SLIDE 1
September 2018
ROTARY & TURBINE GAS METER
Fátima Gouveia, Product Manager
ROTARY & TURBINE GAS METER Ftima Gouveia, Product Manager - - PowerPoint PPT Presentation
ROTARY & TURBINE GAS METER Ftima Gouveia, Product Manager - - PowerPoint PPT Presentation
ROTARY & TURBINE GAS METER Ftima Gouveia, Product Manager September 2018 AN EYE TO THE PAST DELTA SE PACKAGING Former packaging Improved packaging (from July/2018) AN EYE TO THE FUTURE DN80 NEW FLOW STRAIGHTENER What will change?
SLIDE 2
SLIDE 3
DELTA SE PACKAGING
Former packaging Improved packaging (from July/2018)
SLIDE 4
AN EYE TO THE FUTURE
SLIDE 5
DN80 NEW FLOW STRAIGHTENER
What will change?
- New Flow straightener
- Wheel MU 60° will be replaced
- Wheel 45° remains unchanged
Why change (advantages)?
- Improve conformity with EN12261:2002 Annex B (Perturbation
testing).
- Improve linearity on HP calibration
- Eliminate the need to rework the turbine wheel as today,
improving FPY and reducing cost related to operation “Optimization” for HPcalibration
- To be confirmed the possibility to get high accuracy for all DN80
When change?
- New MID certificate release by end of October
- By the end of the year
SLIDE 6
DN80 NEW FLOW STRAIGHTENER
- Customer approval ?!!!
- New flow straightener not compatible with today MUs.
- Spare part list will reflect the change.
- New flow straightener code
- New MU code
- 651-180-00, 500 pcs will be kept in stock for possible
replacements (sales = 1200 pcs from 2004 / 2018)
SLIDE 7
TURBINES UNIVERSAL TOTALIZER SEALING
- With the renewed MID certification, Delta sealing plan will be applied for TZ
Today Future
SLIDE 8
TURBINES HF3/2 PLUG SEALING
Will be removed on the next revision
- f MID certificate
Will be removed on the next revision
- f MID certificate
SLIDE 9
SLIDE 10
