Relativistic Red-Black Trees

Philip W. Howard, Jonathan Walpole, October 2013.

• Presented by Kendall Stewart

CS510 Concurrent Systems, Spring 2014

The Story so Far

• Locking is slow
• Non-blocking algorithms are complicated
• Memory barriers are necessary on most systems
• RCU solves many issues by providing full read-side

concurrency and a simple API

• But so far, we’ve just seen it in the context of the

Linux kernel. Does it generalize? How?

Relativistic Programming

Read-Copy Update Relativistic Programming spin_lock spin_unlock write-lock write-unlock rcu_read_lock rcu_read_unlock start-read end-read rcu_assign_pointer rcu_dereference rp-publish rp-read synchronize_rcu wait-for-readers call_rcu(kfree, …) rp-free

Relativistic Programming

• Captures the important idea of RCU: insert delays to

restrict the order of causally dependent events, while letting independent events proceed concurrently.

• Use publish / subscribe semantics (with memory

barriers and compiler directives) to prevent hardware

• r software reordering of causally dependent writes
• Wait for existing readers to preserve causal ordering

within non-atomic operations (e.g. complex changes to a data structure)

• What’s all this talk of causality about?

Relativism and Causality

W1 and W2 happen at the same time. R1 observes W1 before W2. R2 observes W2 before W1.

Relativism and Causality

W1 causes W2. R1 and R2 must both observe W1 before W2.

If we want a consistent ordering, W2 can wait until after W1 occurs:

Relativism and Causality

• Causal relationships are easy to reason about


for the same reason that sequential programs are easy to reason about — memory invariance is achieved by an implicit a causal relationship between all program statements.

• But not all concurrent relationships are causal.

Enforcing causality where it isn’t needed requires unnecessary delays which defeat concurrency.

• How do we figure out when causality is necessary?

Atomic Operations

Consider a simple deletion from a (singly) linked list: Takes effect atomically, by using rp-publish:

D = C.next rp-publish(B.next, D) rp-free(C)

No ordering issues; no inconsistent state.

Complex Operations

What about a more complex operation, like a move? If we could lock down the list, we could do it all in-place. But since we’ve got concurrent readers, we’ll have to make a copy of C to swing in.

Complex Operations

C’ = copy(C) C’.next = B rp-publish(A.next, C’) rp-publish(B.next, D) rp-free(C)

Simple, right? But wait…

Complex Operations

What if a reader was at B the whole time? That reader will miss C!

Reader

C’ = copy(C) C’.next = B rp-publish(A.next, C’) wait-for-readers() rp-publish(B.next, D) rp-free(C)

Complex Operations

• What happened?
• The insertion of C’ and the deletion of C were causally related:


C could not be removed until its copy was in place, because otherwise some readers might have missed the value of C.

• Therefore, we needed to enforce an ordering by inserting a delay


(waiting for existing readers).

• But some readers can still see the value of C twice! Once at C’, and once

at C before the removal takes effect.

• Whether or not this is okay depends on the semantics of the abstract

data type implemented by the list.

• If duplicates are okay, we do not need to wait for readers if we are moving

C to a position later in the list — some readers would simply be guaranteed to see the value of C twice.

• The insertion and deletion are still causally related, but the semantics of

the traversal pattern guarantee an ordering for free.

Complex Complexity

• That’s a lot of head-scratching for a really simple

data structure.

• Is relativistic programming really generalizable?
• As data structure complexity increases, does

applying RP get harder, or stay about the same?

• Let’s try applying it to a complicated data structure,

say, a Red-Black Tree.

Red-Black Trees

• A self-balancing binary search tree.
• Most commonly used for implementing a sorted

“map” data structure (i.e., a table of <key, value> pairs, sorted by key).

• Supports O(log N) inserts, lookups, and deletions.

Red-Black Trees

• Invariants:
• Standard BST (< to the left, >= to the right).
• Each node has a color (red or black).
• Both children of a red node are black.
• Every path from the root to a leaf has the same number

• f black nodes.
• Maintaining these invariants involves performing restructuring
• perations (rotations) during insertion and deletion.
• Red-black trees are difficult to parallelize for this reason!
• Previous attempts have involved global locking (slow as you

might expect) and fine-grained locking (susceptible to deadlock)

• A good test case for applying RP!

Relativistic Red-Black Trees

• Where do we need be careful with ordering?
• Operations to scrutinize:
• Read-side:
• Lookup
• Traversal (more on this towards the end)
• Write-side:
• Insertion
• Deletion
• Restructure (occurs during insertion and deletion)

Lookups

• Lookups do not require reading the color of a node, or chasing its

parent pointer.

• The ADT being implemented is a single map, which means that each

key is associated with exactly one value — so readers can stop searching once they find the key they’re looking for.

• Implications for Readers:
• They can proceed at full speed with only “start-read” and “end-read”
• Implications for Updaters:
• Changes to parent pointers or color will not affect readers.
• Having temporary duplicate nodes is okay, so long as we ensure

that all potential readers can find at least one of the copies.

Insertions

• New nodes are always inserted at a leaf position
• Readers will either see it or not, depending on the
• rdering of the updater’s rp-publish and the

reader’s rp-read.

• No chance to observe an inconsistent state.
• However, insertion may leave the tree unbalanced,

requiring restructuring!

Deletions

• Deleting a leaf is just like insertion — readers either see

the update or don’t (c.f. the linked list removal we saw earlier)

• Deleting an interior node is more complicated —

therefore we will swap the interior node with its in-order successor (which must be a left-leaf), and then remove the leaf node.

• A chance for special-case optimization arises if the in-
• rder successor is the immediate right child of the node

to be removed.

• Deletion also raises the spectre of restructuring!

General Internal Delete

To remove B:

• 1. Identify B’s successor (C) and make a copy (C’).
• 2. Replace B with C’.
• 3. Defer collection of B.
• 4. Remove C and defer its collection.

General Internal Delete

Oh, right! A reader looking for C might miss it.

• 1. Identify B’s successor (C) and make a copy (C’).
• 2. Replace B with C’.
• 3. Defer collection of B.
• 4. Wait for existing readers.
• 5. Remove C and defer its collection.

Reader Reader Reader

General Internal Delete

• 2. Replace B with C’
• 1. Identify and copy successor
• 3. Defer collection of B.
• 4. Wait for existing readers.
• 5. Remove C and defer

its collection.

Special Case

To remove B, where next node is right child:

• No copy is necessary, but A is still temporarily duplicated.
• Why don’t we have to use wait-for-readers()?
• Same reason as moving a node to a later position in a linked list: traversal ordering.

Diagonal Restructure

Zig Restructure

Read-side (Lookup) Performance

Single-writer Performance

Multi-writer Performance

• Possible synchronization mechanisms:
• Global locking — same as Linux kernel RCU
• Fine-grained locking — susceptible to deadlock
• Non-blocking algorithms — usually complex
• Software Transactional Memory — to be discussed next week!
• Used for comparison here:
• swissTM — STM applied to all operations
• RP-STM — Relativistic reads, transactional writes
• ccavl — Non-blocking AVL tree (separate data structure)
• rp — Relativistic reads, global locking for writes
• rpavl — AVL tree with relativistic reads, global locking for writes

Multi-writer Performance

Linearizability

• Can be a valuable property for some applications, and makes proofs
• f correctness easier — but it is not a pre-condition for correctness!
• These linearizability arguments rely on the fact that temporary

duplicate nodes are okay — so these are properties of relativistic red- black trees implementing a particular ADT, not of relativistic red-black trees in general.

• Lookups: take effect at the rp-read used to get to the current node
• Insertions: take effect at the rp-publish used to swing in the new node
• Deletions: take effect at the rp-publish used to make the node

unreachable — wait-for-readers ensures no inconsistent state is visible

• Traversals: may not be linearizable!

Traversals

• More complex than single lookups, because they require going up and

down the tree

• Current update algorithms assume that readers don’t chase parent

pointers, and therefore don’t take traversal patterns into account — this means that traversing readers may miss some nodes, or report duplicates

• Three possible solutions:
• Treat traversals as atomic — use reader-writer locking instead of

relativistic reads for traversals

• Conduct an O(N log N) traversal by executing a relativistic


lookup of every node

• Write more complex update operations to support relativistic


O(N) traversals

Traversals

O(N) algorithm clearly provides faster traversals:

Traversals

But slower updates:

Traversals

• Which method to use depends on the situation:
• Use reader-writer locking when a linearizable

snapshot is necessary

• Use O(N log N) algorithm when updates need to

be fast even in the presence of traversals

• Use O(N) algorithm for maximum traversal speed

Conclusions

• That wasn’t much more difficult to reason about than the


linked list traversal!

• Read performance is nearly at full unsynchronized speed, and


scales linearly

• Relativistic programming looks promising as a generalizable approach
• Unanswered questions:
• This is still just a case study — can we prove RP is generalizable?
• Can a compiler do this automatically?
• What would it take? What kind of analysis is needed?
• What kind of hints would the programmer have to give?

References

• Jonathan Walpole, “Relativistic Red Black Trees”.

• Slides. Spring 2013. http://www.cs.pdx.edu/

~walpole/class/cs510/spring2013/slides/14.pptx
