Regulatory and Institutional frameworks for Smart Governance in Dam Safety Dr. Adrin Morales Torres Chief Technical Officer adrian.morales@ipresas.com Workshop about Water Adrin Morales Torres Security in Bulgaria Sofia, 19 th September,

slide-1
SLIDE 1

Regulatory and Institutional frameworks for Smart Governance in Dam Safety

  • Dr. Adrián Morales Torres

Chief Technical Officer

adrian.morales@ipresas.com Adrián Morales Torres www.ipresas.com

Workshop about Water Security in Bulgaria Sofia, 19th September, 2017

slide-2
SLIDE 2

REGULATORY AND INSTITUTIONAL FRAMEWORK IN DAM SAFETY

2

slide-3
SLIDE 3

IMPORTANCE OF DAM SAFETY REGULATORY FRAMEWORK

3

Source: Comparative Analysis of Dam Safety Case Studies in Latin American. World Bank (In Process).

2016

Survey for evaluation of Dam Safety Regulatory Framework:

0% 10% 20% 30% 40% 50% 60% Very low Low Medium High Very high

slide-4
SLIDE 4

IMPORTANCE OF DAM SAFETY REGULATORY FRAMEWORK

4

Source: Comparative Analysis of Dam Safety Case Studies in Latin American. World Bank (In Process).

2016

Survey about main Weak Points in Dam Safety Management:

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% Design Standards and Safety Reviews Monitoring and Surveillance Rainfall Forecasting Systems Flood Warning Systems Emergency Management Flood Risk Mapping Communication, Training and Education Programs Technical Capacity Building in Dam Risk Management Transboundary Watersheds Coordination Regulatory Framework

slide-5
SLIDE 5

DAM SAFETY REGULATORY FRAMEWORK IN EUROPEAN UNION

5

Currently, there is not a specific UE Directive about Dam Safety Management but…

DIRECTIVE 2007/60/EC ON THE ASSESSMENT AND MANAGEMENT OF FLOOD RISKS DIRECTIVE 2008/114/EC — IDENTIFICATION AND DESIGNATION OF EUROPEAN CRITICAL INFRASTRUCTURES AND ASSESSMENT OF THE NEED TO IMPROVE THEIR PROTECTION

DAM SAFETY MANAGEMENT

slide-6
SLIDE 6

DAM SAFETY REGULATORY FRAMEWORK IN EUROPEAN UNION

6

Source: EurCOLD Website: http://cnpgb.apambiente.pt/IcoldClub/index.htm

2016

1

  • DAMS AND HEALTH

2

  • DAMS AND ENERGY

3

  • DAMS AND CLIMATE

4

  • DAMS AND ENVIRONMENT

5

  • DAMS AND SUSTAINABLE SOCIETIES

6

  • OUTCOME: A CALL FOR A SMARTER GOVERNANCE FRAMEWORK
slide-7
SLIDE 7

DAM SAFETY GOVERNANCE

7

FLOODS (water levels, freeboards, waves) EARTHQUAKES (DBE, OBE) STRUCTURAL SAFETY (safety factor, stresses, strains, aging, uplift) INPECTION AND MONITORING (what, why, how, who and when) HYDROMECHANICAL ASSETS (design, operation, maintenance) OPERATIONAL RULES (Normal conditions, abnormal, extreme) REPORT (performing, analysis) DAM’S TECHNICAL DOCUMENTATION EMERGENCY ACTION PLANS (Identification, triggering factors, civil protection, warnings, communications, coordination, policies, processes, procedures) OPERATION & MAINTENANCE (water supply, energy, environmental restrains, maintenance activities)

MODERN DAM SAFETY PROGRAM/STANDARDS

Integration?

slide-8
SLIDE 8

8

FLOODS (water levels, freeboards, waves) EARTHQUAKES (DBE, OBE) STRUCTURAL SAFETY (safety factor, stresses, strains, aging, uplift) INPECTION AND MONITORING (what, why, how, who and when) HYDROMECHANICAL ASSETS (design, operation, maintenance) OPERATIONAL RULES (Normal conditions, abnormal, extreme) REPORT (performing, analysis) DAM’S TECHNICAL DOCUMENTATION EMERGENCY ACTION PLANS (Identification, triggering factors, civil protection, warnings, communications, coordination, policies, processes, procedures) OPERATION & MAINTENANCE (water supply, energy, environmental restrains, maintenance activities)

Loads System response Consequences

DAM SAFETY GOVERNANCE

RISK-INFORMED DECISION MAKING

slide-9
SLIDE 9

9

RISK-INFORMED DAM SAFETY GOVERNANCE

RISK = PROBABILITY OF FAILURE CONSEQUENCES X ACTIONS PRIORITIZATION DAM SAFETY GOVERNANCE

slide-10
SLIDE 10

10

RISK-INFORMED DAM SAFETY GOVERNANCE

slide-11
SLIDE 11

11

LESSONS FROM REAL IMPLEMENTATION

Spain 2008- Argentina 2017-

Source: www.ipresas.com

USA 2016-

slide-12
SLIDE 12

12

DAM SAFETY GOVERNANCE IN SPAIN

  • 600 mm of average yearly

precipitation

  • 2200 mm/year in Santiago
  • 120 mm/year in Cabo de

Gata

  • Over 1200 large dams in

Spain (9th in the world):

  • Public

and private dam

  • wners (responsible of Dam

Safety).

Source: MAGRAMA (Spanish Ministry of Agriculture, Food and Environment)

LEGEND (hm3)

slide-13
SLIDE 13

13

DAM SAFETY GOVERNANCE IN SPAIN

Ribadelago dam break in 1959 [144 fatalities]  1967 Dam design and construction regulation Tous dam break in 1982 [10 fatalities]  1996 Dam safety Technical regulation

slide-14
SLIDE 14

14

DAM SAFETY GOVERNANCE IN SPAIN

Available at: http://www.spancold.es/paginas/lista_publicaciones.asp?Categoria=GuiasTecnicas

slide-15
SLIDE 15

15

DAM SAFETY GOVERNANCE IN SPAIN

slide-16
SLIDE 16

16

CASE STUDY: DUERO RIVER AUTHORITY

27 dams and 95 proposed measures:

slide-17
SLIDE 17

17

CASE STUDY: DUERO RIVER AUTHORITY

slide-18
SLIDE 18

18

CASE STUDY: DUERO RIVER AUTHORITY

Source: Liana Ardiles, Daniel Sanz, Pedro Moreno, Esther Jenaro, Jürgen Fleitz and Ignacio Escuder at 6TH INTERNATIONAL CONFERENCE ON DAM ENGINEERING (2011)

slide-19
SLIDE 19

19

CASE STUDY: DUERO RIVER AUTHORITY

27 dams and 95 proposed measures:

Portfolio societal risk (lives/year)

Implementation cost (M€)

After implementing the first 5 risk reduction measures (Optimal sequence) No risk reduction after implementing measure nr. 37 ≈3M€ ≈28M€ ≈18M€

0.3 lives/year

slide-20
SLIDE 20

20

DAM SAFETY GOVERNANCE IN ARGENTINA

OBJETIVES

  • Capacity-building in risk-informed dam safety management.
  • Prioritization of investments informed by risk results.
  • Strategic action plan to apply risk-informed decision making in other dams in

the country.

  • Support to promote the development of a Dam Safety Law in Argentina.

Dam Safety Regulator Organism in Argentina

  • Regulates safety of main hydropower dams in

the country (32 dams).

  • Advisory body for other dams.

PILOT CASE ON QUALITATIVE AND QUANTITATIVE RISK ANALYSIS

slide-21
SLIDE 21

21

DAM SAFETY GOVERNANCE IN ARGENTINA

slide-22
SLIDE 22

22

PILOT CASE: CERROS COLORADOS SYSTEM

slide-23
SLIDE 23

23

FAILURE MODES IDENTIFICATION

  • 50 participants from different public and private entities related with safety in

the system of dams.

  • 20 failure modes were identified.
slide-24
SLIDE 24

24

DAM SAFETY GOVERNANCE IN USA

  • Public agency in charge of flood protection systems

(including 700 dams with multiple purposes).

  • Self-regulated.

Risk-informed Dam Safety Program Purpose: To protect life, property, lifelines, and the environment by ensuring that all dams are designed, constructed, regulated, operated, and maintained as safely and effectively as is reasonably practicable.

slide-25
SLIDE 25

25

USACE DAM SAFETY PROGRAM

Source: Safety of dams – Policy and Procedures (2014).

slide-26
SLIDE 26

26

USACE DAM SAFETY PROGRAM

Source: Safety of dams – Policy and Procedures (2014).

slide-27
SLIDE 27

27

DAM SAFETY GOVERNANCE IN USA

slide-28
SLIDE 28

helps to identify gaps, reinforce and promote

28

CONCLUSIONS: DAM SAFETY GOVERNANCE

Modern Dam Safety Program/Standards Risk-Informed Dam Safety Management Regulation and Institutional Framework are the basis for

slide-29
SLIDE 29

29

CONCLUSIONS: DAM SAFETY GOVERNANCE

PEOPLE RESPONSIBILITY RESOURCES INTEGRATION CONTINUOUS IMPROVE

SUCCESS

KEYS FOR A SUCCESSFUL GOVERNANCE AND REGULATORY FRAMEWORK FOR DAM SAFETY

slide-30
SLIDE 30

Thank you for your attention

  • Dr. Adrián Morales Torres

Chief Technical Officer

adrian.morales@ipresas.com Adrián Morales Torres www.ipresas.com

Workshop about Water Security in Bulgaria Sofia, 19th September, 2017
