Rateless Reed-Solomon Codes

Reza Rafie Borujeny Masoud Ardakani

University of Alberta Department of Electrical and Computer Engineering

Overview

• We propose a new class of erasure codes

based on Reed-Solomon codes that are truly rateless.

• These rateless Reed-Solomon (RLRS) codes
• ffer zero reception overhead regardless of

the block length.

• The coding complexity of RLRS codes is

lower than competitive solutions.

Slide 2 of 8

Procedure

• RLRS codes start with a high rate (low

complexity) Cauchy-based* RS code.

• When needed, using Preservative Field

Extension*, RLRS codes reduce their rate, while staying MDS.

• Because of their MDS property, their

reception overhead is always zero.

• They are rateless since further field

extensions can be performed as needed.

Slide 3 of 8

Benefits

• In comparison with Random Linear Fountain

codes, RLRS have a lower coding complexity, 𝑃(𝑙3) vs. 𝑃(𝑙2).

• RLRS codes have zero overhead while short

block length Raptor codes suffer from a relatively large overhead.

• The main advantage of our RLRS codes over

a very low rate MDS code is that our code has a lower coding complexity.

Slide 4 of 8

Conclusion

• RLRS codes seem to be a good choice for

applications with small block length, where Raptor codes are too costly in terms of overhead and Random Fountain Codes are too costly in terms of decoding complexity.

Slide 5 of 8

Appendix 1: Preservative Field Extension

Slide 6 of 8

× 1 1 1 × 00 01 10 11 00 00 00 00 00 01 00 01 10 11 10 00 10 11 01 11 00 11 01 10 Multiplication Table for 𝔾2 Multiplication Table for an Isomorphism of 𝔾4 That is a Preservative Extension of 𝔾2

Appendix 2: Cauchy Based RS Codes

Slide 7 of 8

Rateless Reed-Solomon Codes

Reza Rafie Borujeny reza.rafie@ualberta.ca Masoud Ardakani ardakani@ualberta.ca

University of Alberta Department of Electrical and Computer Engineering
