Introduction Applications Limitations Return on Investment Hardware & Software Options Lessons Learned VR or Virtual reality is an artificial environment that is created with software and presented to the user in

slide-1
SLIDE 1
slide-2
SLIDE 2
  • Introduction
  • Applications
  • Limitations
  • Return on Investment
  • Hardware & Software Options
  • Lessons Learned
slide-3
SLIDE 3
  • VR or Virtual reality is an artificial environment that is

created with software and presented to the user in such a way that the user accepts it as a real environment.

slide-4
SLIDE 4

This Photo by Unknown Author is licensed under CC BY-SA

slide-5
SLIDE 5
slide-6
SLIDE 6

2.9%

1.3% 0.0% 0.6% 1.2%

0.0% 0.5% 1.0% 1.5% 2.0% 2.5% 3.0% 3.5%

Commerical & Industrial Construction Single-Family Construction Road, Highway, Infrastructure Manufacturing Nonfarm Business

Average Annual Productivity Change (2007 - 2017)

United States Department of Labor: Bureau of Labor Statistics, 2018

slide-7
SLIDE 7
slide-8
SLIDE 8
  • Immersive Plan Review
  • Planning
  • Logistics
  • Quality Control
  • Training
  • Safety
  • Operations
  • Education
  • Sales
slide-9
SLIDE 9

Plan reviews for Safety, Accessibility and Constructability. Tools include

  • Markups, Measuring, Verifying materials and parts, and Exporting

snapshots for RFI or Coordination.

images: http://www.irisVR.com

slide-10
SLIDE 10
slide-11
SLIDE 11
  • Improve Quality
  • Reduce Rework
  • Increase Field Engagement with

Model

  • Reduce Safety Incidents
  • Improve Collaboration
slide-12
SLIDE 12

Traditional Plan Review Method

  • Average of 3 design related

rework incidents per project

  • Average cost of rework incident:

$2,460

Virtual Reality Review Method

  • Eliminate 1 design related rework

incident per project using VR review

  • Cost of VR System: $5,800
  • Cost of VR Review: $275

Project Based Pay Back Analysis

Payback period is less than three projects!

slide-13
SLIDE 13
  • Multi-user Experience
  • Model Required
  • Model Quality
  • Rendering / Appearance
  • Hardware Setup (Sensors, Space)
  • Durability
slide-14
SLIDE 14
slide-15
SLIDE 15
  • Virtual Reality Hardware ($200 - $800)
  • HTC Vive
  • Oculus Rift/ Go / Quest
  • Windows Mixed Reality (HP, Others)
  • BIM -> Virtual Reality Software (No Additional Cost - $5,000 Annually+)
  • Autodesk Live/ 3DS Max Interactive
  • Prospect by IrisVR
  • InsiteVR
  • The WILD
  • Workstation ($1,750 - $4,500)
  • Not all workstations are created equal

HARDWARE & SOFTWARE OPTIONS

slide-16
SLIDE 16

Benchmark Scores via Passmark PerformanceTest 9

www.passmark.com

slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
  • Hardware
  • HP Omen X ($2,200+)
  • HTC Vive (Room Scale Tracking) ($499)
  • Software
  • Prospect Workstation by irisVR (~$5,000 / year)
  • Autodesk AEC Collection ($2,825 / year)
  • Accessories
  • Sensor Stands ($50)

http://store.hp.com/ http://irisvr.com/

slide-21
SLIDE 21

DO!

  • Multiple Super Users
  • “Budget” Time
  • Get Buy-in Early
  • Leverage Software Trials
  • Take it home
  • Invest in the right hardware

DON’T!

  • Play Games at work
  • Start with Large/Complex

Models

  • Over-promise
  • Beware of VR Gimmicks
