • 2. ATJ 35/2018 Geometric Guideline for Exclusive Motorcycle Lane
  • 3. ATJ 10/86 (Pindaan 2018) A Guide on The Design of Cycle Track*

* final editing stage

12

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

slide-13
SLIDE 13

NTJ 33/2015 Guidelines for Motorcycle Facilities

13

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Scope of Document

NO. TOPIC 1. INTRODUCTION 2. WARRANTS FOR MOTORCYCLE FACILITIES 3. EXCLUSIVE MOTORCYCLE LANE 4. NON-EXCLUSIVE MOTORCYCLE LANE 5. TREATMENT OF NON-EXCLUSIVE MOTORCYCLE LANE AT POINTS OF CONFLICT 6. MOTORCYCLE SHELTER 7. ROAD LIGHTING 8. TRAFFIC BARRIER 9. TRAFFIC MANAGEMENT PLAN AT MOTORCYCLE LANE FOR MAINTENANCE AND CONSTRUCTION WORKS

slide-14
SLIDE 14

NTJ 33/2015

  • The objective is to provide engineering practitioners with better understanding
  • f motorcyclists’ safety needs and incorporate the needs in the upgrading and

maintenance of existing roads and the planning, design and construction of new roads.

  • Design consideration for motorcycle facilities:
  • Understanding motorcyclists behavior, average height and built
  • Historical motorcycle accident data
  • Motorcycles design, characteristics and capabilities
  • Willingness to use the road as planned and designed
  • Adopting sound engineering judgment

14

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Introduction
slide-15
SLIDE 15

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

NTJ 33/2015

Numerical Warrants Type of Roads Expressways Non Expressways Section of Expressways and Non Expressways 1. Total Volume of Traffic > 15,000 vehicle per day > 15,000 vehicle per day along a 2-lane 2-way road OR > 10,000 vehicle per day per lane along a multi-lane road

  • For Section with Expressway Road

Conditions, Warrant for Expressways shall apply. OR

  • For Section with Non Expressway Road

Conditions, Warrant for Non Expressways shall apply. OR

  • For combination of Expressway and Non

Expressways along the road, the engineer’s experience and engineering judgment is required to decide the most appropriate form of motorcycle facilities. 2. Percentage of Motorcycles > 30% of main stream traffic > 30% of main stream traffic 3. Total Number of Motorcycle Accidents > 5 accidents per km per year > 5 accidents per km per year 4. Side Friction Scores Not Applicable < 30 friction scores 5. Combination of 1,2,3 and/or 4

  • Can be provided even if not fulfilling criteria 1, 2, 3 or 4 if its

absence would be detrimental to the safety of motorist/other road user.

  • Warrants if there is a high likelihood of warrants 1, 2, 3 and/or 4

being met within 5 years of design life of the project. 15

  • Warrants for Motorcycle Facilities
slide-16
SLIDE 16

NTJ 33/2015

  • The topics discussed in this chapter include motorcycle design and characteristics, capacity and

level of service (LOS) for exclusive motorcycle lane.

  • Eventually, JKR published a separate guideline on exclusive motorcycle lane, namely the

ATJ35/2018 Geometric Guideline for Exclusive Motorcycle Lane. The topics as in this chapter of NTJ, are further deliberated in the new ATJ.

16

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Exclusive Motorcycle Lane
slide-17
SLIDE 17

NTJ 33/2015

  • Adjacent to main carriageway
  • Significantly improve safety
  • Design requirement
  • 2.0m lane width (max 2.5m)
  • Red colour separator with road studs

17

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Non-Exclusive Motorcycle Lane (NEML)
slide-18
SLIDE 18

NTJ 33/2015

  • Potential conflict areas
  • At-grade intersections
  • Interchanges (normally passing through)
  • Bus / taxi stop

18

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Treatment of NEML at Points of Conflict

‘Motorcycle Storage’ near LRT Bandaraya Station T-intersection

slide-19
SLIDE 19

NTJ 33/2015

  • Road signs and markings (also mentioned in ATJ 35/2018)

19

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

slide-20
SLIDE 20

NTJ 33/2015

  • Safer environment for motorcyclists to stop / rest especially during wet condition
  • Shelter type
  • Stand alone
  • Under bridge / structure
  • Topics covered include proposed shelter amenities, area size as well as typical layouts for both

shelter types.

  • JKR is currently finalizing the standard drawing for the shelter types.

20

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Motorcycle Shelter

Motorcycle shelter in Jalan Kuching (north-bound)

slide-21
SLIDE 21

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

21

slide-22
SLIDE 22

22

slide-23
SLIDE 23

23

slide-24
SLIDE 24

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

NTJ 33/2015

24

  • Road Lighting (also mentioned in ATJ 35/2018)
slide-25
SLIDE 25

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

NTJ 33/2015

25

  • Road Lighting
slide-26
SLIDE 26

NTJ 33/2015

  • Semi-rigid barriers with TL3 (recommended), minimum TL2
  • Additional rub rail
  • Special impact attenuators

26

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Traffic Barrier (also mentioned in ATJ 35/2018)
slide-27
SLIDE 27

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

NTJ 33/2015

27

  • Traffic Management Plan at Motorcycle Lane
slide-28
SLIDE 28

NTJ 33/2015

  • TMP should be in accordance to JKR Guideline ATJ 2C/85 (Pindaan 2017)
  • Adequate number of signs
  • Clear and definitive signs
  • Advance warning signs (where appropriate)
  • Proper delineation especially night time

28

  • Traffic Management Plan at Motorcycle Lane

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Upgrading works of Motorcycle Lane at the Federal Highway FT002

slide-29
SLIDE 29
  • To assists road designers on the design criteria and approach to provide uniform

and standard design for Exclusive Motorcycle Lane (EML)

  • It is imperative that being motorcycles being given special consideration and

provision of EML for the safety of the rides and pillions. *This guideline is to be used in conjunction with other guidelines that have been or will

be produced by JKR.

29

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Objective

ATJ 35/2018 Geometric Guideline for Exclusive Motorcycle Lane

slide-30
SLIDE 30

ATJ 35/2018

  • Scope of Document

30

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION NO. TOPIC SUB-TOPIC 1. INTRODUCTION 2. MOTORCYCLE LANE MOTORCYCLE LANE CLASSIFICATION / HIERARCHY CLASSIFICATION AND DESIGN DESIGN STANDARDS FOR MOTORCYCLE LANE STANDARDS ACCESS CONTROL SELECTION OF DESIGN STANDARDS TOPOGRAPHY 3. DESIGN CONTROL AND CRITERIA DESIGN MOTORCYCLE CHARACTERISTICS SPEED CAPACITY 4. ELEMENT OF DESIGN SIGHT DISTANCE HORIZONTAL ALIGNMENT VERTICAL ALIGNMENT COMBINATION OF HORIZONTAL AND VERTICAL ALIGNMENT

slide-31
SLIDE 31

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

NO. TOPIC SUB-TOPIC 5. CROSS SECTION ELEMENTS PAVEMENT LANE WIDTH & MARGINAL STRIPS FOR MOTORCYCLE LANE SHOULDERS TRAFFIC BARRIERS UNDERPASS 6. TREATMENTS FOR SPECIAL TREATMENT OF EML APPROACHING EGRESS AND INGRESS CONDITIONS TREATMENT OF EML APPROACHING PEDESTRIAN CROSSING 7. OTHER ELEMENTS DRAINAGE AFFECTING GEOMETRIC LIGHTING DESIGN UTILITIES SIGNING AND MARKINGS EROSION CONTROL, LANDSCAPE DEVELOPMENT AND ENV. IMPACTS

31

  • Scope of Document (cont’)
slide-32
SLIDE 32

ATJ 35/2018

  • In normal road design practice, all vehicle types share the same carriageway

travelling from one destination to another.

  • With the high number of motorcycles, the likelihood for fatal accident to occur

involving motorcyclists is greater.

  • Separating motorcycles from other vehicles in traffic by providing motorcycle

lanes is a good engineering measure to improve the safety of motorcyclists.

  • There has been no established guideline for the design of exclusive motorcycle

lanes.

  • This guideline is to be used in conjunction with other guidelines that have been
  • r will be produced by JKR.

32

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Introduction
slide-33
SLIDE 33

33

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Exclusive Motorcycle Lane at the Federal Highway FT002

slide-34
SLIDE 34

ATJ 35/2018

  • Exclusive motorcycle lane is proposed to be constructed at:
  • New road with minimum JKR R5 standard
  • Existing road which passed the warrant for construction of motorcycle lane (NTJ 33/2015)
  • Provision of motorcycle lane reserve has been considered in other JKR guidelines;
  • ATJ 8/86 (Pindaan 2015) A Guide on Geometric Design of Roads
  • NTJ 33/2015 Guideline for Motorcycle Facilities

34

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Design Application

Source: ATJ 8/86 (Pindaan 2015)

slide-35
SLIDE 35

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Source: NTJ 33/2015

35

slide-36
SLIDE 36

ATJ 35/2018

  • Motorcycle class : 250cc and below
  • Rider’s eye height : 1.49 m
  • Design speed : 50 – 90 km/h

36

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Design Criteria
slide-37
SLIDE 37

ATJ 35/2018

  • Horizontal alignment
  • Superelevation rates, e (e max 8%)
  • Minimum radius

37

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Design Elements
slide-38
SLIDE 38

ATJ 35/2018

  • Vertical alignment
  • K values

38

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Design Elements
slide-39
SLIDE 39

ATJ 35/2018

  • Pavement structure
  • Flexible pavement (advisable)
  • Rigid pavement

39

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Cross Section Elements

Flexible pavement Rigid pavement

slide-40
SLIDE 40

ATJ 35/2018

  • Typical cross section – with shelter area

40

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Cross Section Elements
slide-41
SLIDE 41

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Typical cross section – without shelter area

ATJ 35/2018

41

  • Cross Section Elements
slide-42
SLIDE 42

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

ATJ 35/2018

  • Egress & Ingress

42

  • Treatments for Special Conditions

Egress Ingress

slide-43
SLIDE 43

ATJ 35/2018

  • Drainage – flat terrain

43

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Other Elements
slide-44
SLIDE 44

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

ATJ 35/2018

  • 44
  • Other Elements
slide-45
SLIDE 45

ATJ 10/86 (Pindaan 2018) A Guide on The Design of Cycle Track

  • Scope of Document

45

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION NO. TOPIC 1. INTRODUCTION 2. GENERAL CONSIDERATION 3. PLANNING FOR CYCLE TRACK 4. ELEMENTS OF DESIGN 5. JUNCTION AND CROSSING 6. DRAINAGE 7. TRAFFIC CONTROL DEVICE AND FACILITIES 8. MAINTENANCE AND MANAGEMENT 9. OTHER REQUIREMENTS

slide-46
SLIDE 46

ATJ 10/86 (Pindaan 2018)

  • Cycle tracks - Paths, trails, lanes and routes, cycle crossings and intersections,
  • verpass and other related facilities which serve non-motorized two-wheelers.
  • Two types of cycle track:
  • Non-exclusive (on carriageway)
  • Exclusive (off carriageway)
  • The objective is to provide designers with proper cycle tracks design

consideration and criteria which incorporates safety aspects.

46

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Introduction
slide-47
SLIDE 47

ATJ 10/86 (Pindaan 2018)

  • Convenient
  • Accessible
  • Safe
  • Comfortable
  • Attractive
  • Design of cycle tracks should consider categories of cyclists and their

characteristics

47

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • General Consideration
slide-48
SLIDE 48

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

ATJ 10/86 (Pindaan 2018)

48

  • General Consideration
slide-49
SLIDE 49

ATJ 10/86 (Pindaan 2018)

  • Route location
  • Demand for cyclists (existing or potential)
  • Integrated with transport and land use planning
  • Consideration of Provision (either on @ off carriageway)
  • Traffic reduction
  • Speed reduction
  • Traffic management
  • Redistribution of carriageway lanes
  • Segregation of cycle tracks from main carriageway
  • Conversion of footways to unsegregated shared use cycle track

49

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Planning for Cycle Track
slide-50
SLIDE 50

ATJ 10/86 (Pindaan 2018)

  • Design speed : 30 – 50 km/h
  • Minimum radius :
  • Superelevation rates, e (e max 3%)
  • Desirable vertical grades : 5% (max 10%)

50

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Elements of

Design

slide-51
SLIDE 51

ATJ 10/86 (Pindaan 2018)

  • Lane width
  • Crossfall : 2.5%
  • Pavement structure
  • Flexible pavement (advisable)
  • Rigid pavement

51

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

  • Cross Section Elements
slide-52
SLIDE 52

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

ATJ 10/86 (Pindaan 2018)

  • Bicycle Path at Bus Stop

52

slide-53
SLIDE 53
  • Specific routes provided to minimize conflicts

53

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

ATJ 10/86 (Pindaan 2018)

  • Junction and Crossing
slide-54
SLIDE 54

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

54

slide-55
SLIDE 55

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

55

slide-56
SLIDE 56

56

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Cycle track along Jalan Sultan Ismail, Kuala Lumpur

slide-57
SLIDE 57
  • Painted word: LALUAN BASIKAL
  • Symbol:

57

ATJ 10/86 (Pindaan 2018)

  • Road Marking

Cycle track near LRT Bandaraya station SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

slide-58
SLIDE 58

ATJ 10/86 (Pindaan 2018)

  • Traffic Signs and Signals

Cycle track in residential area (Taman Melawati, Ampang Jaya) SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION Example of traffic signal

58

slide-59
SLIDE 59

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

ATJ 10/86 (Pindaan 2018)

  • Cycle Parking

59

slide-60
SLIDE 60

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

ATJ 10/86 (Pindaan 2018)

  • Cycle Parking

60

slide-61
SLIDE 61

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

61

CONCLUSIONS

  • There are guidelines available in Malaysia for two wheelers facilities
  • The 3 guidelines will help designers in designing facilities for two

wheelers:

  • Motorcyles
  • Bicycles
slide-62
SLIDE 62

SAFER ROAD BY INFRASTRUCTURE DESIGN AND OPERATION

62
