Results of H2 VLE Simulations 23.10.2017, Marcel Rosenthal, Nikolaos Charitonidis, Yannis Karyotakis, Yiota Chatzidaki Outline Updates on Geometry New optics Definition of GoodParticles Comparison of optics Particle

slide-1
SLIDE 1

Results of H2 VLE Simulations

23.10.2017, Marcel Rosenthal, Nikolaos Charitonidis, Yannis Karyotakis, Yiota Chatzidaki

slide-2
SLIDE 2

Outline

  • Updates on Geometry
  • New optics
  • Definition of “GoodParticles”
  • Comparison of optics
  • Particle rates for 80 GeV/c secondaries
  • Particle rates for -80 GeV/c secondaries
  • Background Studies:
  • Beam in H2
  • Beam in H4
  • Electron Target Study

23.10.2017

  • M. Rosenthal

2

slide-3
SLIDE 3

Geometry

23.10.2017

  • M. Rosenthal

3

slide-4
SLIDE 4

Updates on Geometry

  • Complete setup of combined model of H2 and H4

23.10.2017

  • M. Rosenthal

4

Soil below floor for more realistic background estimation Upstream shielding of H4 around GIF. Thanks to our summer student Rachel Margraf Default G4BL magnet models for both beamlines More detailed models in VLE after tertiary target

slide-5
SLIDE 5

Updates on Geometry

  • Complete setup of combined model of H2 and H4

23.10.2017

  • M. Rosenthal

5

More detailed models in VLE after tertiary target: Dipoles Quadrupoles Detailed shielding implemented for VLE section

slide-6
SLIDE 6

Dipoles

  • Bending magnets
  • Shaped stainless-steel pipes
  • aligned to optimize acceptance
  • Iron yokes and copper coils
  • Magnetic field map

23.10.2017

  • M. Rosenthal

6

slide-7
SLIDE 7

Quadrupoles

  • Quadrupoles
  • Round stainless-steel pipes
  • Iron yokes and copper coils
  • Magnetic field map extracted from

HALO software

  • Increased gap/aperture compared

to prior generic quad version

  • Pipe “serves” as obstacle/aperture

limitation

23.10.2017

  • M. Rosenthal

7

slide-8
SLIDE 8

Detectors

  • Detector
  • 4(5) layers:
  • Membrane: Fe
  • Insulation: Air
  • IronPlate: Fe
  • DetectorVolumes: Vacuum

23.10.2017

  • M. Rosenthal

8

param FieldCageWidth=6230 FieldCageLength=6230 FieldCageHeight=5880 param LArWidth=8548 LArLength=8548 LArHeight=7900 param ironPlateThickness=10 param insulationThickness=798 param membraneThickness=2

slide-9
SLIDE 9

Pipes and Windows

  • Detailed pipe models in VLE section
  • Mylar windows

23.10.2017

  • M. Rosenthal

9

slide-10
SLIDE 10

Shielding

  • Comparison with reality
  • Many details implemented

from step files (Thanks to Sylvain Girod and Vincent Clerc)

23.10.2017

  • M. Rosenthal

10

slide-11
SLIDE 11

Optics

23.10.2017

  • M. Rosenthal

11

slide-12
SLIDE 12

y in mm z in mm

Comparison of tracks

  • Original by Nikos
  • High transmission optimization by Yiota (increase by ≈ 3% in G4BL)

23.10.2017

  • M. Rosenthal

12

x in mm z in mm

12 GeV/c “GoodParticles”

Courtesy: Yiota Chatzidaki → see also previous talk

slide-13
SLIDE 13

“GoodParticle” Definition

23.10.2017

  • M. Rosenthal

13

slide-14
SLIDE 14

Schematic overview H2-VLE

23.10.2017

  • M. Rosenthal

14

slide-15
SLIDE 15

Four explored Options

  • Option 1: same particle hits each detector
  • Detectors: TOF1, TRIG1, TRIG2
  • Detectors: TOF1, TRIG1, TRIG2, BPROFs, COLL1, NP02front
  • Option 2: at least one 𝜌, 𝐿, 𝜈, 𝑓, 𝑞 hit in each detector
  • Detectors: TOF1, TRIG1, TRIG2
  • Detectors: TOF1, TRIG1, TRIG2, BPROFs, COLL1, NP02front

23.10.2017

  • M. Rosenthal

15

(𝑱) (𝑱𝑱) (𝑱𝑱𝑱) (𝑱𝑾)

  • nly counted

in option 2 counted in option 1 & 2

slide-16
SLIDE 16

Composition 80 GeV/c → 12 GeV/c

23.10.2017

  • M. Rosenthal

16

(𝑱)

𝝆 𝑳 𝒒 𝝂 𝒇

(𝑱𝑱) (𝑱𝑱𝑱) (𝑱𝑾)

scored @ TRIG2

slide-17
SLIDE 17

Momentum Spectra @ TRIG2

23.10.2017

  • M. Rosenthal

17

(𝑱) (𝑱𝑱𝑱)

Momentum of all “GoodParticles” for different options

Timing not considered

slide-18
SLIDE 18

In-Beam Muon Origin

23.10.2017

  • M. Rosenthal

18

(𝑱) (𝑱𝑱𝑱)

  • a. u.

Only muons before TOF1 are counted in this option

slide-19
SLIDE 19

In-Beam Muon Origin vs. Momentum

23.10.2017

  • M. Rosenthal

19

(𝑱) (𝑱𝑱𝑱)

  • a. u.

Taking into account decays in the GoodParticle definition allows for a more complete picture of the muon contribution

slide-20
SLIDE 20

Four explored Options

23.10.2017

  • M. Rosenthal

20

(𝑱) (𝑱𝑱) (𝑱𝑱𝑱) (𝑱𝑾)

  • Option 1: particle hits each detector
  • Detectors: TOF1, TRIG1, TRIG2
  • Detectors: TOF1, TRIG1, TRIG2, BPROFs, COLL1, NP02front
  • Option 2: at least one 𝜌, 𝐿, 𝜈, 𝑓, 𝑞 hit in each detector
  • Detectors: TOF1, TRIG1, TRIG2
  • Detectors: TOF1, TRIG1, TRIG2, BPROFs, COLL1, NP02front

Following results obtained with selection scheme 3 (but no consideration of timing yet)

slide-21
SLIDE 21

Rates for 80 GeV/c

23.10.2017

  • M. Rosenthal

21

slide-22
SLIDE 22

Pion Rate

23.10.2017

  • M. Rosenthal

22

rate ± stat. error (fraction of GoodParticles)

Physics list: FTFP_BERT

  • Kin. energy cut: 10 MeV

Scored at TRIG2 Selection scheme III Normalized to 106 in 4.8s

W-target Cu-target Cu-target

slide-23
SLIDE 23

Total Rate

23.10.2017

  • M. Rosenthal

23 Physics list: FTFP_BERT

  • Kin. energy cut: 10 MeV

Scored at TRIG2 Selection scheme III Normalized to 106 in 4.8s

𝒒 𝒇 𝝂 𝑳 𝝆 W-target Cu-target Cu-target

slide-24
SLIDE 24

Rates for -80 GeV/c

23.10.2017

  • M. Rosenthal

24

slide-25
SLIDE 25

Pion Rate

23.10.2017

  • M. Rosenthal

25 Physics list: FTFP_BERT

  • Kin. energy cut: 10 MeV

Scored at TRIG2 Selection scheme III Normalized to 106 in 4.8s

W-target Cu-target Cu-target

slide-26
SLIDE 26

Total Rate

23.10.2017

  • M. Rosenthal

26 Physics list: FTFP_BERT

  • Kin. energy cut: 10 MeV

Scored at TRIG2 Selection scheme III Normalized to 106 in 4.8s

𝒒 𝒇 𝝂 𝑳 𝝆 W-target Cu-target Cu-target

slide-27
SLIDE 27

Background Studies

23.10.2017

  • M. Rosenthal

27

slide-28
SLIDE 28

Full model: H2-beam on

23.10.2017

  • M. Rosenthal

28 Particles scored in NP02 Fieldcage volume when H2 beam is on Detector materials currently vacuum: → Score all particles entering LAr volume in direction to field cage

slide-29
SLIDE 29

Background Composition 12 GeV/c

23.10.2017

  • M. Rosenthal

29

slide-30
SLIDE 30

Coordinates for NP02

  • Study distribution of background
  • Rotated cryostat
  • Project to new

coordinates:

  • 𝑦, 𝑨 → (𝑦, 𝑨)

23.10.2017

  • M. Rosenthal

30

Beam x z z x

slide-31
SLIDE 31

Background from Muons (12 GeV/c)

23.10.2017

  • M. Rosenthal

31

Kinetic energy cutoff @ 10 MeV

10 GeV/c 1 GeV/c 0.1 GeV/c

  • a. u.
slide-32
SLIDE 32

Background from Neutrons (12 GeV/c)

23.10.2017

  • M. Rosenthal

32

Kinetic energy cutoff @ 10 MeV

10 GeV/c 1 GeV/c 0.1 GeV/c

  • a. u.
slide-33
SLIDE 33

Muons & Neutrons

23.10.2017

  • M. Rosenthal

33

Target Momenta of VLE-magnets

𝜈 𝑜

slide-34
SLIDE 34

Charged Particles

23.10.2017

  • M. Rosenthal

34

slide-35
SLIDE 35

Full model: H4-beam on

23.10.2017

  • M. Rosenthal

35 Particles scored in NP02 Fieldcage volume when H4 beam is on Detector materials currently vacuum: → Score all particles entering LAr volume in direction to field cage

slide-36
SLIDE 36

Background Composition: 7 GeV/c (H4)

23.10.2017

  • M. Rosenthal

36

17 kHz of neutrons simulated for Vacuum (no LAr in detector volumes!) Is this an issue? Do we need additional shielding?

slide-37
SLIDE 37

Background from Neutrons (7 GeV/c)

23.10.2017

  • M. Rosenthal

37

Kinetic energy cutoff @ 10 MeV

10 GeV/c 1 GeV/c 0.1 GeV/c

  • a. u.
slide-38
SLIDE 38

Background from Muons (7 GeV/c)

23.10.2017

  • M. Rosenthal

38

Kinetic energy cutoff @ 10 MeV

10 GeV/c 1 GeV/c 0.1 GeV/c

  • a. u.
slide-39
SLIDE 39

Effect of beam pipes

23.10.2017

  • M. Rosenthal

39

slide-40
SLIDE 40

Composition / 80 GeV/c →1/12 GeV/c

23.10.2017

  • M. Rosenthal

40

(𝑱𝑱𝑱)

𝝆 𝑳 𝒒 𝝂 𝒇

(𝑱𝑱𝑱) (𝑱𝑱𝑱) (𝑱𝑱𝑱)

Vacuum 1GeV/c Vacuum 12GeV/c Steel 1GeV/c Steel 12GeV/c

slide-41
SLIDE 41

Electron Target Study

23.10.2017

  • M. Rosenthal

41

slide-42
SLIDE 42

Study of 𝒇+ beam in H2-VLE

  • 60 GeV/c momentum of secondary beam
  • Very conservative: 90% positrons, 10% charged hadrons mixed in
  • Explore lead target as secondary target
  • Thicknesses: 5 to 30 mm
  • Tertiary Momenta: 1, 4, 8, 12 GeV/c
  • Radiation length of Pb ≈ 5 mm
  • After 1, 2, 3, 4, 5 𝑌0 : ≈ 22, 8, 3, 1, 0.4 GeV/c
  • Expectation: Optimum between 10 to 20 mm depending on tertiary

momentum

23.10.2017

  • M. Rosenthal

42

slide-43
SLIDE 43

𝒇+-rate for 𝟐𝟏𝟕 secondaries in 4.8 s

  • Expectation confirmed
  • Optimum at 10-15 mm

(one target used at all tertiary momenta)

  • Rate of “Good Particles”:
  • 10 - 20 kHz
  • Purity of “Good Particles”:
  • ≈ 100% electrons

23.10.2017

  • M. Rosenthal

43

Target length (mm) Target length (mm) 12 GeV/c 8 GeV/c 1 GeV/c 4 GeV/c

10 kHz 12 kHz 16 kHz 16 kHz

slide-44
SLIDE 44

Summary

  • Detailed, combined model for H2 and H4 with VLE extensions

implemented

  • New estimates of the trigger rates available for H2-VLE
  • Rate increase due to more realistic quadrupoles with larger apertures is

compensated by implementing beam pipes

  • nTuples for H2 will be made available on shared beamgroupdisk this week

(/eos/experiments/neutplatform/protodune/npmcproddisk/beamgroupdisk/DP/v27c/)

  • Old GoodParticle definition inside!
  • H4-VLE estimations will follow soon after implementing the new Quay model
  • Electron/Positron yield using a lead target has been estimated
  • Multiple kHz for a 10-15 mm lead target at all momenta

23.10.2017

  • M. Rosenthal

44
