Rectangling Panoramic Images via Warping Kaiming He Huiwen Chang Jian Sun Microsoft Research Asia Tsinghua University Microsoft Research Asia Introduction Panoramas are irregular Introduction Panoramas are irregular Rectangles

slide-1
SLIDE 1

Rectangling Panoramic Images via Warping

Kaiming He

Microsoft Research Asia

Huiwen Chang

Tsinghua University

Jian Sun

Microsoft Research Asia

slide-2
SLIDE 2

Introduction

  • Panoramas are irregular
slide-3
SLIDE 3

Introduction

  • Panoramas are irregular
  • Rectangles are favored

panoramas in panoramas in

slide-4
SLIDE 4

Introduction

  • Panoramas are irregular
  • Rectangles are favored
  • “Rectangling” the panoramas
slide-5
SLIDE 5

Introduction

  • Panoramas are irregular
  • Rectangles are favored
  • “Rectangling” the panoramas

– Cropping

slide-6
SLIDE 6

Introduction

  • Panoramas are irregular
  • Rectangles are favored
  • “Rectangling” the panoramas

– Cropping – Inpainting

content-aware fill

slide-7
SLIDE 7

Introduction

  • Panoramas are irregular
  • Rectangles are favored
  • “Rectangling” the panoramas

– Cropping – Inpainting

content-aware fill

slide-8
SLIDE 8

Introduction

  • Panoramas are irregular
  • Rectangles are favored
  • “Rectangling” the panoramas

– Cropping – Inpainting – Warping new

  • ur warping
slide-9
SLIDE 9

Why Warping?

  • Panoramas are often distorted

distortion

slide-10
SLIDE 10

Why Warping?

  • Panoramas are often distorted
  • Warping can be unnoticeable
  • ur warping
slide-11
SLIDE 11

Why Warping?

  • Panoramas are often distorted
  • Warping can be unnoticeable
  • Warping is robust

– shape manipulation – image retargeting – image projection – video stabilization

[Igarashi et al, SIGGRAPH 05] … [Wang et al, SIGGRAPH Asia 08] … [Carroll et al, SIGGRAPH 09] … [Liu et al, SIGGRAPH 09] …

slide-12
SLIDE 12

Why Warping?

  • Panoramas are often distorted
  • Warping can be unnoticeable
  • Warping is robust
  • Rectangling via warping
slide-13
SLIDE 13

Challenges

  • Meshing

– irregular input – boundary conditions

?

slide-14
SLIDE 14

Challenges

  • Meshing

– irregular input – boundary conditions

  • Content-preserving

– boundary constraints – shapes – straight lines

?

slide-15
SLIDE 15

Solution: Local + Global

local warping mesh global warping warped back

slide-16
SLIDE 16

Local Warping

  • Mesh-free
slide-17
SLIDE 17

missing known pix

Local Warping

  • Mesh-free
  • Seam Carving [Avidan & Shamir 07]

longest missing boundary

slide-18
SLIDE 18

Local Warping

  • Mesh-free
  • Seam Carving [Avidan & Shamir 07]

– insert a seam – shift pixels

seam

shift

slide-19
SLIDE 19

Local Warping

  • Mesh-free
  • Seam Carving [Avidan & Shamir 07]

– insert a seam – shift pixels

  • Seam Carving = Warping

seam

shift

slide-20
SLIDE 20

Local Warping

  • Mesh-free
  • Seam Carving [Avidan & Shamir 07]

– insert a seam – shift pixels

  • Seam Carving = Warping

(A video was removed when converting this ppt to pdf.)

seam carving

slide-21
SLIDE 21

Local Warping

  • Mesh-free
  • Seam Carving [Avidan & Shamir 07]

– insert a seam – shift pixels

  • Seam Carving = Warping

grid mesh

slide-22
SLIDE 22

Local Warping

  • Mesh-free
  • Seam Carving [Avidan & Shamir 07]

– insert a seam – shift pixels

  • Seam Carving = Warping

warped back

slide-23
SLIDE 23

Global Warping

  • Mesh optimization

min 𝐹(𝑊)

𝑊: all vertexes

slide-24
SLIDE 24

Global Warping

  • Mesh optimization

– Boundary constraints

𝐹𝐶 𝑊 : hard data term

slide-25
SLIDE 25

Global Warping

  • Mesh optimization

– Boundary constraints – Shape preservation

as-similar-as- possible

[Igarashi et al, SIGGRAPH 05] [Liu et al, SIGGRAPH 09] [Wang et al, SIGGRAPH 10] …

𝐹𝑇 𝑊 = 𝑊𝑈𝑀𝑊

𝑀: Laplacian

smoothness term in warping

slide-26
SLIDE 26

input boundary + shape boundary + shape + line detected lines

[PAMI 10]

slide-27
SLIDE 27

Line Preservation

  • Lines in the same direction

are rotated by the same 𝜄

[Chang & Chuang, CVPR 12]

detected lines

in a block

slide-28
SLIDE 28

Line Preservation

  • Lines in the same direction

are rotated by the same 𝜄

[Chang & Chuang, CVPR 12]

quantized directions

(50 bins)

direction 𝑗 direction 𝑘

slide-29
SLIDE 29

Line Preservation

  • Lines in the same direction

are rotated by the same 𝜄

[Chang & Chuang, CVPR 12]

warped

direction 𝑗 direction 𝑘

𝜄𝑗 𝜄

𝑘

slide-30
SLIDE 30

Line Preservation

  • Lines in the same direction

are rotated by the same 𝜄

[Chang & Chuang, CVPR 12]

  • Bind lines to mesh

𝒗 𝒇

warp

𝒇 𝒗

rotate 𝜾

𝑾

bilinear

𝐹𝑀 𝑊, 𝜄 = 𝑊𝑈𝑀𝜄𝑊

𝑀𝜄: Laplacian

slide-31
SLIDE 31

Global Warping

  • Mesh optimization

– Boundary constraints – Shape preservation – Line preservation – Total energy

𝐹 𝑊, 𝜄 = 𝐹𝐶 + 𝐹𝑇 + 𝐹𝑀

fix 𝜄 update 𝑊 fix 𝑊 update 𝜄

slide-32
SLIDE 32

Global Warping

  • Target rectangle

input bounding box normalized scaling x : y ≈ 1:1

slide-33
SLIDE 33

Results

input

slide-34
SLIDE 34

Results

warp

slide-35
SLIDE 35

Results

input

slide-36
SLIDE 36

Results

warp

slide-37
SLIDE 37

Results

input

slide-38
SLIDE 38

Results

warp crop content-aware fill

slide-39
SLIDE 39

Results

input

slide-40
SLIDE 40

Results

warp

slide-41
SLIDE 41

Results

zoom-in output

slide-42
SLIDE 42

Results

zoom-in input

slide-43
SLIDE 43

Results

16-Mp CPU 1-core 2s

slide-44
SLIDE 44

Failure

input

slide-45
SLIDE 45

Failure

warp

slide-46
SLIDE 46

Conclusion

  • New concept - rectangling via warping
  • Unnoticeable, robust, and fast
