slide-1
SLIDE 1

Reaching the Goal with the Regensburg Marathon Cluster

  • A NetBSD Cluster Project -

Hubert Feyrer <hubert@feyrer.de>

slide-2
SLIDE 2

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 2/32

Introduction

  • 5.500 runners
  • Cooperation between FH Regensburg and R-KOM
  • 45 machines
  • Video rendering
  • 100% Open Source based
slide-3
SLIDE 3

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 3/32

Cluster Client Setup: Hardware

  • Four public rooms with 15 machines
  • 15 machines with Solaris preinstalled
  • Remaining machines available for reinstall
  • Hardware: Dell OptiPlex PCs
  • PII-500MHz, 64MB RAM, 4GB harddisk
  • PIII-1GHz, 256MB RAM, 10GB harddisk
slide-4
SLIDE 4

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 4/32

Cluster Client Setup: Software

  • Chosen node OS: NetBSD
  • Supports the hardware
  • Easy to install
  • Know-how available in-house
  • Software available in 3rd party software collection
  • Cluster software:
  • dumpmpeg, mpeg_encode
  • tload, ucd_snmp, statd
  • Image cloning: g4u
slide-5
SLIDE 5

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 5/32

Cluster Client Setup: Deployment

slide-6
SLIDE 6

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 6/32

Tasks of the Cluster

slide-7
SLIDE 7

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 7/32

Cluster Task #1: Splitting MPEG Sequences

  • Splitting sequences of the input video into single images
  • 11 minutes per sequence
  • 16.500 resulting images
  • 45 minutes on 1GHz machines
  • Software: dumpmpeg
slide-8
SLIDE 8

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 8/32

Cluster Task #1: Optimisations (I)

  • dumpmpeg writes BMP per default
  • we needed JPG for the 2nd step
  • sizeof(BMP) >> sizeof(JPG)
  • No JPEG-writing routines in SDL and smpeg
  • Source code changed to use NetPBM tools
  • After 250 BMPs written to disk,

batch conversion to JPG in one run

slide-9
SLIDE 9

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 9/32

Cluster Task #1: Optimisations (II)

  • Replacing external calls (fork/exec are expensive)

with NetPBM and jpeg lib functions not done (ENOTIME)

  • Improving access times by placing 250 images each in

their own directory

slide-10
SLIDE 10

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 10/32

Intermediate Step

  • For each sequence, record exact time of first and last

image into a MySQL datebase

  • Calculate actual framerate for this sequence
  • Framerate is not always 25 frames/sec due to thermal

effects and resulting mechanical inaccuracies

  • A small difference could add up to unusable results over

5 hours of video material

slide-11
SLIDE 11

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 11/32

Cluster Task #2: rendering videos (I)

  • Render videos for each runner reaching the goal
  • 5.500 runners (reaching the goal; >7.000 starters)
  • Three disciplines:
  • Marathon (42km)
  • Half-marathon (21km)
  • Speed skating (21km)
  • Seperate lists of results for women and men
slide-12
SLIDE 12

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 12/32

Cluster Task #2: rendering videos (II)

  • Image selection:
  • Images were copied to a working directory
slide-13
SLIDE 13

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 13/32

Cluster Task #2: rendering videos (III)

  • Credit frames include data for the runner,

written into a template:

slide-14
SLIDE 14

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 14/32

Cluster Task #2: rendering videos (IV)

  • Image of the runner reaching the goal:
slide-15
SLIDE 15

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 15/32

Cluster Task #2: rendering videos (V)

  • Software: mpeg_encode
  • First send a few images to each machine,

to estimate machine speed

  • Distribute remaining images accordingly
  • Images are read from NFS storage by the nodes
  • Resulting video-parts are written back to NFS storage
  • The master mpeg_encode process then collects and

merges the video-parts at the end

slide-16
SLIDE 16

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 16/32

* Cluster Task #2: rendering videos (VI)

  • The available machines were split into four subclusters:
  • Seperate mpeg_encode config file for each subcluster
slide-17
SLIDE 17

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 17/32

Cluster Task #2: rendering videos (VII)

  • List of results was available as CSV file, containing

name, place and time

  • For each runner:
  • Prepare working dir with images
  • Render video
  • Store video
  • Store image of runner reaching the goal
slide-18
SLIDE 18

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 18/32

Cluster Task #2: rendering videos (VIII)

  • mpeg_encode used rsh (not ssh!) for accessing the cluster

nodes to prevent authentication overhead:

  • rendering MPEG:

3-8 s

  • ssh authentication:

2 s

slide-19
SLIDE 19

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 19/32

Experiences

  • Deployment took longer than expected
  • dumpmpeg has problems on Solaris
  • dumpmpeg ran longer than expected
  • mpeg_encode doesn‘t scale infinitely
  • mpeg_encode sometimes hangs
slide-20
SLIDE 20

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 20/32

Experiences: Deployment

  • Image size: 650MB
  • Deployment of one image took about 30min (for setup of

room server)

  • Deployment of 11 / 14 machines from one room server

took rather long (>2h) due to many machines fighting

  • ver network bandwidth and disk IO
  • All client nodes were connected to the same switch,

possible improvement: one switch per room

slide-21
SLIDE 21

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 21/32

Experiences: dumpmpeg & Solaris (I)

  • dumpmpeg worked fine on NetBSD and Linux
  • dumpmpeg sporadically dumped core on Solaris
  • some poking in gdb shows crashes in malloc(3)
  • probably overwritten memory
  • Guess: Solaris takes overwritten buffers more serious

than NetBSD and Linux

  • No quick fix was available, so we lost 15 machines!
  • In retrospect, linking with libbsdmalloc would probably

have helped

slide-22
SLIDE 22

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 22/32

Experiences: dumpmpeg & Solaris (II)

  • With more time and testing on the real target platform,

this could have been avoided.

  • Not all the world is Linux!
slide-23
SLIDE 23

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 23/32

Experiences: dumpmpeg too slow

  • 18min test sequence took 60min to split w/ 1GHz
  • For 12 machines running through 5 hrs of video input,

we estimated 5 hours.

  • In reality, the machines took 8 hours.
  • Possible reasons here are related to disk IO on the local

disk and NFS storage, network load etc.

slide-24
SLIDE 24

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 24/32

Experiences: mpeg_encode & # of nodes

  • A sequence of 156 images cannot be computed
  • n more than about 15 machines
  • As a result, we did split the available machines into

several subclusters

  • Minor adjustments of config files and handling scripts

was needed

  • Scheduling of which lists to run on which subcluster

was done manually.

slide-25
SLIDE 25

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 25/32

Experiences: mpeg_encode hangs

  • After printing „Wrote 160 frames“, mpeg_encode
  • sometimes hangs
  • After some quick code inspection, there‘s no obvious
  • reason what‘s happening.
  • Workaround was to
  • ^C the program
  • edit the list of runners to process,

removing the ones already done

  • restart the subcluster in question
slide-26
SLIDE 26

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 26/32

Some stats

  • Disk utilisation of the NFS server (write=blue,

read=green):

  • Network traffic between the cluster machines and the

control machine (blue=client read, green=client write):

slide-27
SLIDE 27

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 27/32

More stats (I)

  • System load (load average) while splitting sequences:
slide-28
SLIDE 28

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 28/32

More stats (II)

  • The cluster running at full steam on all eng^Wnodes:
slide-29
SLIDE 29

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 29/32

Some numbers

  • Participants: 5.501
  • Available computers: 57
  • Running time of video tapes: 5 h
  • Number of images after step #1: 669.936
  • Diskspace of images after step #1: 17.5 GB
  • Average size of image (JPEG): 27 kB
  • Average size of video (MPEG): 987 kB
  • Overall data images: 150 MB
  • Overall data video: 5.4 GB
slide-30
SLIDE 30

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 30/32

Software

  • dumpmpeg: splittimg MPEG into JPEGs
  • mpeg_encode: rendering MPEGs from JPEGs
  • SDL, smpeg, NetPBM: for dumpmpeg)
  • perl, gimp, ImageMagick: misc utilities
  • tload, xmeter: node monitoring
  • g4u: image deployment
  • NetBSD: OS of the cluster client machines
slide-31
SLIDE 31

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 31/32

The Marathon Cluster Team

  • Hubert Feyrer
  • Jürgen Mayerhofer
  • Oliver Melzer
  • Daniel Ettle
  • Christian Krauss
  • Tino Hirschmann
  • Fabian Abke
  • Udo Steinegger
slide-32
SLIDE 32

Reaching the Goal with the Regensburg Marathon-Cluster - A NetBSD Cluster Project Hubert Feyrer <hubert@feyrer.de> 32/32

Thanks!

Questions?

  • Hubert Feyrer

<hubert@feyrer.de>
