Robert L. Bayt, Ph.D. Verification and Validation Manager, Commercial Crew Program 2017

Advancing Human Spaceflight

The vision of commercial human spaceflight to low-Earth orbit is a robust, vibrant enterprise with many providers and a wide range of private and public users. A successful human space transportation system will strengthen the International Space Station Program, allow NASA to focus on deep-space exploration, potentially reduce the cost of human access to space and significantly contribute to the national economy. NASA’s Commercial Crew Program serves two purposes: Public Purpose

Support the development of non-NASA markets for commercial human transportation services to and from low-Earth orbit

NASA Purpose

Safe transport of NASA and NASA- sponsored astronauts to and from the station

Building a Bridge to the Future

Requirements  Verification  Certification

Commercial Approach Inter-Agency Collaboration Certification & Services Building the Requirements “Seeding” the Market Pioneering Approach

Building the Requirements

• Provided high-level requirements for

performance and mandatory requirements for safety, giving providers maximum flexibility

• Conducted open industry forums very early in

the development phase to gain feedback and weigh requirements against impacts to industry

• Allowed use of alternate standards in many

cases and framework for partnering the verification and validation of the system

• Evolved requirements from previous human

spaceflight and ISS COTS interface requirements

Show components can survive/operate in an environment Evaluate Component Performance

• Flow Vs. ∆P
• Frequency

Response

• Dynamics
• Power Draw

Component Qualification System Qualification Subsystem Tests Vehicle Tests Component Model Validation System Model Validation Vehicle Model Validation

May be rolled into vehicle testing

Evaluates all primary and redundant systems are verified

Component Design

Design and Construction Standards

Component Designed and Built properly SMC-S-016 or Alternate Comp. Ready for Qual Evaluate Integrated Performance

NASA-STD-7009 Critical Functions Verified for Hazard Reports

System Req’t Verification Depiction of how Commercial Crew Program requirements and standards work together to ensure a qualified system that meets end user requirements

Requirements and Verification Framework

Certification Framework

• Certification Roadmap developed by the Provider’s and approved by

NASA to include:

• Verification Strategies for each requirement
• Joint Tests and Verifications with the ISS
• Hazard Controls and Verifications
• Human System Integration Strategy with Crew-in-the-Loop Testing
• Flight Tests, Objectives and Plans
• Joint Operations Planning

We are moving forward on the final development and certification of two safe, reliable and cost-effective, American- made crew transportation systems

Moving Forward

Summary

The Commercial Crew Program continues to execute its mission under the framework that was

• utlined in 2010

This allows industry to meet critical needs, while providing a stepping stone to the future of commercial space
