Safe Initialization of Objects Fengyun Liu LAMP, EPFL June 26, - - PowerPoint PPT Presentation

Safe Initialization of Objects

Fengyun Liu

LAMP, EPFL June 26, 2020

Problem Challenges Reasoning Evaluation Inference Model

A 50-year old problem

1

class Hello {

2

val message = "Hello, " + name

3

val name = "world"

4

}

5 6

println(new Hello().message))

1 / 63

A 50-year old problem

1

class Hello {

2

val message = "Hello, " + name

3

val name = "world"

4

}

5 6

println(new Hello().message))

At runtime: Hello, null

1 / 63

A 50-year old problem

1

class Hello {

2

val message = "Hello, " + name

3

val name = "world"

4

}

5 6

println(new Hello().message))

At runtime: Hello, null

1 / 63

Status quo

All mainstream object-oriented languages still suffer from the problem, including C++, Java, Scala, C#, Kotlin, ...

2 / 63

Why the problem is important?

Not only are partially-constructed objects a source

• f consternation for everyday programmers, they are

also a challenge for language designers wanting to provide guarantees around invariants, immutability and concurrency-safety, and non-nullability. — Joe Duffy, “On partially-constructed objects”

http://joeduffyblog.com/2010/06/27/on-partiallyconstructed-objects/ 3 / 63

Is it only a problem of OOP?

1

let rec even n = n = 0 || odd (x - 1)

2

and odd n = n = 1 || even (x - 1)

3

and flag = odd 3

The latest OCaml compiler rejects the code!

4 / 63

Is it only a problem of strict languages?

The following Haskell code loops forever:

1

a = if b then 10 else 20

2

b = a >= 10

3 4

main = putStrLn (show a)

Initialization errors are disguised as non-termination!

5 / 63

Problem Challenges Reasoning Evaluation Inference Model

Can we disallow usage of this before initialization?

6 / 63

Can we disallow usage of this before initialization?

Requirement 1. Call methods and access fields on this.

Gil et al. (2009) report that over 8% constructors include method calls on this.

6 / 63

Can we disallow usage of this before initialization?

Requirement 1. Call methods and access fields on this.

Gil et al. (2009) report that over 8% constructors include method calls on this.

Requirement 2. Creation of cyclic data structures.

1

class Parent { val child: Child = new Child(this) }

2

class Child(parent: Parent)

6 / 63

Challenge 1: virtual method calls

1

abstract class AbstractFile {

2

def name: String

3

val extension: String = name.substring(4)

4

}

5 6

class RemoteFile(url:String) extends AbstractFile {

7

val localFile: String = url.hashCode

8

def name: String = localFile

9

}

10 11

new RemoteFile("...")

7 / 63

Challenge 1: virtual method calls

1

abstract class AbstractFile {

2

def name: String

3

val extension: String = name.substring(4)

4

}

5 6

class RemoteFile(url:String) extends AbstractFile {

7

val localFile: String = url.hashCode

8

def name: String = localFile

9

}

10 11

new RemoteFile("...") null pointer exception at runtime

7 / 63

Challenge 1: virtual method calls

1

abstract class AbstractFile {

2

def name: String

3

val extension: String = name.substring(4)

4

}

5 6

class RemoteFile(url:String) extends AbstractFile {

7

val localFile: String = url.hashCode

8

def name: String = localFile

9

}

10 11

new RemoteFile("...")

virtual call this.name

7 / 63

Challenge 1: virtual method calls

1

abstract class AbstractFile {

2

def name: String

3

val extension: String = name.substring(4)

4

}

5 6

class RemoteFile(url:String) extends AbstractFile {

7

val localFile: String = url.hashCode

8

def name: String = localFile

9

}

10 11

new RemoteFile("...")

access uninitialized this.localFile

7 / 63

Challenge 2: aliasing

1

class Knot {

2

val a = this

3

val b = a.c + 5

4

val c = 10

5

}

aliasing of this

8 / 63

Challenge 2: aliasing

1

class Knot {

2

val a = this

3

val b = a.c + 5

4

val c = 10

5

}

aliasing of this

a.c is not initialized

8 / 63

Challenge 3: traits

1

trait TA { val x = "EPFL" }

2

trait TB { def x: String; val n = x.length }

3 4

class Foo extends TA with TB

5

class Bar extends TB with TA

6 7

new Foo // ok

8

new Bar // error null pointer exception

9 / 63

Challenge 3: traits

1

trait TA { val x = "EPFL" }

2

trait TB { def x: String; val n = x.length }

3 4

class Foo extends TA with TB

5

class Bar extends TB with TA

6 7

new Foo // ok

8

new Bar // error null pointer exception

x is initialized after n

9 / 63

Challenge 4: first-class functions

1

class Rec {

2

val even = (n: Int) => n == 0 || odd(n - 1)

3

even(6)

4

val odd = (n: Int) => n == 1 || even(n - 1)

5

even(6)

6

}

10 / 63

Challenge 4: first-class functions

1

class Rec {

2

val even = (n: Int) => n == 0 || odd(n - 1)

3

even(6)

4

val odd = (n: Int) => n == 1 || even(n - 1)

5

even(6)

6

} null pointer exception

10 / 63

Challenge 4: first-class functions

1

class Rec {

2

val even = (n: Int) => n == 0 || odd(n - 1)

3

even(6)

4

val odd = (n: Int) => n == 1 || even(n - 1)

5

even(6)

6

}

it is OK to call even here

null pointer exception

10 / 63

Challenge 5: inner classes

1

class Trees {

2

class ValDef { counter += 1 }

3

class EmptyValDef extends ValDef

4 5

val theEmptyValDef = new EmptyValDef

6

private var counter = 0

7

}

11 / 63

Challenge 5: inner classes

1

class Trees {

2

class ValDef { counter += 1 }

3

class EmptyValDef extends ValDef

4 5

val theEmptyValDef = new EmptyValDef

6

private var counter = 0

7

}

11 / 63

Challenge 5: inner classes

1

class Trees {

2

class ValDef { counter += 1 }

3

class EmptyValDef extends ValDef

4 5

val theEmptyValDef = new EmptyValDef

6

private var counter = 0

7

} counter is not yet initialized

11 / 63

Challenge 6: properties

1

class A {

2

val a = "Bonjour"

3

val b = a.size

4

}

5 6

class B extends A {

7

• verride val a = "Hi"

8

}

9 10

new B null pointer exception

12 / 63

Challenge 6: properties

1

class A {

2

val a = "Bonjour"

3

val b = a.size

4

}

5 6

class B extends A {

7

• verride val a = "Hi"

8

}

9 10

new B null pointer exception

this.a is a dynamic method call!

12 / 63

Challenge 6: properties

1

class A {

2

val a = "Bonjour"

3

val b = a.size

4

}

5 6

class B extends A {

7

• verride val a = "Hi"

8

}

9 10

new B null pointer exception

this.a is a dynamic method call!

12 / 63

Engineering Challenges

Initialization

Safety Simplicity Performance Usability Expressivity

13 / 63

Problem Challenges Reasoning Evaluation Inference Model

A golden idea: local reasoning

If a constructor is called with only transitively initialized arguments, so is the resulting object. If the receiver and arguments of a method call are transitively initialized, so is the result.

Summers, Alexander J. and Peter M¨

• uller. “Freedom before commitment.” OOPSLA ’11

14 / 63

Three pillars of local reasoning

local reasoning

weak monotonicity stackability scopability

15 / 63

A small language

P ∈ Program ::= (C, D) C ∈ Class ::= class C(ˆ f :T) { F M } F ∈ Field ::= var f :T = e e ∈ Exp ::= x | this | e.f | e.m(e) | new C(e) | e.f = e; e M ∈ Method ::= def m(x:T) : T = e S, T, U ∈ Type ::= C

1

class Parent { var child: Child = new Child(this) }

2

class Child(parent: Parent)

16 / 63

Semantics

e (σ, ρ, ψ) = (l, σ′)

17 / 63

Semantics

e (σ, ρ, ψ) = (l, σ′)

σ: the heap before evaluation ρ: the environment ψ: value for this σ′: the heap after evaluation l: the resulting value

17 / 63

Semantics - Examples

x (σ, ρ, ψ) = (ρ(x), σ) this (σ, ρ, ψ) = (ψ, σ) e.f (σ, ρ, ψ) = (ω(f ), σ1) where (l0, σ1) = e (σ, ρ, ψ) and ( , ω) = σ1(l0)

18 / 63

Reachability

An object l′ is reachable from l in the heap σ, written σ l l′, is defined below: l ∈ dom(σ) σ l l σ l0 l1 ( , ω) = σ(l1) ∃ f . ω(f ) = l2 l2 ∈ dom(σ) σ l0 l2

19 / 63

Abstractions: cold, warm and hot

Cold A cold object may have uninitialized fields Warm A warm object has all its fields initialized Hot A hot object only reaches warm objects

20 / 63

Formal definition

Definition (Cold) σ l : cold

• l ∈ dom(σ)

Definition (Warm) σ l : warm

• ∃(C, ω) = σ(l) fields(C) ⊆ dom(ω)

Definition (Hot) σ l : hot

• l ∈ dom(σ)
• ∀l′.σ l l′ =

⇒ σ l′ : warm

21 / 63

Weak Monotonicity

Definition (Weak Monotonicity) σ σ′

• ∀l ∈ dom(σ).

(C, ω) = σ(l) = ⇒ (C, ω′) = σ′(l) dom(ω) ⊆ dom(ω′) Theorem (Weak Monotonicity) e (σ, ρ, ψ) = (l, σ′) = ⇒ σ σ′

22 / 63

Stackability, formally

Definition (Stacking) σ ≪ σ′

• ∀l ∈ dom(σ′). σ′ l : warm
• l ∈ dom(σ)

Theorem (Stackability) e (σ, ρ, ψ) = (l, σ′) = ⇒ σ ≪ σ′

23 / 63

Stackability, visually

1 2 4 3 time 5 6 1 2 4 3 5 6 stacked non-stacked

Scopability, formally

Definition (Scoping) (σ, L) ⋖ (σ′, L′)

• ∀l ∈ dom(σ).

σ′ L′ l = ⇒ σ L l Theorem (Scopability) e (σ, ρ, ψ) = (l, σ′) = ⇒ (σ, codom(ρ) ∪ { ψ }) ⋖ (σ′, { l })

25 / 63

Scopability, visually

1 7 2 4 3 5 6 1 7 2 4 3 5 6 8 9

˟

Heap σ Heap σ’ ⟦e⟧(σ, ø, 2)

the result value

26 / 63

Scopability, visually

1 7 2 4 3 5 6 1 7 2 4 3 5 6 8 9

˟

Heap σ Heap σ’ ⟦e⟧(σ, ø, 2)

the result value σ′ 8 7 7 ∈ dom(σ) σ 2 7 (σ, 2) ⋖ (σ′, 8)

26 / 63

Local reasoning theorem

e (σ, ρ, ψ) = (l, σ′) σ { ψ } ∪ codom(ρ) : hot σ′ l : hot

27 / 63

Problem Challenges Reasoning Evaluation Inference Model

The basic model

µ ::= cold | warm | hot T ::= C µ hot ⊑ warm ⊑ cold

28 / 63

Typestate polymorphism

1

class C {

2

// ...

3

def g(): Int = 100

4

}

g can be called for any initialization state of this

29 / 63

Typestate polymorphism

1

class C {

2

// ...

3

def g(): Int = 100

4

}

g can be called for any initialization state of this

• how to express the polymorphism in the system?
• how to avoid syntactic overhead for polymorphism?

29 / 63

Flow-sensitivity and typestate polymorphism

In a flow-sensitive system, we need to resort to parametric polymorphic because a method has to represent the typestates of this both before and after the method call.

1

class C {

2

def g(): Int = 100 // g: ∀M.M M

3

}

Qi, Xin and Andrew C. Myers. “Masked types for sound object initialization.” POPL ’09 30 / 63

Flow-insensitivity and typestate polymorphism

In a flow-insensitive system, we may resort to subtyping polymorphism to support typestate polymorphism.

1

class C {

2

@cold def g(): Int = 100

3

}

Summers, Alexander J. and Peter M¨

• uller. “Freedom before commitment.” OOPSLA ’11

31 / 63

Strong monotonicity

Hot/warm objects continue to be hot/warm: σ σ′

• ∀l ∈ dom(σ). σ l : µ =

⇒ σ′ l : µ

F¨ ahndrich, Manuel and K. Rustan M. Leino. “Heap Monotonic Typestate.” (2003). 32 / 63

Perfect monotonicity

Hot/warm fields continue to be hot/warm: σ σ′

• ∀l ∈ dom(σ).

(C, ω) = σ(l) = ⇒ (C, ω′) = σ′(l)

• ∀f ∈ dom(ω).σ ω(f ) : µ =

⇒ σ′ ω′(f ) : µ

33 / 63

Typing rules - T-New

Ti = constrType(C) Γ; T ⊢ ei : C µi

i

C µi

i

<: Ti µ = (⊔ µi) ⊓ warm Γ; T ⊢ new C(e) : C µ (T-New) local reasoning and stackability

34 / 63

Typing rules - T-Invoke

Γ; T ⊢ e : C µ0 (µm, Ti, Dµr ) = methodType(C, m) µ0 ⊑ µm Γ; T ⊢ ei : Dµi

i

Dµi

i

<: Ti µ = (⊔ µi = hot)?hot : µr Γ; T ⊢ e.m(e) : Dµ (T-Invoke) local reasoning typestate polymorphism

35 / 63

Typing rules - T-Block

Γ; T ⊢ e1.f : C µ Γ; T ⊢ e2 : C hot Γ; T ⊢ e : T1 Γ; T ⊢ e1.f = e2; e : T1 (T-Block) perfect monotonicity

36 / 63

Typing rules - selection

Γ; T ⊢ e : Dhot C µ = fieldType(D, f ) Γ; T ⊢ e.f : C hot (T-SelHot) Γ; T ⊢ e : Dwarm U = fieldType(D, f ) Γ; T ⊢ e.f : U (T-SelWarm)

37 / 63

Authority, flow-insensitivity and strong updates

The meta-theory depends on authority: ∀l ∈ dom(Σ).Σ(l) = C µ = ⇒ Σ′(l) = C µ Σ Σ′

38 / 63

Authority, flow-insensitivity and strong updates

The meta-theory depends on authority: ∀l ∈ dom(Σ).Σ(l) = C µ = ⇒ Σ′(l) = C µ Σ Σ′ In a flow-insensitive system without aliasing tracking, it is

• nly safe to perform strong updates of initialization states

via the outstanding alias this in a local flow inside the constructor.

38 / 63

Design principles of initialization

Authority Each field should have a unique location in the constructor where it is officially initialized. Stack- ability All fields of an object should be initial- ized at the end of the class constructor. Mono- tonicity Initialization states cannot be reversed. Scop- ability Access to uninitialized objects should be controlled by static scoping.

39 / 63

Principled design of constructors

To align with the principles, we advocate

• class parameters
• mandatory field initializers

40 / 63

Principled design of constructors

To align with the principles, we advocate

• class parameters
• mandatory field initializers

1

class RemoteDoc(url: String) {

2

val localFile: String = url.hashCode

3

def name: String = localFile

4

}

40 / 63

Languages in industry

language

class C(f:Int) var f:Int = e

year Java

• 1995

C#

• 2000

D

• 2001

Scala

• 2003

Ceylon

• 2011

Dart

• 2011

Kotlin

• 2011

TypeScript

• 2012

Crystal

• 2014

Swift

• 2014

41 / 63

Problem Challenges Reasoning Evaluation Inference Model

What is wrong with type-based approach?

To be honest, the reason this approach has likely not yet seen widespread use is that the cost is not commensurate with the benefit. ... For systems programmers, this makes sense. For many other programmers, it would be useless ceremony with no perceived value. — Joe Duffy, “On partially-constructed objects”

http://joeduffyblog.com/2010/06/27/on-partiallyconstructed-objects/ 42 / 63

Drawbacks of type-based approach

• Annotation overhead
• Inadequate to handle traits, inner classes, properties
• Does not handle inheritance well
• Difficult to integrate in compilers

43 / 63

Type-and-effect systems

Γ, x : S ⊢ t : T ! ǫ Γ ⊢ λx:S.t : S

ǫ

− → T ! ∅ (T-Abs) Γ ⊢ t1 : S

ǫ3

− → T ! ǫ1 Γ ⊢ t2 : S ! ǫ2 Γ ⊢ t1 t2 : T ! ǫ1 ∪ ǫ2 ∪ ǫ3 (T-App)

Lucassen, J.M., Gifford, D.K. (1988). Polymorphic effect systems. POPL ’88. 44 / 63

Potentials and effects

Potentials represent aliasing information of objects possibly under initialization. β ::= this | warm[C] | cold π ::= β | π.f | π.m

45 / 63

Potentials and effects

Potentials represent aliasing information of objects possibly under initialization. β ::= this | warm[C] | cold π ::= β | π.f | π.m Effects represent operations on objects possibly under initialization. φ ::= π.f ! | π.m♦ | π↑

45 / 63

Potentials and effects

Potentials represent aliasing information of objects possibly under initialization. β ::= this | warm[C] | cold π ::= β | π.f | π.m Effects represent operations on objects possibly under initialization. φ ::= π.f ! | π.m♦ | π↑ Γ; C ⊢ e : D ! (Φ, Π) If Π = ∅, the value of e must be hot.

45 / 63

Expression Typing - Block

Γ; C ⊢ e0 : E0 ! (Φ0, Π0) E1 = fieldType(E0, f ) Γ; C ⊢ e1 : E1 ! (Φ1, Π1) Γ; C ⊢ e2 : E2 ! (Φ2, Π2) Φ = Φ0 ∪ Φ1 ∪ Φ2 ∪ Π1↑ Γ; C ⊢ e0.f = e1; e2 : E2 ! (Φ, Π2) (T-Block) ensures that e1 is hot

46 / 63

Example – field access effect

1

class C {

2

var x: Int = this.y

3

var y: Int = 10

4

}

effects: { this.y! }

47 / 63

Example – potentials

1

class C {

2

var a = this

3

var b = this.a

4

}

48 / 63

Example – potentials

1

class C {

2

var a = this

3

var b = this.a

4

}

potentials: { this } effects: ∅

48 / 63

Example – potentials

1

class C {

2

var a = this

3

var b = this.a

4

}

potentials: { this } effects: ∅ potentials: { this.a } effects: { this.a! }

48 / 63

Example – potentials

1

class C {

2

var a = this

3

var b = this.a

4

}

potentials: { this } effects: ∅ potentials: { this.a } effects: { this.a! }

48 / 63

Example – method call effects

1

class C {

2

var a = this.m()

3

var b = this

4

def m() = this.b

5

}

49 / 63

Example – method call effects

1

class C {

2

var a = this.m()

3

var b = this

4

def m() = this.b

5

}

potentials: { this.m } effects: { this.m♦ }

49 / 63

Example – method call effects

1

class C {

2

var a = this.m()

3

var b = this

4

def m() = this.b

5

}

potentials: { this.m } effects: { this.m♦ } potentials: { this.b } effects: { this.b! }

49 / 63

Example – method call effects

1

class C {

2

var a = this.m()

3

var b = this

4

def m() = this.b

5

}

potentials: { this.m } effects: { this.m♦ } potentials: { this.b } effects: { this.b! }

49 / 63

Example – promotion effects

1

class C(fun: C => Int) {

2

var x: Int = fun(this)

3

}

50 / 63

Example – promotion effects

1

class C(fun: C => Int) {

2

var x: Int = fun(this)

3

}

potentials: ∅ effects: { this↑ }

50 / 63

Example – promotion effects

1

class C(fun: C => Int) {

2

var x: Int = fun(this)

3

}

potentials: ∅ effects: { this↑ } Promotion is the same as requiring a value to be hot.

50 / 63

Two-phase checking

1

class C {

2

var a: Int = h()

3

def h(): Int = g()

4

def g(): Int = h()

5

}

51 / 63

Two-phase checking

1

class C {

2

var a: Int = h()

3

def h(): Int = g()

4

def g(): Int = h()

5

}

First phase method effects potentials h { this.g♦ } { this.g } g { this.h♦ } { this.h }

51 / 63

Two-phase checking

1

class C {

2

var a: Int = h()

3

def h(): Int = g()

4

def g(): Int = h()

5

}

First phase method effects potentials h { this.g♦ } { this.g } g { this.h♦ } { this.h } Second phase fixpoint({ this.h♦ }) = { this.g♦, this.h♦ }

51 / 63

Two-phase checking

1

class C {

2

var a: Int = h()

3

def h(): Int = g()

4

def g(): Int = h()

5

}

First phase method effects potentials h { this.g♦ } { this.g } g { this.h♦ } { this.h } Second phase fixpoint({ this.h♦ }) = { this.g♦, this.h♦ }

✔

51 / 63

Cyclic data structures

1

class Parent {

2

val child: Child = new Child(this)

3

child.name // OK

4

}

5 6

class Child( parent: Parent @cold ) {

7

val name = "Jack"

8

}

52 / 63

Cyclic data structures

1

class Parent {

2

val child: Child = new Child(this)

3

child.name // OK

4

}

5 6

class Child( parent: Parent @cold ) {

7

val name = "Jack"

8

}

potentials: { warm[Child] }

52 / 63

Full-construction analysis

1

abstract class AbstractFile {

2

def name: String

3

val extension: String = name.substring(4)

4

}

5 6

class RemoteFile(url:String) extends AbstractFile {

7

val localFile: String = url.hashCode

8

def name: String = localFile

9

}

53 / 63

Full-construction analysis

1

abstract class AbstractFile {

2

def name: String

3

val extension: String = name.substring(4)

4

}

5 6

class RemoteFile(url:String) extends AbstractFile {

7

val localFile: String = url.hashCode

8

def name: String = localFile

9

}

Analysis entry point: primary constructor of concrete classes

53 / 63

Full-construction analysis

1

abstract class AbstractFile {

2

def name: String

3

val extension: String = name.substring(4)

4

}

5 6

class RemoteFile(url:String) extends AbstractFile {

7

val localFile: String = url.hashCode

8

def name: String = localFile

9

}

follows super constructor calls

53 / 63

Full-construction analysis

1

abstract class AbstractFile {

2

def name: String

3

val extension: String = name.substring(4)

4

}

5 6

class RemoteFile(url:String) extends AbstractFile {

7

val localFile: String = url.hashCode

8

def name: String = localFile

9

}

resolve virtual call this.name

53 / 63

Full-construction analysis

1

abstract class AbstractFile {

2

def name: String

3

val extension: String = name.substring(4)

4

}

5 6

class RemoteFile(url:String) extends AbstractFile {

7

val localFile: String = url.hashCode

8

def name: String = localFile

9

} access uninitialized this.localFile

53 / 63

Functions

Function potential: π ::= . . . | Fun(Φ, Π)

54 / 63

Functions

Function potential: π ::= . . . | Fun(Φ, Π) effects when called potentials of return

54 / 63

Functions

Function potential: π ::= . . . | Fun(Φ, Π) effects when called potentials of return

1

class Rec {

2

val even = (n: Int) => n == 0 || odd(n - 1)

3

val odd = (n: Int) => n == 1 || even(n - 1)

4

val flag: Boolean = odd(6)

5

}

54 / 63

Functions

Function potential: π ::= . . . | Fun(Φ, Π) effects when called potentials of return

1

class Rec {

2

val even = (n: Int) => n == 0 || odd(n - 1)

3

val odd = (n: Int) => n == 1 || even(n - 1)

4

val flag: Boolean = odd(6)

5

}

✔

54 / 63

Inner classes

β ::= this | cold | warm(C, π) π ::= β | π.f | π.m | π.outer(C) φ ::= π↑ | π.f ! | π.m♦ | π.init(C)

55 / 63

Inner classes

β ::= this | cold | warm(C, π) π ::= β | π.f | π.m | π.outer(C) φ ::= π↑ | π.f ! | π.m♦ | π.init(C)

• uter potential π

potential of outer constructor effect

55 / 63

Inner classes

β ::= this | cold | warm(C, π) π ::= β | π.f | π.m | π.outer(C) φ ::= π↑ | π.f ! | π.m♦ | π.init(C)

• uter potential π

potential of outer constructor effect

1

class C {

2

private var counter = 0

3

class D { counter += 1 }

4

val d = new D

5

}

55 / 63

Inner classes

β ::= this | cold | warm(C, π) π ::= β | π.f | π.m | π.outer(C) φ ::= π↑ | π.f ! | π.m♦ | π.init(C)

• uter potential π

potential of outer constructor effect

1

class C {

2

private var counter = 0

3

class D { counter += 1 }

4

val d = new D

5

}

warm(D, this).init(D) warm(D, this).outer(D).counter! this.counter!

✔

this.outer(D).counter!

55 / 63

Termination - limit length

1

class C {

2

var a = this.g

3

def g = this.g.g

4

}

56 / 63

Termination - limit length

1

class C {

2

var a = this.g

3

def g = this.g.g

4

}

Infinite Loop this.g♦ = ⇒ this.g.g♦ = ⇒ this.g.g.g♦ = ⇒ this.g.g.g.g♦ = ⇒ . . .

56 / 63

Termination - limit length

1

class C {

2

var a = this.g

3

def g = this.g.g

4

}

Infinite Loop this.g♦ = ⇒ this.g.g♦ = ⇒ this.g.g.g♦ = ⇒ this.g.g.g.g♦ = ⇒ . . . Limit length this.g♦ = ⇒ this.g.g♦ = ⇒ this.g.g↑ = ⇒ . . . = ⇒

✔

56 / 63

Termination - widening (1)

1

class B {

2

class C extends B

3

val c: C = new C

4

}

57 / 63

Termination - widening (1)

1

class B {

2

class C extends B

3

val c: C = new C

4

}

warm(C, this).init(C) = ⇒ warm(C, warm(C, this)).init(C) = ⇒ warm(C, warm(C, warm(C, this))).init(C) = ⇒ . . .

57 / 63

Termination - widening (2)

1

class B {

2

class C extends B

3

val c: C = new C

4

}

It is safe to widen warm(C, π) to cold: warm(C, this).init(C) = ⇒ warm(C, warm(C, cold)).init(C) = ⇒ warm(C, warm(C, cold)).init(C) = ⇒ ✔

58 / 63

Problem Challenges Reasoning Evaluation Inference Model

Implementation

Implemented in Scala 3 compiler, under the option

• Ycheck-init.
• Lazy summarization of methods
• Takes advantage of TASTy for separate compilation
• Zero changes to core type system

59 / 63

Debuggability

1

class Greeting {

2

val message: String = this.welcome()

3

val name: String = "Jack"

4

def welcome() = "Hello, " + name // error

5

}

60 / 63

Debuggability

1

class Greeting {

2

val message: String = this.welcome()

3

val name: String = "Jack"

4

def welcome() = "Hello, " + name // error

5

}

1

• - Error: code/greeting.scala:3:6 ------------------------------

2

3 | val name: String = "Jack"

3

| ^

4

|Access non-initialized field name. Calling trace:

5

| -> val message: String = this.welcome() [ greeting.scala:2 ]

6

|

• > def welcome()

= "Hello, " + name [ greeting.scala:4 ]

60 / 63

Experiment

We run the checker for 0.6 million real-world Scala code.

• It finds bugs in Dotty, ScalaTest and Scala stdlib
• It reports 0.6 warnings/KLOC

2 4 6 8 10 d

• t

t y i n t e n t a l g e b r a s t d L i b 2 1 3 s c a l a c h e c k s c a l a t e s t s c a l a X m l s c

• p

t s c a l a p s q u a n t s b e t t e r f i l e s S c a l a P B s h a p e l e s s e f f p i s c

• n

f i g m u n i t Warnings/KLOC 0.7 39.5 4.7 0.6 1.1 0.4 0.1 0.0 5.4 0.0 0.0 0.3 0.8 0.5 0.6 1.1

61 / 63

Performance

20 40 60 80 100 120 d

• t

t y i n t e n t a l g e b r a s t d L i b 2 1 3 s c a l a c h e c k s c a l a t e s t s c a l a X m l s c

• p

t s c a l a p s q u a n t s b e t t e r f i l e s S c a l a P B s h a p e l e s s e f f p i s c

• n

f i g m u n i t Percent (%)

The percentage of time for initialization check relative to the whole compilation time.

62 / 63

Conclusion

• modular understanding of local reasoning
• monotonicity, stackability, scopability, authority
• abstractions of cold, warm, hot
• type-and-effect inference system with potentials
• implementation in Scala 3 compiler

63 / 63

Problem Challenges Reasoning Evaluation Inference Model

Proof of scopability (1)

Definition (Scoping Preservation) σ1 σ2 ⋖ L

• ∀σ0, L0, L1.

(σ0, L0) ⋖ (σ1, L)

• (σ0, L0) ⋖ (σ1, L1)

= ⇒ (σ0, L0) ⋖ (σ2, L1) Without scoping preservation, in an evaluation e (σ, ρ, ψ) = (l, σ′), we cannot even conclude that (σ, L) ⋖ (σ′, L), where L = codom(ρ) ∪ { ψ }.

Proof of scopability (2)

1 7 2 4 3 5 6 1 7 2 4 3 5 6 8 9

˟

Heap σ’ Heap σ’’

1 7 2 4 3 5

⟦e⟧(σ, ø, 4) Heap σ ⟦e.m()⟧(σ, ø, 4)

˟

⟦e’⟧(σ’, ø, 2)

˟

• (σ, 1) ⋖ (σ′, 6) is not preserved in σ′ σ′′
• (σ, 4) ⋖ (σ′, 6) is preserved in σ′ σ′′

Proof of scopability (3)

Theorem (Scopability) If e (σ, ρ, ψ) = (l, σ′), then we have

• (σ, codom(ρ) ∪ { ψ }) ⋖ (σ′, l)
• σ σ′ ⋖ codom(ρ) ∪ { ψ }

Local reasoning lemma

Lemma (Local Reasoning) (σ, L) ⋖ (σ′, L′) σ ≪ σ′ σ σ′ σ L : hot σ′ L′ : hot Proof. Let’s consider a reachable object l from L′, i.e. σ′ L′ l. Depending on whether l ∈ dom(σ), there are two cases.

• Case l /

∈ dom(σ). Use the fact that σ ≪ σ′, we know σ′ l : warm.

• Case l ∈ dom(σ).

Use the fact that (σ, L) ⋖ (σ′, L′), we have σ L l. From the premise σ L : hot, we have σ l : warm. From σ σ′, we have σ′ l : warm. In both cases, we have σ′ l : warm, by definition we have σ′ L′ : hot.

Meta-theory

1

class C {

2

// ...

3

var x: D @warm = e

4 5

var y: Int = 10

6

}

Meta-theory

1

class C {

2

// ...

3

var x: D @warm = e

4 5

var y: Int = 10

6

}

Σ0(ψ) = C µ

Meta-theory

1

class C {

2

// ...

3

var x: D @warm = e

4 5

var y: Int = 10

6

}

Σ0(ψ) = C µ Σ1(ψ) = C hot

Meta-theory

1

class C {

2

// ...

3

var x: D @warm = e

4 5

var y: Int = 10

6

}

Σ0(ψ) = C µ Σ1(ψ) = C hot Σ2(ψ) = C hot breaks typing, as by I.H. we

• nly know the value of e

is warm.

Challenging examples (1)

1

class RecType(parentExp: RecType => Type) {

2

val parent = parentExp(this)

3

}

Challenging examples (2)

1

• bject Foo {

2

case class Student(name: String, age: Int)

3

call(Student("Jack", 30) // currently a warning

4

}

Challenging examples (3)

1

def foo(x: => Int) = new A(x)

2

class A(init: => Int)

3

class Foo {

4

val a: A = foo(b) // warning!

5

val b: Int = 100

6

}

Fragile base class

1

class Base {

2

def g(): String = "hello"

3

}

4 5

class Foo extends Base {

6

val a = this.g()

7

}

8 9

class Bar extends Base {

10

val b: String = "b"

11

• verride def g(): String = this.b

12

}

Strong and weak updates

Suppose that Σ maps addresses to a lattice L: Σ : Loc ⇀ L Weak update Σ(l) ⊑ Σ′(l) Strong update Σ(l) ⊑ Σ′(l)

Scala Puzzle

What does the following Scala code prints at runtime?

1

class A(n: Int) { println(n) }

2 3

class B(val m: Int) extends A(m) {

4

println(m)

5

}

6 7

new B(10) { override val m = 10 }

Scala Puzzle

What does the following Scala code prints at runtime?

1

class A(n: Int) { println(n) }

2 3

class B(val m: Int) extends A(m) {

4

println(m)

5

}

6 7

new B(10) { override val m = 10 }

Answer: 10, 0

Swift

The Swift compiler rejects the following code:

1

class Position {

2

var x, y: Int

3

var f: () -> Int

4

init() {

5

x = 4

6

y = x * x // OK

7

f = { () -> Int in self.y } // error

8

}

9

}

Overly restrictive and inconsistent!
