Regulating the Environment The Atomic Weapons Establishment David Griffiths Team Leader Defence and Commercial Team Nuclear Regulation Group Our priorities and focus Radioactive substances regulation including discharges to the
SLIDE 2
SLIDE 3
Our priorities and focus
Radioactive substances regulation – including discharges to the environment and radioactive waste management/disposal Industrial processes Conventional wastes – water, solids Conventional discharges – water, liquid wastes Construction associated permitting Wider issues – resource usage
SLIDE 4
My “resources”
2 full time Nuclear Regulators 2 full time Environment Officers Access to the wider expertise of the Environment Agency eg flooding, legal services, waste management expertise Close work with other regulators including HSE,NII and DNSR on common issues
SLIDE 5
It’s not just about discharge limits!
Limits – RSA60, RSA93, EPR10 How limits are met depends on: plant and equipment – abatement, filtration Processes – effluent treatment Maintenance of all environmentally important plant Upgrades and replacements Managing discharges – BPM, BPEO – BAT
SLIDE 6
Key environmental discharges
Aqueous – Pangbourne Pipeline, “trade wastes”, Aldermaston Stream – north ponds Airborne – stack discharges Alpha Beta/gamma
SLIDE 7
1500 3000 4500 6000 7500 9000 10500 1952 1956 1960 1964 1968 1972 1976 1980 1984 1988 1992 1996 2000 2004
Year Activity MBq
Alpha Beta
Alpha and Beta Discharges to the Thames via the Pangbourne Pipeline (Aldermaston)
SLIDE 8
10 20 30 40 50 60 1993 1995 1997 1999 2001 2003 2005
Year Activity MBq
Alpha Beta
Alpha and Beta Discharges to the Thames via the Pangbourne Pipeline (Aldermaston)
SLIDE 9
Tritium Discharges to the Thames via the Pangbourne Pipeline (Aldermaston)
100 200 300 400 500 600 700 800 900 1965 1969 1973 1977 1981 1985 1989 1993 1997 2001 2005
Year Tritium Activity GBq
SLIDE 10
Tritium Discharges to the Thames via the Pangbourne Pipeline (Aldermaston)
5 10 15 20 25 30 35 1993 1995 1997 1999 2001 2003 2005
Year Tritium Activity GBq
SLIDE 11
100 200 300 400 500 600 700 800 1958 1963 1968 1973 1978 1983 1988 1993 1998 2003 2008 Year Activity MBq
Alpha Beta
Alpha and Beta Discharges to the Silchester Sewer (Aldermaston)
SLIDE 12
0.5 1 1.5 2 2.5 2000 2002 2004 2006 2008 2010
Year Activity GBq Tritium Discharges to Aldermaston Stream
SLIDE 13
10 20 30 40 50 60 1993 1995 1997 1999 2001 2003 2005 2007 2009 Year Activity MBq Alpha Beta Alpha and Beta Discharges to the Silchester Sewer (Aldermaston)
SLIDE 14
2 4 6 8 10 12 1962 1967 1972 1977 1982 1987 1992
Year Activity MBq
Alpha Beta
Alpha and Beta Discharges of Treated Trade Waste to Burghfield Brook
SLIDE 15
50 100 150 200 250 300 350 400 1952 1962 1972 1982 1992 2002
Year Activity MBq
Alpha Beta
Alpha and Beta discharges to Air (Aldermaston)
SLIDE 16
0.05 0.1 0.15 0.2 0.25 1993 1995 1997 1999 2001 2003 2005 2007 2009
Year Activity MBq
Alpha Beta
Alpha and Beta discharges to Air (Aldermaston)
SLIDE 17
100 200 300 400 500 1959 1964 1969 1974 1979 1984 1989 1994 1999 2004 2009
Year Activity TBq Tritium Discharges to Air (Aldermaston)
SLIDE 18
2 4 6 8 10 12 14 16 18 20 1993 1995 1997 1999 2001 2003 2005 2007 2009
Year Activity TBq Tritium Discharges to Air (Aldermaston)
SLIDE 19
0.5 1 1.5 2 1993 1995 1997 1999 2001 2003 2005 2007 2009 Year Activity KBq Alpha Discharges to Air (Burghfield)
SLIDE 20
0.02 0.04 0.06 0.08 0.1 0.12 0.14 1994 1996 1998 2000 2002 2004 2006 2008 Year Activity GBq Tritium Discharges to Air (Burghfield)
SLIDE 21
Checks and balances
AWE Environmental Monitoring Programme – imposed through permit by us on the company – various samples – soil, waters, herbage, fruits/vegetables, fish etc EA/FSA Check Monitoring Programmes Audit and Inspections of systems, procedures, assurance, training and standards Radioactivity in Food and the Environment – RIFE Reports
