SLIDE 1

Resolving Journaling of Journal Anomaly via Weaving Recovery Information into DB Page Beomseok Nam

UNIST

NVRAMOS ‘14 10.30. 2014

SLIDE 2

Outline

Motivation
Journaling of Journal Anomaly
How to resolve Journaling of Journal anomaly
Multi-Version B-Tree (MVBT)
Optimizations of Multi-Version B-Tree
Lazy Split
Reserved Buffer Space
Lazy Garbage Collection
Metadata Embedding
Disabling Sibling Redistribution
Evaluation
Conclusion

2

SLIDE 3

Storage I/O Problems in Android

Performance Bottleneck

3

1 1 1 1 1 1 1 1 1 1

Lifetime of Storage

Cause = Excessive IO

SLIDE 4

Android I/O Stack

Block Device Driver EXT4 SQLite

Apps

Insert/Update/Delete/Select

Read/Write

4

Txn Journaling Write() Journaling

Misaligned Interaction

SLIDE 5

Journaling of Journal Anomaly

Journaling in SQLite (TRUNCATE mode)

SQLite

Insert a DB entry Open rollback journal. Record the data to journal. Put commit mark to journal. Insert entry to DB Truncate journal.

5

SLIDE 6

EXT4 Journaling (ordered mode)

6

EXT4 SQLite

Write data block Write EXT4 journal Write journal metadata Write journal commit write()

SLIDE 7

Journaling of Journal Anomaly

7

EXT4 SQLite insert

One insert of 100 Byte  9 Random Writes of 4KByte

Write data block Write EXT4 journal Write journal metadata Write journal commit

SLIDE 8

How to Resolve Journaling of Journal?

EXT4 SQLite

Insert a DB entry Database Journaling Database Insertion Journaling of journal anomaly.

8

SLIDE 9

How to Resolve Journaling of Journal?

fsync() fsync() fsync() Journal DB Journal+DB =

Version-based B-Tree (MVBT)

9

SLIDE 10

Version-based B-Tree (MVBT)

Versioning

10 [T1, ∞) T1 Insert 10 Update 10 with 20 T2 10 [T1, T2) 20 [T2, ∞) Time

Do not overwrite old version data Do not need a rollback journal

10

Dead Entry

SLIDE 11

Node Split in Multi-Version B-Tree

key 25, ver=5

11

5 [3~∞) 10 [2~∞) 12 [4~∞) 40 [1~∞) P1

SLIDE 12

Node Split in Multi-Version B-Tree

key 25, ver=5

12

5 [3~5) 10 [2~5) 12 [4~5) 40 [1~5) P1 Dead Node

SLIDE 13

Node Split in Multi-Version B-Tree

13

5 [3~5) 10 [2~5) 12 [4~5) 40 [1~5) P1 key 25, ver=5

SLIDE 14

5 [5~∞) 10 [5~∞) P3 12 [5~∞) 40 [5~∞) P2

Node Split in Multi-Version B-Tree

14

5 [3~5) 10 [2~5) 12 [4~5) 40 [1~5) P1 key 25, ver=5

SLIDE 15

∞ [0~5) : P1

Node Split in Multi-Version B-Tree

15

5 [3~5) 10 [2~5) 12 [4~5) 40 [1~5) P1 5 [5~∞) 10 [5~∞) P3 12 [5~∞) 40 [5~∞) P2 10 [5~∞) : P3 ∞ [5~∞) : P2 P4 key 25, ver=5 25 [5~∞)

SLIDE 16

∞ [0~5) : P1

Node Split in Multi-Version B-Tree

16

5 [3~5) 10 [2~5) 12 [4~5) 40 [1~5) P1 5 [5~∞) 10 [5~∞) P3 12 [5~∞) 40 [5~∞) P2 10 [5~∞) : P3 ∞ [5~∞) : P2 P4 25 [5~∞) dirty dirty dirty dirty One more dirty page than

riginal B-Tree

SLIDE 17

I/O Traffic in MVBT

DB buffer cache

fsync()

17

Reduce the number of dirty pages!

MVBT

SLIDE 18

I/O Traffic in MVBT

MVBT LS -MVBT

DB buffer cache

fsync()

DB buffer cache

fsync()

18

SLIDE 19

Optimizations in Android I/O

Write

Read twrite tread

>>

Write Transaction 1 Write Transaction 2 Write Transaction 3

19

Single Insert Transaction

Multiple Insert

SLIDE 20

Optimizations

LS-MVBT

Lazy Split Multi-Version B-Tree (LS-MVBT)

Lazy Split Disabling Sibling Redistribution Metadata Embedding Lazy Garbage Collection Reserved Buffer Space

20

SLIDE 21

Legacy Split in MVBT

Optimization1: Lazy Split

21

∞ [0~5) : P1 5 [3~5) 10 [2~5) 12 [4~5) 40 [1~5) P1 5 [5~∞) 10 [5~∞) P3 12 [5~∞) 40 [5~∞) P2 10 [5~∞) : P3 ∞ [5~∞) : P2 P4 25 [5~∞) dirty dirty dirty dirty

4 dirty pages

SLIDE 22

Optimization1: Lazy Split

22

key 25, ver=5 5 [3~∞) 10 [2~∞) 12 [4~∞) 40 [1~∞) P1

SLIDE 23

Optimization1: Lazy Split

23

key 25, ver=5 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1 Lazy Node: Half-dead, Half-live

SLIDE 24

Optimization1: Lazy Split

24

key 25, ver=5 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1

SLIDE 25

Optimization1: Lazy Split

25

key 25, ver=5 12 [5~∞) 40 [5~∞) P2 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1

SLIDE 26

Optimization1: Lazy Split

26

key 25, ver=5 12 [5~∞) 40 [5~∞) P2 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1 10 [5~∞) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3 25 [5~∞)

SLIDE 27

Optimization1: Lazy Split

Lazy Node Overflow

27

key 8, ver = 6 Dead entries Dead entries 12 [5~∞) 40 [5~∞) P2 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1 10 [5~∞) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3 25 [5~∞)

SLIDE 28

Lazy Node Overflow → Garbage collect dead entries

Optimization1: Lazy Split

key 8, ver = 6

28

12 [5~∞) 40 [5~∞) P2 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1 10 [5~∞) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3 25 [5~∞)

SLIDE 29

Lazy Node Overflow → Garbage collect dead entries

Optimization1: Lazy Split

29

5 [3~∞) 8 [6~∞) 10 [2~∞) P1 10 [5~∞) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3 key 8, ver = 6 12 [5~∞) 40 [5~∞) P2 25 [5~∞) But, what if the dead entries are being accessed by other transactions?

SLIDE 30

Optimization2: Reserved Buffer Space

Option 1. Wait for read transactions to finish

30

12 [5~∞) 40 [5~∞) P2 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1 10 [5~∞) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3 25 [5~∞) key 8, ver = 6

SLIDE 31

5 [6~∞) 10 [6~∞) P3

Optimization2: Reserved Buffer Space

Option 2. Split as in legacy MVBT split

31

5 [3~6) 10 [2~6) 12 [4~5) 40 [1~5) P1 10 [5~∞) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3 12 [5~∞) 40 [5~∞) P2 25 [5~∞) key 8, ver = 6

SLIDE 32

5 [6~∞) 8 [6~∞) P3

Optimization2: Reserved Buffer Space

Option 2. Split as in legacy MVBT split

32

5 [3~6) 10 [2~6) 12 [4~5) 40 [1~5) P1 10 [5~6) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3 12 [5~∞) 40 [5~∞) P2 25 [5~∞) key 8, ver = 6 10 [6~∞) : P3 10 [6~∞)

SLIDE 33

Option 3. Pad some buffer space in tree nodes

Optimization2: Reserved Buffer Space

Buffer space is used when lazy node is full

33

40 [5~∞) P2 10 [2~∞) 12 [4~5) 40 [1~5) 9 [6~∞) P1 10 [5~∞) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3 25 [5~∞) key 8, ver = 6 12 [5~∞) If buffer space is also full, split as in legacy MVBT

SLIDE 34

Similar to rollback in MVBT

10 [5~∞) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3

Rollback in LS-MVBT

34

Txn 5 crashes

12 [5~∞) 40 [5~∞) P2 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1 25 [5~∞)

Rollback

Number of dirty nodes touched by rollback of LS- MVBT is also smaller than that of MVBT. 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1 10 [5~∞) : P1 ∞ [0~5) : P1 ∞ [5~∞) : P2 P3 5 [3~∞) 10 [2~∞) 12 [4~5) 40 [1~5) P1 ∞ [0~5) : P1 P3 ∞ [0~∞) : P1 P3 5 [3~∞) 10 [2~∞) 12 [4~∞) 40 [1~∞) P1

SLIDE 35

Optimization3: Lazy Garbage Collection

Periodic Garbage Collection

35

P1 P2 P3 P1

Transaction buffer cache

Transaction 1

SLIDE 36

Optimization3: Lazy Garbage Collection

Periodic Garbage Collection

36

Garbage Collection

P1

GC buffer cache

Transaction 1

P2 P3

Stopped

P1 P2 P3

fsync()

Extra Dirty Pages

Transaction buffer cache

SLIDE 37

Optimization3: Lazy Garbage Collection

Lazy Garbage Collection

37

P2 P3

Transaction buffer cache

Transaction 1

fsync()

P1 P1

Do not garabge collect if no space is needed

Insert

No Extra Dirty Page by GC

SLIDE 38

Version = “File Change Counter” in DB header page

25 [5~∞) 40 [1~∞) 15 [6~∞)

Optimization4: Metadata embedding

5

Header Page 1

Page 2 ...

Write Transaction

6

Read Transaction

5 6 Commit

dirty dirty

38

Page N

++

2 dirty pages

SLIDE 39

RAMDISK

Optimization4: Metadata embedding

Flush “File Change Counter” to the last modified

page and RAMDISK

Write Transaction

6

Read Transaction

5 Commit 5

39

25 [5~∞) 40 [1~∞) 15 [6~∞)

Header Page 1

Page 2 ...

Page N

5 4 6 6

SLIDE 40

Optimization4: Metadata embedding

Flush “File Change Counter” to the last modified

page and RAMDISK

RAMDISK

Volatile

6 6

40

Write Transaction

6

Read Transaction

5 Commit 25 [5~∞) 40 [1~∞) 15 [6~∞)

Header Page 1

Page 2 ...

Page N

6

dirty

4 1 dirty page CRASH

SLIDE 41

P5: 10 : P4 40 : P3

∞ : P2 25 12

Optimization5: Disable Sibling Redistribution

Sibling redistribution hurts insertion performance
Disable sibling redistribution → avoid dirtying 4 pages

P4: 5 10 P3: P2: 55 ∞

Insertion of key 20

12 25 15 40 20 P5: 10 : P4 40 : P3 ∞ : P2 40 10 dirty dirty dirty dirty

4 dirty pages

41

SLIDE 42

Optimization5: Disable Sibling Redistribution

Disabled sibling redistribution

42

P4: 5 10 P3: P5: 10 : P4 P2: 55 90

Insertion of key 20

12 25 15 40 40 : P3 90 : P2 P5: 20 15 : P5 dirty dirty dirty

3 dirty pages

SLIDE 43

Summary

Optimizations

43

Lazy Split Disabling Sibling Redistribution Metadata Embedding Lazy Garbage Collection Reserved Buffer Space

LS-MVBT

Avoid dirtying an extra page when split occurs Reduce the probability

f node split

Delete dead entries on the next mutation Avoid dirtying header page Do not touch siblings to make search faster

SLIDE 44

Performance Evaluation

Implemented LS-MVBT in SQLite 3.7.12
Testbed: Samsung Galaxy-S4 (JellyBean 4.3)
Exynos 5 Octa 5410 Quad Core 1.6GHz
2GB Memory
16GB eMMC
Performance Analysis Tools
Mobibench
MOST

44

SLIDE 45

WAL (Write-Ahead-Logging) mode

Default mode in Jelly Bean and KitKat
Commit -> Write to a log file
Checkpointing -> Flush logs to DB pages

DRAM WAL Log dirty DB Page DB Page 1 2

SLIDE 46

LS-MVBT fsync WAL fsync() B-tree computation

Analysis of insert Performance

WAL Checkpointing Interval

SQLite Insert (Response Time)

LS-MVBT: 30~78% faster than WAL mode

46

SLIDE 47

Analysis of insert Performance

LS-MVBT flushes

nly one dirty page

47

SQLite Insert (# of Dirty Pages per Insert)

SLIDE 48

Analysis of Block I/O Behavior

10 insertions (LS-MVBT) 10 insertions (WAL) 100 insertions (WAL) 100 insertions (LS-MVBT)

20 block accesses 34 block accesses 148 block accesses 218 block accesses

48

SQLite Insert (# of Accesses to Block Device)

SLIDE 49

I/O Traffic at Block Device Level

49

LS-MVBT saves 67% I/O traffic: 9.9 MB (LS-MVBT) vs 31 MB (WAL) x3 longer life time of NAND flash

SQLite Insert (I/O Traffic per 10 msec)

1000 insertions (LS-MVBT) 1000 insertions (WAL)

SLIDE 50

How about Search performance?
LS-MVBT is optimized for write performance.

50

SLIDE 51

Search Performance

LS-MVBT wins unless more than 93% of transactions are search

51

Transaction Throughput with varying Search/Insert ratio

SLIDE 52

How about recovery latency?
WAL mode exhibits longer recovery latency

due to log replay.

How about LS-MVBT?

52

SLIDE 53

Recovery

LS-MVBT is x5~x6 faster than WAL.

53

Recovery Time with varying # of insert operations to rollback

SLIDE 54

How much performance improvement

for each optimization?

54

SLIDE 55

Effect of Disabling Sibling Redistribution

Disabling sibling redistribution

↓

20% faster insertion

55

SQLite Insert: (Response Time and # of Dirty Pages)

SLIDE 56

Performance Quantification

56

Throughput of SQLite: Combining All Optimizations

40% improvement

51% improvement

70% improvemnet

X1.7 performance improvement LS-MVBT: 704 insertions/sec WAL : 417 insertions/sec

SLIDE 57

Conclusion

LS-MVBT resolves the Journaling of Journal anomaly via
Reducing the number of fsync()’s with Version based B-tree.
Reducing the overhead of single fsync() via lazy split,

disabling sibling redistribution, metadata embedding, reserved buffer space, lazy garbage collection.

LS-MVBT achieves 70% performance gain against WAL mode

(417 ins/sec 704 ins/sec) solely via software optimization.

57

SLIDE 58

Future/Ongoing Works

1. Improve the performance of WAL mode

3 dirty pages per insertion → not really necessary
Easier work than replacing the entire B-tree
Compatible with current SQLite database files
We expect the performance benefit would be similar to

LS-MVBT

2. SQLite for Non-Volatile Memory
Logging/Journaling in NVRAM
3. SQLite for multi-cores

58

SLIDE 59

Credit

59

Woo-Hee Kim Beomseok Nam Dongil Park Youjip Won
