Real Time Image Guided HDR Brachytherapy for Prostate Cancer. Equipment and Quality Assurance Bashar Al-Qaisieh Equipment Bashar.Al-Qaisieh@leedsth.nhs.uk Theatre Bed Bashar.Al-Qaisieh@leedsth.nhs.uk Stepper Unit

slide-1
SLIDE 1

Real Time Image Guided HDR Brachytherapy for Prostate Cancer. Equipment and Quality Assurance

Bashar Al-Qaisieh

slide-2
SLIDE 2

Bashar.Al-Qaisieh@leedsth.nhs.uk

Equipment

slide-3
SLIDE 3

Bashar.Al-Qaisieh@leedsth.nhs.uk

Theatre Bed

slide-4
SLIDE 4

Bashar.Al-Qaisieh@leedsth.nhs.uk

Stepper Unit

slide-5
SLIDE 5

Bashar.Al-Qaisieh@leedsth.nhs.uk

Template, Needles, Ruler and Tools

slide-6
SLIDE 6

Bashar.Al-Qaisieh@leedsth.nhs.uk

QA for HDR Brachytherapy

Besides the typical QA procedures established for common HDR treatments, we need to implement additional ones

slide-7
SLIDE 7

Bashar.Al-Qaisieh@leedsth.nhs.uk

Prostate HDR QA Overview

  • Pre-Treatment Quality Assurance Checks
  • Independent physics check
  • Pre-Treatment needle free length check
  • TPS Commissioning, Source change, Software and

hardware update/upgrade.

  • Dose point calculation

TG43 algorithm test Optimisation consistency test

  • Isodose check
  • DVH check
  • Data transfer check
  • Image transfer check (Ultrasound phantom)

Image distortion test Volume consistency test

  • Applicator Commissioning
slide-8
SLIDE 8

Bashar.Al-Qaisieh@leedsth.nhs.uk

Pre-Treatment QA

  • Objective:

Test the integrity of the treatment planning system and check the current source data file and equipment setup.

  • Procedure

US probe mark, US & TCS connectivity, verify stepper encoder, AKS, point dose calculation, isodose plot..etc

slide-9
SLIDE 9

Bashar.Al-Qaisieh@leedsth.nhs.uk

Pre-Treatment QA

slide-10
SLIDE 10

Bashar.Al-Qaisieh@leedsth.nhs.uk

Independent Calculation Check- Point Dose

  • Calculation base on TG43-U1 1D formalism (point source

approximation)

  • OCP Calculation based full 2D TG43-U1 formalism (line source)
  • TG43 data from Daskalov et al, Med Phys 25(11) Nov 98, 2200-2207

Example

slide-11
SLIDE 11

Bashar.Al-Qaisieh@leedsth.nhs.uk

Independent Calculation Check- TRAK

Example

slide-12
SLIDE 12

Bashar.Al-Qaisieh@leedsth.nhs.uk

Plan Record and Catheter QA

  • Needle template

position and needle

  • rder
  • Free length

measurements

  • Base measurement
  • Probe position
slide-13
SLIDE 13

Bashar.Al-Qaisieh@leedsth.nhs.uk

Plan Record and Catheter QA

slide-14
SLIDE 14

Bashar.Al-Qaisieh@leedsth.nhs.uk

Template Calibration

Ultrasound Template TPS Template Guidance Template

slide-15
SLIDE 15

Bashar.Al-Qaisieh@leedsth.nhs.uk

Template Calibration

slide-16
SLIDE 16

Bashar.Al-Qaisieh@leedsth.nhs.uk

Volume Test

  • Check volume

captured from US is similar to the volume contoured on planning system

slide-17
SLIDE 17

Bashar.Al-Qaisieh@leedsth.nhs.uk

Dose Point Calculation

Air Kerma Strength + Dwell Times → Dose at point (s)

Oncentra Prostate Dose / Gy Point Expected Dose / Gy 1 32.3233 2 32.2828 3 31.6897 4 18.9138 5 19.0976 6 48.9164 7 48.8740 8 8.3312 9 8.2626 Performed by:

slide-18
SLIDE 18

Bashar.Al-Qaisieh@leedsth.nhs.uk

Optimisation Check

Air Kerma Strength + Prescribed dose to PTV → Dwell Times

Opt

Oncentra Prostate dwell time / s Catheter Dwell time / s 1 43.09 2 30.01 3 56.44 4 34.18 Performed by:

e.g.

slide-19
SLIDE 19

Bashar.Al-Qaisieh@leedsth.nhs.uk

DVH

cc r V 1 . 113 3 4

3 =

= π

3.0cm

slide-20
SLIDE 20

Bashar.Al-Qaisieh@leedsth.nhs.uk

Isodose/DVH check

This test uses DVH values to verify the dose volume calculation of the planning system.

Oncentra Prostate value Parameter Value D90 5.9740 Gy V100 235.9343 cm3 V150 151.8108 cm3 V200 108.0353 cm3 Performed by:

e.g.

slide-21
SLIDE 21

Bashar.Al-Qaisieh@leedsth.nhs.uk

Data Transfer Check

To verify accurate delivery of plan to TCS

slide-22
SLIDE 22

Bashar.Al-Qaisieh@leedsth.nhs.uk

Data transfer check

slide-23
SLIDE 23

Bashar.Al-Qaisieh@leedsth.nhs.uk

3D Ultrasound

  • Better visibility
  • Improved treatment

planning

  • Reproducibility
slide-24
SLIDE 24

Bashar.Al-Qaisieh@leedsth.nhs.uk

Image transfer check (Ultrasound phantom)

1.4cm 1cm

slide-25
SLIDE 25

Bashar.Al-Qaisieh@leedsth.nhs.uk

Image transfer check (Ultrasound phantom)

Correct value? (Tick) Parameter Ideal value Tolerance Vertical spacing 1.0 cm 0.1 cm Diagonal spacing 1.4 cm 0.1 cm Small volume 3.6 cm3 1.0 cm3 Medium volume 8.8 cm3 1.0 cm3 Large volume 20.4 cm3 1.0 cm3 Performed by:

slide-26
SLIDE 26

Bashar.Al-Qaisieh@leedsth.nhs.uk

Needles Commissioning

Dead end and first DP

slide-27
SLIDE 27

Bashar.Al-Qaisieh@leedsth.nhs.uk

US Image Geometry and Catheter Reconstruction

slide-28
SLIDE 28

Bashar.Al-Qaisieh@leedsth.nhs.uk

Ultrasound Machine Check

  • Assurance of Mechanical and Electrical

Safety

  • Distance Accuracy (vertical and horizontal)
  • Contrast and Brightness (Gray bar

visualization)

  • Image Uniformity
  • Penetration
  • Lateral Resolution
slide-29
SLIDE 29

Bashar.Al-Qaisieh@leedsth.nhs.uk

Thank You
