SLIDE 1
Hanoch Haim – Principal Engineer
- Overview
- Stateless
- Advance Stateful
Agenda
2
Realistic Traffic Generator Hanoch Haim Principal Engineer Agenda - - PowerPoint PPT Presentation
Realistic Traffic Generator Hanoch Haim Principal Engineer Agenda - - PowerPoint PPT Presentation
Realistic Traffic Generator Hanoch Haim Principal Engineer Agenda Overview Stateless Advance Stateful 2 TRex Results Open Source Cisco Customers 3 TRex Usa sage ge Ana nalyti ytics cs mont nthl hly y repo
SLIDE 2
SLIDE 3
TRex – Results
- Open Source
- Cisco Customers
3
SLIDE 4
TRex Usa sage ge Ana nalyti ytics cs mont nthl hly y repo port t (*)
(**) Users are distinct (*) ~1200 0 distinct return rnin ing users,
4
SLIDE 5
TRex models of operation
5
- L7, DUT terminate
TCP/SSL, flow based
- DUT inspect L7.
does not change
- TCP. Flow based
- DUT L2/L3 Switch ,
packet based
SLIDE 6
What Problem is Being Solved?
- Networks include complex L4-7 features, such as
- Load Balancer, DPI/AVC, Firewall, NAT
- Requires testing with stateful and realistic traffic mix
6
Firewall, NAT DPI/AVC LB
SLIDE 7
What Problem is Being Solved?
- Traffic generators for realistic traffic are
- Expensive ~$100-500K
- Not scalable for high rates
- Not flexible
- Implication
- Limited and late testing
- Different benchmarks and test methodologies
- Real life bottlenecks and design issues
7
SLIDE 8
What is TRex?
- Linux user-space application uses DPDK library
- Stateless
ss: Stream based uses Scapy
- Stateful: flow based
Generates, manipulates and amplifies based on templates of real, captured flows (W/O TCP stack)
- High perform
- rmance
ance: up to 200 Gb/sec
- Low cost: Standard server hardware
- Flexible and Open Software
- Virtualization
- Easy installation and deployment
8
SLIDE 9
9
SLIDE 10
Stateless
SLIDE 11
Stateless High level functionality
- High scale – ~10M-35MPPS/core
- Profile can support multiple streams, scalable to 20K parallel streams
- Interactive support – GUI/TUI
- Statistic per port/ stream (e.g. latency/ Jitter)
- Python automation support
- Multi-user support
- Capture to Wireshark
- Scalable services using plugins (e.g. DHCP,IPv6)
11
SLIDE 12
Traffic Profile Example
12
SLIDE 13
Control plane High level
13
SLIDE 14
One stream with two directions
14
SLIDE 15
15
Python Automation example
SLIDE 16
link
Performance XL710 MPPS/Core
16
SLIDE 17
Advanced Stateful
SLIDE 18
Use ser sp space ce TCP P st stack ck
18
SLIDE 19
TRex ASTF fe feature ures
- High scale
- TCP is the core component
- Can be tuned MSS/initwnd/delay-ack
- TCP is based on BSD with acceleration
- Interactive
- Accurate latency measurement – usec
- Simulation of latency/jitter/drop in high rate
- OpenSSL integration
- L7 emulation layer
- Emulate application using “micro-instructions”
- Field engine
19
SLIDE 20
L7 7 Emul ulati tion n layer er
Client side Server side
20
SLIDE 21
HTTP P si simpl ple pr profi file le
21
SLIDE 22
Client ent si side de ps pseud udo co code de
22
SLIDE 23
Server r si side de ps pseud udo co code de
23
SLIDE 24
Pr Profi file e with h two templ plat ate
24
SLIDE 25
Statis isti tic c
25
SLIDE 26
Und nder the he ho hood
26
SLIDE 27
TCP P st stack ck – Flow Sca cale -TX TX
10M flows 320GByte 320M mbuf =10GB
0.01GB
27
SLIDE 28
TCP P st stack ck – Flow Sca cale iss ssue ue - RX RX
10M flows 320GByte 3-50GB for 1%
drop rate
0.01GB
28
SLIDE 29
TCP sta tack k – Delay/Ji /Jitte tter/ r/Dro Drop sim imulat ation ion
100MPPS *100msec =10MPPS in Queue 100MPPS *100msec =10*16MPPS=0.16G B
29
SLIDE 30
TRex vs NGINX
3
SLIDE 31
Performance setup #2
3
SLIDE 32
Performance numbers
3
https://trex-tgn.cisco.com/trex/doc/trex_astf_vs_nginx.html
x80 faster x2000 less memory
