Reinforcement Learning

Course 9.54 Final review

Agent learning to act in an unknown environment

Reinforcement Learning Setup

St

Background and setup

• The environment is initially unknown or partially known
• It is also stochastic, the agent cannot fully predict what will

happen next

• What is a ‘good’ action to select under these conditions?
• Animals learning seeks to maximize their reward

Formal Setup

• The agent is in one of a set of states, {S1, S2,…Sn }
• At each state, it can take an action from a set of available

actions {A1, A2,…Ak}

• From state Si taking action Aj –> a new state Sj and a possible

reward

A1 A2 S1 A3 S2 S3 S1 S3 S2

R=2 R= -1

Stochastic transitions

The consequence of an action:

• (S,A) → (S', R)
• Governed by:
• P(S' | S, A)
• P(R | S, A, S')
• These probabilities are properties of the world. (‘Contingencies’)
• An assumption that the transitions are Markovian

Policy

• The goal is to learn a policy π: S → A
• The policy determines the future of the agent:

S1 S2 S3 A2 A1 A3 π π π

Model-based vs. Model-free RL

• Model-based methods assume that the probabilities:

– P(S' | S, A) – P(R | S, A, S')

are known and can be used in the planning

• In model-free methods:

– The ‘contingencies’ are not known – Need to be learned by exploration as a part of policy learning

S S(1) S(2) a1 a2 r1 r2

Step 1 defining Vπ(S)

• Start from S and just follow the policy π
• We find ourselves in state S(1) and reward r1 etc.
• Vπ(S) = < r1 + γ r2 + γ2 r3 + … >
• The expected (discounted) reward from S on.

Step 2: equations for V(S)

• Vπ(S) = < r1 + γ r2 + γ2 r3 + … >
• = Vπ(S) = < r1 + γ (r2 + γ r3 + … ) >
• = < r1 + γ V(S') >
• These are equations relating V(S) for different states.
• Next write the explicitly in terms of the known parameters

(contingencies):

A S1 S S3 S2 r1 r3 r2

Equations for V(S)

• Vπ(S) = < r1 + γ Vπ (S') > =
• E.g.:

Vπ(S) = Vπ(S) = [ 0.2 (r1 + γVπ (S1)) + 0.5 (r2 + γVπ (S2)) + 0.3 (r3 + γVπ (S3)) ]

• Linear equations, the unknowns are Vπ (Si)





'

] ) (S' V ) S' a, [r(S, a) S, | p(S'

S 



Improving the Policy

• Given the policy π, we can find the values Vπ(S) by solving the

linear equations iteratively

• Convergence is guaranteed (the system of equations is

strongly diagonally dominant)

• Given V(S), we can improve the policy:
• We can combine these steps to find the optimal policy

A’ S1 S S3 S2 r1 r3 r2 A π

Improving the policy

Value Iteration

learning V and π when the ‘contingencies’ are known:

Value Iteration Algorithm

* Value iteration is used in the problem set

Q-learning

• The main algorithm used for model-free RL

Q-values (state-action)

A1 A2 S1 A3 S2 S3 S1 S3 S2

R=2 R= -1

Q(S1, A1 ) Q(S1, A3 ) Qπ (S,a) is the expected return starting from S, taking the action a, and thereafter following policy π

Q-value (state-action)

• The same update is done on Q-values rather than on V
• Used in most practical algorithms and some brain

models

• Qπ (S,a) is the expected return starting from S, taking

the action a, and thereafter following policy π:

A1 A2 S1 A3 S2 S3 S1 S3 S2

R=2 R= -1

Q-values (state-action)

Q(S1, A1 ) Q(S1, A3 )

SARSA

• It is called SARSA because it uses:

s(t), a(t), r(t+1), s(t+1), a(t+1)

• A step like this uses the current π, so that each S has its

action according to the policy π: a = π(S)

SARSA RL Algorithm

* ԑ-greedy: with probability ԑ , do not select the greedy action. Instead select with equal probability among all actions.

TD learning Biology: dompanine

Behavioral support for ‘prediction error’

Associating light cue with food

‘Blocking’

• No response to the bell
• The bell and food were consistently associated
• There was no prediction error.
• Conclusion: prediction error, not association, drives learning !

Learning and Dopamine

• Learning is driven by the prediction error:

δ(t) = r + γV(S’)) – V(S)

• Computed by the dopamine system

(Here too, if there is no error, no learning will take place)

Dopaminergic neurons

• Dopamine is a neuro-modulator
• In the:

– VTA (ventral tegmental area) – Substantia Nigra

• These neurons send their axons to brain

structures involved in motivation and goal- directed behavior, for example, the striatum, nucleus accumbens, and frontal cortex.

Major players in RL

Effects of dopamine, why it is associated with reward and reward related learning

• Drugs like amphetamine and cocaine exert their

addictive actions in part by prolonging the influence of dopamine on target neurons

• Second, neural pathways associated

with dopamine neurons are among the best targets for electrical self- stimulation:

– Animals treated with dopamine receptor blockers learn less rapidly to press a bar for a reward pellet

Dopamine and prediction error

• The animal (rat, monkey) gets a cue (visual, or auditory).
• A reward after a delay (1 sec below)

Dopamine and prediction error
