SLIDE 1
Design Presentation: 13
ROBBY GORDON – TODD ROMANO
DANIEL GRANGER –KYLE SWOBODA
SPEED UTV
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
ROBBY GORDON TODD ROMANO DANIEL GRANGER KYLE SWOBODA Design - - PowerPoint PPT Presentation
ROBBY GORDON TODD ROMANO DANIEL GRANGER KYLE SWOBODA Design - - PowerPoint PPT Presentation
ROBBY GORDON TODD ROMANO DANIEL GRANGER KYLE SWOBODA Design Presentation: 13 FOR PUBLIC RELAEASE: 06/17/2020 SPEED UTV 2 GENERAL SUSPENSION STEERING CHASSIS BODY INTERIOR DRIVETRAIN CUSTOMER SUGESTION: OIL DRAIN Ginger, Please
SLIDE 2
SLIDE 3
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
3
Ginger, Please pass my suggestion on to Robby or the engineering guys. In regards to the oil filter cover plate. Please consider adding a drain plug in the middle of the plate. This way when servi cing and changing the oil & filter you can drain the 1/4 to 1/2 quart of oil in that chamber before removing the 3 bolts to drop the plate and pull the oil filter. If you have ever done a VW bug engine you would understand the mess you make when you start to unbolt the cover as oil starts to seep out around the plate. You end up with oil draining everywhere. On your tools, hands, just running down everywhere. This is why they later came out with a drain plug in the middle of the plate. We had a boat with an external filter just like this. It to was a disaster to pull the filter cover as oil ended up all in the hull. I ended up drilling a hole In the plate, welding a small nut to the backside of the plate and making my own drain plug. It was still a little messy as the nut step up did not allow it to drain completely. But it was a huge improvement over the quart that drained before. Thank you, Todd Cunningham Master # 1064
CUSTOMER SUGESTION: OIL DRAIN
SLIDE 4
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
4
CUSTOMER SUGESTION: OIL DRAIN
Excellent suggestion Todd, We have implemented your suggestions and added a drain hole
- n the oil filter cap in addition to the
drain on the pan and dry sump tank.
SLIDE 5
SPEED UTV
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
5
360 spinner configurator in progress...
SLIDE 6
SPEED UTV
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
6
We are working on updating owner's profile in the order that they were placed
SLIDE 7
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
7
Create your Speed account to access the Owners section at SpeedUTV.com Keep track of:
- Preorder
- Upgrades
- Acessories
- Color selections
- Delievery details
SPEED UTV: OWNERS ACCOUNT
SLIDE 8
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
8
Membership section:
- Roadmap for
completing your purchasing journey.
- Pre-Order Deposit is
your "Passport" to this section.
- Will be automatically
added once your account has been processed.
SPEED UTV: OWNERS ACCOUNT
SLIDE 9
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
9
Membership section:
- Roadmap for
completing your purchasing journey.
- Pre-Order Deposit is
your "Passport" to this section.
- Will be automatically
added once your account has been processed.
SPEED UTV: OWNERS ACCOUNT
SLIDE 10
INTERIOR UPDATES
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
10
Custom Trim Center Panel For: radio, intercom, iPad ect. 10'' Display HUGE Glovebox Optional Second Display screen Moved up for better visibility HVAC Vents
SLIDE 11
#UTVFAILS HONDA
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
11
Cheap, thin walled tube 2'' OD 0.049'' - 0.078'' Wall
Honda Tallon A-Post 0.060'' With Powdercoat
SLIDE 12
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
12
Wildcat XX with Robby's Previous Cage and Suspension design rolled 7 times kept
- ccupants safe. Damage: 1
bent tube, bent factory tie-rod and rim.
#UTVFAILSWINS WILDCAT XX
SLIDE 13
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
13
Robby Gordon's Opinion of SPEED UTV
SLIDE 14
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
14
Robby Gordon's Oppinion of SPEED UTV
Triangulated Spine Structure Supported Bends Full Length Spine Integrated Shock mounts Sheet metal shock towers
SLIDE 15
Black Frame & Cage Charcoal Suspension
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
15
CAGE AND COLOR CLARIFICATION
Black Frame Charcoal Cage Charcoal Suspension Black Frame Orange Cage Orange Suspension RG EDITION LIMITED EDITION BASE EDITION
SLIDE 16
REAR MOUNT RADIATOR
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
16
- Full time
bleeder lines from head and water pump
- Three 10''
Fans
- Hot Air exits
- ut in-front of
bed
SLIDE 17
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
17
Upright Hub
FORGED ALUMINUM PARTS
Bearing Carrier
SLIDE 18
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
18
2 SEAT DISCOUNT ENDS JULY 15th
Discount Pricing on Bandit & Diablo LE and RG edition ends JULY 15th. Get your orders in before midnight eastern time if you want to take advantage of Early Pre-Order pricing. Order at www.SpeedUTV.com
SLIDE 19
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
19
4 SEAT PREORDER PRICE
Discount Pricing on El Jefe LE and RG edition has changed. You can still place an order for Pre-Order pricing. Order at www.SpeedUTV.com
SLIDE 20
SPEED UTV
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
20
LIVE CALL IN:
704-949-1255
ASK YOUR QUESTIONS
SLIDE 21
SPEED UTV
SUSPENSION STEERING CHASSIS BODY DRIVETRAIN INTERIOR GENERAL
- Order now at:
