~ E ~ N ~ S ~ O ~ ~ R ~ City of Prince George Wells Protection Plan: For CN Related Risks Presented by: CITY OF ENGINEERING PLANNING CONSULTING www.radloffeng.com PRINCE GEORGE Radloff March 21 st , 2016 ~:\ mber of th Assocl tNI Engin

slide-1
SLIDE 1

City of Prince George Wells Protection Plan:

For CN Related Risks

ENGINEERING PLANNING CONSULTING www.radloffeng.com Presented by:

March 21st, 2016

Radloff

CITY OF

PRINCE GEORGE

~:\

~

R ~

E ~

O ~ N ~ S ~

~

mber of th Assocl tNI Engin ring Group of Compan, s

slide-2
SLIDE 2

Purpose

Assessment of risk to the City’s wells from CN related activities and the means to mitigate this risk.

slide-3
SLIDE 3

The Nechako Aquifer

The aquifer:

  • Provides 95% of City’s well water (PW660, PW605,

PW602/601)

  • Is a highly valuable natural feature producing

excellent well water

  • Is classified by MOE as “1A” (heavily developed

and highly productive and highly vulnerable)

slide-4
SLIDE 4

Nechako Aquifer

Area in Pink

slide-5
SLIDE 5

Scope

Focus of study between Mile 0 (CN Rail Yard) to Mile 6.31 (Miworth Subdivision)

slide-6
SLIDE 6

Wells

Three (3) active wells along the Nechako River: PW601/602, PW605, PW660

  • Located between the CN rail lines & the river
  • Installed value of aprox. $6 million per well
  • Radial Collector Wells
  • Located primarily in glacio-fluvial sand & gravel with

no confining unit to protect from surface spills

  • Vertical migration could be very swift (18 min. worst

case)

slide-7
SLIDE 7

Radial Collector Well

VERTICAL TURBINE PUMPS & MOTORS REINFORCED CONCRETE CAISSON

i

!

/

f

/

I

I

I

/

I

~:

C) I

(;:! :

I ,il:, I

>:: I

~ = ~ =

  • -WATER LEVEL

,,,/

/

::s •

~ =

~:

  • BOTTOM SEAL

__ ..,.,..,. ... ~,,.,,,_,,.,/

_

_,

PUMP COLUMN a

___,

PUMP SUCTION

I

,.,./'

/

'- I

() I I

~ =

~

I

e:

~ =

C) I I I

I I I I

,,..

I I

I I

I I I I I I I I

~

  • :.

,•

.,

.i,..

.,,,""

  • '

~,

~,

~

  • ____ ,

... -

slide-8
SLIDE 8

Capture Zones

RAILWAY R/W GROUND WATER FLOW ARROWS

LEGEND

CJTYWEU. WATER MAIN WA.TEAT~

NOPUW'now

  • PUMPING
FLOW
  • +

CIIPTURE ZONE 600AVS

  • I YEAR

5YEARS

  • 20YEARS
  • 250m

500r1 750m

,ooom

1

WATERTABLE CONTOURS

  • ELEV. (m)

PWWELL605 PW WELL 601

slide-9
SLIDE 9

Predictive Contaminant Model

RAILWAY R/W RAILWAY R/W

1

(

LEGEND

CllY WELL @) WATER NAIN WATERTABLE NO PUMP FLOW

  • PUMPING FLOW
  • -+

CAPTURE ZONE

60 DAYS

  • I YEAR

CJ

5 YEARS

D

20 YEARS

  • O

~ m

!!iiiil!!!!!!!!!!!

20 ~0-m_. 4 .0~ 0m

!!!!!!!!!!~

6 ~ 0~ 0m

  • ..

8 ~

00ml

SPILL IMPACT AREA

slide-10
SLIDE 10

Likelihood Consequence 1 Insignificant 2 Minor 3 Moderate 4 Major 5 Catastrophic A (almost certain) Moderate High Very High Very High Very High B (likely) Moderate High High Very High Very High C (possible) Low Moderate High Very High Very High D (unlikely) Low Low Moderate High Very High E (rare) Low Low Moderate High High

Risk Matrix

slide-11
SLIDE 11

Potential Source Likelihood of Occurrence Magnitude of Consequence Risk to Drinking Water Derailments in CN yard D (Unlikely) 2 (Minor) Future wells would need to avoid the CN yard. Low Derailments on railway track and train collisions C (Possible) 4 (Major) The City has 3 active wells; therefore, loss of all wells with one derailment is unlikely. Very High (within 60 days**)

Risk Summary

slide-12
SLIDE 12

Potential Source Likelihood of Occurrence Magnitude of Consequence Risk to Drinking Water Grade crossing accidents C (Possible) 4 (Major) The City has 3 active wells; therefore, loss of all wells with one derailment is unlikely. Very High (within 60 days**) Well houses (train collision) E (Rare) 4 (Major) The City has 3 active wells; therefore, loss

  • f all wells with one

derailment is unlikely. High (within 1 day**)

Risk Summary

slide-13
SLIDE 13

Potential Source Likelihood of Occurrence Magnitude of Consequence Risk to Drinking Water Track maintenance chemicals D (Unlikely) 2 (Minor) Low Track switch C (Possible) 4 (Major) Very High

Risk Summary

slide-14
SLIDE 14

High Priority Actions Initiating Party Preventative (P)

  • r

Responsive (R) Remote pump shut‐down capabilities and procedures (for the wells) City R Emergency water quality monitoring plan (spill incident) City R Remote operation capabilities and procedures (for the wells) City R Additional studies (i.e. groundwater flow direction study; updating numerical flow model of capture zones near CN tracks) focusing on risk and mitigation options. City P Additions to City’s Groundwater Protection Areas (wellheads and Nechako River) City P

Recommendations

slide-15
SLIDE 15

High Priority Actions Initiating Party Preventative (P)

  • r

Responsive (R) Reduction of train speeds CN P Creation of a joint emergency response committee (to provide emergency plans and a contact list)* Joint P Enhancement of track maintenance CN P

Recommendations

slide-16
SLIDE 16

Moderate Priority Actions Initiating Party Preventative (P)

  • r

Responsive (R) Creation of alternate supply capability (redundancy for PW605) City P/R Greater transparency and improved communication Joint P Minimization/elimination of at grade crossings Joint P

Recommendations

slide-17
SLIDE 17

Additional Actions Initiating Party Preventative (P)

  • r

Responsive (R) Advance notification if dangerous goods are being transported CN P/R Installation of at grade crossing arms Joint P Installation of a ground seal (significantly reduces speed of infiltration) – option to be determined based

  • n additional studies

City P Installation of interceptor wells and trenches – option to be determined based on additional studies City P

Recommendations
