Refactoring Section 7.2.1 (JIAs) OTHER SOURCES Code Evolution Programs evolve and code is NOT STATIC Code duplication Outdated knowledge (now you know more) Rethink earlier decisions and rework portions of the code Customer

slide-1
SLIDE 1

Refactoring

Section 7.2.1 (JIA’s) OTHER SOURCES

slide-2
SLIDE 2

Code Evolution

 Programs evolve and code is NOT STATIC

 Code duplication  Outdated knowledge (now you know more)

 Rethink earlier decisions and rework portions of the code  Customer changes

 Performance  Clarifications for teammates

 Refactoring!  In industry, it is common for refactoring not to be done due to

time pressure

 Fail to refactor now and there will be a far greater time investment to fix

problems later on as size and dependencies increase

 Code that needs refactoring can be viewed as a tumor or “growth”

slide-3
SLIDE 3

Refactoring

 The process of rewriting a computer program

 to improve its structure or readability  while explicitly preserving its external behavior

 A series of small behavior-preserving transformations

 Each transformation (called a 'refactoring') does little  The system is also kept fully working after each refactoring

 Reduces the chances that a system gets seriously broken during the

restructuring

 We can prove that after refactoring, behavior has not changed by rerunning

  • ur tests

 If not done regularly

 Over time, as more and more code is written, system becomes harder to

maintain and extend

slide-4
SLIDE 4

Refactoring

 Refactoring does not fix bugs or add new functionality

 Improves the understandability of the code  Changes code structure and design

 e.g. eliminates duplication or optimize

 Removes dead code

 Make it easier for human maintenance in the future

 Adding new behavior to a program might be difficult with

the program's current structure

 Refactor it first to make it easy, and then add the new

behavior

slide-5
SLIDE 5

Refactoring

 Coined in analogy with the factorization of numbers

and polynomials

 x2 − 1 can be factored as (x + 1)(x − 1)  Revealing an internal structure that was previously not

visible

 such as the two roots at −1 and +1

 Similarly, the change in visible code structure can often

reveal the "hidden" internal structure of the original code

 Over 100 in total

 18 supported by eclipse (3.0)

slide-6
SLIDE 6

Guidelines

 Make sure you have good tests before

refactoring

 Know quickly if your changes have broken system

 Don’t refactor and add functionality at the

same time

 WHY?

 Refactor early and refactor often

slide-7
SLIDE 7

Refactoring

 Simple example:

 Change a variable name into something more

meaningful, such as from a single letter i to interestRate

 More complex examples

 Eliminating duplicate code

slide-8
SLIDE 8

Refactoring Recurring Code

 Eliminates duplicate code segments

 Makes maintenance costly

 Consists of the following steps

 Identifying recurring code segments

 Same logic and often same exact code  CAVEAT: Not all code that looks alike is actually alike!

 Capture this logic in a generic component defined ONCE  Restructure program so that every occurrence of the code segment is a

reference to the generic component

 via

 method invocation  inheritance  delegation

slide-9
SLIDE 9

Refactoring via Method Invocation

Class Computation

void method1( . . .) {

 //…  computeStep1();  computeStep2();  computeStep3();  //..  }

void method2( . . .) {

 //…  computeStep1();  computeStep2();  computeStep3();  //..  }

//..

}

Class RefactoredComputation

void method1( . . .) {

 //…  computeAll();  //..  }

void method2( . . .) {

 //…  computeStepAll();  //..  }

void computeAll(. . .){

 computeStep1();  computeStep2();  computeStep3();}

//..

}

slide-10
SLIDE 10

via Method Invocation

 Extract Method Refactoring  Effective only when

 All methods that contain the recurring code

segment belong to the same class

 Each occurrence of the recurring code segment is

contained within a single method

slide-11
SLIDE 11

via Inheritance

 class ComputationA{

 void method1(…) {

 //…  computeStep1();  computeStep2();  computeStep3();  //..}

 //… }

 class ComputationB{

 void method2(…) {

 //…  computeStep1();  computeStep2();  computeStep3();  //..}

 //… }

 For recurring code segments in different classes

slide-12
SLIDE 12

via Inheritance

 Introduce a common superclass for ComputationA and

ComputationB

Place common code in a method in superclass

class Common{

 void computeAll( . . .) {

computeStep1();

computeStep2();

computeStep3();}

 }

When extracting common code segments to a superclass, all fields involved in the computations must also be extracted and promoted

 Pull Up Method Refactoring

slide-13
SLIDE 13

via Inheritance

 class ComputationA

extends Common{

 void method1(…) {

 //…  computeAll();  //..}

 //… }

 class ComputationB

extends Common{

 void method2(…) {

 //…  computeAll();  //..}

 //… }

slide-14
SLIDE 14

via Inheritance

 Example 7.1 (p.257) and Example 4.12 (p.149)

slide-15
SLIDE 15

via Delegation

 Done also for refactoring recurring code

segments in different classes like via inheritance

 In cases where (at least one of) the involved

classes already extend(s) other classes

 Can’t extend any further

 Introduce a helper class

slide-16
SLIDE 16

via Delegation

 class ComputationA

extends SuperClass{

 void method1(…) {

 //…  computeStep1();  computeStep2();  computeStep3();  //..}

 //… }

 class ComputationB{

 void method2(…) {

 //…  computeStep1();  computeStep2();  computeStep3();  //..}

 //… }

slide-17
SLIDE 17

via Delegation

 Place common code in a method in helper class

 class Helper{

 void computeAll( . . .) {  computeStep1();  computeStep2();  computeStep3();}  }

 Both classes need to contain references to the helper

class

slide-18
SLIDE 18

via Delegation

 class ComputationA

extends SuperClass{

 void method1(…) {

 //…

Helper helper = new Helper();

 helper.computeAll();  //..}

 //… }

 class ComputationB {

 void method2(…) {

 //…

Helper helper = new Helper();

 helper.computeAll();  //..}

 //… }

slide-19
SLIDE 19

Important Refactorings

 Rename Method or Field  Extract Method  Pull Up Method or Field  Push Down Method or Field  Move Method or Field  Encapsulate Field  Decompose Conditional  Replace Magic Number with Symbolic

Constant

 100 or so more

slide-20
SLIDE 20

Bad Code Smells

 Duplicate Code

 Number 1 enemy  Duplication in the same class or in different classes

 Long Methods

 Methods should be short  Easier to understand and maintain  Do only what they are supposed to do

 Large Classes

 A class trying to do too much  Too many instance variables (not very related to one another)

 E.g. university person (student, faculty, staff, etc …)

 Long Parameter Lists

 Pass enough to get everything you need  E.g. instead of passing all instance variables of an object, pass the object

itself

slide-21
SLIDE 21

Bad Code Smells

Feature Envy

A method in a class seems more interested in a class other than the one it is actually in

Move Method to other class

Lazy Classes

A class must pay for itself

Costs money and time to maintain and understand classes!

E.g. Data Classes

Classes having ONLY fields, setters and getters

Dumb data holders

Manipulated a lot by other classes

Comments

Don’t use them as deodorant

Thickly commented code implies that code is hard to understand and probably needs refactoring

[http://www.cs.uu.nl/docs/vakken/oomp/BadSmells.html]

[http://sourcemaking.com/refactoring/bad-smells-in-code]

slide-22
SLIDE 22

Composing Methods

 Refactoring deals a lot with composing

methods to package code properly

 Get rid of methods that are too long or do too

much

 A lot of their information gets buried by their

complex logic

 Extract Method  Replace Temp with Query  Remove Assignments to Parameters

slide-23
SLIDE 23

Extract Method

You have a code fragment that can be grouped together

Reduce method size (Method is too long)

Clarity (Need comments to understand into purpose)

Eliminate redundancy (Code is duplicated in multiple methods)

Turn the fragment into a method whose name explains the purpose of the method

shorter well-named methods

Can be used by other methods

Higher-level methods read more like a series of comments

void printOwing() {

printBanner(); //print details

System.out.println("name: " + _name);

System.out.println("amount: " + getOutstanding());

}

slide-24
SLIDE 24

 void printOwing() {

 printBanner();  printDetails(getOutstanding());

 }

 void printDetails (double outstanding) {

 System.out.println ("name: " + _name);

 System.out.println ("amount " + outstanding);

 }

Extract Method

slide-25
SLIDE 25

 Steps

 Create a new method and name it after what it does  Copy extracted code from the source into the target  Scan the extracted method for references to any variables that are local

in scope to the source method

 These are local variables and parameters to the target method  Temporary variables used only within the extracted code become temporary

variables declared in target method

 Remove from old code  Temporary variables that are read from the extracted code (used elsewhere)

are passed into the target method as parameters

 Check for local-scope variables modified by extracted code  One modified variable: treat extracted code as a query and assign the result to

the variable concerned

 More than one variable: can’t extract method as it stands

 Replace extracted code in source method with a call to target method  Compile and test

Extract Method

slide-26
SLIDE 26

Example: No Local Variables

void printOwing() {

List listOfOrders = this.orders.elements();

double outstanding = 0.0;

// print banner

System.out.println ("**************************");

System.out.println ("***** Customer Owes ******");

System.out.println ("**************************");

// calculate outstanding

for(Order order: listOfOrders)

  • utstanding += order.getAmount();

}

//print details

System.out.println ("name:" + this.name);

System.out.println ("amount" + outstanding);

}

slide-27
SLIDE 27

Example: No Local Variables

void printOwing() {

List listOfOrders = this.orders.elements();

double outstanding = 0.0;

printBanner();

// calculate outstanding

for(Order order: listOfOrders)

  • utstanding += order.getAmount();

}

//print details

System.out.println ("name:" + this.name);

System.out.println ("amount" + outstanding);

}

void printBanner() {

// print banner

System.out.println ("**************************");

System.out.println ("***** Customer Owes ******");

System.out.println ("**************************");

}

slide-28
SLIDE 28

Example: Using Local Variables

void printOwing() {

List listOfOrders = this.orders.elements();

double outstanding = 0.0;

printBanner();

// calculate outstanding

for(Order order: listOfOrders)

  • utstanding += order.getAmount();

}

//print details

printDetails(outstanding);

 }

 void printDetails (double outstanding) {

 System.out.println ("name:" + _name);  System.out.println ("amount" + outstanding);

 }

slide-29
SLIDE 29

Example: Reassigning a Local Variable

void printOwing() {

List listOfOrders=this.orders.elements();

double outstanding = 0.0;

printBanner();

// calculate outstanding

for(Order order: listOfOrders)

  • utstanding += order.getAmount();

}

//print details

printDetails(outstanding);

}

void printOwing() {

printBanner();

double outstanding = getOutstanding();

printDetails(outstanding);

}

double getOutstanding() {

List listOfOrders = this.orders.elements();

double outstanding = 0.0;

for(Order order: listOfOrders)

  • utstanding +=
  • rder.getAmount();

return outstanding;

}

slide-30
SLIDE 30

Example: Reassigning a Local Variable

 The List variable is used only in the extracted code

 We can move it entirely within the new method

 The outstanding variable is used in both places

 We need to return it from the extracted method

 The outstanding variable is initialized only to an

  • bvious initial value

 We can initialize it only within the extracted method  If something more involved happens to the variable, we

have to pass in the previous value as a parameter

slide-31
SLIDE 31

Moving Features Between Objects

 One of the most fundamental decision in object-

  • riented design is deciding where to put

responsibilities

 “I've been working with objects for more than a decade, but

I still never get it right the first time. That used to bother me, but now I realize that I can use refactoring to change my mind in these cases.”

 Martin Fowler

 Move Method  Move Field  Extract Class

slide-32
SLIDE 32

Move Method

 A method is using more features or is used by more methods of

another class than the class on which it is defined

 Create a new method with a similar body in the class it uses most  Either turn the old method into a simple delegation, or remove it

altogether

slide-33
SLIDE 33

Move Method

Examine all class attributes used by the source method that are defined on the source class and consider whether they also should be moved

If the attribute is used only by the method you are about to move, you might as well move it

If the attribute is used by other methods, consider moving them as well

Declare the method in the target class

You may choose to use a different name, one that makes more sense in the target class

Copy the code from the source method to the target

Adjust the method to make it work in its new home

If the method uses its source, you need to determine how to reference the source object from the target method

 If there is no mechanism in the target class, pass the source object reference to the

new method as a parameter

Compile the target class

slide-34
SLIDE 34

Move Method

Determine how to reference the correct target object from the source

There may be an existing field or method that will give you the target

If not, see whether you can easily create a method that will do so

If not, you need to create a new field in the source that can store the target

Turn the source method into a delegating method

Compile and test

Decide whether to remove the source method or retain it as a delegating method

Leaving the source as a delegating method is easier if you have many references

If you remove the source method, replace all the references with references to the target method

You can compile and test after changing each reference, although it is usually easier to change all references with one search and replace

Compile and test

slide-35
SLIDE 35

Move Method

class Account{

private AccountType type;

private int daysOverdrawn;

double overdraftCharge() {

if (type.isPremium()) {

double result = 10;

if (daysOverdrawn > 7)

result += (daysOverdrawn - 7) * 0.85;

return result;}

else

return daysOverdrawn * 1.75;

}

double annualBankCharge() {

double result = 25;

if (daysOverdrawn > 0)

result += overdraftCharge();

return result;

}

}

slide-36
SLIDE 36

Move Method

Imagine

Several new account types

Each has its own rule for computing the overdraft charge

Thus, we need to move the overdraftCharge method over to the AccountType class

Start by looking at the features that the overdraftCharge method uses and consider whether to move a batch of methods together

We need the daysOverdrawn field to remain on the account class

Will vary with individual accounts

Copy the method body over to the account type and get it to fit

slide-37
SLIDE 37

Move Method

 When we need to use a feature of the source

class we can do one of the following:

 (1) move this feature to the target class as well,  (2) pass the source object as a parameter to the

method

 (3) create or use a reference from the target class

to the source

slide-38
SLIDE 38

Move Method

 class AccountType...

 double overdraftCharge(int daysOverdrawn){

 if (isPremium()) {

 double result = 10;

 if (daysOverdrawn>7)

 result+=(daysOverdrawn-7)*0.85;

 return result;}

 else

 return daysOverdrawn * 1.75;

 }

slide-39
SLIDE 39

Move Method

class Account...

private AccountType type;

private int daysOverdrawn;

double overdraftCharge() {

return type.overdraftCharge(daysOverdrawn);}

double annualBankCharge() {

double result = 4.5;

if (daysOverdrawn > 0)

result += overdraftCharge();

return result;

}

We can leave things like this, or we can remove the method in the source class

To remove the method I need to find all callers of the method and redirect them to call the method in account type:

slide-40
SLIDE 40

Move Method

 class Account...

 private AccountType type;  private int daysOverdrawn;  double annualBankCharge() {

 double result = 4.5;  if (_daysOverdrawn > 0)  result += type.overdraftCharge(daysOverdrawn);  return result;

 }

 Once we’ve replaced all the callers, we can remove

the method declaration in account

slide-41
SLIDE 41

Move Field

 A field is, or will be, used by another class

more than the class on which it is defined

 Create a new field in the target class, and

change all its users

slide-42
SLIDE 42

Move Field

 As the system develops, we find the need for new

classes and the need to shuffle responsibilities around

 A design decision that is reasonable and correct one

week can become incorrect in another

 Consider moving a field if you see more methods on

another class using the field than the class itself

 This usage may be indirect, through getting and setting

methods

 We may choose to move the methods; this decision is based

  • n interface

 But if the methods seem sensible where they are, we move the field

slide-43
SLIDE 43

Move Field

If field is public, make it private and create a setter and a getter

Compile and test

Create a field in the target class with a getter and setter methods

Compile the target class

Determine how to reference the target object from the source

An existing field or method may give you the target

If not, see whether you can easily create a method that will do so

If not, you may need to create a new field in the source that can store the target

slide-44
SLIDE 44

Move Field

class Account...

private AccountType type;

private double interestRate;

double interestForAmountDays(double amount, int days) {

 return interestRate * amount * days / 365;

}

Move the interest rate field to the account type

Assume there are several methods with that reference, of which interestForAmountDays is one example

class AccountType...

private double interestRate;

void setInterestRate (double arg) {

 interestRate = arg;

}

double getInterestRate () {

 return interestRate;

}

slide-45
SLIDE 45

Move Field

 Redirect the methods from the account class to

use the account type and remove the interest rate field in the account

 private double interestRate;

 double interestForAmountDays (double amount,

int days){

 return type.getInterestRate() * amount * days /

365;

 }

slide-46
SLIDE 46

Organizing Data

 Refactorings that make working with data

easier

 Replace Array with Object  Change Unidirectional Association to

Bidirectional

 Replace Magic Number with Symbolic

Constant

 Encapsulate Field

slide-47
SLIDE 47

Replace Magic Number with Symbolic Constant

 You have a literal number with a particular meaning  Create a constant, name it after the meaning, and replace the

number with it

 double potentialEnergy(double mass, double

height) {

 return mass * 9.81 * height;}

 double potentialEnergy(double mass, double

height) {

 return mass * GRAVITATIONAL_CONSTANT * height;}  static final double GRAVITATIONAL_CONSTANT = 9.81;

slide-48
SLIDE 48

Replace Magic Number with Symbolic Constant

 Motivation

 Magic numbers are one of oldest ills in computing  They are numbers with special values that usually are not obvious  Magic numbers are really nasty when you need to reference the same

logical number in more than one place

 If the numbers might ever change, making the change is a nightmare.  Even if you don't make a change, you have the difficulty of figuring out what

is going on

 Many languages allow you to declare a constant

 There is no cost in performance  There is a great improvement in readability.

 If the magic number is the length of an array, use an

Array.length instead

slide-49
SLIDE 49

Replace Magic Number with Symbolic Constant

 Declare a constant and set it to the value of the magic number  Find all occurrences of the magic number  See whether the magic number matches the usage of the

constant; if it does, change the magic number to use the constant

 Compile  When all magic numbers are changed, compile and test  At this point all should work as if nothing has been changed

 A good test is to see whether you can change the constant easily

slide-50
SLIDE 50

Encapsulate Field

 There is a public field

 Make it private and provide accessors

 public String name  

 private String name;  public String getName()

 {return name;}

 public void setName(String arg)

 {name = arg;}

slide-51
SLIDE 51

Encapsulate Field

 One of the principal tenets of object orientation

is encapsulation, or data hiding

 Should never make your data public  When you make data public, other objects can

change and access data values without the owning

  • bject's knowing about it

 This separates data from behavior

slide-52
SLIDE 52

Encapsulate Field

 Create getting and setting methods for the field  Find all clients outside the class that reference the field

 If the client uses the value, replace the reference with a call to the

getting method

 If the client changes the value, replace the reference with a call to the

setting method

 Compile and test after each change  Once all clients are changed, declare the field as private  Compile and test

slide-53
SLIDE 53

Simplifying Conditional Expressions

 Conditional logic has a way of getting tricky and there are a

number of refactorings which can used to simplify it

 Decompose Conditional

 breaks a conditional into pieces  separates the switching logic from the details of what happens

 Consolidate Duplicate Conditional Fragments

 used to remove any duplication within the conditional code

 Remove Control Flag

 used to get rid of the awkward control flags

 Introduce Assertion

slide-54
SLIDE 54

Decompose Conditional

 You have a complicated conditional (if-then-else)

statement

 Extract methods from the condition, then part, and

else part (charge in summer VS winter)

if (date.before (SUMMER_START)|| date.after(SUMMER_END))

charge = quantity * _winterRate + _winterServiceCharge;

else

charge = quantity * _summerRate;

if (notSummer(date))

charge = winterCharge(quantity);

else

charge = summerCharge(quantity);

slide-55
SLIDE 55

Decompose Conditional

Motivation

The problem usually lies in the fact that the code, both in the condition checks and in the actions, tells you what happens but can easily obscure why it happens

Can make our intention clearer by decomposing it and replacing chunks of code with a method calls named after the intention of that block of code

With conditions you can receive further benefit by doing this for the conditional part and each of the alternatives

This way you highlight the condition and make it clear what you are branching

  • n

You also highlight the reason for the branching

Steps

Extract the condition into its own method

Extract the then part and the else part into their own methods

Do each extraction separately and compile and test after each one

slide-56
SLIDE 56

Example

if (date.before(SUMMER_START)|| date.after(SUMMER_END))

charge = quantity * this.winterRate + this.winterServiceCharge;

else

 charge = quantity * this.summerRate;

 Extract the conditional and each leg as follows  if (notSummer(date))

 charge = winterCharge(quantity);

 else

 charge = summerCharge(quantity);

slide-57
SLIDE 57

Example

private boolean notSummer(Date date) {

return date.before (SUMMER_START) || date.after(SUMMER_END);

}

private double summerCharge(int quantity) {

 return quantity * this.summerRate;

}

private double winterCharge(int quantity) {

return quantity * this.winterRate + this.winterServiceCharge;

}

slide-58
SLIDE 58

Making Method Calls Simpler

 Objects are all about interfaces  Coming up with interfaces that are easy to understand and use

is a key skill in developing good object-oriented software

 We explore refactorings that make interfaces more

straightforward

 Rename Method  Add Parameter  Parameterize Method  Preserve Whole Object  Hide Method  Replace Error Code with Exception

slide-59
SLIDE 59

Rename Method

 The name of a method does not reveal its

purpose

 Change the name of the method

slide-60
SLIDE 60

Rename Method

 Methods should be named in a way that communicates their

intention

 A good way to do this is to think what the comment for the

method would be and turn that comment into the name of the method

 Sometimes you won't get your names right the first time

 May well be tempted to leave it—after all it's only a name

 If you see a badly named method, it is imperative that you

change it

 Remember your code is for a human first and a computer second

 Good naming is a skill that requires practice; improving this skill

is the key to being a truly skillful programmer

slide-61
SLIDE 61

Rename Method

Steps:

Check to see whether the method signature is implemented by a superclass or subclass

 If it is, perform these steps for each implementation

Declare a new method with the new name

Copy the old body of code over to the new name and make any alterations to fit

Compile

Change the body of the old method so that it calls the new one

 If you only have a few references, you can reasonably skip this step

Compile and test

Find all references to the old method name and change them to refer to the new

  • ne

Compile and test after each change

Remove the old method

 If the old method is part of the interface and you cannot remove it, leave it in place

and mark it as deprecated

Compile and test

slide-62
SLIDE 62

Example

 public String getTelephoneNumber() {

 return ("(" + officeAreaCode + ") " + officeNumber);

 }  Rename the method to getOfficeTelephoneNumber  class Person...

 public String getTelephoneNumber(){

 return getOfficeTelephoneNumber();

 }  public String getOfficeTelephoneNumber() {

 return ("(" + officeAreaCode + ") " + officeNumber);

 }

 Find the callers of the old method, and switch them to call the

new one

slide-63
SLIDE 63

Dealing with Generalization

 Mostly dealing with moving methods around a

hierarchy of inheritance

 Pull Up Field  Pull Up Method  Push Down Method  Push Down Field

slide-64
SLIDE 64

Pull Up Field

 Two subclasses have the same field  Move the field to the superclass

slide-65
SLIDE 65

Pull Up Field

 Steps:

 Inspect all uses of the candidate fields to ensure they are

used in the same way

 If fields do not have same name, rename the fields so that

they have the name you want to use for the superclass field

 Compile and test  Create a new field in the superclass

 If the fields are private, you will need to protect the superclass

field so that the subclasses can refer to it

 Delete the subclass fields  Compile and test  Consider using encapsulation the new field

slide-66
SLIDE 66

Pull Up Method

 You have methods with identical results on

subclasses

 Move them to the superclass

slide-67
SLIDE 67

Pull Up Method

Steps:

Inspect the methods to ensure they are identical

If the methods have different signatures, change the signatures to the one you want to use in the superclass

Create a new method in the superclass, copy the body of one of the methods to it, adjust and compile

 If the method calls another method that is present on both subclasses but not the

superclass, declare an abstract method on the superclass

 If the method uses a subclass field, use Pull Up Field

Delete one subclass method

Compile and test

Keep deleting subclass methods and testing until only the superclass method remains

Take a look at the callers of this method to see whether you can change a required type to the superclass

slide-68
SLIDE 68

Example

slide-69
SLIDE 69

Example

 The createBill method is identical for each class:  void createBill (date Date){

 double chargeAmount = chargeFor (lastBillDate, date);  addBill (date, charge);

 }  Assume we can't move the method up into the superclass,

because chargeFor is different on each subclass

 First declare it on the superclass as abstract:  class Customer...

 abstract double chargeFor(date start,date end)

slide-70
SLIDE 70

Example

 Copy createBill from one of the subclasses  Compile with that in place and then remove the

createBill method from one of the subclasses, compile, and test

 Then remove it from the other, compile, and

test

slide-71
SLIDE 71

Example

slide-72
SLIDE 72

Push Down Method

 Behavior on a superclass is relevant only for

some of its subclasses

 Move it to those subclasses

slide-73
SLIDE 73

Push Down Method

 Steps:

 Declare a method in all subclasses and copy the body into

each subclass

 You may need to declare fields as protected for the method to access

them

 Usually you do this if you intend to push down the field later  Otherwise use an accessor on the superclass  If this accessor is not public, you need to declare it as protected.

 Remove method from superclass  Compile and test  Remove the method from each subclass that does’t need it  Compile and test

slide-74
SLIDE 74

Push Down Method

 A field is used only by some subclasses  Move the field to those subclasses

slide-75
SLIDE 75

Push Down Field

 The opposite of Pull Up Field  Steps

 Declare the field in all subclasses  Remove the field from the superclass  Compile and test  Remove the field from all subclasses that don't

need it

 Compile and test

slide-76
SLIDE 76

Refactorings

 Extract Method  Move Field or Method  Encapsulate Field  Decompose Conditional  Replace Magic Number with Symbolic

Constant

 Rename Method or Field  Pull Up Field  Pull Up Method  Push Down Field  Push Down Method
