Purdue University Project Chaffee Critical Design Review Launch Vehicle Vehicle Dimensions Length: Diameter: 3 Wall Thickness: 0.057 Fin Thickness: 0.125 Weight (loaded): 22 lbs. Weight (unloaded): 20.5
SLIDE 2
SLIDE 3
Vehicle Dimensions
- Length:
- Diameter: 3”
- Wall Thickness: 0.057”
- Fin Thickness: 0.125”
- Weight (loaded): 22 lbs.
- Weight (unloaded): 20.5 lbs.
SLIDE 4
Vehicle Materials
- Filament-wound fiberglass: Airframe; coupler tubes
- G10 fiberglass: Fins; bulkheads; centering rings
- Kevlar: Shock cord
- Nylon: Parachutes
- Epoxy: Adhesive for fixed joints
- Stainless steel: Recovery hardware (eyebolts, quick links, etc.)
- 6061 Aluminum: Motor retainer
- ABS: Custom-printed parts (avionics sled, payload mounting, etc.)
SLIDE 5
Flight Simulation
SLIDE 6
Stability Analysis
- Center of Pressure:
- Center of Gravity:
- Static Stability Margin:
- Minimum Dynamic Stability:
- Launch Rail Clearance Velocity:
SLIDE 7
Motor Data
- Designation: Aerotech K828FJ
- Maximum Thrust: 1303.8 N
- Average Thrust: 862.9 N
- Burn Time: 2.5 s
- Total Impulse: 2157.2 Ns
- Thrust/Weight Ratio: 8.8
SLIDE 8
Recovery
- 2 redundant altimeters
- Primary Altimeter
- Featherweight Raven
- Secondary Altimeter
- Missile Works RRC3
- Drogue Parachute Deployment
- Apogee
- Main Parachute Deployment
- 700 Feet
SLIDE 9
Recovery cont.
- Main Parachute
- 60” Sky Angle
- Drogue Parachute
- 24” Sky Angle
- Shock Cord
- 5/16” Tubular Nylon
SLIDE 10
Kinetic Energy and Drift Analysis
SLIDE 11
Payload Design
Closed Loop PID controller that has multiple filters to help create accurate results
SLIDE 12
Control Theory
Theta dot- roll rate V infinity- Velocity Phi- Fin Deflection (s+a/(s+b))- compensator TF- actuator transfer function 1/s-integration
SLIDE 13
Physical Mechanism
SLIDE 14
Physical Mechanism
SLIDE 15
Parts List
SLIDE 16
Payload Testing
- Hard Code Test
- Torque Testing
SLIDE 17
Computing and Sensors
- Arduino Pi
- processing
- Adafruit Flora 9-DOF
- Orientation, velocity, gyroscope
SLIDE 18
Safety
- Construction Safety
○ Use appropriate PPE, and obey all university lab procedures
- Failure Modes
○ Addressed through verification plan (see next slide) ○ Many prevented through material selection
- Launch checklists to ensure safety
SLIDE 19
Verification Plan
- Payload Verification
○ During construction and before launch
- Vehicle Verification
○ During construction and before full-scale test flight
- Pre-Flight Verification
○ To take place before every flight
SLIDE 20
Launch Operations
- Launch checklists to be used before all flights
○ Hotel Procedures - Verify functionality ○ Prep Table Procedures - Secure all components ○ Pad Procedures - Arm all electronics ○ Launch Area Procedures - Assure personnel safety
SLIDE 21
Subscale Test Flight
SLIDE 22
SLIDE 23
Subscale
- 320 feet.
- Canted fins had noticeable but smooth effect.
- Landed safely
- Noticed bad “weathercock”
○ Design change
SLIDE 24
Interfaces
- Navigation
○ Eggfinder GPS transmitter/receiver ○ 900 MHz frequency range
- Igniters
○ Ensure proper installation before flight
